used
x-travel:1120 mm y-travel:345 mm z-travel:400 mm total power requirement:14,5 kW weight of the machine ca.:3,85 t dimensions of the machine ca.:3.500 x 2.920 x 2.710 mm table-size:1600 x 400 mm spindle taper:SK 50
used
Vertical console milling machine make HECKERT type FSS 315 SMachine -No: 314212/2 Year 1992Table longitudinal path X-axis: 950 mmKonseol vertical path Y-axis: 450 mmTransverse Z-axis: 500 mmCross slide cross travel: 270 mmTable size W x L: 430 x 1600 mmNumber of clamping stages: 4Table load: 1000 kgSpindle mount: ISA 4018 speeds: 28 - 1400 rpm.18 feeds lengthwise: 16 - 800 mm / minxa0xa0xa0 vertical: 5 - 250 mm / minRapid traverse longitudinal and transverse: 3150 mm / minRapid traverse vertical: 1000 mm / minDrive power: 1.5 kWConnected load: 8.0 kWDimensions: 2800 x 2800 x 1995 mmWeight approx: 3000 kgWith- swivel spindle head- tableau control- Control cabinet SIEMENS- Central lubricationused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be plea ...
used
Universal console milling machine make WMW HECKERT type FU 355 x 1250Masch. -No: 47512/1962 built in 1962Table mounting surface: 355 x 1250 mmTable can be swiveled 45 ° on both sidesTable can be swiveled: + - 45 °Table longitudinal path X: 1120 mmCross slide cross travel: 345 mmConsole vertical path: 400 mmTable load max .: 1500 kgSpeed range: 28 - 1400 rpm.Feed area longitudinal and transversal: 16 - 800 mm / minFeed range vertical: 5 - 250 mm / minRapid traverse longitudinal and transverse: 3150 mm / minRapid traverse vertical: 1000 mm / minTool holder: ISO 50Drive power: 14.5 kWWeight: 3850 kgExternal dimensions: 2400 x 2300 x 1800 mmused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available ...
used
Vertical -consol milling machine, used   Vertical -milling machine, used Make/make: WMW HECKERT Type/ model: FQS 400 Year built: 1978 Control type / control: conventional  x-way: 1190 mm  y-way: 530 mm z-way: 540 mm Table size/ table: 1600 x 400 mm Spindle power/ spindle power: 11kW Tool holder/tool taper: ISO 50 Speeds/ speeds: 28 - 1400 rpm Feeds: 16- 800 mm/min Total power requirement: 21 kW Machine weight: 4.8 t Â
used
Crank press HECKERT PKZ 400.1 built in 1980. Technical data : - maximum pressing force: 400 t - working path - lower position of the slider to the maximum pressing force: 21 mm - maximum drawing depth: 125 mm - pressing force using the maximum drawing depth: 160 Mp - idle speed of the slider: 18 min-1 - maximum number of switchings: 9 min-1 - ram stroke (min-max): 315 mm - slider adjustment: 200 mm - holding force of the drawing device at air pressure: 63 Mp, 5 kp / cm2 - force of the drawing device ejector at air pressure: 10 MP, 7 kp / cm2 - total weight: 38.5 t
new
New drive shafts for Vertical and Universal Fraeshead FU 400 - FW 400 HECKERT Germany Price 900,-- Euro per square plus VAT
used
Heckert machine Maud. SZ 12-10-03/15.2-7.1. machine is in working order. Connected.
used
Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition
used
Type: FU 400 2 / PS Parameters: 1600x400 mm Manufacturer: Heckert Year of production / SO / GO: 1985 / - / -
used
Dosing hoppers Manufacturer: HECKERT Type: Dosing bunker specifications: Sliding floor length: approx. 8,500 mm Sliding floor width: approx. 2,700 mm Sliding floor height: approx. 2,360 mm Side wall height: approx. 2,000 mm Capacity: approx. 40 m³ Drive power: to follow!
