utilisé
X-axis: 2000mm, y-axis: 400mm, z-axis: 560mm, connected load: 23kVA, weight: 4.7t, fourth axis axis with tailstock, ran in two-shift operation, on-site inspection is possible.
utilisé
x-travel:550 mm y-travel:300 mm z-travel:425 mm CNC-control:Sinumerik table-size:950 x 350 mm max. table load:500 kg spindle taper ISO:30 spindle turning speed range:20 - 10500 U/min spindle drive motor:5,5 kW tool change unit:12 Pos. coolant:inkl. voltage:380 V tool adaptor:Steilkegel 40 groove width:32/28 mm no. of flutes:3 rapid speed:40.000 mm/min total power requirement:15 kVA weight of the machine ca.:3,3 t chip conveyor:inkl. dimensions of the machine ca.:2000x 3000 x2500 mm Documents:vorhanden - Serial Number: 186 - 78 - Control: FANUC O-M - with various tool holders - coolant equipment
utilisé
x-travel:550 mm y-travel:400 mm z-travel:360 mm control:Siemens Shopmill 840 D Tilting Axis A Angle:± 100 ° table surface area:Ø 280 mm Spindle RPM:20-12000 1/min spindle drive:9,5 / 14 kW Spindle Torque:90 Nm rapid travel x/y/z:60 mm/min tool magazin::48 HSK-A63 tool diameter:82 (125) mm weight of tools max.:5 kg Tool change time tool/tool, milling spindle:2,4 s total power requirement:15 kW weight of the machine ca.:8,2 t Dimensions (L/W/H):3,8 x 4,1 x 3,3 mm internal coolant system feed:10/20/30/40/50/60/70 bar Motoman robot:NX 100 This is a well maintained vertical 5-axis machining center with coolant through spindle 10-70 bar. Motoman Robot for parts loading
utilisé
Description: Note! without machine vise and tooling z-motion: 425 mm, x-motion: 550 mm, y-motion: 300 mm, control: Siemens Sinumerik, table surface area l x w : 660 x 350 (2x) mm, numbers of pallets: 2, taper: SK40, toolchanger positions: 20, power capacity - spindle: 11 kW, turning speed range: 10,000 rpm, rapid motion: 40 m/min, weight approx.: 4,000 kg, Approx. Onsite Dimension. (l x w x h): 3,550 x 2,240 x 2,450 mm
utilisé
This 5-axis Chiron Mill 800 was manufactured in 2005. It features a spindle revised in September 2022, capable of 20000 rpm and a robust Heidenhain iTNC-530 control. The machine handles up to 380kg on its table with a tool capacity of 40. It has comprehensive cooling options and a full panelling setup. A significant opportunity to buy this Chiron Mill 800 vertical machining centre. Contact us for more information.
utilisé
utilisé
utilisé
N° de série : 161-24 X-Course : 550 mm Course Y : 300 mm Course Z : 425 mm Nombre d’heures de travail : 35284 h refroidissement : Innen nein : max. 10.500 : commande NEIN : Simens Sinumerik 810D poids : 4000 kg
utilisé
: 489-41 x-course : 550 mm y-course : 300 mm z-course : 425 mm Nombre d’heures de travail : lässt sich nicht auslesen h refroidissement : Innen nein : max. 10.500 4ème axe : nein contrôle : Simens Sinuerik 810 poids : 4000 kg
utilisé
x-course : 2000 mm y-course : 425 mm z-course : 425 mm Nombre d’heures de travail : lässt sich nicht auslesen h refroidissement : Kühlung ja : max. 10.500 : ja control : Simens Sinumerik 810 poids : 6700 kg
utilisé
N° de série : 456-16 x-course : 550 mm y-course : 300 mm z-course : 425 mm refroidissement : Innen nein : max. 10.500 : nein contrôle : Simens Sinumerik 810 poids : 4000 kg
utilisé
N° de série : 143-86 X-Course : 550 mm Y-Course : 300 mm Z-Course : 425 mm Nombre d’heures de travail : 58046 h refroidissement : Innen nein : max. 10.500 : nein contrôle : Simens Sinumerik 810D poids : 4600 kg
utilisé
N° de série : 162-74 X-Course : 550 mm Y-Course : 300 mm Z-Course : 425 mm Nombre d’heures de travail : 58370 h Refroidissement : Ja : 10.500 : Nein Control : Simens Sinumerik 810D Poids : 4000 kg
utilisé
Chiron FZ08KW MAG Vertical Machining Center With 4th Axis Siemens 840D Control Unit 15 000 rpm Double table Double dividing head(Peiseler) Renishaw probe All maintenance has been done Chiron Turkey
utilisé
x-travel: 300 mm y-travel: 250 mm z-travel: 250 mm table surface area: 2 x 550 x 300 mm spindle taper: HSK-A 32 spindle taper: DIN 69893 spindle turning speed - stepless: 20 - 15.000 U/min spindle motor: 7,4 kW max. torque on the spindle: max. 23 Nm spindle throat: 200 - 450 mm distance table - lower edge spindle: 170 - 420 mm power feed x/y/z: 2000 / 2000 / 3000 N rapid traverse longitudinal and cross: 40 m/min rapid traverse vertical: 60 m/min coolant tank: 100 l control: SIEMENS, 840 D total power requirement: kW weight of the machine ca.: 2,2 t dimensions of machine L x W x H: 2,75 x 1,45 x 2,25 m Accessories: various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
utilisé
This CHIRON DZ15W MAGNUM HS Vertical Machining Centre was manufactured in 2015. It is equipped with a FANUC Series 31i-model B5 control unit, has 4 axes and a 12000 rpm spindle. The machine comes with swarf conveyor, tooling, coolant / paper filtration unit, high pressure coolant and pallet.
