Göpfert SRE-2 Maxi Mod. 250 Boxmaker

ID 170188644

ID 170188644

usedVerified seller
Request price Directly to the seller
Göpfert SRE-2 Maxi Mod. 250 Boxmaker
1 / 6

Technical data

· ID 170188644
Source: seller information

Used machinery

Condition
used
Location
Emskirchen - Nürnberg

Identifikation

ManufacturerGöpfert
ModelSRE-2 Maxi Mod. 250
Item number26054

Technik

Quantity1

Description

Der Boxmaker Göpfert SRE Maxi macht alle Verarbeitungsschritte in einem: Rillen und Schneiden - längs und quer, Schlitzen und Stanzen. Wellpappenverarbeitung.
The Göpfert SRE Maxi boxmaker performs all processing steps in a single operation: creasing and cutting—lengthwise and crosswise—slotting, and die-cutting. Corrugated Converting.

Boxmaker Göpfert SRE-2 Maxi Mod. 250 - 2 (120) Compact

Baujahr / Year 1995 - Serial-No. 1536.95.03
Arbeitsbreite / Working width min. 360mm - max. 2.500mm
Arbeitslänge / Working Length min. 800mm - max. 10.000mm
Dicke des bearbeiteten Materials / Thickness Of Processed Material min. 2mm - max. 16mm
Schlitztiefe / Slot Depth 0–1.000mm
Produktionskapazität / Production Capacity 250–380 pieces/hour

Geeignet für alle Arten von Wellpappe (ein-, zwei- und drei-wellig),
Suitable For All Kinds Of Corrugated Board (Single, Double, Triple Wall)

Stromanschluss / Power supply 25KW, 50A
Druckluftanschluss / Compressed air Connection min. 8bar - max. 10bar
