선반 사용 판매를 위해 (3,145)

제어: FANUC 0i TC 회전 직경: 520 mm 회전 길이: 1090 mm 회전 속도: -3500 U/min 상단 터렛 공구 호들러:: 12 빠른 회전 X축: 20 m/minrapid 회전 Z축: 24 m/min 전체 크기: 3000 x 1800 x 2000 mm 기계 무게 약 6 t이 광고 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

제어: FANUC 21i TB 선반 직경: 355 mm 회전 길이: 1330 mmc 축: 인덱싱: 0.001 회전 속도: -2800 U/mintool 테이퍼: BMT 65 상단 터렛 공구 호들러:: 12 빠른 회전 X축: 16 m/minrapid 회전 Z축: 24 m/min 전체 크기: 4000 x 2000 x 2100 mm 기계 무게 약 6700 t이 광고 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

control: GE Fanuc Series 21i-T Distance between centres: 5000 mmcenter bore: 425 swing over bed: 850 mmbed width: 425 mmrapid feed: 10000 mm/minworking feed: 7000 mm/minmain spindle bore: 85 mmMain spindle: DIN 55027-n°8 taper: 5 spindle speeds: 0-2000 U/minSpindle power: 11 KWtailstock quill diameter: 96 mmtailstock travel: 215 mmweight of the machine ca.: 7 tdimensions of the machine ca.: 7.300x1.700x1.900 mSupport Guides 2Swing over cross carriage 560 mm.Automatic ranges 2Turret type AutomaticTurret positions 8Hydraulic tailstock quill stroke INCLUDEDTailstock taper MORSE 63 Jaw Auto-centering hydraulic chuck Ø 300 mm. INCLUDED4 support steady rest Ø 450 mm. INCLUDED3 support steady rest Ø 250 mm INCLUDEDChuck protection INCLUDEDComplete rear protection INCLUDEDDual handwheel for carriage control INCLUDEDFoot pedals for hydraulic chuck opera ...

turning diameter over bed: 1930 mmturning diameter over slide rest: 1520 mmturning length: 5000 mmturning speeds: 0,5-250 U/minspindle bore: 105 mmworkpiece weight: 35 tsteady: 400-700 mmsteady: 700-1200 mmsteady: 1000-1600 mmcontrol: Siemens total power requirement: 106 kWweight of the machine ca.: tdimensions of the machine ca.: mThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us Morethan 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit.Your Markus Hirsch TeamTh ...

centre distance: 1000 mmturning diameter over bed: 420 mmturning diameter over bed slide: 235 turning length: 1000 mmspindle taper: DIN 55027 Gr. 6control: MANUALPlus 4110 spindle bore: 51 mmturning speed range: 3 - 3000 U/minfeed:: 5.000/10.000 mm / mindrive capacity - spindle motor: 11 kWtaper in tailstock-quill: MK 4 dia. of quill: 70 mmquill stroke: 110 mmcoolant: ja/yes voltage: 400 VNumber of working hours: 6.908 hweight of the machine ca.: 3 tdimensions of the machine ca.: 3,4 x 2 x 2,2 mBOEHRINGER DUS 400 ti CNC cycle-controlled lathe, built in 2006-Control system: Heidenhain ManualPlus 4110-11 kW AC main drive with 2-stage gearbox-Work area cover with chip guard door-Control panel mounted on the support, moves with the machine-Holding brake-Programmable cycles-4-position quick-change turret-Size 2 tool holder on fixed base-With 1 WD ‘/25’ tool holder-Tailstock-Rapid traverse ...

