STUDER maquina usada para la venta

Máquina no. 2037.04 Ver fotos !

Cubiertas telescópicas para los ejes X y Z para muchas rectificadoras CNC Studer S21, S31, S33, S40, etc. Y para muchos otros fabricantes de máquinas bajo pedido.

Studer S31 Peso: 1000 mm / Esf.: 175 mm Fanuc 16i- TB Control Puesta en marcha 2004 Carreras: eje X 285 mm / eje Z 1150 mm Rectificadora cilíndrica universal 2x rectificado externo y 1x interno

Key data: 180 mm, 800 mm

Control Fanuc 31 i - A Diámetro máx. de mecanizado 180 mm Longitud máx. de mecanizado 800 mm Husillo principal con mandril motorizado 30 kN Contrahusillo con mandril neumático Dos cabezales de molienda Torreta de herramientas con 12 estaciones de herramientas accionadas

DIÁMETRO MÁXIMO 450 . LONGITUD MÁXIMA 1600

Key data: 1000 mm, 285 mm, 1000 mm

Studer S33 CNC Universal Cylindrical Grinder Nuevo 2018 Control CNC: sí Tipo de control CNC: Fanuc Oi-TD Capacidades y características: 350mm x 1000mm Dimensiones de la muela OD: 500 x 63 x 203,2 mm Recorrido del eje X: 285 mm Recorrido del eje Z: 1000 mm Resolución: 0,0001 mm Peso máximo de la pieza de trabajo entre centros: 80 kg Mesa giratoria: -15 - +225 Indexación: Acoplamiento automático de 1 Hirth del eje B Tamaño de la muela: 500 x 63 x 203,2 mm Velocidad periférica máx.: 50 m/seg Capacidad de potencia del motor: 14.47HP / 11kW Cabezal del husillo de la pieza de trabajo: Vea las especificaciones a continuación: Vea las especificaciones a continuación Número de revoluciones: 1 - 1.500 rpm Potencia del motor del cabezal de trabajo: 1,6 / 3 kW Paso del husillo: 30 mm Conicidad cónica: MK 5 Altura central: 175 mm Carga de trabajo ...

Rectificado Studer S21 Lean CNC :::CARACTERÍSTICAS TÉCNICAS::: Modelo CNC: Fanuc Versión CNC: 21i-T Carrera del eje X: 254 mm Carrera del eje Z: 483 mm Banda de muela: 40 mm Diámetro de la muela: 400 mm Otros datos técnicos: Cabezal de molienda giratorio (B) -15°/+195° 1° 2 muelas exteriores 1 muela interior Muela de afilar externa 400 mm x 40 mm x 127 mm 4 kW Cabezal de pieza CM 4 :::D IMENSIONES Y PESO::: Longitud: 2300mm Ancho: 2000mm Altura: 2100mm Peso: 4300Kg

Rectificadora cilíndrica externa CNC, marca Studer, tipo S40-4, Bi 1987, Los documentos están disponibles. El precio es neto

Diámetro de molienda 250 mm Longitud de molienda 650 mm Ancho central 700 mm Altura de la punta 125 mm Diámetro de la muela 400/450 mm Ancho de la muela 50/80 mm Velocidad del husillo de la pieza de trabajo de hasta 675 1/min Cabezal de pieza de trabajo giratorio +/- 45 ° Cómoda Dispositivo de medición Sistema de refrigerante Muela

Longitud de molienda

- Husillo de rectificado interno - Pantalla digital Heidenhain Altura pico 100 mm Ancho de la punta 450 mm Ruedas de molienda de 300 mm Tamaño de la mesa 950x200 mm Trayectoria longitudinal 450 mm Cono de husillo MK 5 Velocidad del husillo continuamente 40 - 650 rpm Girar la mesa +/- 10 grados Peso aprox. 1700 kg Dimensiones 1570x1100x1400 mm

