Producent:
(Kategoria: 106)
CONTROLS PLC SIEMENS S7-400 PRESS DESIGN drive system: hydraulic number of suspensions: 1 slide ejectors / cushion: no table cushion: no opening in table: no feedstock transport direction: back-front PRESS FORCES total force (nominal): 1000 toPRESS TABLE table surface (left-right): 2066 mm table surface (front-back): 2000 mm height above floor level: 630 mmSLIDE stroke: 900 mmSLIDE (HYDR. PRESS) approximation velocity max.: 600 mm/s working velocity min.: 15 mm/s working velocity max.: 40 mm/s return velocity max.: 390 mm/s return force: 100 toTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1710 mm distance table - slide max.: 1700 mmELECTRICAL SPECIFICATIONS total power consumption: 160 kW mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS height above floor level: 6500 mm t ...
CONTROLS PLC SIEMENS S7 300 PRESS DESIGN drive system: hydraulic PRESS FORCES total force (nominal): 800 toPRESS TABLE table surface (left-right): 2000 mm table surface (front-back): 2000 mm height above floor level: 700 mmSLIDE table surface (left-right): 2000 mm table surface (front-back): 2000 mm stroke: 900 mmSLIDE (HYDR. PRESS) approximation velocity max.: 400 mm/s working velocity min.: 5 mm/s working velocity max.: 160 mm/s return velocity max.: 300 mm/sTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1700 mm distance between columns (H-frame): 2100 mmELECTRICAL SPECIFICATIONS total power consumption: 370 kW mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS total weight approx.: 81000 kgATTACHMENTS (PRESSES) press automation: yes gripper transfer system: yes acc. to actual acci ...
PRESS DESIGN quick die change system: yes SLIDE total force (nominal): 100 to stroke: 20 mm stroke rate (max.): 80 /minTOOL DIMENSIONS lower table (left-right): 430 mm shut height max.: 220 mmApprox. 79 million strokes
PRESS DESIGN drive system: hydraulic SLIDE total force (nominal): 40 to stroke: 45 mm stroke rate (max.): 110 /minTOOL DIMENSIONS lower table (left-right): 300 mm lower table (front-back): 280 mm shut height max.: 90 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 1835 mm space requirements -front/back-: 1500 mm total height: 1800 mm total weight approx.: 2500 kg
SLIDE total force (nominal): 40 to stroke rate (max.): 110 /minTOOL DIMENSIONS lower table (left-right): 300 mm lower table (front-back): 280 mm shut height max.: 180 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 1835 mm space requirements -front/back-: 1500 mm total height: 1800 mm total weight approx.: 2500 kg
SLIDE total force (nominal): 80 to stroke rate (max.): 120 /minV-RING stroke: 90 mmTOOL DIMENSIONS lower table (left-right): 420 mm lower table (front-back): 420 mm upper table (left-right): 420 mm upper table (front-back): 420 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 2970 mm space requirements -front/back-: 1665 mm total height: 242 mm total weight approx.: 6000 kg
CONTROLS SIEMENS SIMATIC PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 160 toPRESS TABLE table surface (left-right): 1200 mm table surface (front-back): 970 mmSLIDE stroke rate (max.): 90 /minSLIDE (MECHAN. PRESS) slide adjustment: 120 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 3200 mm space requirements -front/back-: 1600 mm total height: 4400 mm total weight approx.: 32000 kg
CONTROLS conventional PRESS FORCES total force (nominal): 160 toPRESS TABLE table surface (left-right): 1000 mm table surface (front-back): 850 mmSLIDE stroke: 705 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1205 mmMachine hours: 78571
CONTROLS PLC SIEMENS SIMATIC OP 47-12 PRESS FORCES total force (nominal): 200 toPRESS TABLE table surface (left-right): 2440 mm table surface (front-back): 1500 mmSLIDE table surface (left-right): 1500 mm table surface (front-back): 1100 mm stroke: 180 mmSLIDE (MECHAN. PRESS) slide adjustment: 150 mm stroke rate (min.): 20 /min stroke rate (max.): 120 /min main drive power: 45 kWOVERALL SPECIFICATIONS (COIL LINES) sheet thickness max.: 2.5 mmDECOILER sheet width max.: 300 mm sheet width (min): 30 mm coil weight max.: 3 to max. diameter of coil: 1500 mm mandrel expansion range from: 460 mm mandrel expansion range up to: 530 mmLEVELLER UNIT sheet width max.: 30 mm sheet width (min): 300 mm number of leveller rolls: 9 diameter of leveller rolls: 30 mm number of intermediate rolls: 11 feed velocity min.: 5 m/min fee ...
