ARKU máquina utilizada para venda

Referência: 850162 no. de item: 40219 F. Nr: 193 Conexão: 380 V /50 Hz

Coil weight: 2 x 500 kg Material width: 300 mm Coil exterior diameter: 1200 mm Expansion range: 350 - 610 mm Weight of machine approx.: 2,2 ton

material width:350 mm coil weight:2,0 t coil internal diameter:470 - 530 mm coil external diameter:1500 mm power requirement:1,0 kW weight:1,5 t dimensions (WxDxH):1,3 x 1,6 x 1,9 m

material width:500 mm coil weight:2 x 2,0 t material thickness:1,0 - 6,0 mm coil internal diameter:350 - 420 mm coil external diameter:1600 mm no. of straightening rolls:9 straightening roll diameter:50 mm number of draw-in rolls:2 speed:0 - 40 m/min material thickness at 500 mm material width:3,5 mm power requirement:17,5 kW Dimensions (WxDxH):2,3 x 4,2 x 2,4 m straightening machine:RM 5050.4/9 double decoiler:AH 2000/2/M snubber roll:pneumatic interchangeable jaws:130 mm expansion of the inner diameter

Processing: both sides, dry, max. workpiece width: 1300mm, material thickness: 0.8-100mm, max. passage width: 1300mm, length: 3100mm, width: 2100mm, height: 2400mm, weight: 5.6t, total operating hours/automatic: 11,002/ 5566h, including 2x 2000mm auxiliary conveyors and extensive documentation, without extraction system or abrasives, on-site inspection is possible.

material width:600 mm material thickness: - 4,0 mm no. of straightening rolls:21 straightening roll diameter:30 mm material cross-cut:1800 mm² speed:6 - 36 m/min Power capacity:4,5 kW Weight:2,0 t Dimensions (WxDxH):1,5 x 2,0 x 1,9 m

CONTROLS   PLC OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 500 mm   sheet thickness max.: 4 mm   coil weight max.: 10.5 to   feedstock transport direction: right to left COIL CHAIR   coil weight max.: 10.5 to   stroke: 750 mm DECOILER   design: single reel   sheet width max.: 500 mm   sheet width (min): 150 mm   coil weight max.: 10.5 to   max. diameter of coil: 2020 mm   mandrel expansion range from: 470 mm   mandrel expansion range up to: 530 mm   feed velocity max.: 20 m/min CROP SHEAR   sheet thickness max.: 4.5 mm   working width max.: 1130 mm LEVELLER UNIT   sheet width max.: 500 mm   sheet width (min): 150 mm   sheet thickness max.: 4 mm   sheet thickness min.: ...

CONTROLS   PLC SIEMENS S5 115 U OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 350 mm   sheet thickness max.: 8 mm   coil weight max.: 4 to   feed velocity max.: 10 m/min   feedstock transport direction: left to right DECOILER   design: single reel   sheet width max.: 350 mm   coil weight max.: 4 to   max. diameter of coil: 1500 mm   mandrel expansion range from: 370 mm   mandrel expansion range up to: 530 mm   feed velocity max.: 10 m/min LEVELLER UNIT   sheet width max.: 350 mm   sheet thickness max.: 8 mm   number of leveller rolls: 21   diameter of leveller rolls: 50 mm   number of infeed-/outfeed rolls: 2   diameter of feed rolls: 120 mm   feed velocity max.: 10 m/min ELECT ...

