型号
(生产厂家: INDEX)
turning length:400 mm total power requirement:45 kW weight of the machine ca.:4 t dimensions of the machine ca.:3,58 x 1,91 x 2,05 m spindle passage:45 mm
turning diameter:626 mm turning length:3000 mm Turning diameter:600 mm spindle bore:100 mm spindle turning speed range:2800 U/min weight of the machine ca.:18 t Machine overhold and retrofit in 2003 with SIEMENS 840 D control - NC steady rest - 12-fold revolving head - splash doors - tailstock - coolant device
turning diameter: 140 mm turning length: 615 mm control: C200-4D spindle passage: 65 mm Main spindle: turning speeds: 5.000 U/min max. torque at 40% / 100% load: 145 / 105 kW turret-slide: 1,2 und 3 x-travel: 110 mm z-travel: 360 mm y-travel: 70 mm rapid traverse X/Y/Z: 25/12/45 m/min Opposed spindle: slide travel X-axis: 150 mm Z- Travel: 600 mm turning speeds: 5.000 U/min B - axis: B-Korrekturachse +/- 1 ° tool turret - number of stations: 3 x 12 tool taper DIN 69880: VDI 25 x 48 C-axis: 0,001 ° total power requirement: 61 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 9,75 x 3,10 x 2,85 m Loading: Breuning Profimat 65.8x270/8 multi-channel loading magazine, built in 2005 for bars with lengths of 500–3,000 mm, 8 guide channels with spindle insert tubes (Ø 16, 25, 30, 40, 45, 55, 60, 65 mm) Unloading: BREUNING ILS-REX-7208 automatic workpiece unloader, built i ...
turning diameter: 580 mm turning length: 1600 mm control: Siemens 810 T turning diameter over slide rest: 320 mm spindle passage: 85 mm Tool changer: turning speeds: 12,5-4000 U/min transmission ratio: 4 chip conveyor: 3 jaw chuck Forckrath: 315 mm steady: 170 mm tail stock: total power requirement: 53 kW weight of the machine ca.: t dimensions of the machine ca.: m Machine has been overhauled The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by ...
turning diameter: 600 mm turning length: 1500 mm control: C200 T turning diameter over slide rest: 425 mm spindle passage: 100 mm Tool changer: live tooling: turning speeds: 10-2800 U/min transmission ratio: 4 chip conveyor: 3 jaw chuck Forckrath: 315 mm steady: tail stock: c-axis: total power requirement: 53 kW weight of the machine ca.: t dimensions of the machine ca.: m Speed monitoring The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by a ...
turning diameter: 400 mm turning length: 1250 mm control: Siemens type: 840 C swing diameter: 590 mm turning speeds: 3500 U/min Torque: 275/178 Nm spindle passage: 50/65 mm clamping chuck diameter: 250 mm output: 43/28 kw Tool changer: 80 Pos. tool taper: Capto C 4 Turret 12-fold, 12 stations: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Counter spindle 3500 rpm Flexible head 1500/6000 rpm (2 gear ratios) Head with 4 stations (2 fixed stations for turning/2 milling stations) Power 9.4 kW Travel 1250 mm Spindle head ISO 702/1 size 8 (HSP) size 6 (GSP) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 it ...
turning diameter: 200 mm turning length: 400 mm control: Siemens type: C 200-4 840 C spindle passage: 65 mm Tool changer: 2 x14 Pos. Turret 12-fold, 12 stations: c-axis: live tooling: 2x Revoler total power requirement: kW weight of the machine ca.: 4 t dimensions of the machine ca.: m Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader Index MBL Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, o ...
turning diameter: 80 mm turning length: . mm control: Siemens C 200 tool change unit: 14 live tooling: swing diameter: 130 mm spindle passage: 42 mm turret head: 2 total power requirement: kW weight of the machine ca.: t Synchronous spindle on turret Turret 1: 12 tool positions Turret 2: 8 tool positions 3 tool positions for synchronous spindle Collet set Many tool holders Various driven tools Bar loader Index MBL Chip conveyor with coolant unit Set of spindle reducers and much more (see images) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, o ...