turning diameter: 65 mmturning length: 150 mmcontrol: Siemens 840D spindle passage: 75 mmturning length: 150 mmc-axis: 2x 0,001 °gripping station: 65 mmspeeds: 5000 U/minrapid traverse: 30 m/minturret (x-stations): 3x12 Number of axles: 10 St.number of toolholder-holes: 36 chip conveyor: ja / yes kWcoolant filtering unit: ja / yes kWNumber of working hours: 35000 htotal power requirement: 22 kWweight of the machine ca.: 9 tdimensions of the machine ca.: 4,4 x 2 x 2,3 + Iemca mbar loader: Iemca Master 880 DMG Sprint 64 Linear CNC lathe, built in 2007, 10 axes, 2 spindles,3 turrets with Iemca Master 880 loading magazineAccessories:a large number of tool holdersin total 104 off, 24 of them are driven tool holderThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bar material dia.: 32/38 mmspindle passage: 44 mmturning length: 320 mmturning speeds: 200-8000 U/minc-axis: 0,001 Gradgripping station: 32/38 mmturning length: 120 mmturning speeds: 200-8000 U/minc-axis: 0,001 0number of tools: 13 fixnumber of milling stations: 4+5 drivencontrol: Mitsubishi Meldas M70 Number of axles: 5+2 St.total power requirement: 7,5 kWweight of the machine ca.: 2850 kgdimensions of the machine ca.: 2,5 x 1,4 x 1,75 + FMB mbar loader: FMB turbo 3-36 fire distinguisher: Kraft & Bauer CNC sliding headstock machine Citizen L32-1M8, built 01/2019 with barloaderFMB turbo 3-36equipped with swarf & coolant tank, fire distiguisher.ON/OFF 29.564h (status 24.03.2026)Running hours 26.607h (status 24.03.2026)GBL function (standard)LFV function: noThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 400 mmturning length: 230 mmcontrol: Fanuc total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mFanuc controlat each spindle is a 3-jaw chuck mounted2x 12-fold revolverchip conveyorcoolant deviceTechnische Daten: / technical detailsSchwingdurchmesser / rotary diameter 500 mmmax. Drehdurchmesser / max. turning diameter 400 mmmax. Drehlänge / max. turning length 230 mmX-Weg / X-travel 220 mmZ-Weg / Z-travel 230 mmmax. Drehzahl der Spindeln / max. spindle speed of the spindles 2000 UpM /rpmAnzahl der Revolverplätze / number of tool places 2x 12 Eilgang x, z / rapid feed x, z 30, 30 m/minAntriebsleistung Spindeln / drive capacity spindles 18,5/15 kWGewicht ca. / weight ca. 9400 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, acces ...

turning diameter: 330 mmturning length: 669 mmcontrol: Sinumerik 828D total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mCNC control Sinumerik 828D12-fold revolver Sauter VDI40driven toolsC-axis3-jaw chuckTool Eyepart catcherchip conveyortail stockcoolant device with high pressure pumpbar loading device IemcaTechnische Daten / technical details:Umlaufdurchmesser über Bett / rotary diameter over bed 600 mmmax. Drehdurchmesser / max. turning diameter 330 mmmax. Drehlänge / max. turning length 669 mmX-Weg / X-travel 260 mmZ-Weg / Z-travel 762 mmDrehzahl / spindle speed 3400 UpM /rpmWerkzeugrevolver / turret head 12 fach /holesmax. Stangendurchmesser / max. bar diameter 75 mmEilgang X / rapid feed X 20 m/minEilgang Z / rapid feed Z 24 m/min.Gewicht der Maschine ca. / weight ca. 5700 kgT ...

turning diameter over bed: 330 mmturning diameter over slide rest: 190 mmcentre distance: 650 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mturning length: mm3-jaw chuckMultifix tool holder devicetail stock coolant deviceTechnische Daten / technical details:Spitzenweite / center to center 650 mmDreh-Ø über Bett / turning diameter over bed 330 mmDreh-Ø über Schlitten / turning diameter over sledge 190 mmSpindelbohrung / spindle hole 36 mmDrehzahlbereich / spindle speed 30-2500 UpM /rpmAntriebsleistung / drive capacity 2,2 kWGewicht der Maschine ca. / weight ca. 600 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of the machine are not binding.The data for this ad was created with ModulMWS - the software solution of LogoTech ...

