używany
Wysięg brzeszczotu 95 mm Rozmiar cięcia 4300x2200 mm Szerokość stołu podnośnego 2200 mm Opcje: z podnośnikiem i koncepcją mocy
używany
używany
Description: Technical data Saw blade projection for saw blade diameter 450 mm to 125 mm Collet opening 130 mm Main saw motors 18 kW each Scoring saw motors 2.2 kW each W.02 number : 9105 QUICK CLAMPING DEVICE 'POWER-LOC' FOR HS Patented quick clamping system with high axial clamping force. Simple operation, working without without compressed air. W.04 Number : 9115 QUICK CLAMPING DEVICE 'POWER-LOC' FOR VS Patented quick clamping system with high axial clamping force. Simple operation, working without compressed air. Translated with www.DeepL.com/Translator (free version) cutting height: max 125 mm, main saw blade: 450 mm, main motor: 18 kW, scoring saw: 2,2 kW, Approx. Onsite Dimension. (l x w x h): 1,400 x 800 x 700 mm, weight approx.: 150 kg
używany
saw blade protection: bei sägeblattdurchmesser 450 mm bis zu 125 mm, Approx. Onsite Dimension. (l x w x h): 1,400 x 800 x 700 mm, weight approx.: 150 kg
używany
Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 800 mm, weight approx.: 70 kg
używany
Description: max. load capacity 1000 kg Stroke height max. 820 mm Battery voltage 12 V With charger  , Attention: automatic stacking function must be checked Approx. Onsite Dimension. (l x w x h): 1,800 x 900 x 1,600 mm, weight approx.: 180 kg
używany
Description: Very well maintained and powerful panel saw with:  , label printer integrated in pressure beam motorical stroke of scoring saw machine table completely equipped with air cushion dynamic package saw saw carriage and pressure beam option for thin panels with combi-profile rails , option for grooving panel thickness min/ max. 0,8/60 mm 4 pneumatical trimming fences at ,75 / 475 / 1075 / 2625 mm lifting element for full packages postfroming aggregate label printer Pica II data transfer to storage systems with CE certificate. For further technical details please see pdf -files Read off operating hours: 2,698 h, main motor: 11 kW, serial number: 0-240-82-5052, cutting length: 4,300 mm, saw blade protection: 80 mm, collets: 6 pieces, main saw blade: 350x4.4x60 mm, scoring saw blade: 180x4.4-5.4x45 mm, saw carriage speed forward: 1-130 m/min, saw carriage s ...
używany
main motor: 13.5 kW, serial number: 0-240-06-3129, cutting length: 4,200 mm, cutting depth: 4,200 mm, cutting height: 75 mm, collets: 7 pieces, main saw blade: 380 mm, scoring saw blade: 200 mm, air table: 3, scoring saw: 2,20 kW, control: CADMATIC, total power approx: 17,50 kW, Approx. Onsite Dimension. (l x w x h): 7,000 x 8,500 x 2,000 mm, weight approx.: 6,000 kg
używany
Description: • Horizontal panel saw with lifter table • Serial number 0-240-02-1525 • Total installed power approx. 24 KW • Cutting width 4300 mm • Saw blade projection 125 mm • Cutting height approx. 110 mm • 7 Grippers • Main saw blade: max. diameter 450 mm and motor 13.50 KW • Scoring saw blade: motor 2.20 KW • Saw carriage feed speed: 0 - 120 m/min • Saw carriage return speed: 120 m/min • Pushers maximum speed: 80 m/min • 4 front air tables with dimensions 2160 x 650 mm • Max. panel dimensions on platform approx. 4300 x 2200 mm • Max. height of panel stack on platform approx. 680 mm • Max. weight supported by the lifting table 7000 kg • CADMATIC control Approx. Onsite Dimension. (l x w x h): 12,600 x 7,000 x 2,100 mm, weight approx.: 12,000 kg
używany