utilisé
This CHIRON MILL 2000 Vertical Machining Center was manufactured in the year 2003. It is equipped with a Siemens Sinumerik control unit. The machine has a spindle speed of 12000 rpm.
utilisé
This CHIRON DZ24 WM HS Vertical Machining center was manufactured in the year 2015 in Germany. It is equipped with a Fanuc Series 31 i â MODEL B5 control unit and has 4 axis. The machine has a spindle speed of 15000 rpm.
utilisé
This CHIRON MILL FA 800 vertical machining center was built in the year 2006 in Germany. it is equipped with a Siemens Sinumerik 840D control unit and has 5 axis. The machine has a spindle speed of 12000 rpm.
utilisé
This CHIRON MILL 800 Vertical Machining center was manufactured in the year 2015 in Germany. It is equipped with a SIEMENS SINUMERIK control unit and has 5 axis.
utilisé
This CHIRON FZ15W Vertical Machining center was manufactured in the year 2001. It is equipped with a Siemens SINUMERIK 840D control unit and has 3 axis. There are 2 units available.
utilisé
This CHIRON FZ15W Vertical Machining center was manufactured in the year 2002 in Germany. It is equipped with a Siemens SINUMERIK 840D control unit and has 4 axis.
utilisé
This CHIRON MILL 2000 Vertical Machining centre was manufactured in the year 2005 in Germany. Contact us anytime for further questions.
utilisé
course x : 550 mm course y : 300 mm course z : 425 mm cône d’outil : SK 40 contrôle : Siemens 840 D puissance totale requise : 12 KVA poids de la machine env. : 5 t dimensions de transport Lxlxh : 2,1 x 3,1 x 3,0 m chiron fz 12 wm avec plaque interchangeable avec 2 x 4. axe PEISELER avec ONTROL SIEMENS 810
utilisé
x-travel: 800 mm y-travel: 630 mm z-travel: 550 mm control: TNC 640 Millturn Heidenhain Main spindle: turning speed range - main spindle: max. 12.000 U/min power capacity - main spindel: 7,5 - 22,5 kW max. Torque: 140 Nm tool taper: HSK-A 63 NC-Rotary table:: faceplate diameter: 280 mm T-slots: H7 x 50 measuring system: ECN 225 swivellable: +/-120 ° Torque: max. 180 Nm Holding Torque: 800 Nm max. table load: 320 kg turning speeds: 200 min/-1 Tool-Presetter:: numbers of positions in the tool changer: 40 max. tool diameter: 75 mm max. tool-dia with free toolbox: 160 mm max. tool length: 320 mm max. tool weight: 4 kg feed: rapid travel ( X / Y / Z ): 60 m/min total power requirement: 31 kVA weight of the machine ca.: 7,8 t dimensions of the machine ca.: 5,0 x 6,0 x 3,0 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: 40 bar through spindle coolant: triple signal li ...
utilisé
utilisé
: 2 Nombre d’essieux : 4 Cône d’outil : HSK 63 Tourelles de péage : 60 Poids : 9600 kg
utilisé
Sinumerik 810M GA3 Basket tool changer: 20 x SK30 Tool change under 2 seconds. Spindle Max: 10500 rpm Table size: 2x (660mm x 350mm) Axes travel: X= 550mm Y= 300mm Z= 425mm B= 360 degrees (4th-axis) Under rotary table on the left: Yes. Coolant unit with Knoll swarf conveyor. Weight: 4000Kg CRT screen was upgreaded to TFT. Equiped with 1x 4th axis
utilisé
X axis movement : 630 mm Y axis movement : 400 mm Z axis movement : 630 mm Double table Table size : 620 mm x 940 mm Machine has been used on aluminium
utilisé
Itâs had very little use over the last few years. Has to be the most productive machine in its class. YOM: 2001 Control: Fanuc 21iM Spindle: 15000 RPM Swarf Conveyor Includes all spindle tooling and custom Microloc work holding bases & clamps (as seen in the photos). We have all the manuals, operation, programming, maintenance, spares and electrical.