Number of axes: 3, center height: 175mm, distance between centers: 1000mm, grinding length: 500mm, strokes X/Z: 267mm/650mm. Continuous orientation: +/-8.5°, Outer grinding wheel dimensions X/Y/Z: 500mm/80mm/203mm. Cutting speed: 44m/s, taper type: CM5, C-axis: +/-0.5°, speed: 1000rpm. Tailstock: taper type: CM3, quill stroke: 35mm, quill diameter: 50mm, max. piece weight between centers: 130kg. Dimensions X/Y/Z: 2700mm/2350mm/2100mm, weight: 4000kg, operating hours: approx. 28000h. Tailstock (hydraulic clamping cylinder and clamping spring) recently overhauled. Documentation available.

CONTROLS   CNC controls GE FANUC SERIES 16 GC WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 130 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 1000 mm WORKPIECE SPINDLESTOCK   spindle revolutions (min): 30 /min   spindle revolutions (max): 1000 /min   continuous speed variation: yes   c-axis: yes TAILSTOCK   distance betw. centers (max): 1000 mm SPINDLESTOCK GRINDING SPINDLE   Z-axis travel: 1000 mm   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 210 °   drive power: 7.5 kW GRINDING TOOL   type of grinding tool: wheel   diameter (max): 500 mm SPINDLESTOCK INTERNAL GRINDING   tilting ran ...

CONTROLS   CNC controls FANUC 310I-A WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 180 mm   workpiece weight between centers (max): 25 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 400 mm   grinding length: 1000 mm TAILSTOCK   distance betw. centers (max): 1000 mm   taper: MK 4   Z-axis travel: 1600 mm SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 220 mm   Z-axis travel: 1600 mm   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 25 °   drive power: 6.8 kW GRINDING TOOL   type of grinding tool: wheel   diameter (max): 400 mm   borehole: diameter: 127 mm ELECTRICAL SPECIFICATIONS   mains power supply: 45 kVA   mains voltage: 400 V   mains frequ ...

CONTROLS   CNC controls FANUC 0I-TFP WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 80 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 500 mm WORKPIECE SPINDLESTOCK   spindle revolutions (max): 1500 /min   drive power: 3 kW   spindle bore diameter: 30 mm   tool fixture: MK 5   c-axis: yes   - positioning/indexing: 0.5 ° TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 60 mm   taper: MK 4 SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 370 mm   Z-axis travel: 500 mm   tilting range (B-direction) min: 60 °   drive power: 9 kW GRINDING TOOL   diameter (max): 500 mm    ...

CONTROLS   CNC controls FANUC WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 650 mm TAILSTOCK   distance betw. centers (max): 650 mm   sleeve stroke: 35 mm   sleeve diameter: 80 mm   taper: MK 3 SPINDLESTOCK GRINDING SPINDLE   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 8.5 °   - mode of operation: manual GRINDING TOOL   type of grinding tool: wheel   diameter (max): 500 mm   width: 63 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2670 mm   space requirements -front/back-: 2100 mm   total height: 1800 mm ATTACHMENTS (GRINDING)   internal grin ...

CONTROLS   digital read out WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 200 mm   workpiece weight between centers (max): 400 kg   workpiece weight flying (max): 20 kg WORKPIECE SPINDLESTOCK   spindle revolutions (min): 80 /min   spindle revolutions (max): 800 /min   tool fixture: MK 4 TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 20 mm   taper: MK 2 SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (min): 1600 /min   spindle revolutions (max): 2200 /min   drive power: 3 kW GRINDING TOOL   diameter (max): 350 mm   borehole: diameter: 127 mm   width: 30 mm

grinding diameter: 0,2 - 190 mm grinding length:400 mm centre height:100 mm weight of the machine ca.:1,6 t dimensions of the machine ca.:2 x 1,5 x 1,8 m

internal diameter: mm grinding depth: mm centre height:175 mm grinding length:120 mm longitudinal and cross slide:300 grinding wheel diameter:10 mm grinding wheel speeds:90.000 U/min Z-axis:300 mm Incl. automatic feeding B-Axis

grinding diameter:300 mm grinding length:540 mm centre height:175 mm total power requirement:20 kVA centre distance:1000 mm

grinding diameter:50 mm grinding length:100 mm centre height:100 mm centre distance:200 mm

grinding diameter:400 mm grinding length:650 mm centre height:125 mm total power requirement:5/8,25 kW weight of the machine ca.:3,4/3,5 t

