Modèle
(Fabricant: ALZMETALL)
Machine de perçage de colonne ALZMETALL AB3 ESB Broche: CM3 Rotation: 1 plage 220 -800 RPM + 1 plage 800-2900 RPM Taille de la table: Longueur 615 mm x Largeur 470 mm Course de la broche: 160 mm Profondeur de gorge: 280 mm Réglage de la vitesse par entraînement par courroie Table rotative à 360° Descente automatique 3 vitesses: 0,006 - 0,12 - 0,18 mm/min. Pompe à lubrifiant Tension : 380 V Largeur: 800 mm Profondeur: 1300 mm Hauteur totale: 1900 mm Poids: environ 800 kg
distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg
bore stroke:170 mm total power requirement:3,5 kW dimensions of the machine ca.:0,75 x 1,10 m bore spindle turning speed range:30-3000 U/min bore range:diameter:4-60 mm
Capacité d’alésage en acier (diamètre) : 28 mmbras longueur : 700 mm hauteur maximale de la pièce : 1300 mm coniques de l’outil : MK3 avances : 0,1-0,3 mm/Plage de vitesse de rotation sur la broche : 100-1,220 U/min Puissance totale requise : 1,4 kWweight de la machine environ : 1,3 tDimensions de la machine vers : LBH 1,8 x 0,8 x 2,3 mIncl. Table à cubes Inclus. Alimentation de forageClampage mécaniqueLes données de cette publicité ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.
Fabricant : Alzmetall Modèle : AB 4/HST Année de fabrication : 2001 Tension : 400 V Plage de vitesse : 60 - 1 530 tr/min Puissance du moteur : 2,6 / 3,1 kW (3,5 / 4,2 ch) Porte-outils : MT 4 Profondeur de gorge : 330 mm Course de la broche : 200 mm Hauteur : 2 135 mm Poids : 850 kg Pour en savoir plus, cliquez ici - / Contactez-nous à -
x-travel: 1200 mm y-travel: 600 mm z-travel: 800 mm Control: Heidenhain type: TNC 426 table surface area: 1250x630 mm workpiece weight: 1000 kg Tool changer: 24 spindle taper ISO: 40 turning speeds: 30-8000 U/min total power requirement: kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 4,2x3,3x3,15 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data ...
bore capacity in steel St 60: 30 mm bore capacity in cast iron GG 20: 30 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 132 / 724 mm feed: von Hand spindle turning speed - stepless: 225 - 4300 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 40 mm threading in St 60: M24 threading in GG 20: M30 Short spindle: MK 3 Center of spindle to wall or column: 293 mm spindle turning speed - stepless: 160 - 2250 U/min Column diameter: 115 mm spindle stroke: 120 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 117/701 mm feed: 0,10 + 0,20 mm/U Motor output: 1,45 / 1,9 kW height of the machine: ca. 1840 mm weight of the machine ca.: 285 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 36.0 mm bore capacity in cast iron: 45.0 mm throat: 300 mm bore stroke: 160 mm : 4 speeds: 120-900 / 240 - 1780 U/min column diameter: 145 mm table-size: 615 x 460 mm feed: 0.1 / 0.2 / 0.3 / 0.4 mm/U total power requirement: 1.75 / 2.5 kW weight: 440 kg dimensions: 1200 x 800 x 2300 mm well-maintained condition () current new price approx. 18.000 Euro special price on request Equipment: - robust pillar drill (V-belt) - electromagnetic feed clutch = spindle feed with overload protection and electrical handle cross circuit - mushroom pushbutton (latching) for EMERGENCY STOP, in the front panel - electric stepless speed adjustment - Digital speed display - clockwise rotation of the drill spindle - pole-changing drive motor - Infinitely adjustable drilling depth stop - Work table with 2x T-slots - height-adjustable - Operating instructions in German T ...