turning diameter: 300 mm turning length: 360 mm control: Siemens S3 T swing diameter: 370 mm tail stock: Tool changer: 14 Pos total power requirement: kW weight of the machine ca.: t 14-station tool turret, Many accessories Bar loader The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 300 mm turning length: 360 mm control: Siemens S3 T swing diameter: 370 mm Tool changer: 14 Pos live tooling: turning speeds: 25-4000 U/min transmission ratio: 2 total power requirement: kW weight of the machine ca.: t Quill Turret with 14 tool positions Driven tools Documentation Almost complete collet set 2-jaw chuck 3-jaw chuck Multiple jaws, both hard and soft + various claw jaws Multiple tool holders Various driven tool holders Hydraulic bar feed Hydro Sameca Feed tubes for all diameters Chip conveyor Coolant unit Set of spindle reducers The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your worksh ...
turning diameter: 440 mm turning length: 1500 mm control: C 200 Tool changer: 16 3 jaw chuck Forckrath: 500 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Optional tool package can be purchased The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 straight turning atchm. - working travel: . mm turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the ...
turning diameter: 626 mm turning length: 3000 mm control: Siemens type: 840D spindle passage: 100 mm Turret 12-fold, 12 stations: turning speeds: 2800 U/min total power requirement: kW weight of the machine ca.: 18 t dimensions of the machine ca.: m Machine overhauled in 2003 and equipped with a Siemens 840 D - NC steady rest - 400 mm power chuck The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your ...
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 straight turning atchm. - working travel: . mm turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar type: 6.32HS-4.4 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m No.: ER25071388 Parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this a ...
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 straight turning atchm. - working travel: . mm turret head: 8 thread cutting attachment: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m No.: ER25071388 Parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software ...
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 straight turning atchm. - working travel: . mm turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the ...
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar type: 6.26HS-4.4 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech ...
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar type: 6.30HS-4.4 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech ...
spindle passage: 60 mm cross-slide: 4 turret head: 6 Pos. thread cutting attachment: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
machine: 15 Pos. accessories:: Pos. electric measuring devices: 1 For sale is an entire production line for mass and small parts. This includes: 1x INDEX GS30 with SAMECA bar loader 8x INDEX ER25 with LNS Hydrobar bar loader 2x INDEX B60 2x BOLEY 2x INDEX ER25 1x Index 18 Ulmer tool presetter Complete magazine with accessories, spare parts, and tools, some in like-new condition The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We lo ...
turning diameter: 250 mm turning length: 750 mm control: Siemens type: 840 c spindle passage: 65 mm Tool changer: 2 Turret 12-fold, 12 stations: Pos. c-axis: live tooling: 2x Revoler total power requirement: kW weight of the machine ca.: 7 t dimensions of the machine ca.: m Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader Index MBL Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your busine ...
spindle passage: 60 mm cross-slide: 4 turret head: 6 Pos. thread cutting attachment: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle passage: 25 mm turning speeds: 5750 U/min Rest: 4 turret head: 8 thread cutting attachment: bar loader: LNZ Hydrobar total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m parts catcher The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 280 mm turning length: 800 mm control: Siemens type: 840 D c-axis: live tooling: Tool changer: turning speeds: 4000 U/min swing diameter: 320 mm 3 jaw chuck Forckrath: 250 mm tail stock: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Machine has been overhauled The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team Th ...
turning diameter: 250 mm turning length: 400 mm control: C 200 / 8 total power requirement: 60 kW weight of the machine ca.: 8,5 t Swing Ø above bed, max. 300 mm Max. turning Ø for chucking work, approx. 250 mm Travel of Slides: Turret 1, X / Z travel 163 / 550 mm Turret 2, X / Z / Y travel 140 / 250 / 260 mm Spindle bore, approx. 65 mm Tool holder bore 30 mm Spindle speeds 25 - 5,000 rpm Feed range 0 - 15,000 rpm Spindle drive 0.5 - 40 kW Total electrical load 60 kW - 380 V - 50 Hz Weight, approx. 8,500 kg Accessories / Special Features SIEMENS CNC Continuous Path Control, Model 880 (INDEX C 200-8) for at least 6 axes, with enlarged memory and with subprograms, simulation, etc. Double column loading device for large workpieces, mounted above the machine. With 3-jaw gripper and storage system for blanks and finished parts, integrated in the CNC control. Spindle indexing an ...
