welding table used for sale

Technical data: 2009 overtaken Table load: 100 to. Table diameter: 3500 mm Table diameter with extension arms: 6000 mm Plan disc: 8 double T-slots Slot distance: 180 mm incl. 8 extension arms to increase the diameter of the washer to 6000 mm.

Faceplate speed level 1: 0.005 0.25 Faceplate speed level 2: 0.019 1.02

Table load: 12 to.

Technical data: Table load 40 to. Table diameter 3,330 mm Speed 0.01 0.2 U/Min. Voltage 400 V / 50 Hz Power 6 KW To the weight of the table 15. Dimensions L x W x H 5,600 x 2500 x 3,200 mm

Technical data: -Lifting capacity 2000 kg -max load capacity horiz. 3500 kp -Faceplate hub 1750 x 1750 mm -Drehkreuzverängerungen -Faceplate geared motor Tiltable 0-90 ° -Rotation Electr. adjustable 0.2-1.5 m / min -Right - left rotation - welding current transmission 1200 A -400 V - table height in horiz drive. Position with frame approx. 2070 mm -Table height at horiz. Position without stand approx. 940 mm -Space requirement approx. B 1650 x H 1130 / 940 x H 2500 mm -Weight approx. 2.2 t

Technical data: -Load capacity 300 kg -Faceplate diameter 500 mm -Faceplate in grid levels of tilt - rotation Electr. infinitely variable approx. 0-1.2 m / min -Sweat power 650 A -Drive 220 V / 0.09 kW -Table height in horizontal position approx. 650 mm -Re + reverse - space requirement approx. B H 800 x 650 X 700 mm -Weight approx. 180 kg

Technical data: -Load capacity 30 kg -Faceplate diameter 280 mm -Faceplate swivel - faceplate RPM elect. infinitely variable - re + Li - run -Foot switch -Transmission of welding current 300 A -Drive 220 V - table height in horizontal position 360 / 890 mm -mobile base -3 jaw Chuck -Space requirement approx. B 550 x H 890 x T 550 mm -Weight approx. 50 kg

Technical data: -max load capacity 3000 kg -Faceplate cross 1600 x 1600 mm -Faceplate cross extension tubes - faceplate cross mot. adjustable 0-90 / 135 ° - rotation infinitely variable 0,01-4 U/min -Right - + rotation control -Transmission of welding current approx. 500 A -400 V - table height in horiz drive. Position without stand approx. 1200 mm -Table height at horiz. Position with frame approx. 2200 mm -Space requirement approx. B H 1600 x 1200 + 1000 X 2400 mm -Weight approx. 2700 kg

Technical data: -max load capacity 250 kg -Faceplate dimensions 500 mm -Faceplate you. Swiveling via Handwheel 0-135 ° -Rotation infinitely variable 0,01-4 U/min -Right - + reverse - transmission welding current approx. 400 A -Drive 220 V 1,1 kW -Table height in horizontal position approx. 800 mm -Space requirement approx. B H 600 x 500 X 1100 mm -Weight approx. 200 kg

Welding turning and tipping-positioning table Technical data: -Load capacity at horizontal position 15000 kg -Load capacity in vertical position 10000 kg -Planpauc diameter 1850 mm -Plane disc with crane support can be swivelled continuously -Rotary motion electr. infinitely controllable -Right-Link Run -Drive 400 V -Ft remote taster -Massea cables -Welding current transmission 500 A -Table height at horizontal position 1850 mm -Space requirements approx. B 2450 x H 1850/2300 x T 3000 mm -Weight approx. 6000 kg

Mot. Welding turning and tilting table Make: DEUMA Type: DK 5000 S Machines - No.: 6890 Built: 1992 Offer number: 19110 Technical data: - max. Load capacity 5000 kg - Flat discs 1800 x 1300 mm - Flat disc hydr. swivel 0 - 90 / 135 ° - Rotational movement infinitely adjustable approx. R&din - Right - + Left-hand drive controllable - Welding current transmission approx. 500 A - Drive 400 V - Table height at horiz. Position approx. 1450 mm - E. hand-held remote button - Space requirement approx. W 2000 x H 1450 x D 3100 mm - Weight approx. 4000 kg

