型号
(生产厂家: ALZMETALL)
阿尔兹金属公司 刀柄 MK4 具有 3 种进给速度的自动进给 2档和无级变速控制 右左筒、螺纹切割装置 脚部冷却装置 带孔的圆桌 不带转速计 机器罩根据照片由塑料制成 转速： 80-710 转/分 工作台直径： 450 mm 主轴到脚的最大距离： 1200 mm 投影到主轴中心： 170 mm 机器高度约 200 厘米 特
二手机器，状况良好。可立即交货。 - 最大刀具长度： 300/225 [350/225] - 刀位数量：33 - 控制器：HEIDENHAIN ITNC 530 - 工作区域 （X x Y x Z）：650 x 650 x 550 毫米 - C 轴： 360 ？ - 最大刀具重量： 10 kg - 营业时间：51.651 - 轴数：5 - 功率：最大安装功率：16 kW - 重量： 13.000 - 尺寸（长 x 宽 x 高）：2.345 x 4.250 x 2.600 毫
立柱钻床阿尔兹金属AB3 ESB 主轴： CM3 旋转：1 个范围 220 -800 RPM + 1 个范围 800-2900 RPM 桌面尺寸： 长 615 毫米 x 宽 470 毫米 主轴行程： 160 mm 喉深： 280 mm 通过皮带传动进行速度调节 360°旋转工作台 自动下降 3 种速度：0，006 - 0，12 - 0，18 毫米/分钟。 润滑泵 电压： 380 V 宽： 800毫米 深度： 1300 mm 总高度： 1900 mm 重量： 约 800 公斤
distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg
bore stroke:170 mm total power requirement:3,5 kW dimensions of the machine ca.:0,75 x 1,10 m bore spindle turning speed range:30-3000 U/min bore range:diameter:4-60 mm
total power requirement:2.2 kW bore spindle turning speed range:70-4000 in 4 stufen U/min
: 18 mm : M 12 : M 14 : MK 2 : 225-4.300 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel total power requirement: 0,37/0,55 kW Machine height: 840 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 bore stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle - machine table min./max.: 132/724 mm feed: Hand spindle turning speed range: 225-4300 UpM height of the machine: 1790 mm total power requirement: 1,0/1,6 kW Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
table length: 605 mm table width: 250 mm weight: ca. 40.0 kg Current list price: approx. 3.000 euros Special price available upon request Features - Sturdy / solid cross table - From an ALZMETALL column drill press - Machined clamping surface: 605 x 250 mm - Maximum travel: 600 mm - Adjustment range: 0.05 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 36.0 mm bore capacity in cast iron: 45.0 mm throat: 300 mm bore stroke: 160 mm : 4 speeds: 65 - 2000 U/min column diameter: 145 mm table-size: 615 x 460 mm feed: 0.1 / 0.2 / 0.3 mm/U total power requirement: 1.75 / 2.5 kW weight: 440 kg dimensions: 1200 x 800 x 2300 mm Current list price: approx. 18.000 euros Special price available upon request Features: - Robust column drill press (V-belt drive) - Electromagnetic feed clutch = spindle feed with overload protection and electric cross-handle control - mushroom-head pushbutton (latching) for EMERGENCY STOP located on the front panel - continuously variable speed control - clockwise rotation of the drill spindle - Pole-reversible drive motor - Infinitely adjustable drilling depth stop - Work table with 2 T-slot - height-adjustable - Separate coolant system, with reservoir - Operating instructions in ...
bore capacity in steel (diameter): 35 mm throat: 300 mm bore stroke: 180 mm turning speeds: 55 - 1450 U/min taper MK: 4 column diameter: 145 mm total power requirement: 2,2 kW weight: 500 kg dimensions: 800 x 1000 x 2000 mm Features: - Heavy-duty pillar drill - Infinitely variable speed control (V-belt) - Automatic spindle feed with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots height-adjustable via hand crank - Coolant system - Machine vise - Drill chuck - Emergency stop The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 16 mm : M 12 : MK 2 : 100-2.000 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel Machine height: 825 mm total power requirement: 0,7 kW weight: 93 kg Standard equipment: 5 TFT LCD display with touch function: Manual input of spindle speed setpoint, speed display actual value, integrated drilling depth display with touch function. setpoint, actual speed display, integrated drilling depth display with touch zero point transfer, virtual drilling depth scale in the display, machine status status indicators and warnings on the display, Service information, Selectable operator language operator language: DE/EN/FR/ES/IT/NL/RU. - AC motor 230 Volt, 50 Hz - Connection plug ready fitted, cable length 3 m - Infinitely variable speed adjustment via potentiometer - Thre ...
