Presses d'injection de caoutchouc

clamping force: 350 kNinjection volume: 59 cm³screw diameter: 25 mmplaten size: 400 x 400 mmCondition: used,Specification: injection moulding machine for rubber - used International size: 350-90 clamping unit:- clamping force: 350 kN- clamping platen size: 400 x 400 mm- Clear distance between tie bars: 270 x 270 mm- Mould installation height min.: 225 mm- Distance between clamping platens: max. 550 mm- Opening stroke max.: 325 mm- Ejector stroke: 125 mmInjection unit:- Screw diameter: 25 mm x 20D- Injection volume max.: 49 cm³- Injection part weight: 59 g/hp- Max. injection pressure: 1,860 bar- Screw circumferential speed: 37 m/min- Cylinder heating: 4x 900 W- Nozzle heating:  ...

clamping force: 1.300 kNinjection volume: 230 cm³screw diameter: 45 mmplaten size: 685 x 685 mmCondition: used,Specification: injection moulding machine for TPE - usedincluding Koch dosing unitclamping unit:- clamping force: 1.300 kN- heating platen size: 685 x 685 mm- Clear distance between tie bars: 470 x 470 mm- Mould installation height min.: 250 mm- Distance between platens max.: 900 mm- Opening stroke max.: 650 mm- Ejector stroke: 225 mmInjection unit:- Screw diameter: 45 mm x 18D- Injection volume max.: 230 cm³- Injection part weight: 210 g/hp- Max. injection pressure: 1,670 bar- Screw circumferential speed: 75 m/min- Cylinder heating: 4x 2,200 W- Nozzle heating: 600 W- Connection value: 3x 400 V, 50 Hz- Electrica ...

clamping force: 350 kNinjection volume: 58,5 cm³screw diameter: 28 mmplaten size: 260 x 254 mmCondition: used,Specification: injection moulding machine for TPE - usedclamping unit:- clamping unit: vertical- clamping force: 350 kN- opening stroke max.: 300 mm- platen distance max.: 500 mm- Mould installation height min.: 200 mm- Clear width between tie bars: 260 x 254 mm- Ejector stroke max.: 80 mm- Clamping unit: VV- Lift of protective bonnet: 500 mmInjection unit:- Screw diameter: 28 mm- Screw L/D ratio: 18.6- Screw stroke max.: 95 mm- Injection volume max.: 58.5 cm³- Injection pressure: 1577 bar- Plasticising flow: 8.6 g/s- Injection flow: 85.5 g/s- Connected load: 3x 400 V, 50 Hz- Max. heating power: 5.8 kW- Drive power: 7,4 kW- Total power:  ...

clamping force: 11000 kNinjection volume: 12500 cm³screw diameter: -- mmplaten size: -- mmCondition: used,Specification: injection moulding machine for rubber - used, in very good condition machine was serviced annually by manufacturerclamping unit:- Euromap (size): 11000-25600- clamping force: 11.000 kN- size of heating platens L/W/H: -- x -- x mmInjection unit:- Injection volume max.: 12,500 cm³- Injection pressure: 2050 bar- Dosing force: 118 kN- Control: Siemens S7- Connected load: 3x 400 V, 50 Hz, N- Total current: 276 A- Back-up fuse: 300 A- Pump drive: 277 bar- Driving power: 45 kW- Weight approx.: 43.8 tOperating hours approx.: 33,130 hoursThe data for this ad was created with ModulMWS - t ...

clamping force: 2700 kNinjection volume: 3300 cm³screw diameter: -- mmplaten size: 780 x 670 mmCondition: used,Specification: vertical injection moulding machine for rubber NR, EPDM, SBR, NBR, CR, etc. - used, in very good condition 6 months in useclamping unit:- Euromap (size): 2700-7200- Clamping force: 2,700 kN- Heating platen size L/W/H: 780 x 670 mm- Distance between upper and lower platen: 970 mm- Stroke min.: 420 mm- Stroke: 550 mmInjection unit:- Injection volume max.: 3,300 cm³- Injection pressure: 2,180 bar- Nozzle contact force: 80 kN- Connected load: 3x 400 V, 50 Hz, N- Back-up fuse: 125 A- Pump drive: 265 bar- Drive power: 22 kW- Pump speed: 66 rpm-  ...

clamping force: 2700 kNinjection volume: 3300 cm³screw diameter: -- mmplaten size: 780 x 670 mmCondition: used,Specification: vertical injection moulding machine for rubber NR, EPDM, SBR, NBR, CR, etc. - used, in very good condition almost unused!clamping unit:- Euromap (size): 2700-7200- Clamping force: 2,700 kN- Heating platen size L/W/H: 780 x 670 mm- Distance between upper and lower platen: 970 mm- Stroke min.: 420 mm- Stroke: 550 mmInjection unit:- Injection volume max.: 3,300 cm³- Injection pressure: 2,180 bar- Nozzle contact force: 80 kN- Connected load: 3x 400 V, 50 Hz, N- Back-up fuse: 125 A- Pump drive: 265 bar- Drive power: 22 kW- Pump speed: 66 rpm- C ...