Description: Dimensions and weight: 7.6 x 1.4 x 2.3 m 5800 kg 9.2 x 1.0 x 1.4 m 4000 kg 2.8 x 0.8 x 1.6 m 500 kg 2.1 x 0.9 x 2.4 m 300 kg . = 12 loading meters, truck can be fully covered and with continuous loading space !  , 2. truck: Dimensions and weight: 6.6 x 2.85 x 2.2 m 3500 kg = 7 loading meters, over width 2.85 m, truck can be fully unloaded and full length Load space ! serial number: 0-240-10-1280, cutting length: 4,300 mm, cutting depth: 2,200 mm, saw blade protection: 125 mm, program fence speed reverse: 80 m/min, software: CADmatic 4.0, Approx. Onsite Dimension. (l x w x h): 20,500 x 2,850 x 2,300 mm, weight approx.: 14.100 kg
używany
Description: serial number: 0-240-05-1126 Technical details: total installed power: 24.50 kW cutting width: 4300 mm saw blade projection: 125 mm (with saw blade diameter 450mm) cutting height approx. 110 mm maximumum grippers opening: 130 mm main saw blade: max. diameter 450 mm and motor 13.5 kW scoring saw blade: motor 2.2 kW variable feed speed of the saw carriage: 5 - 100 m/min return speed of the saw carriage: 130 m/min maximumum pusher speed: 80 m/min front air tables: 4 pieces max. dimensions of the panels on the platform approx. 4300 x 2200 mm max. height of the panel stack on the platform approx. 680 mm max. load capacity of the lift table 7000 kg CADMATIC V3.0 control system CE marks main motor: 13.5 kW, serial number: 0-240-05-1126, cutting depth: 4,300 mm, cutting height: 110 mm, saw blade protection: 125 mm, main saw blade: 450 mm, control: CADMATIC V3.0, ...
używany
Description: HOLZMA HPP81/42-CAD Optimat Panel Saw M-No.: 0-240-06-3081 , ,  , , ,  , , ,  , , ,  , , ,  , Year of manufacture: 1999 , ,  , , ,  , , ,  , , ,  , , ,  , Control with Cadmatic Holzma CAD Matic 3 - Ethernet connection , ,  , , ,  , , ,  , , ,  , , ,  , Windows embedded , ,  , ,19' TFT screen , ,  , , ,  , , ,  , , ,  , , ,  , Total connected load: 20 KW, 38A , ,  , , ,  , , ,  , , ,  , , ,  , Cutting length 4.250 mm , ,  , , ,  , , ,  , , ,  , , ,  , Cutting width/depth: 4.300 mm , ,  , ...
używany
Description: Controller: CAD Matic V6.0 with 17' color display CAD Link interface for interfacing with external optimization programs Saw length: 3100 mm, with automatic pressure gauge for sheet alignment Main saw: ø350x4.4x75 mm, 7.5 kW, Powerlock system Saw height: 55 mm Sawing speed:5 to 60 m/min Front-zip saw: ø200x4.4x75 mm, 1.1 kW, Powerlock system Program slide: 5-60 m/min (CE limited to 25 m/min) Frames: 5 pieces Air cushion tables: 4 tables Ball jars floating on air- dimension: 650 x 2160 mm CE standard main motor: 7.5 kW, cutting length: 3,100 mm, cutting height: 55 mm, saw carriage speed forward: 5 - 60 m/min, air table: 4x, scoring saw: 1.1 kW, software: CAD Matic V6.0, Approx. Onsite Dimension. (l x w x h): 7,700 x 1,200 x 1,600 mm, weight approx.: 3,500 kg
używany
Professional saw for cutting large materials -cutting width 4200mm -cutting height 95 mm -machine dimensions: width-6450 height-2100 length- 12300 -rear automatic loading -automatic material rotation -associated cuts -air tables 4 pcs -pneumatic disc change 380mm discs pre-cut 180mm -wheels 4500/min -electronic adjustment of cutting and pre-cutting height -optimization program -power of main motor 17,2 KW -total power input 24 kW -400V -year of manufacture 2012 The machine is continuously serviced and the following parts have been replaced: - servomotor of the main disc - servomotor of the pre-cutting - ball screws of the saw unit guide - 4 pcs of frequency converters - Replacement of air handling tables - Replacement of belts, valves, stops, end sensors, cables, cable lines, oil, etc.