Description: Center height 175 mm, center width 1000 mm, maximum longitudinal slide travel 1050 mm, longitudinal slide speed 0.0001 to 10000 mm per minute, maximum table inclination 8.5 degrees, maximum cross slide travel 275 mm, maximum cross slide speed 0,0001 to 10000 mm per minute, quill travel of tailstock 35 mm, maximum workpiece weight between centers 130 kg, speed range of workpiece spindle 30 to 750 rpm, including manual operation and existing documentation, machine number 011.0126.60.021 control: GE FANUC SERIES 16-GC, weight approx.: 6,000 kg, Approx. Onsite Dimension. (l x w x h): 4,400 x 2,300 x 2,600 mm

CNC : Fanuc 21i-TB Internal and External Grinding Machine : Distance between centers : 1000mm Center heights : 175 mm Tailstock :

Machine in good technical condition, after agreement possibility of testing. Grinding diameter Ø 250 mm Grinding length 750 mm Size of grinding wheel 400 x 50 mm. Length 2400 mm Width 1300 mm Height 1500 mm.

Distance between centers : 1000 mm Centers height : 175 mm Grinding wheel holder headstock orientation : 0 - 180 ° Grinding wheel holder headstock indexing precision : 5 ° Grinding wheel dimensions : 500 x 63 x 203 mm Cutting speed : 35 m/sec Headstock power : 7.5 kW Maximum workpiece weight : 130 kg Table orientation : 10 ° headstock rotation speed : 35-520 rpm EQUIPMENT : Sensitron 6 : Internal grinding spindle : 1 Measuring head MOVOMATIC ES124 for the diameter : 1 Tailstock : 1 Diamond grinding device for external wheel : 1 Radius grinding devic : 1 Display 2 axes HEIDENHAIN : 1 Lubricating tank with paper filtration : 1 Set of grinding wheel holders and grinding wheels : 1

Used Studer s 31 Cylindrical external / internal grinding machine Visible under power in Italy Year: 2003

digital readout: make: SONY type: LG10 centre height: 175 mm centre distance: 650 mm grinding wheel size: 400x80x127 mm turning speeds: 1670/2110 U/min cross travel: 300 mm rapid- return speed for machining unit: 60 mm workpiece spindle head:: speeds:: 30-1000 U/min rotation movement: 0-90 Grad spindle taper MT: 5 taper in tailstock MT: 3 tailstock quill adjustment: 35 mm weight of the machine ca.: 3400 kg dimensions of the machine ca.: 2035x1970x1780 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 250 mm grinding length: 1000 mm centre height: 125 mm total power requirement: 16 kW weight of the machine ca.: 3,0 t dimensions of the machine ca.: 2,0 X 1,2 X 1,8 m A Studer RHU 1000 circular grinding machine built in 1979 is for sale. The machine is expected to be released in February 2024 and can be under power be visited. This is the variant with a grinding wheel on the right side External and longitudinal grinding with straight and angled grooves. The machine was carried out in accordance with the manufacturers maintenance specifications maintenance serviced. Manufacturer: Fritz Studer AG Type: RHU 1000 / 125-DR Machine number: 61.41 Year of construction: 1979 Mains voltage: 380V 50Hz System weight: 2600 kg Max. workpiece weight: 80 kg Main dimensions: Tip height: 125 mm Center width: 1025 mm Largest longitudinal slide path: 1020 mm Longitudinal slide: Table spee ...
