JUNKER maquina usada para la venta

Núm. Inv. : 7323 Tipo: BUAJ 30 Productor: Junker Creado: 1999 Parámetros: Dimensiones de la mesa: 1380x160 mm Distancia entre puntas: 630 mm Peso de la máquina: 2800 kg

Venta previa reservada - posibles errores Número de referencia interno: D-1143-3

Flexible high-performance grinding machine JUROBOT handling-cell (FANUC M-10iA): Z-axis/grinding length: 500mm max., orbital diameter: 150mm max., workpiece weight: 15kg max., grinding wheel diameter: 350mm max., operating hours: 23219h, with documentation, an on-site inspection is possible.

Flexible high-performance grinding machine with JUROBOT handling-cell (FANUC M-10iA): Z-axis/grinding length: 500mm max., orbital diameter: 150mm max., workpiece weight: 15kg max., grinding wheel diameter: 350mm max., operating hours: 12238h, with documentation, an on-site inspection is possible.

weight of the machine ca.:24 t dimensions of the machine ca.:3900 x 3500 x 2500 m -the machine has no B axis -two grinding spindles with one grinding wheel each - The transport instructions can be found in the documentation (attachment). including Hoffmann KSM filter system Loading list available Operating data v. 03/27/2023: Operating time: 21727 h / production time: 11960 h Machine documentation: 1 set of circuit diagrams, electrical plans, operating instructions Accessories: 2 replacement measuring heads Marposs S/500; prism supports Other: Hoffmann KSM filter system Machine condition: according to age, due to processing with emulsion

Velocidades de giro: - Frecuencia U/min : - Salida Hz : - kW

Velocidades de giro: - Frecuencia U/min : - Salida Hz : - kW

The machine is in good technical condition, can be tested under power. Parameters: 630 mm, 300 mm Location: Czech Republic

Description: machine number: 3299 control: SIEMENS Sinumerik  , max. grinding length: 800 mm max. clamping length: 800 mm max. center height: 150 mm max. workpieve weight: 80 kg  , max. grinding wheel diameter: 400 mm max. grinding wheel width: 63 ,mm bore of the grinding wheel: 127 mm motor power: 7.5 kW rotational speed of the wheel: 45 m/s adjustment travel: 350 mm  , workpiece headstock: spindle taper: MK5 spindle speed: 0 - 1000 rpm swivel angle: 90°  , tailstock: taper: MK4 quill stroke: 90 mm  , including: ASTOS FS100 Filtration Station, YOM 2005, serial number: 0511 AKTIVIT loading/transportation/conveyor system  , please also have a look at the PDF documents of this machine grinding length: 800 mm, control: SIEMENS Sinumerik, weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x h): 6,000 x 3,000 x 3,5 ...

Description: machine number: 3388 control: SIEMENS Sinumerik  , max. grinding length: 800 mm max. clamping length: 800 mm max. center height: 150 mm max. workpieve weight: 80 kg  , max. grinding wheel diameter: 400 mm max. grinding wheel width: 63 ,mm bore of the grinding wheel: 127 mm motor power: 7.5 kW rotational speed of the wheel: 45 m/s adjustment travel: 350 mm  , workpiece headstock: spindle taper: MK5 spindle speed: 0 - 1000 rpm swivel angle: 90°  , tailstock: taper: MK4 quill stroke: 90 mm  , including: ASTOS FS100 Filtration Station, YOM 2007, serial number: 07650232 AKTIVIT loading/transportation/conveyor system  , please also have a look at the video and the ,PDF documents of this machine grinding length: 800 mm, control: SIEMENS Sinumerik, weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x  ...

Description: serial number: 3075 control: SIEMENS Sinumerik  , grinding diameter: 300 mm grinding length: 600 mm centre height: 150 mm  , max. grinding disc diameter: 400 mm max. grinding disc width: 63 mm grinding disc bore: 127 mm motor power: 5.5 kW grinding disc speed: 45 m/s adjustment travel of the sanding spindle carriage: 300 mm swivelling: +45° / -15°  , travelling distance: X-axis: 160 mm Z-axis: 756 mm  , workpiece headstock: taper: MK5 spindle speed: 23 - 291 rpm swivelling: 90°  , tailstock: taper: MK4 quill stroke: 30 mm  , feed speed: 0 - 7.5 m/min.  , connected load: 60 kVA ,  , please also have a look at the PDF documents of this machine grinding diameter: 300 mm, grinding length: 600 mm, control: SIEMENS Sinumerik 840D, weight approx.: 8,000 kg, Approx. Onsite Dimension. (l x w x h): 4,500  ...