Suction capacity: 1500m3/h Pressure Pa: 1200 Engine power: 1.1 kW Voltage: 400 V Weight: 150 kg Built: 2002 Rated current A 2.5 Frequency: 50 Hz Rust area: 750x500 mm Width: 760 mm Depth: 1050 mm Height: 890

specifications: - Load capacity Positioning table approx. 750 kg - Sheet plate diameter 500 mm - max workpiece diameter 1600 mm - Height turntable at horizontal position approx. 750 mm - Turntable with right, + left-hand run - Rotary axis turntable endless 360° - Turning time per revolution 12.5 sec. - Pan left + right - Pivot axis rotation angle 180° - Swivel time for 180° swivel angle 10 sec. - 2 x double foot button for turntable + swivel arm - hydr. Clamping bolts for clamping the workpiece in the centre of the turntable - Clamping stroke / clamping distance of the clamping bolt 32 mm - Clamping force pressing / pulling 80 / 48.9 kN - Clamping cylinder internal thread M 27 x 40 - Positioning control SIEMENS - Operation manually or via control - Space requirement approx. W 1500 x D 2800 x H 1100 mm - Weight approx. 2500 kg - sepa ...

number: 33 Positionen weight: 52 kg condition: neu : 28 mm P-Set 1:27 pieces, 28mm system (15mm), consisting of: Clamps: 5 Sk. 100 / 350mm Stop: 2 pieces 500mm Stop: 2 pieces 150mm Angle: 2 pieces 175 x 175mm Flat angles: 2 pieces. 350 x 250mm Flat angles: 2 pieces 275 x 150mm Eccentric discs 2 pcs. 100mm Quick release bolts: 10 pcs. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 1000 mm table width: 1000 mm table load: 1,5 t flange diameter: 700 mm turning speed: max. 0,04 U/min weight of the machine ca.: 1,2 t dimensions of machine L x W x H: 1,60 x 2,0 x 1,50 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 29 Positionen : 16 mm condition: neu weight: 11 kg Set 1 29 pieces, 16mm system, consisting of: Clamps: 4 x 160610 Bolt: 12 x 160511 Stop: 4 x 160420.N Angle: 4 x 160108.N Angle: 4 x 160110.N Accessory set. 1 x 163999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 33 Positionen weight: 52 kg condition: neu : 28 mm Set 1: 33 pieces, 28mm system, consisting of: Clamps: 4 x 280610.N Clamps: 2 x 280630.N Prism: 2 x 280648.1.N Bolt: 12 x 160511 Stop: 4 x 280410.N Stop: 4 x 280420.N Angle: 2 x 160110.N Angle: 2 x 280152.N Accessory set. 1 x 283999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 1200 mm table width: 800 mm table height: 850 mm Vertikal stroke: 40 mm weight of the machine ca.: 0,18 t dimensions: 1,2 x 0,8 x 0,85 m Special offer ! Siegmund Workstation incl. 2 drawers + tool set B Through hardened tool steel, bore Ø 16 mm Holes surface 50x50 mm grid, material thickness approx. 11.5 - 13 mm. Consisting of: 1x 004002 (Siegmund Workstation) 1x 164004.X07 (perforated plate) 1x 164030 (clamp holder) 1x 004020 (shelf) 1x 164035 (bolt and prism holder) 1x 004025 (tool wall including shelf) 2x 004210 (drawer) 4x 160620 (clamp) 8x 160511 (double quick release bolts without groove) 6x 160412 (stop) 2x 160108.N (angle) 1x 160852 (Allen key) 1x 164301 (vice) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 1200 mm table width: 800 mm table height: 850 mm Vertikal stroke: 50 mm weight of the machine ca.: 0,19 t dimensions: 1,2 x 0,8 x 0,85 m Siegmund workstation including 2 drawers Premium Light, through hardened tool steel X8.7, plasma nitrided and BAR coated. Drilling Ø 28 mm, drilling surface 100x100 mm grid. Material thickness approx. 15 mm With the new workstation from Siegmund, you can create your ideal workplace in a modular system. The Siegmund Workstation can be individually adapted and expanded to meet your needs and wishes. Whether sawing, drilling or welding - the absolute all-rounder in every workshop! Consisting of: 1x 004002 (Siegmund Workstation) 1x 804004.X7 (perforated plate) 1x 284030 (clamp holder) 1x 004020 (shelf) 1x 284035 (bolt and prism holder) 1x 004025 (tool wall including shelf) 2x 004210 (drawer) Spacer ring 800653.N is required for clamping with  ...