: 40 mm threading in St 60: M24 threading in GG 20: M30 Short spindle: MK 3 Center of spindle to wall or column: 293 mm spindle turning speed - stepless: 160 - 2250 U/min Column diameter: 115 mm spindle stroke: 120 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 117/701 mm feed: 0,10 + 0,20 mm/U Motor output: 1,45 / 1,9 kW height of the machine: ca. 1840 mm weight of the machine ca.: 285 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel St 60: 30 mm bore capacity in cast iron GG 20: 30 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514 x 360 mm T-Slots Amount - Width - Distance: 2 x 14 x 224 mm Distance spindle-table min.: 132 / 724 mm feed: von Hand spindle turning speed - stepless: 100 - 1.800 U/min total power requirement: 1,0/1,6 kW weight of the machine ca.: 260 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
二手
: throat: mm bore capacity in steel (diameter): 35 mm tool taper: MK4 0 bore spindle turning speed range: 1400 U/min feed range: 0.04-0.40 mm/min total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 30.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 225 - 4300 U/min column diameter: 115 mm distance spindle /table: 132 / 724 mm engine output: 1.0 / 1.6 kW weight: 260 kg Machine height: 1790 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - Spindle protection with electrical fuse - Three separate buttons for clockwise rotation - counterclockwise rotation - stop - Mushroom pushbutton (latching) for EMERGENCY STOP - ...
bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm feed: 0.10 + 0.20 mm/U T-slots: 2 x 14 x 224 mm distance spindle /table: 117 / 701 mm engine output: 1.45 / 1.90 kW weight: 285 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Infinitely variable speed setting by means of an adjusting lever - automatic spindle feed with feed overload protection - Spindle protection with electrical fuse - Three separate buttons for cloc ...
bore capacity in steel (diameter): 36.0 mm bore capacity in cast iron: 45.0 mm throat: 300 mm bore stroke: 160 mm : 4 speeds: 120-900 / 240 - 1780 U/min column diameter: 145 mm table-size: 615 x 460 mm feed: 0.1 / 0.2 / 0.3 / 0.4 mm/U total power requirement: 1.75 / 2.5 kW weight: 440 kg dimensions: 1200 x 800 x 2300 mm well-maintained condition () current new price approx. 18.000 Euro special price on request Equipment: - robust pillar drill (V-belt) - electromagnetic feed clutch = spindle feed with overload protection and electrical handle cross circuit - mushroom pushbutton (latching) for EMERGENCY STOP, in the front panel - electric stepless speed adjustment - Digital speed display - clockwise rotation of the drill spindle - pole-changing drive motor - Infinitely adjustable drilling depth stop - Work table with 2x T-slots - height-adjustable - Operating instructions in German T ...
: 14 mm : M 10 : MK 2 : 230-4.000 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel Machine height: 825 mm total power requirement: 0,7 kW weight: 93 kg Standard equipment: 5 TFT LCD display with touch function: Manual input of spindle speed setpoint setpoint, actual speed display, integrated drilling depth display with touch zero point transfer, virtual drilling depth scale in the display, machine status status indicators and warnings on the display, Service information, Selectable operator language operator language: DE/EN/FR/ES/IT/NL/RU. - AC motor 230 Volt, 50 Hz - Connection plug ready fitted, cable length 3 m - Infinitely variable speed adjustment via potentiometer - Three separate buttons for clockwise rotation - anticlockwise rotation - stop (spindle ...
bore capacity in steel (diameter): 40.0 mm bore capacity in cast iron: 45.0 mm throat: 300 mm bore stroke: 160 mm morse taper: 4 MK table:: 615 x 430 mm turning speeds: 100 - 1800 U/min column diameter: 145 mm thread: M 24 ST60 thread: M 30 GG20 feed: 0.1-0.2-0.3-0.4 mm/U distance spindle /table: 138 / 688 mm engine output: 1.4 / 2.2 kW weight: 470 kg Machine height: 1865 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread dept ...
: 40 mm threading in St 60: M24 threading in GG 20: M30 : MK 3 spindle stroke: 120 mm : 80-1.125 U/min. throat: 293 mm column diameter: 115 mm : 514 x 360 mm : 2 x 14 x 224 mm distance spindle /table: min. 117 / max. 701 mm feed: 0,1 + 0,2 mm/U height of the machine: ca. 1840 mm weight of the machine ca.: 270 kg Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6thread/min (thread cutting capacity depending on spindle speed), thread depth adjustable via depth stop and on the TFT LCD display (4 tools) - Infinitely variabl ...
bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 140 mm morse taper: 3 Kurzspindel MK table:: 420 x 350 mm turning speeds: 160 - 2250 U/min column diameter: 115 mm throat: 293 mm distance spindle /table: min 117 / max 701 mm T-slots: 2 x 14 x 224 total power requirement: 1.45 / 1.90 kW weight: 370 kg dimensions of the machine ca.: 1200 x 800 x 1840 mm Current list price ~ 12.500 euros Special price available upon request Features: - Sturdy column drill press (V-belt) - stepless speed adjustment - pole-changing drive motor - height-adjustable worktable with 2 T-slots - R/L rotation of the drill spindle (reversing switch) - Main switch with motor protection switch - Mushroom-head pushbutton (latching) for EMERGENCY STOP - Operating instructions (PDF) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 50 mm bore capacity in cast iron: 56 mm : 50 mm : M 30 : M36 : MK 4 throat: 300 mm : 615x430 mm : 70-4000 U/min. : 2x14x224 mm Distance spindle/table max.: 147/688 mm column diameter: 145 mm spindle stroke: 160 mm feeds: 0,1-0,4 mm/U height of the machine: 1885 mm drive motor: 1,8/2,9 kW weight of the machine ca.: 530 kg Standard equipment: - Electromagnetic feed clutch with overload protection and electrical Cross Handle Switches - Control and light transformer - Main switch lockable - Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel - Clockwise rotation by contactor control - Speed adjustment stepless - Speed display digital - Speed setting electrically - Protection IP 54 - Motor insulation class F - Spindle protection with electrical protection Pos. 12 LED machine lamp with radially adjustable light beam, supply voltage 24 Volt, protection class IP 65 Pos. 20.1 T ...
