JUNKER machine à vendre

N° Inv. : 7323 Modèle : BUAJ 30 Producteur : Junker Création : 1999 Paramètres: Dimensions de la table : 1380x160 mm Distance entre les pointes : 630 mm Poids de la machine : 2800 kg

Vente préalable réservée - erreurs possibles Numéro de référence interne : D-1143-3

turning speeds: - U/min frequency: - Hz output: - kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Flexible high-performance grinding machine JUROBOT handling-cell (FANUC M-10iA): Z-axis/grinding length: 500mm max., orbital diameter: 150mm max., workpiece weight: 15kg max., grinding wheel diameter: 350mm max., operating hours: 23219h, with documentation, an on-site inspection is possible.

Flexible high-performance grinding machine with JUROBOT handling-cell (FANUC M-10iA): Z-axis/grinding length: 500mm max., orbital diameter: 150mm max., workpiece weight: 15kg max., grinding wheel diameter: 350mm max., operating hours: 12238h, with documentation, an on-site inspection is possible.

grinding diameter:280/320 mm grinding length:750 mm centre height:170 mm weight of the machine ca.:22,5 t dimensions of the machine ca.:4,7 x 3,65 x 3,0 m

weight of the machine ca.:24 t dimensions of the machine ca.:3900 x 3500 x 2500 m -the machine has no B axis -two grinding spindles with one grinding wheel each - The transport instructions can be found in the documentation (attachment). including Hoffmann KSM filter system Loading list available Operating data v. 03/27/2023: Operating time: 21727 h / production time: 11960 h Machine documentation: 1 set of circuit diagrams, electrical plans, operating instructions Accessories: 2 replacement measuring heads Marposs S/500; prism supports Other: Hoffmann KSM filter system Machine condition: according to age, due to processing with emulsion

Description: Max. Grinding diameter : Ø 280 mm Center height : 150 mm Center width : 800 mm Grinding wheel holder for wheel: Ø 400 x 127 Grinding wheel diameter : max Ø 400 mm wheel speed : 45 m/s Control : Fanuc 21 grinding diameter: 280 mm, grinding length: 800 mm, control: FANUC 21, weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 2,500 x 2,800 mm

vitesses de rotation : - Fréquence U/min  : - Sortie Hz  : - kw

vitesses de rotation : - Fréquence U/min  : - Sortie Hz  : - kw

JUNKER EJ 50 grinding machine Year 2007 55kva 400V 50Hz

Dot height: 150mm, Distance between points: 1000mm, Grinding wheel dimensions (od x id x width): Ø400xØ127x50mm, Internal grinding head: 4 units, Centre height: 150mm, Max. workpiece weight: 80Kg, X-axis travel (transverse): 350mm, X-axis speed: 10 meters per minute, Z-axis travel (longitudinal): 1000mm, Z-axis speed: 12 meters per minute, Z-axis resolution: 0.00004, B-axis swivel range: 210°, B-axis resolution: 0.0001°, Drive capacity: 10 HP, Grinding wheel diameter: 400mm, Max. width Grinding wheel width: 63mm, Spindle speed range: 0-1000 RPM, Spindle swivel range: 0° - 90°, Tailstock stroke: 30mm, Equipped with: Fanuc 21i-TB CNC Control, Dimensions: 3350x 2130x 2130, Weight: 4535Kg, Accesories: Steady rests, magnetic plate, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.

The diameter of the ground workpiece for internal grinding is 8 - 190 mm. External grinding: - center distance 640 mm - workpiece diameter 295 mm Total machine input 35kVA. The machine is functional, but needs an initial investment in repairs.

Mold heating, fan heaters, heating, gas heating, construction heating, construction dryers, heating, hall heating, gas heating for casting molds, foundry technology -Manufacturer: Junker, gas heating WA 26532 on a mobile transport frame -Burner: Wiedemann B202 H2-3 175 kW -Blower: Spelleken 5.5 kW volume flow 500 m³/h -Individual components/accessories: see photos -Dimensions 1500/1250/H2010 mm -Weight 625 kg