회전 직경: 680 mm 회전 길이: 600-635 mm 제어: 지멘스 총 전력 요구량: kW 기계 무게 약 6500 kg 기계 크기: m이 광고의 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

회전 직경: 340 mm 회전 길이: 500 mm 제어: OSP 7000L 총 전력 요구량: kW 기계 무게 약 4000 kg 기계 크기 약 약 m. 이 광고의 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

Maximum turning diameter: 2800 mmMaximum swing diameter: 3000 mmdiameter of spindle flange: 1100 mmcontrol: Siemens 840 D sl Table rpm: 230 1/minMaximum speed of driven tools: 6000 1/minx-travel: 2700 mmz-travel: 1000 mmFeed - X: 24 m/minfeed capacity - x: 22 kNtool taper: CAPTO C8 total power requirement: 200 kVAdimensions of the machine ca.: 10,4 x 6.3 x 5,7 mweight of the machine ca.: 120 tEquipment/Accessories: - 2 tool changers one with 25 positions and one with 41 positions- 2 x chip conveyors- Coolant system, 6 bar- High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply- Hydraulic unit - Automatic door - Electric handwheel - Technical documentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 420 mmturning length: 1350 mmspindle passage: 101 mmcontrol: Siemens SL 828D ShopTurnnumber of controlled axis: 4 turning speed range: 3000 U/minpower requirement: 22/18,5 kWrapid speed: 30 m/minnumber of tapers in turret head: 12/24 BMT 65number of driven tools in turret: 12 BMT 65Spindel speed of driven tools: 5000 U/minSpindelpower on driven tool: 7,5/5,5 kWy-axis: +/- 65 mmtail stock: MT-5 weight: 8,0 tdimensions: 5,7 x 2,3 x 2,32 mHeavy CNC- lathe with driven tools and Y- Axis in very good condition.First instalation: 03/2023 Appr. 5400 h Power on.- 2x 3-jaw chuck Ø 325 + 400 mm- some fixed tool holders- Tool pre- setter- chip conveyor- 4x driven tool holders- 2 + 2 driven toolholders with Capto C4- oildust collector- band filter system with appr. 1000 ltr.- hydr. steady moveable wit turret SMW Autoblock SLU-X3.1 (Ø 20- 165 mm)- 3 colour signal lamp- coolant gun- ...

turning diameter: 200 mmturning length: 393 mmcontrol: MSX 853 weight of the machine ca.: 3,5 ttotal power requirement: kWdimensions of the machine ca.: mMSX 853 cnc control3-jaw chuck diameter 210mm12-fold revolverC-axisdriven toolstail stockcoolant devicechip conveyorTechnische Daten: / technical detailsDrehdurchmesser / turning diameter 200 mmDrehlänge / turning lenght 393 mmX-Weg / X-travel 160 mmZ-Weg / Z-travel 450 mmmax. Drehzahl Spindel / max. spindle speed 50-3000 UpM /rpmEilgang X/Z / rapid feed X/Z 24/30 Anzahl der Revolverplätze / number of tool places 12 max. Stangendurchmesser / max. bar diameter 51 mmAntriebsleistung Spindel / drive capacity spindle 13,5 kWGewicht ca. / weight ca. 3500 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description of ...

turning diameter: max. 356 mmturning length: 705 mmcontrol: MSX 850 III MAPPS Mitsubishigreates pass round over bed: 923,8 mmSwing dia. over traverse guideway: 755 mmstandard turning dia.: 275 mmMain spindle:: max. spindle speed: 4.000 min/-1power capacity - main spindel: 18,5 / 15 kWspindle nose: JIS A2-8 spindle bearing diameter: 140 mmspindle bore: 91 mmmax. bar capacity: 80 mmchucking diameter: 305 mmC-Axis: 0,001 °Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1power capacity - Sub spindle: 11 / 7,5 kWspindle nose: JIS A2-5 spindle bearing diameter: 85 mmspindle bore: 43 mmchucking diameter: 210 mmC-Axis: 0,001 °turret:: number of toolpositions: 12 pos.Number of driven toolspositions: 12 pos.Shank diameter: 26 mmDrill shank diameter: 50 mmSpindle speed - driven tool stations: max. 6.000 min -1turret change time: 0,25 sec.axis stroke:: x-axis: 260 mmz-axis: 795 mm ...