number: 96 Positionen weight: 600 kg condition: neu : 28 mm Special set 96 pieces, 28mm system, consisting of: 1x tool trolley 30x quick release bolts with twist lock short, without O-rings 8x universal stop 150 L - nitrided 4x universal stop 225 L - nitrided 8x stop and clamping angle 175 L - cast 2x stop and clamping angle 500 G left - nitrided 1x stop and clamping bracket 750 G left - nitrided 1x stop and clamping bracket 750 G right - nitrided 1x stop and clamping bracket 500 G left - nitrided 1x stop and clamping bracket 500 G right - nitrided 4x stop and clamping angle 300 G left - nitrided 8x prism Ø60-135 ° burnished - with collar complete with screw collar and countersunk head 16x professional screw clamps - nitrided 6x Professional screw clamp 45 ° / 90 ° - nitrided 4x universal stop 300 - nitrided 1x accessory set consisting of: Eccentric, Allen key, brush, sharpening ston ...

table diameter: 1500 mm table load: 5 t swivelling range: 0 - 130 Grad turning speeds: 0,05 - 0,5 U/min : 10000 Nm 0: 1,5 / 1,5 kW welding current: 700 Ampere • Self-locking gear, therefore no forward and backward at eccentric load. • Electronic components from Schneider, Siemens and Delta. • Frequency-controlled stepless speed of the turntable. • High stability due to the robust construction. • welding power transmission • CE certificate. • Very good price / quality ratio. • The D-HBE series comes as a standard version with a cable remote control and delivered with a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 780 mm table load: 1,0 t swivelling range: 0 - 135 Grad turning speeds: 0,15 - 1,5 U/min table height adjustment: von 780 bis 1560 mm max. torque on the faceplate: 1000 Nm welding current: 500 Ampere including remote control and welding current transmission. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

clamping range of chuck: 80 - 280 mm height: 67,5 mm daylight: 100 mm external diameter: Futter 300 mm external diameter: Spannhebel 480 mm weight: 13 kg Characteristics: • Self-centering. • Reversible jaws. • Fixed clamping levers allow fast workpiece changes. • Low weight and flat design minimize the center of gravity. The D-D quick chuck enables a quick product change and is suitable excellent with frequent component changes. You do not need a loose one Quick release wrench, as the levers are integrated into the quick release chuck. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 57 Positionen weight: 98 kg condition: neu : 28 mm Set 2: 57 pieces, 28mm system, consisting of: Clamps: 6 x 280610.N Clamps: 4 x 280630.N Prism: 4 x 280648.1.N Bolt: 18 x 160511 Magnetic bolt 4 x 280740 Stop: 6 x 280410.N Stop: 6 x 280420.N Angle: 4 x 160110.N Angle: 2 x 280152.N Angle: 2 x 280162.N Accessory set. 1 x 283999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 31 Positionen : 22 mm condition: neu weight: 43 kg Set 1 33-piece, 22mm system, consisting of: Clamps: 4 x 220610.1 Clamps 2 x 220630.1 Bolt: 12 x 220511 Stop: 4 x 220410.N Stop: 4 x 220420.N Angle: 2 x 220110.N Angle: 2 x 220152.N Accessory set. 1 x 223999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 900 mm table load: 1,0 t swivelling range: 135 Grad turning speeds: 0,12 - 1,2 U/min : 820 mm welding current: 500 Ampere total power requirement: 0,75 + 0,55 kW weight of the machine ca.: 1,1 t dimensions of the machine ca.: 1,5 x 1,0 x 0,9 m • Self-locking gear, therefore no forward and backward at eccentric Load. • Electronic components from Schneider, Siemens and Delta. • Frequency-controlled stepless speed of the turntable. • High stability due to the robust construction. • welding power transmission • CE certificate. • Very good price / quality ratio. • The D-HBE series comes as a standard version with a cable remote control and delivered with a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