DESMA 400 tonnes machine de moulage par injection de caoutchouc -Modèle : SIGMA 4000

clamping force: 250 kNinjection volume: 49 cm³screw diameter: 25 mmplaten size: 300 x 300 mmCondition: used,specification: C-frame injection moulding machine - usedclamping unit:- clamping force: 250 kN- heating platen size: 300 x 300 mm- clamping/opening stroke: 330 mm- Closing direction: from below- Lateral ejector: yes- Ejector stroke/force: 115 mm / 12 kNInjection unit:- Injection volume max.: 49 cm³- Screw diameter: 25 mm- Screw length: 16- Screw speed max.: 250 rpm- Injection: from above- Voltage: 3x 400 V, 50 Hz, N, PE- Connected load: 55 kW/92 A- Weight approx.: 3,500 kgVarious accessories are also available:- Injection unit (25 screw)- 2 heating plates- Funnel and various small partsThe data for this ad was created with ModulMWS - ...

clamping force: 450 kNinjection volume: 135 cm³screw diameter: 35 mmplaten size: 600 x 400 mmCondition: used,Specification: C-frame injection moulding machine for TPE - usedclamping unit:- clamping force: 450 kN- heating platen size: 600 x 400 mm- sliding table: yes- Clamping direction: from below- Ejector / lifter: Up + LoInjection unit:- Injection volume max.: 135 cm³- Screw diameter: 35 mm- Connected load: 3x 400 V, 50 Hz- Weight approx.: 5,500 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

clamping force: 450 kNinjection volume: 99 cm³screw diameter: 30 mmplaten size: 860 x 320 mmclosing stroke: 406 mmCondition: used,Specification: C-Frame Injection Moulding Machine - second-hand Serial No.: 45083Clamping unit:- Clamping force: 450 kN- Opening travel: 406 mm- Heating plate size: 860 x 320 mm- Mould height min.: 264 mm- Max. plate spacing: 464 mm- Ejector stroke: 20 mm- Ejector force: 20 kNInjection unit:- Screw diameter: 30 mm- Screw length L/D: 16- Dosing stroke: 140 mm- Stroke volume max.: 99 cm³- Max. spray weight: 114 g- Screw speed: 20 - 300 rpm- Injection flow: 106 cm³/s- Injection flow increased: 71 cm³/s- Special injection pressure: 1451 bar- Spec. injection pressure increased: 2205 bar- Nozzle path: ...

clamping force: 450 kNinjection volume: 99 cm³screw diameter: 30 mmplaten size: 860 x 320 mmclosing stroke: 406 mmCondition: used,Specification: C-Frame Injection Moulding Machine - second-hand Serial No.: 45083Clamping unit:- Clamping force: 450 kN- Opening travel: 406 mm- Heating plate size: 860 x 320 mm- Mould height min.: 264 mm- Max. plate spacing: 464 mm- Ejector stroke: 20 mm- Ejector force: 20 kNInjection unit:- Screw diameter: 30 mm- Screw length L/D: 17- Dosing stroke: 140 mm- Stroke volume max.: 99 cm³- Max. spray weight: 114 g- Screw speed: 20 - 300 rpm- Injection flow: 106 cm³/s- Injection flow increased: 71 cm³/s- Special injection pressure: 1450 bar- Spec. injection pressure increased: 2210 bar- Nozzle path: ...

clamping force: 800 kNinjection volume: 78 cm³screw diameter: 25 mmplaten size: 570 x 552 mmCondition: used,Specification: injection moulding machine for LSR - used Nr. 13EN08clamping unit:- clamping force: 800 kN- size of heating platen: 570 x 552 mm- Between tie bars horizontally: 405 mm- Between tie bars vertically: 345 mm- Opening stroke: 310 mm- Ejector force: 25.4 kN- Ejector stroke: 100 mm- Mould installation height max.: 530 mm- Mould installation height min.: 250 mm- Bar diameter: 60 mm- Control: CC 90-A0Injection unit:- Injection volume max.: 78 cm³- Injection weight max.: 90 g- Screw diameter: 25 mm- Metering stroke: 160 mm- Screw speed max.: 20 - 400 rpm- Injection flow: 87 g/sec- Injection flow (increased): 64 g/sec- Sp ...