turning diameter: 210 mmturning length: 700 mmcontrol: Okuma OSP-E 100 L total power requirement: 35,7 kVAweight of the machine ca.: 7,1 tdimensions of the machine ca.: 2660 x 2000 x 2330 mCNC turning and milling center with C-axis and Y-axis,2 turrets, and subspindle.CNC control: Okuma OSP-E 100 LMaximum turning diameter: 210 mmSwing over bed: 400 mmDistance between spindle noses: 960 mmMain spindle:Spindle bore: 53 mmSpeed range: 50 to 6000 rpmMotor power: 11/7.5 kWSubspindle:Spindle nose: JIS A2-6Speed range: 38 to 5000 rpmMotor power: 11/7.5 kWZ-axis:Travel: 700 / 700 mm (ZA + ZB)Rapid traverse: 40000 mm/minW-axis:Travel: 940 mmRapid traverse: 40000 mm/minX-axis:Travel: 167 / 192 mm (XA + XB)Rapid traverse: 30000 mm/minY-axis:Travel: 92 mm (+50/-42 mm)Rapid traverse: 15000 mm/minC-axis:Indexing: 360° x 0.001°Rapid traverse: 400 rpmDisc turret:2 x 12 stationsTool holder mount: VDI 3 ...

turning diameter: 570 mmturning length: 2000 mmcontrol: num + CNC Keller centre height: 280 mmturning dia. over face-slide: 365 mmspindle bore: 62 mmspindle turning speed range: 3 - 2500 U/minspindle head: DIN 55 027 Gr. 8 cutting speed: Konstant 1 - 9999 m/minfeed in x - axis: 0,01 - 50 mm/Ufeed range Z-direction: 0,01 - 50 mm/Urapid travel - longitudinal/face: 10 / 5 m/minfeed power: x-Achse 7100 Nfeed power: z-Achse 12.500 Ntravel of cross-slide: 345 mmupper slide travel: 125 mmbed width: 360 mmtailstock quill diameter: 80 mmtailstock quill stroke: 190 mmtailstock taper MT: 5 max. workpiece weight -without tailstock: 400 kgmax. workpiece weight between centres: 1000 kgmax.workpiece weight:each extra steadyrest: 300 kgthreading metric: 0,1 - 400 mm/Stg.dimensions of machine L x W x H: 3,98 x 1,87 x 1,81 mtotal power requirement: kWweight of the machine ca.: tAccessories: 3-jaw ch ...

회전 직경: 500 mm 회전 길이: 1000 mm 제어: 하이덴하인 총 전력 요구량: kW 무게 약 3200 kg 기계 크기: m이 광고의 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

회전 직경: - mm 회전 길이: - mm제어: 총 전력 요구량: 기계 무게 약 kW 무게 무게 약 약 1000 대량 기계 크기: m이 광고의 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

turning diameter: 500 mmturning length: 1200 mmcontrol: Siemens 840D greates pass round over bed: 700 mmMain spindle:: turning speed range - main spindle: 20 - 5000 min/-1power capacity - main spindel: 25 /34 kWC-Axis: 0,0001 °spindle diameter: 65 mmmilling spindle: milling spindle motor: 23 / 13 kWmilling head speed: 12000 U/minb-axis: +/- 120 °axis stroke:: x-axis: 490 mmy-axis: +/- 100 mmz-axis: 1300 mmfeeds:: rapid traverse ( X / Y / Z ): 60 / 22,5 / 30 m/minfeed power: 5,6 / 5,6 / 7,4 kNnumber of toolpositions: 24 pos.tool taper: HSK A 63 total power requirement: - kWweight of the machine ca.: 15 tdimensions of the machine ca.: 6 x 3 x 2,3 mCNC turning and milling center - 5 axes simultaneous- CNC control Siemens 840D Ergo Line with ShopTurn- C-axis (0.0001°)- Milling head with B-axis- Y-axis- Coolant device/paper belt filter (through Spindle)- Chip conveyor- Tailstock- SMW A ...

