utilisé
Le centre de tournage CNC NAKAMURA-TOME SUPER NTM3 a été fabriqué en 2004 au Japon. Se distinguant par ses larges capacités d’usinage et son équipement complet, la machine permet des processus de production entièrement automatisés, tout en maintenant une haute précision et des coûts d’exploitation réduits. La construction de haute qualité amortit en outre efficacement les vibrations et assure une stabilité maximale du processus, ce qui se traduit par d’excellents résultats de tournage. Les pièces sont usinées jusqu’à 11 axes à l’aide d’outils fiables stockés dans trois têtes d’outils à 24 positions. Le tour CNC NAKAMURA SUPER NTM3 est proposé avec une large gamme d’équipements, notamment un embarreur BREUNING IRCO SiMag, un contrôleur CNC FANUC 16i-TB et des porte-outils supplémentaires. Le tour CNC à double broche pèse 12000 kg. Spécifica ...
utilisé
Nakamura Tome WT-300 Centre de tournage et de fraisage CNC multi-axes Âge : 2007 FONCTIONNALITÉS: Contrôle CNC FANUC 18I-TB TOURELLES JUMELÉES À 24 STATIONS AVEC FRAISAGE BROCHES OPPOSÉES JUMELLES AXE C LES DEUX BROCHES TOURELLE SUPÉRIEURE DE L’AXE Y LNS QL SERVO S3 CHARGEUR BAR FEED LIQUIDE DE REFROIDISSEMENT HAUTE PRESSION CHIP BLASTER SPÉCIFICATION: PIVOTEMENT MAXIMUM 9.84inch DIAMÈTRE DE TOURNAGE MAXIMUM 10.62inch LONGUEUR DE TOURNAGE MAXIMALE 30.71inch DISTANCE ENTRE LES BROCHES 43.3inch CAPACITÉ DE BARRE 2.5inch SPINDLE PRINCIPALE : VITESSES DE BROCHE PRINCIPALE 45-4500RPM ROTATION DE L’AXE C 0,001 DEGRÉ ALÉSAGE DE LA BROCHE PRINCIPALE 3,15 pouces MOTEUR DE BROCHE PRINCIPALE 25 CV NEZ DE FUSEAU PRINCIPAL A2-6 CONTRE-SPINDLE : VITESSE DE LA BROCHE INFÉRIEURE 4500RPM ROTATION DE L’AXE C 0,001 DEGRÉ DÉPLACEMENT DE L’AXE B 33,46 POUCES ...
utilisé
X-travel: 700mm, y-travel: 250mm, z-travel: 1125mm, B-travel: 1100mm, number of axis: 6, controls: NT Smart X, connected load: 90kVA, length: 4460mm, width: 2670mm, height: 2615mm, weight: 17t, operational hours counter: 18,177h, an inspection is possible.
utilisé
This 11-axis Nakamura-Tome Super NTM3 was manufactured in 2007. It features dual spindles, three turrets, and a Fanuc 16i-TB control system. The main spindle has a 15 kW power with speeds up to 4500 rpm, and the counter-spindle offers 11 kW power with speeds up to 5000 rpm. The machine has a large working space with a maximum turning diameter of 190 mm and a bar diameter of 65 mm. Its a great opportunity to buy this Nakamura-Tome lathe. Contact us for further details.
utilisé
Description: NAKAMURA-TOME TW-10 CNC Doublespindel - Lathe The machine is equipped with: - Workpiece automation GR-203 and WS-231 - Controlled C-axis for main and counter spindle - 2 revolvers with powered tools - Counter spindle - Coolant device - chip conveyor - 8 tool holders (not driven) without tools - including documentation Attention: without chuck! The workpiece automation, C-axis and driven tools were not used by the donor. Therefore function cannot be guaranteed! Further technical data can be found in our machine video and the appendix as a PDF file.  , turning diameter: 210 mm, Drehlänge: 155 mm, turning diameter over slide: 205 mm, control: FANUC Series 18-T, number of places for driven tools: 2 x 12, spindle bore: 42 mm, turning speed range: 55 - 5500 rpm, weight approx.: 5,500 kg, Approx. Onsite Dimension. (l x w x h): 5,300 x 2,500 x 2,350 mm
utilisé
spindle passage: H: 65 / G: 51 mm numbers of positions in the tool changer: 2x12 control: FANUC 18i-T tool taper: BMT55 collet chuck: Hainbuch (RD65) CNC Turning- and Milling Center | NAKAMURA TOME - WT-250 MMY equipped with tool changer and measuring system. Equipment/accessories: - parts gripper - small package of tools (2x radial & 2x axial driven tools + various passive holders) The machine is in a well-maintained condition. A machine video from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: WT-250MMY | WT 250MMY | WT250MMY The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
utilisé
This NAKAMURA TOME WT 250 Lathe machine was manufactured in the year 1999. It is equipped with a FANUC Series 18i-T Control Unit. Drilling and milling work possible over the entire circumference with one clamping. The tools and holders for driven tools are not included in the scope of delivery.