material width:250 mm material thickness:0,4 - 3,5 mm no. of straightening rolls:9 straightening roll diameter:30 mm speed:3 - 15 m/min material thickness at 250 mm material width:3,0 mm material thickness at 200 mm material width:3,5 mm power capacity:1,8 kW weight:0,9 t Dimensions (WxDxH):1,45 x 1,4 x 1,55 m

material width: 0250 mm material thickness: 3,00 mm no. of straightening rolls: 19 sheet thickness - min.: 0,30 mm diam. of the rolls ca.: 18 mm speed: 2-14 m/min back-up rolls-needle bearings: ja / yes straightening rolls - bronze bearings: ja / yes total power requirement: 1,70 kW weight of the machine ca.: 0,60 t dimensions of the machine ca.: 1,15 x 0,90 x 1,25 m - max. roller distance vertically 8 mm - Lubrication of the straightening rollers via grease nipples - Infeed roller table with lateral belt guide - Exit table with belt scanning (start/stop) - Straightening machine is currently designed as a strip straightening machine but can also be used as a part leveling machine The straightener was inspected by the specialist team. Test can be make with your material - please contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 0250 mm coil outside dia.: 1800 mm weight max. in kg: 2 x 3000 kg : 3,80 mm : 470 - 530 mm : 21 : 30 mm : 4 : 18,0 kW speed: 20 m/min power capacity: 18 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Decoiler AH 3000/2/250/ST with continuously variable drive, hydraulic central spread, Automatic post-spreading system, hydraulic pressure device, hydraulic swivel, Straightening machine RM 3025.4/21 with continuously variable drive, driven straightening rollers, manual Roller mill adjustment, quick-change device for the straightening rollers Belt loop control via ultrasound Material thickness / with material width 3.80 / 250 mm Material thickness / with material width 6.00 / 100 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width - max.: 0600 mm coil weight: 3,00 t coil internal dia.: 465 - 530 mm total power requirement: kW weight of the machine ca.: 2,45 t dimensions of the machine ca.: 2,72 x 1,70 x 2,40 m material width (previously) 400 mm mandrel length 630 (655) mm mandrel – Ø (expanding range) 465 – 530 mm height floor - middle of mandrel 1.450 mm height upper edge decoiler construction - middle of mandrel 1.050 mm working direction (previously) right - left accessories: construction 3-segment-construction decoiler movable on base frame hydraulically press arm hydraulically press roll not driven expanding process mechanically decoiler motor driven (via chain) power 3,0 kW no. – limiting arms 6 dimension – limiting arms (l x h) 410 x 180 mm valve components mounted at decoiler construction control unit (breaker unit) with cable hydraulic unit not available The data for this ad was cre ...

Máquina de alisar folhas torna ARKU tipo RM 3020 / 21,4 Ano de construção infelizmente não visível, placa de identificação não disponível Especificações técnica:Largura da folha: 200 mm Espessuramaterial: 0,5 - 4,0 mmmin. Dimensões da peça de trabalho: 50 mmLesar a regulação da máquina: 0,01 mmMax. Distância vertical do rolo: 10 mmNumbre de rolos de alisamento: 21R diâmetro: 30 mm Velocidade de risco: 3,5 - 20 m/min. Potência de acionamento: 4,0 kW Dimensões extraternais aprox.: 1600 x 1500 x 1200 mm Peso aprox .: 1284 kg Com- conduta de descarga- Infeed tableused, em boas condiçõesPrete a pedido. Entrega: ex armazém ou caminhão de carregamento gratuito de localização. Pagamento: líquido na aquisição ou por marcação. Os dados técnicos não são vinculativos. Erros exceto. Ficaríamos satisfeitos se você gosta da nossa oferta e está sempre disponível pa ...

Capacidade: 12 tTable comprimento: 2000 mmSa largura: 0 mmStroke: 2000 mmCNC Marca: _Unknown / Outro Modelo CNC: Leonard en Bauer MAKE   ARKU Alemanha TIPO    VRM 200/7/2000 + AH 1200/2000/MSG-4Q ANO   1990 ESPECIFICAÇÕES Controll   Leonard + Bauer Garganta     2000 mm Espessura máxima da chapa Aço   6,3 mm DIMENSÕES Comprimento   6000 mm Largura     4500 mm Altura    3000 mm ARKU De-Coil & Straightener 2000 x 6,3 mm   Make           : ARKU Alemanha Typ              : VRM 200 / 7 / 2000 Série Nº    : WO 1576 Idade          &nbs p;  : 1989 no Trabalho 1990& ...