used
Fine Bench Drilling Machine make FRITZ HECKERT type BT 2Machine -No: 578 built in 1973Max. Drilling capacity: 6.0 mmStepless speed adjustment: 5000 - 14000 rpm.Discharge: 160 mmTable size: 180 x 180 mmMotor power: 200 WPower connection: 220 V / 50 HzWith- Drill chuck 0 - 6 mm- separate transformer- Spindle stroke with hand leverused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Small precision 2-head series drilling machine WMW Fritz Heckert type BT 6Machine -No: 6304/77 + 890577 built in 1977Technical specifications:Drilling capacity: 6.0 mmNumber of spindle speeds: 6Spindle speeds: 400/630/1080/1760/2790 /: 4700 rpm.Projection: 125 mmColumn diameter: 60 mmTable size: 450 x 170 mmQuill stroke: 60 mmPower connection: 380 V / 50 HzWith- height adjustable head- Drill chucklittle used, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Horizontal milling machine / horizontal bed milling machineMake VEB HECKERT type FBEW 630x2000Fabr. -No: 353514, built in 1977Technical specifications:Table size: 2000 x 650 mmTable width: 750 mmMachining length X: 2000 mmMachining length Z: 800 mmConnected load: 24 kWExternal dimensions L x W x H: 5300 x 2250 x 2530 mmControl cabinet: 1000 x 850 x 1800 mmWeight approx: 7.5 twith- retractable quill- separate control cabinet- rapid traverse- Emergency stop switchused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Machine type: Column drilling machine Make: WMW Heckert Type: BS 32 AI Control type: conventional Drilling capacity in steel (diameter): 32 mm Projection: 320 mm Drilling stroke: 200 mm Spindle mount MK: 4 Feed: 0.08.....1.25 /9 step Speeds: 63 - 1,000 / 9 step rpm Headstock adjustment: 280 manual mm Table clamping surface: 530 x 450 mm Table adjustable: in height 350 mm Footprint: 490 x 440 mm Weight: 1.03 t
used
Transverse slide milling machine with digital display , used milling m/c with vertical head and DRO, used Hersteller/make: HECKERT Typ / model: FQW 400 Baujahr/ year: 1983 Tischgrösse/ table: 400 x 1600 mm Tool holder/ taper: ISO 50 max. table load: 1500 kg Verfahrweg längs / move longit.: 200 ... 1400 mm Verfahrweg quer/ move cross: 55 ... 505 mm Verfahrweg perject / move vertic.: 100 ... 525 mm Spindle speeds: 45 ... 2240 rpm in 18 steps Drive power of the milling spindle | load of spindle: 15 kW Connected load: 21 kW Masse/ weight: 4000 kg
used
x-travel: 650 mm y-travel: 650 mm z-travel: 650 mm Control: Sinumerik 840D weight of the machine ca.: 12 t 1 horizontal machining centre Make: HECKERT type: CWK 400D year 2001 serial no. 18445, control, make: Siemens, type: Sinumerik 840D travel X/Y/Z 650 x 650 x 650 mm 2-fold pallet changer pallet size 400 x 400 mm NC-rotary table 360 x 0,001° 60-fold tool changer, tool holder HSK 63 Speed max. 15,000 rpm IKZ 50 bar Operating hours 57,806 Spindle hours 1.970 Accessories: Coolant temperature control, belt filter, chip conveyor, spindle cooling, preparation for infrared probe, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 800 mm y-travel: 600 mm z-travel: 805 mm Control: Sinumerik 840D weight of the machine ca.: 13 t 1 horizontal machining centre Make: HECKERT type: CWK 500D year 2003 serial no. 16087 control, make: Siemens, type: Sinumerik 840D travel X/Y/Z 800 x 600 x 805 mm 2-fold pallet changer pallet size 500 x 500 mm NC-rotary table 360 x 0,001° 60-fold tool changer, tool holder HSK 63 Speed max. 15,000 rpm IKZ 50 bar Operating hours 32,450 Spindle hours 6.080 Accessories: Coolant temperature control, belt filter, chip conveyor, spindle cooling, Infrared probe preparation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Ref. -No.: 10357 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Steuerung