회전 직경: 16 mm, 회전 길이: 16 mm, 회전 길이: 160 mm, 제어: GE FANUC 시리즈 18 i-T 회전 속도 범위: 8000 U/분속 회전: 30 m/최소 총 전력 요구량: 2.2 kW 기계 무게 약 2.1 t. 부속품: 바 로더 IEMCA, GENIUS 226-32 L, YOM 2002 (바 직경 2 - 26 mm, 바 길이 1500 - 3210 mm용), 칩 컨베이어, 냉각수 이 광고의 데이터는 LogoTech oHG의 소프트웨어 솔루션인 ModulMWS로 작성되었습니다.

faceplate diameter: 6300 mmswing diameter: 9700 mmturning height: 4900 mmram head dimension: 360 x 360 mmfaceplate turning speed range: 0,4 - 50 U/minworkpiece weight: 150 tmain drive motor: 71 kWControl: Siemens Sinumerik 840D total power requirement: 230 kVAweight of the machine ca.: - tdimensions of the machine ca.: - m2010 overhauled and modernised, new electric etc, equipped with:- Siemens Sinumerik 840D (2 Panels Left/right Side)- C-axis and milling spindle- 2 ram support on cross beam- milling spindle with 1000 rpm, 28kW (right ram)- Turning support (left ram)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter max. over bed cover: 570 mmswing diameter over face slide: 420 mmcontrol: Heidenhain CNC PILOT longitudinal stroke: 635 mmface stroke: 220 spindle bore: 79 mmcentre distance: 1000 mmchucking diameter: 250 mmtailstock taper MT: 4 feed speed longitudal: 0,025-24.000 mm/min.feed speed face: 0,025-20.000 mm/min.power feed longitudinal: 7.000 NFeed Force Face: 3.500 Ntotal power requirement: 44 weight of the machine ca.: 5,7 tdimensions of the machine ca.: 7,5 x 4,0 x 1,7 mAccessories: - 3 clamping jaws - various tool holdersThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: FANUC Series 31i Model 5 turning diameter: 540 mmturning length: 1040 mmc-axis: indexing: 0.001 °turning speeds: -5000 U/mintool taper: ASA A2-6 Top turret tool hodler:: 12 y-travel: 170 (+/- 85) mmrapid traverse X-axis: 36 / 24 m/minrapid traverse Z-axis: 36 / 26 m/minOverall size: 8000 x 3000 x 3000 mmweight of the machine ca.: 12000 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

POREBA TCF 160 is a heavy-duty CNC horizontal lathe (turning machine) manufactured by POREBA Machine Tools, a Polish industrial machine tool builder. It’s part of the TCF series, which includes several sizes designed for machining very large, heavy workpieces such as shafts, rolls, and other long cylindrical components.Turning large shafts and heavy cylindrical parts, like those used in shipbuilding, power generation, mining, and heavy machinery.When equipped with optional tooling, it can also perform drilling and milling operations in addition to turning.Rigid construction with hardened guideways and heavy cast components for stability.Milling attachment 5,5 kW with Sk-40 taperCentral lubricationMotorized tailstock4 Chuck 1300 mm CNC control SIEMENS 840D with following softeare options:MMC Easy MaskSpline interpolationLook AheadContour re-alignmentMantel surface programmingFull C-A ...

greates pass round over bed: 640 mmswing diameter over face slide: 435 mmcontrol: Siemens SINUMERIK 810D pl turning speed range: 3 - 2.500 U/mincentre distance: 1.500 mmspindle bore: 70 mmspindle diameter in front bearing: 100 mmLathe - cycle-controlled | VDF-BOERHRINGER - DUS 630 tiThe machine is in good condition and can be inspected under power at any time.Please note that the technical details were added from comparable machines.- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -#Tags: DUS630ti | DUS 630ti | DUS 630 tiThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