utilisé
This Nakamura-Tome WT-100 MMY Lathe was manufactured in the year 2018 and has 18000 production hours. It is equipped with a Nakamura-Tome control unit.
utilisé
This NAKAMURA-TOME TW-20 lathe was made in the year 2003 in Japan. It is equipped with a Nakamura Tome LUCK-BEI control unit and has 2 axis. The machine has 2 spindles and a max. turning diameter of 270 mm.
utilisé
swivelling range: 250 mm max. working diameter: 210 mm max. working lenght: 555 mm control: Fanuc 18i TB spindle taper: JIS A2-6 spindle diameter: 71 mm number of spindle speeds: 5.000 U/min CNC Turning- and Milling Center | NAKAMURA TOME - WT-250 MMY equipped with bar loader (Profimat) Equipment/accessories: - Bar loader - driven tool holders Further technical data: - Chuck size: Hainbuch collets - Distance between spindle end faces: 555 mm - Max. outside diameter for bar material: 65 mm - Spindle power 1 = 11 / 15 kW - Spindle power 2 = 7.5 / 11 kW - Max. torque: Nm 265 (kgf-m 27) The machine is in a well-maintained condition and can be inspected at any time under power. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: WT-250MMY | WT 250MMY | WT250MMY The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
utilisé
Diamètre de tournage: 190 mmLongueur de tournage: 800 mmPositions du tourteau: 24Positions ATC: 0 Nombre d’axe contrôlé: 0 CNC Marque: FanucCNC Modèle: NT-IPS CNC MACH-id 5187 FAIRE Nakamura TYPE WT 150 - II YOP 2016 Spécifications Diamètre de tournage max . 190 mm DBC Longueur de tournage 800 mm Axe C 360.000 Vitesse de la broche principale 5000 tr / min ATC / revolver 24 Vitesse des outils en direct 6000 rpm Outils électriques sous tension 5,5 kW Contrôle FANUC NT-IPS CNC Convoyeur à copeaux Oui Œil d’o ...
utilisé
Diamètre de tournage: 190 mmLongueur de tournage: 970 mmPositions du tourteau: 12Positions ATC: 0 Nombre d’axe contrôlé: 0 CNC Marque: FanucCNC Modèle: 18 iTB MACH-id 5186 MAKE Nakamura Japon TYPE Super NTJ YOP 2011 Spécifications Diamètre de tournage max . 190 mm DBC Longueur de tournage 970 mm Axe C 360.000 Alésage de la broche 65 mm Vitesse de la broche principale 4500 tr/ min ATC / revolver 12 Vitesse des outils en direct 4500 tr / min Outils électriques sous tension 15 kW Contrôle Fanuc 18i TB Convoyeur à copeaux  ...
utilisé
numéro de série: 31302 contrôle: Fanuc avec double broche: diamètre tour: max. 600 mm x-course: 1000 mm avec chargeur: accessoires extensibles: env. 100 Aufnahmen, auch angetrieben poids de la machine ca.: 13 t
utilisé
Détrait de tournage : 0 mm Longueur de tournage : 0 mm Positions DEturret : 0 Positions ATC : 0 Nombre d’axe contrôlé : 0 CNC Marque : 0 CNC Modèle : 0 Contrôle : FANUC Résieur d’exploitation : 2330 Données techniques Nombre de broches : 2 Nombre de revolvers : 2 Couleur de broche de distance : 250 - 870 mm Longueur maximale de tournage : 160 mm Max. diamètre de rotation : 130 mm Coîche deturelle : Carriage 1: Course longitudinale (axe Z) : 200 mm Détrésage longitudinal (axe X) : 180 mm Dépenses transversales (axe Y) : +/-30 mm Portage 2: Dépenses longitudinales (axe X) : 180 mm Dépente transversale (axe Z) : 620 mm Axe Y : +/-30 mm Nombre de positions tourelle 1 : 12 Nombre de positions tourelle 2 : 12 Telle outils moteurs 1 : 6 Etilles d’outils motorisés 2 : 6 Démérités de broche : 3600 tr/min Puissance des outils entraînés : 3.7 / 2.2 kW Broche principale: ...