CONTROLS conventional PRESS FORCES total force (nominal): 100 toSLIDE stroke rate (max.): 55 /minSLIDE (MECHAN. PRESS) slide adjustment: 80 mm stroke min.: 10 mm stroke max.: 120 mmDIMENSIONS / WEIGHTS total weight approx.: 4800 kg
CONTROLS electronic controls SIEMENS PRESS DESIGN drive system: eccentric / crank frame design: C-frame, double sided openings in uprights: yes number of slide actions: 1 PRESS FORCES total force (nominal): 160 toPRESS TABLE table surface (left-right): 1200 mm table surface (front-back): 1050 mm opening in bed (left-right): 240 mm opening in bed (front-back): 200 mmSLIDE table surface (left-right): 900 mm table surface (front-back): 600 mm spigot hole diameter: 50 mmSLIDE (MECHAN. PRESS) slide adjustment: 120 mm stroke min.: 20 mm stroke max.: 200 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 570 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 1600 mm space requirements -front/back-: 3000 mm total height: 4400 mm ...
CONTROLS PLC PRESS DESIGN quick die change system: yes SLIDE total force (nominal): 630 to stroke: 125 mmV-RING nominal force: 320 toTOOL DIMENSIONS lower table (left-right): 800 mm lower table (front-back): 800 mm shut height max.: 420 mmSTRIP-FEEDER band lubrication system: yes ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 6800 mm space requirements -front/back-: 3300 mm total height: 3730 mm height above floor level: 3005 mm height under floor level: 725 mm total weight approx.: 26000 kgATTACHMENTS -FINEBLANKING PRESS- autom. tool clamping device: yes light barrier: yes decoiler: yes leveller unit: yes Strip levelling machine SCHMID HR12H (YoM 1995)including belt system
CONTROLS PLC SIEMENS SIMATIC HMI SLIDE total force (nominal): 320 to stroke: 200 mmCOUNTER RAM nominal force: 63 toV-RING nominal force: 100 toTOOL DIMENSIONS shut height max.: 360 mmDIMENSIONS / WEIGHTS total weight approx.: 18000 kgThe system was fitted with a new control unit approximately 1.5 years agoincluding belt systemInkl. Decoiler Schmid HR10
CONTROLS electronic controls WORKING RANGE PRESS BRAKE total force (nominal): 85 to Working length: 2050 mm distance between columns: 1700 mmBENDING BEAM (Y-AXIS) stroke: 215 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 2700 mm space requirements -front/back-: 2000 mm total height: 2400 mm total weight approx.: 8300 kg
CONTROLS PLC LAUER SLIDE total force (nominal): 320 to stroke: 200 mmSLIDE (HYDR. PRESS) approximation velocity max.: 200 mm/s working velocity min.: 10 mm/s working velocity max.: 44 mm/sCOUNTER RAM nominal force: 63 to stroke: 30 mmV-RING nominal force: 100 to stroke: 30 mmTOOL DIMENSIONS lower table (left-right): 500 mm lower table (front-back): 500 mm upper table (left-right): 695 mm upper table (front-back): 730 mm shut height max.: 650 mmDECOILER sheet width max.: 250 mm sheet width (min): 40 mm coil weight max.: 1250 to max. diameter of coil: 1300 mmLEVELLER UNIT sheet width max.: 250 mm sheet thickness max.: 5 mm sheet thickness min.: 0.8 mm number of leveller rolls: 11 feed velocity min.: 4 m/min feed velocity max.: 12 m/minSTRIP-FEEDER feeder type: grip feeder sheet width max.: 250 mm sheet th ...
CONTROLS electronic controls SIEMENS PRESS DESIGN drive system: hydraulic frame design: 4 column number of suspensions: 1 slide ejectors / cushion: yes table cushion: yes PRESS FORCES total force (nominal): 200 toPRESS TABLE table surface (left-right): 1330 mm table surface (front-back): 1150 mm height above floor level: 850 mm opening in bed (diameter): 250 mmSLIDE slide force: 200 to table surface (left-right): 1200 mm table surface (front-back): 1200 mm stroke: 800 mmSLIDE (HYDR. PRESS) approximation velocity max.: 300 mm/s working velocity min.: 30 mm/s return velocity max.: 400 mm/s return force: 200 toSLIDE EJECTOR / CUSHION working principle: hydraulical nominal force: 30 to stroke: 130 mmDIE CUSHION (TABLE CUSHION) cushion force: 30 to stroke: 850 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V ma ...
