GLEASON machine à vendre

Diamètre de travail maxi 660,4 mm Module max 16,9 Largeur de travail 106,7 mm Min. max non. Nombre de dents 20 - 75 Poids de la machine 17700 Kg Équipé Disques d’indexation Têtes de coupe Jauge Dispositif de réglage de la lame

AFFÛTEUR DE COUPE CONIFLEX Marque : GLEASON Modèle : 104

Pour la vente d’une tête de fraisage d’occasion d’un Gleason Genesis 130 H

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

Description: Spiral bevel gear cutter head make: Gleason type number: C9S10RH Technical details Diameter 235 mm Number of cutting edges: 12 pieces Equipped with 6 knives. Further information Cutter head for Gleason machines No: 7 + No: 16 + No: 26 for spiral bevel gears Approx. Onsite Dimension. (l x w x h): 235 x 235 x 60 mm, weight approx.: 15 kg

Manufacturer Gleason Model Pfauter P 200 G Year 1999 Machine is in good condition

Diamètre: 235 mm Nombre de couteaux: 12 z= adaptateur d’outil: 12 Stück

number: 20 tool adaptor: 55 diameter: 9 Zoll total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Type Nr.30212024, F-Nr.F746550002933, Anz. Messer 20, Anz. d. Messerköpfe a. Lager 9 Type Nr.30212025, F-Nr.F746550002934, Anz. Messer 20, Anz. d. Messerköpfe a. Lager 18 Type Nr.30212026, F-Nr.F746550002935, Anz. Messer 20, Anz. d. Messerköpfe a. Lager 25 Type Nr.30212027, F-Nr.F746550002936, Anz. Messer 20, Anz. d. Messerköpfe a. Lager 1 Type Nr.30212006, F-Nr.F746550002939, Anz. Messer 12, Anz. d. Messerköpfe a. Lager 19 Type Nr.30233008, F-Nr.F746550299197, Anz. Messer 22, Anz. d. Messerköpfe a. Lager 2 Alle Werkeuge 9 Zoll The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hob: External gears workpiece diameter (tip diameter), max.: 100 mm Minimum circle of shell end mill arbor: 22 mm Maximum tooth length 180 mm Maximum length 140 mm Trolley race: Radial stroke (X axis): 90 mm Tangential stroke (Y axis): 80 mm Axial stroke (Z axis): 400 mm Races of auxiliary trolleys: Loading portal (X5 axis): 2268 mm Sliding headstock (Z4 axis): 360 mm Maximum swivel angle of the milling head: Direction -A: 45 degrees Direction +A: 118 degrees Work table: External diameter: 120 mm Bore: 40 mm Machine size(LxWxH): 5195 mm x 3142mm x 2928 mm Feed rates: X axes, and Z: 1 to fast forward mm/min Rapid traverse: X axis: 7500 mm/min Y axis: 5000 mm/min Z axis: 15000 mm/min Rotational speeds: Tool: 50 to 12000 rpm Workpiece spindle: 0 to 3000 rpmControl: SINUMERIK 840D sl Machine Weight: 8000 Kg

max. wheel diameter: 1010 mm gear width: 0 mm max. module: min. module: total power requirement: 15 kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: m Max. depth of tooth 10 mm Max. workpiece Ø (for clearance) 1,010 mm Max. external Ø of coupling 610 mm Sliding base withdraw 216 mm Max. distance from grinding wheel to workpiece nose 90 - 430 mm Max. weight of workpiece, including clamp 500 kg No. of teeth 32 to 150 Grinding wheel Ø, approx 152 - 320 mm Grinding wheel speeds, infinitely variable 0 - 3,600 rpm Work spindle bore 60 mm Total electrical load, approx. 15 kW - 380 V - 50 Hz Weight, approx. 9,500 kg Accessories / Special Features Automatic roughing and finishing process via pre-settable counter and built-in feed cam. Counter for number of teeth. Counter for number of dressing cycles. 2 built-on dressing units with three dressing diamonds for radiu ...

max. wheel diameter: 215 mm gear width: 40,65 mm max. module: total power requirement: 20 kW weight of the machine ca.: 10 t Max. external Ø of workpiece 215 mm Tooth profile, height x width 16 x 40.65 mm No. of teeth 5 - 200 Max. tooth ratio 1 : 10 Grinding wheel Ø 51 - 190 mm Grinding wheel speeds 1,000 - 6,000 rpm X Axis (horizontal) 152 mm Y Axis (vertical) 178 mm Z Axis (slide base plate) 304 mm Distance from middle of machine to middle of workspindle 115 mm Axial speed 125 mm/sec Workpiece speeds 0 - 30 rpm Workspindle bore, conical 3 29/32 inch Total electrical load 20 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features FANUC CNC Control, Model 150 MB, for 7 axes, with monitor and direct input. Automatic calculation of all workpiece and grinding parameters. Extensive coolant equipment with filter system, band filter, etc. Driv ...

max. wheel diameter: 400 mm gear width: 0 mm module: pinion diameter - max.: 254 mm axial cross angle: 90 ° total power requirement: 15 kW weight of the machine ca.: t dimensions of the machine ca.: m This machine is very suitable for precision production testing of spiral and hypoid bevel gears with shaft angle 90°. The gear spindle is vertical and the pinion spindle is horizontal. The pinion cone distance can be adjusted while the machine is working in order to find the optimal mounting position whereby the gear is loaded with a preset torque. The axial pinion position can be adjusted until the quietest meshing position of the traction flank is found. Likewise, the thrust flank can be tested during the return run. Marking compound is sprayed on both sides of the teeth so the flank contact pattern can be seen. Working cycles, as well as the positioning in the tooth gap, are automat ...