bore capacity in steel (diameter): 55.0 mm throat: 300 mm bore stroke: 140 mm morse taper: 4 MK table:: 615 x 430 mm turning speeds: 70 - 1200 U/min column diameter: 145 mm thread: M 30 ST60 thread: M 36 GG20 feed: 0.10 + 0.30 mm/U distance spindle /table: 150 / 735 mm engine output: 1.8 / 2.9 kW weight: 380 kg Machine height: 1850 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - ...
bore capacity in steel (diameter): 40 mm threading: bis M 30 throat: 330 mm bore stroke: 180 mm : 4 speeds: 60 - 765 U/min table-size: 720 x 360 mm total power requirement: 2,6 / 3,2 kW weight: 350 kg dimensions: 720 x 1100 x 2050 mm Equipment: - automatic feed - infinitely variable speed - thread cutting device - adjustable drilling depth stop - coolant device - spindle protection - drill chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 40.0 mm throat: 293 mm bore stroke: 120 mm morse taper: 3 MK table:: 515 x 360 mm turning speeds: 80 - 1125 U/min column diameter: 115 mm thread: M 24 ST60 thread: M 30 GG20 feed: 0.10 + 0.20 mm/U distance spindle /table: 117 / 701 mm engine output: 1.0 / 1.6 kW weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU. Furnishing: - Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - ...
bore capacity in steel (diameter): 50.0 mm throat: 300 mm bore stroke: 160 mm threading: M 30 turning speeds: 100 - 1600 U/min table:: 615 x 430 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 145 mm feed: 0.1-0.2-0.3-0.4 mm/U distance spindle /table: 147 / 688 mm engine output: 1.8 / 2.9 kW weight: 450 kg Machine height: 1865 mm Furnishing : - automatic feed with electromagn. Feed clutch - 4 feed rates 0.1-0.2-0.3-0.4 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation - digital speed display - machined base plate - Motor 1.8 / 2.9 KW - 100 - 1600 rpm. Special accessories included: - LED machine light pos. 12. - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device A pos. 24. (Coolant base plate, complete) - digital drilling depth display pos. 37.1 (5-digit LED dis ...
: 18 mm : M 12 : M 14 : MK 2 : 225-4.300 U/min. spindle stroke: 80 mm throat: 190 mm column diameter: 65 mm : 300x240 mm : 2 x 12 x 80 mm : 75/357 mm : 300x240 mm : 2 x 12 x 80 mm : 437/437 mm feed: von Hand : Handkurbel total power requirement: 0,37/0,55 kW Machine height: 840 mm weight: 120 kg Standard equipment: - Main switch with motor protection switch lockable - Reversing switch for clockwise and anti-clockwise rotation - Speed adjustment stepless - Protection IP 54 - Mushroom pushbutton (latching) for EMERGENCY STOP - Spindle protection with electrical protection Option 12 - LED machine light, with radially adjustable light beam, power rating 230 V, protection class IP 65 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 55.0 mm threading: M 30 / M 42 throat: 300 mm bore stroke: 140 mm turning speeds: 70 - 1200 U/min table:: 615 x 430 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 145 mm feed: 0.10 + 0.30 mm/U distance spindle /table: 150 / 735 mm weight: 380 kg Machine height: 1850 mm Furnishing : - automatic feed - Feed device 0.1 + 0.3 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 (Thread cutting with stop) - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bore capacity in steel (diameter): 60.0 mm threading: M 42 throat: 350 mm bore stroke: 200 mm turning speeds: 60 - 1530 U/min table:: 720 x 510 mm bore spindles - Morse Taper: 4 Kurzspindel MK column diameter: 200 mm feed: 0.15-0.2-0.3-0.36 mm/U distance spindle /table: 159 / 884 mm engine output: 3.6 / 4.3 kW weight: 605 kg Machine height: 1950 mm Furnishing : - automatic feed with electromagn. Feed clutch - 4 feed levels 0.15 / 02, - 0.3 - 0.36 mm / rev - stepless speed adjustment - digital speed display - Feed overload protection - Spindle protection with electr. validation - digital speed display - machined base plate including special equipment: - Coolant device mounted in the foot pos. 24. - Thread cutting device pos. 20.0 - LED machine light pos. 12. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