clamping range of chuck: 200 - 500 mm height: 110 mm daylight: 240 mm external diameter: Futter 320 mm external diameter: Spannhebel 700 mm weight: 56 kg Characteristics: • Self-centering. • Reversible jaws. • Fixed clamping levers allow fast workpiece changes. • Low weight and flat design minimize the center of gravity. The D-D quick chuck enables a quick product change and is suitable excellent with frequent component changes. You do not need a loose one Quick release wrench, as the levers are integrated into the quick release chuck. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1200 mm table load: 1,2 t swivelling range: 0 - 120 Grad turning speeds: 0,06-0,6 U/min max. torque on the faceplate: 2400 Nm table pass: 200 mm welding current: 500 Ampere total power requirement: 0,75 + 1,1 kW weight of the machine ca.: 1,0 t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). No original pictures. Design but identical. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1000 mm table load: 0,6 t swivelling range: 0 - 90 Grad turning speeds: 0,1 - 1,25 U/min max. torque on the faceplate: 900 Nm table pass: 200 mm welding current: 500 Ampere total power requirement: 0,37 + 0,75 kW weight of the machine ca.: t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). No original pictures. Design but identical. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 55 Positionen : 16 mm condition: neu weight: 23 kg Set 2 55 pieces, 16mm system, consisting of: Clamps: 6 x 160610 Clamps: 2 x 160630 Prism: 4 x 160645.1.N Bolt: 18 x 160511 Stop: 4 x 160410.N Stop: 6 x 160420.N Angle: 6 x 160108.N Angle: 6 x 160110.N Angle: 2 x 160162.N Accessory set. 1 x 163999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

clamping range of chuck: 120 - 380 mm height: 95 mm daylight: 170 mm external diameter: Futter 400 mm external diameter: Spannhebel 600 mm weight: 26 kg Characteristics: • Self-centering. • Reversible jaws. • Fixed clamping levers allow fast workpiece changes. • Low weight and flat design minimize the center of gravity. The D-D quick chuck enables a quick product change and is suitable excellent with frequent component changes. You do not need a loose one Quick release wrench, as the levers are integrated into the quick release chuck. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1000 mm table load: 1200 Kg swivelling range: 0 - 135 Grad turning speeds: 0,1 - 1,0 U/min height adjustment: 1000 - 1450 mm max. torque on the faceplate: 2000 Nm engine output: 0,75 / 0,55 kW welding current: 500 Ampere - Manual height adjustment. - Self-locking gearbox, therefore hardly any pre and after-run at eccentric Load. - Electronic components from Schneider, Siemens and Delta. - Frequency-controlled, stepless speed of the turntable. - High stability due to the robust construction. - CE certificate. The D-HBE series comes as a standard version with a cable remote control and a footswitch. Welding power transmission for max.500Ampere. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1400 mm table load: 5 t swivelling range: 0 - 135 Grad turning speeds: 0,05- 0,5 U/min table height adjustment: von 1100 bis 1950 mm max. torque on the faceplate: 7000 Nm welding current: 700 Ampere including remote control and welding current transmission. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 560 mm table load: 0,3 t swivelling range: 0 - 90 Grad turning speeds: 0,25 - 4,0 U/min : 360 Nm welding current: 500 Ampere total power requirement: 0,4 / Hand kW • Self-locking gear, therefore no forward and backward at eccentric Load. • Electronic components from Schneider, Siemens and Delta. • Frequency-controlled stepless speed of the turntable. • High stability due to the robust construction. • welding power transmission • CE certificate. • Very good price / quality ratio. • The D-HBE series comes as a standard version with a cable remote control and delivered with a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1500 mm table load: 5000 Kg swivelling range: 0 - 130 Grad turning speeds: 0,05 - 0,5 U/min height adjustment: 1300 - 2050 mm max. torque on the faceplate: 10000 Nm engine output: 1,5 / 1,5 kW welding current: 1000 Ampere - Manual height adjustment. - Self-locking gearbox, therefore hardly any pre and after-run at eccentric Load. - Electronic components from Schneider, Siemens and Delta. - Frequency-controlled, stepless speed of the turntable. - High stability due to the robust construction. - CE certificate. The D-HBE series comes as a standard version with a cable remote control and a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1400 mm table load: 2,0 t swivelling range: 0 - 135 Grad turning speeds: 0,05 - 0,5 U/min max. torque on the faceplate: 6000 Nm table pass: 200 mm welding current: 700 Ampere total power requirement: 1,1 + 2,2 kW weight of the machine ca.: t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1600 mm table load: 6 t swivelling range: 0 - 130 Grad turning speeds: 0,05 - 0,5 U/min : 12000 Nm 0: 1,5 / 2,2 kW welding current: 700 Ampere • Self-locking gear, therefore no forward and backward at eccentric load. • Electronic components from Schneider, Siemens and Delta. • Frequency-controlled stepless speed of the turntable. • High stability due to the robust construction. • welding power transmission • CE certificate. • Very good price / quality ratio. • The D-HBE series comes as a standard version with a cable remote control and delivered with a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table dimensions: 800 x 800 mm table load: 1500 Kg swivelling range: 0 - 105 Grad turning speeds: 0,15 - 1 U/min height adjustment: 672 - 1180 mm hollow spindle diameter: mm welding current: 500 Ampere max. torque on the faceplate: 3000 Nm total power requirement: 0,75 kW dimensions of the machine ca.: 1560x1120x750 m Characteristics: • Made in EU • Self-locking gear, therefore no leading and trailing at eccentric load • Hydraulic height adjustment allows almost limitless positioning • Electronic quality components from Schneider / Siemens / Delta • Frequency-controlled stepless speed of the turntable • High stability through a heavy and compact design • CE certificate • Very good value for money • Standard version comes with remote control and dual foot pedal • 3 years warranty (see warranty conditions) • Hydraulically height adjustable with locking system (for fal ...

