x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...
x-travel: 560 mm y-travel: 560 mm z-travel: 630 mm Control: MSX 701 III MAPPS Main spindle:: Max. rpm: 14.000 min/-1 power capacity - main spindel: 18,5 / 11 kW max. Torque: 120 Nm tool taper: MAS BT 40 distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 100 - 730 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm max. workpiece height: 900 mm change time of pallets: 6,0 sec b - axis: 0,001 ° Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT 40 max. tool diameter: 70 / (140) mm max. tool length: 400 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 m/min feed speeds: 0 - 50.000 mm/min Tipp feed: 0 - 1.260 mm/min total power requirement: 35 kVA weight of the machine ca.: 9,8 t dimensions of the machine ca.: 5,5 x 3,5 x 2,8 m Docume ...
turning diameter: 390 mm turning length: 507 mm control: MSG 805 MAPPS max. turning diameter: 390 mm greates pass round over bed: 680 mm Swing dia. over traverse guideway: 510 mm centre distance: 618 mm Main spindle:: turning speed range - main spindle: 45 - 4.500 min/-1 power capacity - main spindel: 11 / 7,5 kW spindle bearing diameter: 110 mm spindle bore: 73 mm max. bar capacity: 51 mm spindle nose: JIS A2-6 chucking diameter: 210 mm C-Axis: 0,001 ° axis stroke:: x-axis: 235 (195+40) mm z-axis: 520 mm turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tool stations: max. 3.000 min -1 power capacity driven tool-stations: 5,9 / 4,5 kW Shank height for square tool: 25 mm Drill shank diameter: max. 50 mm turret change time: 0,2 sec. Tailstock:: tailstock adjustment: 490 mm dia. of quill: 85 mm taper of center: MT 4 quill stroke: ...
turning diameter: 370 mm turning length: 424 mm control: MSX-711-IV Mori Seiki swing diameter: 370 mm X1- Axis: 380 mm X2- Axis: 155 mm Z1- Axis: 460+155 mm Z2- Axis: 610 mm y-axis: +/- 105 mm B - axis: +/- 120 ° bar material dia.: 65 mm speed spindle max.: S1 5.000 / S2 6.000 U/min. spindle bore: S1/S2 65/38 mm : 12000 1/min tool taper: Capto C5 toolpiece magazine: chain magazine: 76 Stück tool turret with 10 work positions: total power requirement: 45 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m MAPPS control system Renishaw HPRA (manual tool presetter) Blum Laser Control Direct measuring system X,Y,Z,B Collet chuck SMW Autoblok KSZ-MB-040-Z140 Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar Chip conveyor ConSep 2000 The data for this ad was create ...
turning diameter: max. 320 mm turning length: 810 mm control: MSX 701 MAPPS III standard turning dia.: 200 mm Main spindle:: Number of revolutions: max. 6.000 min/-1 power capacity - main spindel: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Subspindel:: Number of revolutions: max. 6.000 min/-1 power capacity - Sub spindle: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Turret 1 + 3:: number of toolpositions: je 16 pos. Number of driven toolspositions: je 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+65 / -45) mm Turret 2:: number of toolpositions: 16 pos. Number of driven toolspositions: 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+45 / -65) mm axis stroke:: x-travel: 1-3: 210 mm y-travel: 1-3: ...
turning diameter: 176 mm turning length: 570 mm swing diameter: 510 mm working diameter: 420 mm travel -z axis: 570 mm travel -x axis: 245 mm spindle bore: 43 mm diameter of quill: 85 mm quill stroke: 120 mm Spindle Speed: 60-6.000 U/min. rapid power traverse in X-and Z direction: 24 m/min total power requirement: 5,5 kW control: MSG-805 V weight of the machine ca.: 3.400 kg dimensions of the machine ca.: 2000x1700x1800 mm Features/Accessories: - Integrated CNC control - Bed guides and cross-slide guides are induction-hardened and designed as flat guides - Continuously variable AC main spindle drive - Constant cutting speed programming - Cold light lamp integrated into the machine - Power meter for the main spindle drive (ammeter) - Control units for automatic and manual operation, as well as a CNC programming unit and control panel - Tailstock with hydraulically actuated MK 4 tailstock ...
x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: ca. 570 mm turning length: ca. 530-610 mm control: FANUC : ohne Gewähr x-travel: ca 160-200 mm y-travel: ca. 560 mm weight of the machine ca.: 4,5 - 5 t : ca 10 oder 12 spindle bore: 52-76 mm total power requirement: - kW weight of the machine ca.: 4 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 200 mm turning length: 393 mm control: MSX 853 weight of the machine ca.: 3,5 t total power requirement: kW dimensions of the machine ca.: m MSX 853 cnc control 3-jaw chuck diameter 210mm 12-fold revolver C-axis driven tools tail stock coolant device chip conveyor Technische Daten: / technical details Drehdurchmesser / turning diameter 200 mm Drehlänge / turning lenght 393 mm X-Weg / X-travel 160 mm Z-Weg / Z-travel 450 mm max. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpm Eilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mm Antriebsleistung Spindel / drive capacity spindle 13,5 kW Gewicht ca. / weight ca. 3500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are n ...