Control: Sinumerik 840D Country of origin: Schweiz X-Travel: 1200 mm Y-Travel: 950 mm Z-Travel: 1200 mm Work spindle drive power (25% ED): 67 kW Work spindle torque (25% ED): 1508 Nm Tool Taper: HSK-A100 Workpiece interference circle diameter: 1250 mm Tool Piece Magazine With: 80 Pcs./pcs. Tool changer: Werkzeugkettenmagazin Max. Workpiece height: 1200 mm Feed Speeds X/Y/Z Axis: 60000 mm / min Feed Capacities X/Y/Z: 22/18/22 N Speed range - main spindle: 20 - 6000 RPM Numbers Of Pallets: 2 Max pallet load: 1500 kg Size Of Pallet: 800 x 630 mm pallet change time: 14 s Pallet clamping area (lxw): 800 x 630 mm Weight Of The Machine Ca.: 25 t
used
Ref. -No.: 10342 Manufacturer: STARRAG HECKERT Year of construction: 2015 Type of control: CNC Control: Fanuc Series 16i Storage location: Halberstadt Country of origin: Schweiz Serial no.: 12217 X-Travel: 1000 mm Y-Travel: 910 mm Z-Travel: 835 mm Distance spindle center - table: 100 mm Table Dimensions (Lengthxwidth): 630 x 800 mm Table Load: 1250 kg Max. Tool Length: 600 mm Max. Tool Diameter: 500 mm Tool Taper: HSK-A 100 Numbers Of Tools In Magazin: 240 Spindle Speed: 20 - 6000 RPM Feed Capacities X/Y/Z: 20.000 N Rapid Traverse: 40 m / min Internal cooling: 30/40/50 bar External cooling: 2 bar
used
Ref. -No.: 10286 Manufacturer: STARRAG HECKERT Year of construction: 2007 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Schweiz Machine-No.: 24139 X-Travel: 2800 mm Y-Travel: 2100 mm Z-Travel: 1900 mm Table Dimensions (Lengthxwidth): 2 x 1.250 x 1.600 mm Max. Tool Weight: 35 kg Workpiece Diameter At Full Load: 110 mm Tool Piece Magazine With: 60 Pcs./pcs. Tool dimensions (with occupied adjacent spaces): 125 mm Numbers Of Pallets: 2 Operating hours: 26180 H spindle running time: 26180h 43m 46s h/m/s automatic mode: 28559 H on time: 120 H pallet change time: 60 s Further information: internal coolant supply
used
Bench drill, stand drill, pillar drill, pillar drill -Manufacturer: WMW Heckert, bench drill type BT 12/1 with base -Clamping table: 340 x 280 mm -Travel: 370 mm -Spindle mount: MK2 -Projection: 215 mm -Speeds: 224/450/900/1800 rpm -Column: diameter 92 mm -Spindle stroke: 100 mm -Motor: VEB 0.4/0.7 kW with brake -Voltage: 380V -Dimensions: 620/480/H1710 mm -Total weight: approx. 182 kg
used
Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine, hydraulic universal cylindrical grinding machine, polishing machine -Manufacturer: WMW Heckert, hydraulic universal cylindrical grinding machine -Spindle motor: VEB 0.8 / 1 kW / 1410/2840 rpm -Hydraulic drive: ADDA 0.75 kW -Individual components: see photos -Distance between centers: 420 mm -Measurements: see photos -Under cabinet: with extensive accessories incl. -Brush: diameter 230 mm -Dimensions: 1720/920 / H1230 mm -Weight: 790 kg
used
Bench drill, bench drill, column drill, pillar drill -Manufacturer: WMW Heckert, bench drill type BT 2 with underframe -Clamping table: 340 x 280 mm -Travel: 250 mm -Spindle holder: MK2 -Projection: 215 mm -Speeds: 355/710/1400/2800 rpm -Column: diameter 92 mm -Spindle stroke: 100 mm -Motor: VEB 0.8 / 1.0 kW with brake -Voltage: 380V -Dimensions: 570/500 / H2020 mm -Weight: 192 kg
used
Rotary table, rotary indexing table, dividing head, dividing head -Manufacturer: WMW Heckert, rotary table type D 315 k TGL 28561/02 -Clamping surface: O 315 mm -Height: 140 mm -Groove: 14 mm -Dimensions: 615/540 / H150 mm -Weight: 83 kg
used
Quick clamping device, hydraulic clamping device, electro-hydraulic clamping device, -Manufacturer: WMW HECKERT, clamping device from milling machine FSS 315-V -Type: FHKN 3311 -Motor: VEM 0.12 kW -Dimensions: 440/150 / H220 mm -Weight: 24 kg