clamping force: 800 kNinjection volume: 154 cm³screw diameter: 35 mmplaten size: 570 x 552 mmCondition: used,Specification: injection moulding machine for LSR - used Nr. 13EN12 clamping unit:- clamping force: 800 kN- size of heating platen: 570 x 552 mm- Between tie bars horizontally: 405 mm- Between tie bars vertically: 345 mm- Opening stroke: 310 mm- Ejector force: 25.4 kN- Ejector stroke: 100 mm- Mould installation height max.: 530 mm- Mould installation height min.: 250 mm- Bar diameter: 60 mmInjection unit:- Injection volume max.: 154 cm³- Injection weight max.: 156 g- Screw diameter: 35 mm- Metering stroke: 160 mm- Screw speed max.: 20 - 320 rpm- Delivery flow: 35 g/sec- Injection flow: 148 g/sec- Injection flow ...

Machine d’injection HUSKY Type H400 400 tonnes Pression hydraulique 180 BAR max Poids 18 143 kg Marquage Année : 2003

Klockner Desma 100ton Presse à injection Modèle: D968.100.Z0 Taille de la plaque: 400mm de profondeur x 500mm de large Volume de course 350cm3 Force de serrage 1000kN Pression d’injection 2380 bar Tension 3x 400 50Hz Année 1998

LWB Steinl Presse de moulage par injection / vulcanisation Modèle: VCE-B Force de serrage 2500kN Volume d’injection 1000 cm3 Air comprimé 6 bar 75 kW Huile hydraulique 40/45 cst Taille du motif 760 x 630mm Écran tactile LWB Flex Qté 1 Tool Kemp modèle TT-188 (année 2019) coureur chaud. Poids 12850 kgs

Machine de moulage par injection LWB Steinl Modèle VCE-T-TPE-EPDM Capacité de 100 tonnes Contrôle de l’écran tactile ECO

LWB Steinl Presse de moulage par injection / vulcanisation Modèle: VCEFE Force de serrage 2500kN Volume d’injection 1000 cm3 Air comprimé 6 bar 76 kW Huile hydraulique 46/40 cst Taille du motif 760 x 630mm Écran tactile LWB Flex Qté 2 Tool Kemp modèle TT-188 Année 2013 Poids 13500 kgs

LWB Steinl Presse de moulage par injection / vulcanisation Modèle: VCEFE-B Force de serrage 2500kN Volume d’injection 1000 cm3 Air comprimé 6 bar 76 kW Huile hydraulique 46/40 cst Taille du motif 760 x 630mm Écran tactile LWB Flex Qté 2 Tool Kemp modèle TT-188 Poids 13500 kgs

Machine de moulage par injection Maplan Modèle: MTF400 / 80C 80 tonnes Distance de sécurité 162mm Temps d’exécution 81ms Suivi 5mm Taille du motif 510mm x 410mm Contrôle de l’écran tactile

Key data: 1500 kN, 750 cm³

Panneaux 510x400 mm Force de serrage 150 t Volume injecté max. 750 cm³ Largeur libre 440 mm

Rep B46 Machine de moulage par injection Taille des plateaux 430x430mm Unité d’injection volume court 670cm3 Pression d’injection 1690 bar Force d’injection 331kN

clamping force: 1.013 kNinjection volume: 400 cm³screw diameter: 25 mmplaten size: 335 x 400 mmCondition: used,Specification: injection moulding machine for rubber - usedclamping unit:- clamping unit: vertical- clamping force: 1.013 kN- size of heating platen: 335 x 400 mm (standard) core turning unit Injection unit:- screw diameter: 25 mm- Barrel diameter: 51 mm- Injection volume max.: 400 cm³- Injection pressure: 1,500 bar- Connection value: 3x 400 V, 50 Hz 42A fuse protection (incl. periphery)- Electrical power: 29,1 kVA- Control: G8 Control- Hydraulics: 250 bar (tank 200 litres)- Further connections: Cooling water inlet/outletDimensions L/W/H approx.: 2,300 x 3,400 x 2,250 mmWeigh ...

Presse d’injection Yizumi Modèle : YL2-V280L Force de serrage 2800 kN Cylindrée : 2000cc Moule course ouverte 500mm Hauteur min. du moule 100mm Taille du plateau chauffant 670 mm x 780 mm Plaque chauffante lumière du jour 600mm Pression d’injection 1970 bar Volume d’injection théorique 2000cm3 Puissance de la pompe à huile 11kW Pression du système 230 bar Puissance totale 37kW Alimentation : 415V, 50Hz, 3P + N + PE Pompe variable Rexroth + servomoteur Inovance : Année 2021 Marquage