Description: machine number: 3384 control: SIEMENS Sinumerik  , max. grinding length: 800 mm max. clamping length: 800 mm max. center height: 150 mm max. workpieve weight: 80 kg  , max. grinding wheel diameter: 400 mm max. grinding wheel width: 63 ,mm bore of the grinding wheel: 127 mm motor power: 7.5 kW rotational speed of the wheel: 45 m/s adjustment travel: 350 mm  , workpiece headstock: spindle taper: MK5 spindle speed: 0 - 1000 rpm swivel angle: 90°  , tailstock: taper: MK4 quill stroke: 90 mm  , including: ASTOS FS100 Filtration Station, YOM 2007, serial number: 07650232 ASTOS MS 100-P Magnetic Separator, YOM 2012, ,max. flow rate: 100 l/min AKTIVIT loading/transportation/conveyor system  , please also have a look at the PDF documents of this machine grinding diameter: 400 mm, grinding length: 800 mm, contr ...

Description: machine number: 3264 control: SIEMENS Sinumerik  , max. grinding length: 800 mm max. clamping length: 800 mm max. center height: 150 mm max. workpieve weight: 80 kg  , max. grinding wheel diameter: 400 mm max. grinding wheel width: 63 ,mm bore of the grinding wheel: 127 mm motor power: 7.5 kW rotational speed of the wheel: 45 m/s adjustment travel: 350 mm  , workpiece headstock: spindle taper: MK5 spindle speed: 0 - 1000 rpm swivel angle: 90°  , tailstock: taper: MK4 quill stroke: 90 mm  , including: AKTIVIT loading/transportation/conveyor system  , please also have a look at the PDF documents of this machine grinding length: 800 mm, control: SIEMENS Sinumerik, weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x h): 5,500 x 3,500 x 3,500 mm

Description: Max. Grinding diameter : Ø 280 mm Center height : 150 mm Center width : 800 mm Grinding wheel holder for wheel: Ø 400 x 127 Grinding wheel diameter : max Ø 400 mm wheel speed : 45 m/s Control : Fanuc 21 grinding diameter: 280 mm, grinding length: 800 mm, control: FANUC 21, weight approx.: 11,000 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 2,500 x 2,800 mm

JUNKER EJ 50 grinding machine Year 2007 55kva 400V 50Hz

Dot height: 150mm, Distance between points: 1000mm, Grinding wheel dimensions (od x id x width): Ø400xØ127x50mm, Internal grinding head: 4 units, Centre height: 150mm, Max. workpiece weight: 80Kg, X-axis travel (transverse): 350mm, X-axis speed: 10 meters per minute, Z-axis travel (longitudinal): 1000mm, Z-axis speed: 12 meters per minute, Z-axis resolution: 0.00004, B-axis swivel range: 210°, B-axis resolution: 0.0001°, Drive capacity: 10 HP, Grinding wheel diameter: 400mm, Max. width Grinding wheel width: 63mm, Spindle speed range: 0-1000 RPM, Spindle swivel range: 0° - 90°, Tailstock stroke: 30mm, Equipped with: Fanuc 21i-TB CNC Control, Dimensions: 3350x 2130x 2130, Weight: 4535Kg, Accesories: Steady rests, magnetic plate, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.

The diameter of the ground workpiece for internal grinding is 8 - 190 mm. External grinding: - center distance 640 mm - workpiece diameter 295 mm Total machine input 35kVA. The machine is functional, but needs an initial investment in repairs.

Mold heating, fan heaters, heating, gas heating, construction heating, construction dryers, heating, hall heating, gas heating for casting molds, foundry technology -Manufacturer: Junker, gas heating WA 26532 on a mobile transport frame -Burner: Wiedemann B202 H2-3 175 kW -Blower: Spelleken 5.5 kW volume flow 500 m³/h -Individual components/accessories: see photos -Dimensions 1500/1250/H2010 mm -Weight 625 kg
