turning diameter: 620 mm turning length: 2000 mm control: MSX 501 total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 600 mm turning length: 1.045 mm control: MSX - 711 III MAPPS III swing diameter over support: 600 mm distance between spindles: 1.255 mm max. bar capacity: 65 mm Main drive 2: turning speed range - main spindle: max. 5.000 min/-1 power capacity - main spindel: 25 / 22 kW no. of turning speeds: 2 spindle nose: JIS A2-6 spindle bore: 73 mm internal diameter: 120 mm C-Axis: 0,0001 ° chucking diameter: 200 mm Milling Spindle:: Speed range Tool Spindle: max. 12.000 min/-1 Power rating Tool Spindle: 5,5 / 3,7 kW tool taper: Capto C5 internal diameter: 65 mm B - Axis: 0,0001 ° swivellable: +/- 120 ° axis stroke:: x-axis: 685 (610 + 75) mm y-axis: +/- 125 mm z-axis: 1.075 + 130 mm turret:: number of toolpositions: 12 pos. Shank height for square tool: 20 mm Drill shank diameter: max. 32 mm tool magazin:: tools in tool magazin: 40 pos. max. tool diameter: 70 mm max. tool ...
turning diameter: 310 mm turning length: 1000 mm control: MSX 501 total power requirement: --- kW weight of the machine ca.: 6,6 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 530 mm z-travel: 510 mm Control: M 730 BM MAPPS IV Main spindle:: max. spindle speed: 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 transmission ratio: 1 spindle diameter in front bearing: 80 mm work table:: table surface area: 900 x 600 mm max. table load: 800 kg T-slots: 6x 18 x 100 mm distance spindle /table: 150 - 660 mm Tool-Presetter:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 150 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: ca. 1,3 sec change-time chip to chip: ca. 3,45 sec feeds:: rapid traverse ( X / Y / Z ): 30 m/min feed speeds: 1 - 30.000 mm/min Tipp feed: 0 - 5.000 : 20 mm/min total power requirement: 30 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,7 m Documents: Chip conveyor: ...
x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
x-travel: 560 mm y-travel: 560 mm z-travel: 630 mm Control: MSX 701 III MAPPS Main spindle:: Max. rpm: 14.000 min/-1 power capacity - main spindel: 18,5 / 11 kW max. Torque: 120 Nm tool taper: MAS BT 40 distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 100 - 730 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm max. workpiece height: 900 mm change time of pallets: 6,0 sec b - axis: 0,001 ° Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT 40 max. tool diameter: 70 / (140) mm max. tool length: 400 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 m/min feed speeds: 0 - 50.000 mm/min Tipp feed: 0 - 1.260 mm/min total power requirement: 35 kVA weight of the machine ca.: 9,8 t dimensions of the machine ca.: 5,5 x 3,5 x 2,8 m Docume ...
turning diameter: 390 mm turning length: 507 mm control: MSG 805 MAPPS max. turning diameter: 390 mm greates pass round over bed: 680 mm Swing dia. over traverse guideway: 510 mm centre distance: 618 mm Main spindle:: turning speed range - main spindle: 45 - 4.500 min/-1 power capacity - main spindel: 11 / 7,5 kW spindle bearing diameter: 110 mm spindle bore: 73 mm max. bar capacity: 51 mm spindle nose: JIS A2-6 chucking diameter: 210 mm C-Axis: 0,001 ° axis stroke:: x-axis: 235 (195+40) mm z-axis: 520 mm turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tool stations: max. 3.000 min -1 power capacity driven tool-stations: 5,9 / 4,5 kW Shank height for square tool: 25 mm Drill shank diameter: max. 50 mm turret change time: 0,2 sec. Tailstock:: tailstock adjustment: 490 mm dia. of quill: 85 mm taper of center: MT 4 quill stroke: ...
turning diameter: 370 mm turning length: 424 mm control: MSX-711-IV Mori Seiki swing diameter: 370 mm X1- Axis: 380 mm X2- Axis: 155 mm Z1- Axis: 460+155 mm Z2- Axis: 610 mm y-axis: +/- 105 mm B - axis: +/- 120 ° bar material dia.: 65 mm speed spindle max.: S1 5.000 / S2 6.000 U/min. spindle bore: S1/S2 65/38 mm : 12000 1/min tool taper: Capto C5 toolpiece magazine: chain magazine: 76 Stück tool turret with 10 work positions: total power requirement: 45 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m MAPPS control system Renishaw HPRA (manual tool presetter) Blum Laser Control Direct measuring system X,Y,Z,B Collet chuck SMW Autoblok KSZ-MB-040-Z140 Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar Chip conveyor ConSep 2000 The data for this ad was create ...
turning diameter: max. 320 mm turning length: 810 mm control: MSX 701 MAPPS III standard turning dia.: 200 mm Main spindle:: Number of revolutions: max. 6.000 min/-1 power capacity - main spindel: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Subspindel:: Number of revolutions: max. 6.000 min/-1 power capacity - Sub spindle: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Turret 1 + 3:: number of toolpositions: je 16 pos. Number of driven toolspositions: je 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+65 / -45) mm Turret 2:: number of toolpositions: 16 pos. Number of driven toolspositions: 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+45 / -65) mm axis stroke:: x-travel: 1-3: 210 mm y-travel: 1-3: ...