używany
Automatic panel sizing beam saw with rear lifting table Max panelsizes when rear loading: 5600mm x 2240mm Max. cutting length x width: 5600 x 5600 mm. Max. stack weight for the lift: 10 ton max stack height 580 mm Saw blade outstand: 125mm Main cutting motor 13,5 kW Sawblade diameter 450 mm. Scoring saw motor 2,2 kW Feed speed of the saw carriage, forward 5 to 150 m/min, return 150 m/min Speed of the pusher 80 m/min Number of grippers: 9, centers 75/275/475/1075/1775/2475/3275/4075/4875 mm. 5 air flotation tables in the front 2810 x 650 mm Controlls: CAD-matic 4.0
używany
Used Holzma HP P11 / 43 / L panel saw 1998 Holzma HP P11 / 43 / L
używany
Producent: Holzma, Typ: Digimatic,
używany
Producent: Holzma, Rodzaj: HPP 81/42, Rok: 1994, Program: Holzma, Długość cięcia mm: 4200, Wysokość robocza mm: 85, Vorschub Sägewagen : ca.100, Suwak programowania posuwu Min-max m/min: ca.80, Kątownik dociskowy: tak, Średnica tarczy mm: 450, Liczba narzędzi mocujących: 6, Silnik główny kW: ca.12,5, Prędkość posuwu stale regulowana: tak, Podawanie z przodu: tak, Prędkość podawania regulowana w sposób ciągły: tak, Rok :1994
używany
Producent: Holzma , Typ: HPP 82/43, Rok: 2001, Program: CADmatic, Długość obrabianego przedmiotu min-max mm: 4300, Szerokość przedmiotu roboczego min-max mm: 4250, Wysokość robocza mm: 95, Vorschub Sägewagen : 5 - 125, Suwak programowania posuwu Min/min: 125, Możliwość pracy w sieci: tak, Średnica brzeszczotu mm: 380, Silnik główny kW: 13,5, Prędkość posuwu max m/min: 5 - 125, Agregat punktujący : 2,2 kW, Drukarka etykiet: tak, Długość przedmiotu obrabianego min-max mm: 4300, Szerokość obrabianego przedmiotu min-max mm: 4250, Prędkość posuwu max m/min: 5 - 125, Rok:2001
używany
Producent: Holzma , Typ: HPL 380 43/22, Rok: 2010, Optymalizacja: tak, Maksymalny format płyty mm: 4300 X 2200, Minimalna maksymalna grubość blachy mm: 6-40, Długość cięcia mm: 4300, Wysokość robocza mm: 95, Vorschub Sägewagen : 150, Sterowanie belką dociskową: tak, Możliwość łączenia w sieć: tak, Kątowy uchwyt ciśnieniowy: tak, Średnica tarczy piły mm: 380, Liczba narzędzi mocujących: 7, Podawanie z tyłu: tak, WOLNY TEKST: Spannsystem Sägeblatt Powerlook/Voritzer gesteuert für Postforming Platten, Rok :2010
używany
Producent: Holzma, Rok: 1997, Optymalizacja: nie, Maksymalny format płyty mm: 3800 X 3100, Min-max grubość blachy mm: 6-60, Długość przedmiotu obrabianego min-max mm: 3800, Szerokość przedmiotu obrabianego min-max mm: 3100, Występ tarczy: 75, Vorschub Sägewagen : 80, Suwak programowania posuwu Min-max m/min: 60, Średnica brzeszczotu mm: 380, Liczba narzędzi mocujących: 6, Silnik główny kW: 7,5, Długość obrabianego przedmiotu min-max mm: 3800, Szerokość obrabianego przedmiotu min-max mm: 3100, Rok :1997