Manufacturer: INDEX Model: INDEX ABC Year of Manufacture: 1997 - With bar feeder and chip removal Electrical Specifications - Power Supply: 3-phase, 50 Hz - Rated Voltage: 400 V - Control Voltage: 24 V - Rated Current: 32 A Synchronous Spindle - Collet Clamping - Max. torque (Md max. 25%): 10 Nm - Max. speed: 4500 rpm - Max. collet diameter: 42 mm - Clamping depth at max. collet diameter: 38 mm - Spindle bore diameter: 15.5 mm - Max. ejector stroke: 36 mm - Max. clamping pressure: 65 bar Synchronous Spindle - Chuck Clamping - Max. torque (Md max. 25%): 10 Nm - Max. speed: 4000 rpm - Max. chuck diameter (external): 75 mm - Max. ejector stroke: 42 mm - Max. jaw stroke: 0.6 mm - Max. clamping pressure: 20 bar Rear Tool Carrier for Backworking Operations - Capacity: up to 5 fixed tools - Capacity driven tools: up to 3 fixed and 2 driven tools - Max. speed (driven tools): 6000 rpm ...
Manufacturer: INDEX Model: MS42C Year of Manufacture: 1998 ( Machine 1 ) 2002 (machine2 ) Machine 1 : Power supply: 3-phase / 50 Hz Rated voltage: 400 V Control voltage: 24 V Rated current: 125 A Rated power: 69 kW Electrical cabinet weight: 1500 kg Machine weight: 11000 kg Machine 2 : Power supply: 3-phase / 50 Hz Rated voltage: 400 V Control voltage: 24 V Rated current: 100 A Rated power: 72 kW Electrical cabinet weight: 1500 kg Machine weight: 11000 kg Working area Maximum bar diameter (bar feed, external): 42 mm Bar feed positions: spindle positions no. 1, 3, 4, 6 Spindle circle diameter: 320 mm Main spindle (turning spindle) Clamping system: Power clamping with INDEX spring-loaded hollow clamping cylinder and draw tube Maximum clamping stroke: 4 mm Clamping force: 26 kN Drives Main spindle drive (per spindle): Motor type: Variable-speed hollow-shaf ...
swing diameter: 560 mm turning length: 800 mm control: C200-4D Siemens 840 D Main spindle:: spindle head: 8 DIN 55026/55021 ISO 7027/1 bar capacity: 90 mm spindle diameter in front bearing: 140 mm turning speed range - spindle: ~ 3.500 U/min drive capacity - spindle motor: 100% / 40%: 43 / 57 kW Torque: 275 / 363 Nm Indexing: 2,5 ° C-Axis: 0,001 ° turret:: Number of Turrets: 1 number of toolpositions: 12 pos. Spindle speed - driven tool stations: ~ 6.000 min -1 power capacity - driven tool-stations: 11 kW tool taper: 40 x 63 mm DIN 69880 Torque: 21,5 Nm travel -x axis: 300 mm travel -z axis: 800 mm rapid traverse: X/Z: 30 / 22,5 m/min feed power: X: 7.200 N feed power: Z: 9.000 N Tailstock:: dia. of quill: 65 mm Cone: SK 30 longitudinal travel: 800 mm rapid traverse: 10 m/min total power requirement: 51 kVA weight of the machine ca.: ca. 14 t dimensions of the machine ca.: 7,3 x 4,0 ...