turning diameter: max. 356 mm turning length: 705 mm control: MSX 850 III MAPPS Mitsubishi greates pass round over bed: 923,8 mm Swing dia. over traverse guideway: 755 mm standard turning dia.: 275 mm Main spindle:: max. spindle speed: 4.000 min/-1 power capacity - main spindel: 18,5 / 15 kW spindle nose: JIS A2-8 spindle bearing diameter: 140 mm spindle bore: 91 mm max. bar capacity: 80 mm chucking diameter: 305 mm C-Axis: 0,001 ° Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 11 / 7,5 kW spindle nose: JIS A2-5 spindle bearing diameter: 85 mm spindle bore: 43 mm chucking diameter: 210 mm C-Axis: 0,001 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Shank diameter: 26 mm Drill shank diameter: 50 mm Spindle speed - driven tool stations: max. 6.000 min -1 turret change time: 0,25 sec. axis stroke:: x-a ...
x-travel: 1.020 mm y-travel: 510 mm z-travel: 510 mm control: MSC 501 Fanuc table surface area: (APC) 1.200 x 480 mm max. table load: (APC) 550 kg Main spindle:: turning speed range - milling: 10.000 U/min power capacity - milling spindle: 22 / 18,5 kW tool taper: BT 40 Tool-Presetter:: number of toolpositions: 30 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg rapid traverse: 32 m/min feed: 1 ~ 16.000 mm/min Tipp feed: 0 ~ 1.260 mm/min spindle bearing diameter: 85 mm total power requirement: 59,5 kVA weight of the machine ca.: 6,9 t dimensions of the machine ca.: 3,9 x 2,7 x 2,9 m Documents: Chip conveyor: 2x Coolantsystem: high pressure coolant: through spindle coolant: Signal-Light: pallet changer: 2 pos. CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT ...
旋盤直径:370mm 旋回長:424mm 制御:ファナック 総動力要求:機械のkW重量 ca.: 機械の寸法 ca.: mこの広告のデータはLogoTech oHGのソフトウェアソリューションであるModulMWSで作 されました
旋盤直径:190mm 旋盤長:235mm 制御:FANUC/Mori MSX 501 スピンドル回転速度範囲:50-5000 U/minturret ヘッド:2×16 機械の重量 約7.5 tY軸およびB軸 その他アクセサリー詳細は www.marcels-maschinen.ch この広告のデータはLogoTech oHGのソフトウェアソリューションであるModulMWSで作 されました
旋盤直径:190mm 旋盤長:235mm 制御:FANUC/Mori MSX 501 スピンドル回転速度範囲:50-5000 U/minturret ヘッド:2×16 機械の重量 約7.5 tY軸およびB軸 その他アクセサリー詳細は www.marcels-maschinen.ch この広告のデータはLogoTech oHGのソフトウェアソリューションであるModulMWSで作 されました
turning diameter: 460 mm turning length: 795 mm control: MORI SEIKI M730 BM Swing diameter face slide: 590/360 mm spindle passage: 80 mm Traverse X/Z:: 260/795 mm Number of working hours: 19.552 h Cutting time: 10.704 h spindle drive: 18,5 kW total power requirement: 40 kVA weight of the machine ca.: 6,4 t dimensions of the machine ca.: 3.994 x 3.056 x 2.187 m Chip chuck Ø250 mm. Chuck sub-spindle Ø170 mm. Holder HAINBUCH chip conveyor suction Bar feeder Hydrafeed Multiservo mod MSV max. bar length 1,600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
MORI SEIKI SV-503B/40 is a 4-Achsen Bearbeitungszenter, entwickelt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 1320×600 mm, max Werkstückgewicht 1200 kg; Wege X1050, Y510, Z510 mm; Magazin 30 Plätze, BT40. Spindel 0–10.000 min-¹, 22 kW; Anschluss 3x200V 50Hz; 58 kVA; Gewicht ~8030 kg; Abmessungen 2500×2350×2700 mm. Zubehör: Satz Werkzeughalter, Kühlmitteleinrichtung mit 30 bar IKZ, Späneförderer, Teilapparat NIKKEN, Lampe, Zustandsleuchte. Geeignet für präzise Fertigung in Automotive, Luftfahrt, Medizintechnik und Maschinenbau. Technische Daten ohne Gewähr
CONTROLS CNC controls FANUC 18 MB WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 .. among of them simultaneous CNC axes: 3 X-axis travel: 900 mm Y-axis travel: 800 mm Z-axis travel: 980 mm rotating range B-axis from: 0 ° rotating range B-axis up to: 360 ° TABLE table surface (left-right): 630 mm table surface (front-back): 630 mm workpiece load (max): 1200 kg SPINDLE / HEAD spindle type: horizontal spindle revolutions (max): 10000 /min AXIS DRIVES rapid traverse: 50000 mm/min TOOL MAGAZINE number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT store type: table changer number of store positions: 2 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 19000 kg ATTACHMENTS chip conveyor: yes coolant unit: yes ban ...