table diameter: 700 mm table load: 0,6 t swivelling range: 0 - 90 Grad turning speeds: 0,2 - 2,0 U/min : 900 Nm total power requirement: 0,37 / 0,37 kW • Self-locking gear, therefore no forward and backward at eccentric Load. • Electronic components from Schneider, Siemens and Delta. • Frequency-controlled stepless speed of the turntable. • High stability due to the robust construction. • welding power transmission • CE certificate. • Very good price / quality ratio. • The D-HBE series comes as a standard version with a cable remote control and delivered with a footswitch. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1500 mm table load: 5,0 t swivelling range: 0 - 135 Grad turning speeds: 0,05 - 0,5 U/min max. torque on the faceplate: 10000 Nm table pass: 200 mm welding current: 700 Ampere total power requirement: 1,5 + 3,0 kW weight of the machine ca.: t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). No original pictures. Design but identical. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 1200 mm table width: 800 mm table height: 850 mm Vertikal stroke: 50 mm weight of the machine ca.: 0,25 t dimensions: 1,2 x 0,8 x 0,85 m Special offer ! Siegmund Workstation incl. 2 drawers + tool set B Perforated plate: Premium Light. Through hardened tool steel X8.7, plasma nitrided and BAR-coated, bore Ø 28 mm. Drilling surface 100x100 mm grid, material thickness approx. 15 mm. Consisting of: 1x 004002 (Siegmund Workstation) 1x 804004.X7 (perforated plate) 1x 284030 (clamp holder) 1x 004020 (shelf) 1x 284035 (bolt and prism holder) 1x 004025 (tool wall including shelf) 2x 004210 (drawer) 4x 280610.N (clamp) 8x 280511 (double quick release bolts without groove) 1x 800653.N (spacer ring for Premium Light 4-pack) 6x 280412 (stop) 2x 280109.N (angle) 1x 280852.1 (Allen key) 1x 004303 (vice) The data for this ad was created with ModulMWS - the software solution of LogoTech ...

table diameter: 340 mm table load: 290 horizontal kg table load capacity: 190 vertikal kg turning speeds: 0,6 - 6,0 U/min spindle bore: 60,0 mm swivelling range: 0 - 90 Grad weight of the machine ca.: 62 kg dimensions of the machine ca.: 380 x 340 x 425 mm Furnishing: - The table can be tilted and clamped at an angle of 0 to 90 - Start / stop via a location-independent foot switch. - Direction of rotation can be selected right / left. - Adjustable rotation time. - The turntable has a 60 mm hollow shaft. - The turntable has a diameter of 340 mm. The surface is chrome-plated for Protection against welding spatter. - The table speed is adjustable from 0.6 - 6 rpm. - The control of the welding machine via the turntable control is possible. - The ground contact transmits 300 A / 100%. - The turntable and the control are separate. - HF protected. - Operating instructions in German Functions ...