bore capacity in steel St 60: 30 mm bore capacity in cast iron GG 20: 30 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 132 / 724 mm feed: von Hand spindle turning speed - stepless: 100 - 1.800 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 40 mm threading: bis M 30 throat: 330 mm bore stroke: 180 mm : 4 speeds: 60 - 765 U/min table-size: 720 x 360 mm total power requirement: 2,6 / 3,2 kW weight: 350 kg dimensions: 720 x 1100 x 2050 mm Equipment: - automatic feed - infinitely variable speed - thread cutting device - adjustable drilling depth stop - coolant device - spindle protection - drill chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 40 mm threading in St 60: M24 threading in GG 20: M30 Short spindle: MK 3 Center of spindle to wall or column: 293 mm spindle turning speed - stepless: 160 - 2250 U/min Column diameter: 115 mm spindle stroke: 120 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 117/701 mm feed: 0,10 + 0,20 mm/U Motor output: 1,45 / 1,9 kW height of the machine: ca. 1840 mm weight of the machine ca.: 285 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 40 mm throat: 345 mm bore stroke: 200 mm table surface area: 720 x 560 mm 0: 60 - 765 U/min feed: 0,15 - 0,2 - 0,3 - 0,36 mm/U tool taper: MK 4 total power requirement: 3,0 kW weight of the machine ca.: 0,4 t Drill with: Feed 2 gears Left/right rotation Foot switch Coolant pump Machine light new quick-release chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel St 60: 25 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 : M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2x14x224 mm distance spindle - column min./max.: 132/724 mm feed: von Hand 0: stufenlos Spindle Speed: 225-4300 U/min. engine: 1,0/1,6 kW voltage: 400 V Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spi ...
Capacité d’alésage en acier (diamètre) : 40 / 23 mm Gorge : 320 mm course d’alésage : 180 mm : 4 vitesses : 30 - 765 U/taille miniature : 720 x 550 mm Poids : 480 kg Dimensions : 750 x 900 x 1900 mm Équipement : - Tête multi-broches, perceuse 23 mm - alimentation automatique - dispositif de refroidissement - vitesse à variation infinie - arrêt de profondeur de forage réglable Les données de cette publicité ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.
Taper MK : 4 numéro de série : 520 Poids de la machine environ : 440 kg Les données de cette publicité ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.
nombre de broches : 3 cylindrées d’alésage en acier (diamètre) : course de 40 mm : 180 mm, poids de la machine environ : 2,3 t Les données de cette publicité ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.
bore capacity in steel (diameter): 40 mm throat: 345 mm bore stroke: 180 mm spindle turning speed range: 25-640 U/min column diameter: 180 mm table-size: Ø ca. 560 mm surface area: Ø 445 mm feeds: 0,1, 0,2, 0,3 mm/U spindle taper MT: 4 weight of the machine ca.: 1 t dimensions: ca. 650 x 1000 x 2100 mm with thread cutting device foot switch With coolant device in the base steplessly variable speeds, 2 gear stages, and 2 motor speeds The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 40 mm : M 24 : M 30 spindle turning speed - stepless: 160-2250 U/min : MK 3 spindle stroke: 120 mm throat: 293 mm column diameter: 115 mm : 515x360 mm distance spindle /table: min./max. 117/701 mm : 2 x 14 x 224 mm feed: 0,1 + 0,2 mm/U Machine height: 1840 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 34 mm : 40 mm : 40 mm : MK 4 : 100-1.800 U/min. throat: 300 mm : 615x430 mm : 2 x 14 x 224 mm : 138/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,2-0,3-0,4 mm/U Machine height: 1865 mm total power requirement: 1,4/2,2 kW Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Main switch lockable - Motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Speed adjustment stepless - Speed display digital - Protection class IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 20.1 Tapping device with foot switch, for thread cutting with Stop, max. 6 threads/min., (Tapping power dependent on spindle speed) Pos. 25. Coolant device B, consisting of: separate container (33 l), pump with Motor protection switch, complete fitting The data for ...
N° de série : 1296 : ja changer : ja fachdocumentation : ja control : Heidenhain 426 poids de la machine env. : 6 tLes données de cette annonce ont été créées avec ModulMWS - la solution logicielle de LogoTech oHG.
Foret à colonne ALZMETALL Type AB 4 SVMasch. Réf. 14805 Année de construction env. 1980Capacité de perçage 40 mmPorte-broche MK 4 - Piquants courtsSaillie de gorge 340 mmCourse de la plume 180 mmDimensions de la table 710 x 560 mmDiamètre de la colonne 160 mmVitesse de la broche 30 - 765 tr/min réglable en continuPuissance du moteur 2,3 et 3,4 kW commutables en pôlesRaccordement au réseau 380 volts, 50 Hz- Vitesse de la broche sur 2 vitesses du moteur et engrenage réglable en continu- Engrenages à 2 étages pour un couple élevé à basse vitesse- Marche/arrêt de la broche via
avec NC table ronde WALTER 1000 mm, voir photos
voir la feuille latérale ci-dessous, avec la tête de forage à deux broches Franz X. LINDNER SBS-2/2, distance de fuseau 300 mm, (traduction 1:1)