PRESS FORCES total force (nominal): 100 toPRESS TABLE table surface (left-right): 950 mm table surface (front-back): 660 mm thickness of bolster plate: 68 mmSLIDE table surface (left-right): 540 mm table surface (front-back): 450 mm spigot hole diameter: 60 mm stroke: 130 mm stroke rate (max.): 65 /minSLIDE (MECHAN. PRESS) slide adjustment: 100 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 370 mmDIMENSIONS / WEIGHTS total weight approx.: 7000 kgLocated in Barcelona - Spain2 identical units available
CONTROLS electronic controls SCHMIDT PRESS FORCES total force (nominal): 0.25 toPRESS TABLE table surface (left-right): 180 mm table surface (front-back): 150 mmSLIDE slide force: 0.25 to stroke: 100 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS total weight approx.: 35 kgThis is an assembly press with force-displacement monitoring.• Operating hours: approx. 150• Condition: very good, almost like new• Features: Press force monitoring, two-hand operation• Stroke: 100 mm• Tool dimensions: 150 x 100 mm• Press force: 0.25 tons
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 55 toPRESS TABLE table surface (left-right): 750 mm table surface (front-back): 450 mmSLIDE table surface (left-right): 400 mm table surface (front-back): 300 mm spigot hole diameter: 45 mm stroke: 50 mm stroke rate (max.): 100 /minSLIDE (MECHAN. PRESS) slide adjustment: 70 mm stroke min.: 6 mm stroke max.: 50 mm stroke rate (min.): 50 /min stroke rate (max.): 100 /minTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 310 mmELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 1200 mm space requirements -front/back-: 1500 mm total height: 2500 mm total weight approx.: 3850 kgATTACHMENTS (PRESSES) safety guard / safety door: yes 2-hand engagement: yes ...
CONTROLS PLC SCHNEIDER PRESS DESIGN drive system: eccentric / crank number of slide actions: 11 feedstock transport direction: left to right PRESS FORCES total force (nominal): 66 toSLIDE slide force: 6 to stroke: 114 mmSLIDE (MECHAN. PRESS) variable speed: yes stroke rate (min.): 40 /min stroke rate (max.): 130 /min main drive power: 7.5 kWSTRIP-FEEDER feeder type: roll feeder TRANSFER SYSTEM distance between tools, stroke X fixed: 82 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 2875 mm space requirements -front/back-: 1500 mm total height: 2900 mm total weight approx.: 7500 kgATTACHMENTS (PRESSES) safety guard / safety door: yes 2-hand engagement: yes noise protection cabin: yes acc. to actual accident protection regulation: yes Specifications:Number of stations: 12 (11+1)Capacity per ram: 6 tonsMaximum str ...
CONTROLS PC controller BECKHOFF PRESS DESIGN number of slide actions: 13 SLIDE slide force: 3 to stroke: 60 mm stroke rate (max.): 210 /minSLIDE (MECHAN. PRESS) slide adjustment: 6 mm variable speed: yes stroke rate (min.): 70 /min stroke rate (max.): 210 /min main drive power: 4 kWDIMENSIONS / WEIGHTS space requirements -left/right-: 2300 mm space requirements -front/back-: 1000 mm total height: 1900 mm total weight approx.: 4000 kg
PRESS DESIGN drive system: hydraulic frame design: C-frame, single sided table cushion: yes opening in table: yes PRESS FORCES total force (nominal): 100 toPRESS TABLE table surface (left-right): 710 mm table surface (front-back): 560 mmSLIDE slide force: 100 to table surface (left-right): 560 mm table surface (front-back): 450 mm spigot hole diameter: 50 mm stroke: 320 mm thickness of bolster plate: 150 mmSLIDE (HYDR. PRESS) approximation velocity max.: 340 mm/s working velocity max.: 32 mm/s return velocity max.: 330 mm/sSLIDE EJECTOR / CUSHION nominal force: 2 to stroke: 40 mmDIE CUSHION (TABLE CUSHION) cushion force: 10 to stroke: 80 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 455 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 300 mm sheet thickness max.: 20 mm spee ...
CONTROLS PC controller BECKHOFF Offer for servicesof complete Overhaul of a Customer-Owned Fineblanking Press FEINTOOL GKP 160Scope of Overhaul• Complete disassembly into individual components• Inspection of all parts, including crack testing of critical components• Overhaul of the drive system, new motors• Reworking and precise alignment of all guideways• Complete overhaul of the hydraulic cylinders• Overhaul of the clamping tables• Installation of a new hydraulic unit• Renewal of the pneumatic system• Renewal of the electrical systemModernisation / Retrofit• Combined table• Servo feed systems• Central lubrication system• RAZIOL band lubrication• New brake/clutch unit• BECKHOFF PC-based control system with touch panel• PILZ safety control system• Implementation of CE conformityNotes• Special options and customer-specific extensions can be integrate ...