turning diameter: 176 mm turning length: 570 mm swing diameter: 510 mm working diameter: 420 mm travel -z axis: 570 mm travel -x axis: 245 mm spindle bore: 43 mm diameter of quill: 85 mm quill stroke: 120 mm Spindle Speed: 60-6.000 U/min. rapid power traverse in X-and Z direction: 24 m/min total power requirement: 5,5 kW control: MSG-805 V weight of the machine ca.: 3.400 kg dimensions of the machine ca.: 2000x1700x1800 mm Features/Accessories: - Integrated CNC control - Bed guides and cross-slide guides are induction-hardened and designed as flat guides - Continuously variable AC main spindle drive - Constant cutting speed programming - Cold light lamp integrated into the machine - Power meter for the main spindle drive (ammeter) - Control units for automatic and manual operation, as well as a CNC programming unit and control panel - Tailstock with hydraulically actuated MK 4 tailstock ...
x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: ca. 570 mm turning length: ca. 530-610 mm control: FANUC : ohne Gewähr x-travel: ca 160-200 mm y-travel: ca. 560 mm weight of the machine ca.: 4,5 - 5 t : ca 10 oder 12 spindle bore: 52-76 mm total power requirement: - kW weight of the machine ca.: 4 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 200 mm turning length: 393 mm control: MSX 853 weight of the machine ca.: 3,5 t total power requirement: kW dimensions of the machine ca.: m MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are n ...
turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...
x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT ...
转弯直径：370毫米，转弯长度：424毫米，控制：Fanuc 总功率需求：千瓦，机器重量，约：机器的尺寸，约 m。本广告数据由ModulMWS创建——LogoTech oHG的软件解决方案
车削直径：190毫米，车削长度：235毫米，控制：FANUC/M ori MSX 501主轴转速范围：50-5000 U/分转塔头：2x16，机器重量约7.5 tY和B轴附件 更多详情请见 www.marcels-maschinen.ch 本广告的数据由ModulMWS创建——LogoTech oHG的软件解决方案
车削直径：190毫米，车削长度：235毫米，控制：FANUC/M ori MSX 501主轴转速范围：50-5000 U/分转塔头：2x16，机器重量约7.5 tY和B轴附件 更多详情请见 www.marcels-maschinen.ch 本广告的数据由ModulMWS创建——LogoTech oHG的软件解决方案
turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
MORI SEIKI SV-503B/40 is a 4-Achsen Bearbeitungszenter, entwickelt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 1320×600 mm, max Werkstückgewicht 1200 kg; Wege X1050, Y510, Z510 mm; Magazin 30 Plätze, BT40. Spindel 0–10.000 min-¹, 22 kW; Anschluss 3x200V 50Hz; 58 kVA; Gewicht ~8030 kg; Abmessungen 2500×2350×2700 mm. Zubehör: Satz Werkzeughalter, Kühlmitteleinrichtung mit 30 bar IKZ, Späneförderer, Teilapparat NIKKEN, Lampe, Zustandsleuchte. Geeignet für präzise Fertigung in Automotive, Luftfahrt, Medizintechnik und Maschinenbau. Technische Daten ohne Gewähr
CONTROLS CNC controls FANUC 18 MB WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 .. among of them simultaneous CNC axes: 3 X-axis travel: 900 mm Y-axis travel: 800 mm Z-axis travel: 980 mm rotating range B-axis from: 0 ° rotating range B-axis up to: 360 ° TABLE table surface (left-right): 630 mm table surface (front-back): 630 mm workpiece load (max): 1200 kg SPINDLE / HEAD spindle type: horizontal spindle revolutions (max): 10000 /min AXIS DRIVES rapid traverse: 50000 mm/min TOOL MAGAZINE number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT store type: table changer number of store positions: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 19000 kg ATTACHMENTS chip conveyor: yes coolant unit: yes ban ...
CONTROLS CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 1300 mm Y-axis travel: 1200 mm Z-axis travel: 1100 mm TABLE table surface (left-right): 800 mm table surface (front-back): 800 mm workpiece load (max): 2000 kg SPINDLE / HEAD spindle revolutions (max): 0 /min spindle revolutions (max): 6000 /min tool fixture: ISO BT 50 AXIS DRIVES rapid traverse: 42000 mm/min TOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 7400 mm space requirements -front/back-: 4300 mm total height: 3750 mm total weight approx.: 23500 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes through spindle coolant att ...
CONTROLS CNC controls MITSUBISHI M720BM BASIC FUNCTIONS number of spindles: 2 number of turrets: 1 live positions: yes number of c-axes: 2 WORKING RANGE TURNING swing diameter (max): 700 mm turning diameter (max): 350 mm MAIN SPINDLE spindle revolutions (max): 4000 /min spindle bore diameter: 90 mm c-axis: yes X/Z SLIDE - rotation speeds (max): 6000 /min TOOL MAGAZINE number of positions: 24 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 7500 kg ATTACHMENTS (TURNING) chip conveyor: yes coolant unit: yes hydraulic system: yes European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...