CONTROLS CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 1300 mm Y-axis travel: 1200 mm Z-axis travel: 1100 mm TABLE table surface (left-right): 800 mm table surface (front-back): 800 mm workpiece load (max): 2000 kg SPINDLE / HEAD spindle revolutions (max): 0 /min spindle revolutions (max): 6000 /min tool fixture: ISO BT 50 AXIS DRIVES rapid traverse: 42000 mm/min TOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 7400 mm space requirements -front/back-: 4300 mm total height: 3750 mm total weight approx.: 23500 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes through spindle coolant att ...
CONTROLS CNC controls MITSUBISHI M720BM BASIC FUNCTIONS number of spindles: 2 number of turrets: 1 live positions: yes number of c-axes: 2 WORKING RANGE TURNING swing diameter (max): 700 mm turning diameter (max): 350 mm MAIN SPINDLE spindle revolutions (max): 4000 /min spindle bore diameter: 90 mm c-axis: yes X/Z SLIDE - rotation speeds (max): 6000 /min TOOL MAGAZINE number of positions: 24 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 7500 kg ATTACHMENTS (TURNING) chip conveyor: yes coolant unit: yes hydraulic system: yes European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...
製造元:森精紀 モデル番号:SH 633 年:1999年 状態:使用済み 在庫番号:9496 制御システム:森清機 MSG-502 作業台長:700 mm 作業台幅:500 mm 最大テーブル荷重(制服):1200 kg 最大スピンドル回転数:10000 1/分 X軸移動:840 mm Y軸移動:760 mm 移動距離 Z軸:840 mm 機械重量:18500 kg
製造元:森精紀 モデル:NL 2000 SY 年:2005年 状態:使用済み 在庫番号:9458 制御システム:FANUC MSX-850 最大旋回距離:510 mm 最大旋盤径:356 mm トラベルX:260mm トラベルY:100mm トラベルZ:590mm 重量:5800 kg 装備: バーフィーダー SPACESAVER SS 2101
Key data: 440 mm, 363 mm
製造元:森精紀 モデル番号:CL2000B 年:2014年 状態:使用済み 在庫番号:9456 制御システム:森精気M65V 開車時間:61927時間 勤務時間:25326時間 最大旋回距離:363 mm 最大旋盤径:440 mm 重量:2800 kg
この森精機CL2000Bは2008年に製造されました。最大旋 直径440mm、全長363mmを持つ頑丈な水平旋盤機です。10 個の砲塔と8インチのチャックを備えています。操作 系は森精気MSX-805IIです。この森精機CL2000B水平旋盤機 を購入するチャンスを考えてみてください。詳細に いてはお問い合わせください
インビッド番号 : 7790 タイプ:SL-4T プロデューサー:森精機 作成:1984年 パラメーター： 制御システム:FANUC 6T ベッド上の最大回転直径:490 mm サポート上の最大回転直径:320 mm 最大スピンドル速度:3000 1 / min 長さ:3100ミリメートル 幅:1900ミリメートル 高さ:1900ミリメートル 重さ: 5500 kg 備品： コンベヤ
インビッド番号 : 7736 タイプ:CL2000B プロデューサー:森精機 作成:2008年 パラメーター： 制御システム:三菱MAPPS III スイッチオン時間:37200時間 最大回転長さ:560 mm 最大旋削径:350 mm
turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...
This MORI SEIKI NL 1500 SY was manufactured in 2009. It features a control unit MSX-850III and has undergone recent servicing of guideways by DMG MORI. The machine includes a 3-jaw chuck for the main spindle and comes with all tooling and toolholders. If you are looking to get high-quality turning and milling capabilities, consider the MORI SEIKI NL 1500 SY turn-mill centre we have for sale. Contact us for further details.
Mori Seiki NT 5400 DCG - 1800 SZYear of manuf. : 2009 Control : Fanuc 30i (MSX-711) Turning diam. : 920 mmTurning length : 1800 mm____________Description:In General:Year of manufacture:2009Control system:Fanuc 30i (MSX-711)Max. turning diameter:920 (470) mmTurning length:1,800 mmBar capacity:103 mmMilling spindle:8,000 rpm, HSK 100Main spindle:RPM:2,400Max. power:37 kWMax. torque:1,432 NmC-axis:0.001°Chuck:SMW Autoblok KNCS 500-155Sub spindle:RPM:2,400Max. power:37 kWMax. torque:1,432 NmC-axis:0.001°Chuck:SMW Autoblok KNCS 500-155Tool carrier I (X/Y/Z/B):Technology:Traveling column with milling spindleMilling spindle:8,000 rpmPower:30 kWTorque:302 NmTool holder:HSK 100X-axis:1,040 mmY-axis:510 (+/- 255 mm) mmZ-axis:1,940 mmB-axis:+/- 120°, index 1°Tool carrier II (X/Z):Technology:Cross slide with tool turretTool drive:6,000 rpm, 40 NmNumber of stations:10X-axis:267 mmZ-axis:1,8 ...