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 50 toPRESS TABLE table surface (left-right): 700 mm table surface (front-back): 450 mmSLIDE table surface (left-right): 440 mm table surface (front-back): 360 mm spigot hole diameter: 40 mm stroke: 90 mm stroke rate (max.): 70 /minSLIDE (MECHAN. PRESS) slide adjustment: 70 mm stroke min.: 0 mm stroke max.: 90 mm main drive power: 3 kWTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 300 mmDIMENSIONS / WEIGHTS space requirements -left/right-: 700 mm space requirements -front/back-: 1295 mm total height: 2360 mm total weight approx.: 3000 kg
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 45 toPRESS TABLE table surface (left-right): 700 mm table surface (front-back): 440 mm opening in bed (diameter): 40 mmSLIDE table surface (left-right): 410 mm table surface (front-back): 280 mm stroke rate (max.): 110 /minSLIDE (MECHAN. PRESS) slide adjustment: 65 mm stroke min.: 0 mm stroke max.: 90 mm main drive power: 5.5 kWTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 380 mm distance between columns (H-frame): 360 mmATTACHMENTS (PRESSES) 2-hand engagement: yes foot engagement: yes European CE standards: yes
CONTROLS conventional PRESS DESIGN drive system: eccentric / crank frame design: C-frame, single sided PRESS FORCES total force (nominal): 100 toSLIDE slide force: 100 to stroke rate (max.): 72 /minSLIDE (MECHAN. PRESS) slide adjustment: 80 mm stroke adjustment: yes stroke min.: 8 mm stroke max.: 112 mmTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 407 mmATTACHMENTS (PRESSES) 2-hand engagement: yes for safe tools only
CONTROLS PLC SIEMENS S7 300 PRESS DESIGN drive system: hydraulic PRESS FORCES total force (nominal): 800 toPRESS TABLE table surface (left-right): 2600 mm table surface (front-back): 2000 mm height above floor level: 540 mmSLIDE stroke: 900 mmSLIDE (HYDR. PRESS) approximation velocity max.: 460 mm/s working velocity min.: 25 mm/s working velocity max.: 44 mm/s return velocity max.: 460 mm/sTOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 1700 mmELECTRICAL SPECIFICATIONS total power consumption: 180 kWDIMENSIONS / WEIGHTS total weight approx.: 95000 kgATTACHMENTS (PRESSES) press automation: yes gripper transfer system: yes acc. to actual accident protection regulation: yes European CE standards: yes Complete hot forming line consisting of: Hydraulic press NEFF 800 to. Ruhstrat furnace system:- Natural gas heat ...
CONTROLS PLC SIEMENS S7 PRESS DESIGN drive system: link drive feedstock transport direction: left to right SLIDE total force (nominal): 80 to stroke: 50 mm stroke rate (max.): 80 /minCOUNTER RAM nominal force: 22 to stroke: 8 mmV-RING nominal force: 25 to stroke: 15 mmTOOL DIMENSIONS lower table (left-right): 420 mm lower table (front-back): 420 mm upper table (left-right): 420 mm upper table (front-back): 420 mm shut height max.: 220 mm ram adjustment: 80 mm distance between columns (H-frame): 450 mm passline opening (free passage in side columns): 200 mmOVERALL SPECIFICATIONS (COIL LINES) sheet width max.: 180 mm sheet thickness max.: 5 mm feed velocity max.: 999 m/minSTRIP-FEEDER feeder type: roll feeder sheet width max.: 180 mm sheet thickness max.: 5 mm feeding step max.: 999 mm sheet length min: 1350 mm ...
CONTROLS PC controller BECKHOFF PRESS DESIGN drive system: knuckle-joint SLIDE total force (nominal): 250 to stroke: 61 mm stroke rate (max.): 60 /minCOUNTER RAM nominal force: 75 to stroke: 15 mmV-RING nominal force: 75 to stroke: 13 mmTOOL DIMENSIONS lower table (left-right): 540 mm lower table (front-back): 540 mm upper table (left-right): 540 mm upper table (front-back): 540 mm shut height max.: 320 mm ram adjustment: 145 mm distance between columns (H-frame): 560 mm passline opening (free passage in side columns): 270 mmSTRIP-FEEDER feeder type: roll feeder sheet width max.: 250 mm sheet thickness max.: 10 mm feeding step max.: 999.99 mm sheet length min: 1900 mm pilot release system: yes band lubrication system: yes Complete refurbished fineblanking press: disassembly into individual parts findings of all com ...