table diameter: 340 mm table load: 160 horizontal kg. table load: 100 vertikal kg. turning speeds: 0,6 - 6,0 U/min swivelling range: 0 - 90 Grad bore: 60,0 mm motor: 230 Volt weight of the machine ca.: 56 kg. range L-W-H: 385 x 340 x 375 mm Furnishing: - The table can be adjusted at an angle of 0 to 90 degrees tilt and jam - Start / stop via a location-independent foot switch. - Direction of rotation can be selected right / left. - Adjustable rotation time - The turntable has a 60 mm hollow shaft - The turntable has a diameter of 340 mm. The surface is chrome-plated for Protection against welding spatter. - The table speed is adjustable from 0.6 - 6 rpm. - The control of the welding machine via the turntable control is possible. - The ground contact transmits 300 A / 100%. - The turntable and the control are separate. - HF protected. - COM 1800 control with lap welding - Operating in ...

total power requirement: 230 Volt table diameter: 300 mm table load: 100 Horizontal kg swivelling range: 0 - 90 Grad turning speeds: 0,2 - 2,0 U/min turning speeds: 1,2 - 12,0 U/min bore: 20,0 mm weight of the machine ca.: 50 kg dimensions of the machine ca.: 480 x 325 x 470 mm Furnishing: - Precise drive unit with face plate, on a stable floor stand. - clockwise / counterclockwise - 2 speed series, stepless - Swivel range from 0 ° - 90 °. Manual tilt - DC gear motor with worm gear, infinitely variable. - diameter of 300 mm. Chrome-plated surface to protect against weld spatter. - The devices control panel is easy to understand and use. - Start / stop via a location-independent foot switch. - The speed and direction of rotation are set on the machine. - HF protected. Scope of delivery: - control (integrated) - foot switch The data for this ad was created with ModulMWS - the software  ...

weight max. in kg: 1250 kg turning speeds: 2,0 U/min height: max. 1.120 mm Torque: Tisch 4.900 Nm weight: 685 kg The Siegmund Roto-Positioner is ideal for welding, Assembly and maintenance work. The positioning takes place via a hydraulic one Turn and tilt function. The Siegmund Roto-Positioner is also included equipped with a continuously height-adjustable axis. Furnishing: - Hydraulic rotation of the clamping plate - Tilt range up to 95 ° - Hydraulic height adjustment and tilt function - including hand control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight max. in kg: 3000 kg turning speeds: 1,7 U/min height: max. 1.620 mm Torque: Tisch 11.750 Nm weight: 1.305 kg The Siegmund Roto-Positioner is ideal for welding, Assembly and maintenance work. The positioning takes place via a hydraulic one Turn and tilt function. The Siegmund Roto-Positioner is also included equipped with a continuously height-adjustable axis. Furnishing: - Hydraulic rotation of the clamping plate - Tilt range up to 95 ° - Hydraulic height adjustment and tilt function - including hand control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 1400 mm table load: 3,0 t swivelling range: 0 - 135 Grad turning speeds: 0,05 - 0,5 U/min max. torque on the faceplate: 6000 Nm table pass: 200 mm welding current: 700 Ampere total power requirement: 1,1 + 2,2 kW weight of the machine ca.: t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). No original pictures. Design but identical. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 700 mm table load: 0,5 t swivelling range: 0 - 135 Grad turning speeds: 0,2 - 3 U/min height adjustment: 400 - 900 mm boring diameter: 100 mm welding current: max. 500 Ampere total power requirement: 0,75 kW including remote control and welding current transmission. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 1200 mm table width: 800 mm table height: 850 mm Vertikal stroke: 40 mm weight of the machine ca.: 0,26 t dimensions: 1,2 x 0,8 x 0,85 m Special offer ! Siegmund workstation incl. 2 drawers + tool set B high quality steel S355J2 + N, plasma nitrided and BAR-coated Boreholes Ø 22 mm, boreholes surface 100x100 mm grid Material thickness approx. 17 - 19 mm Consisting of: 1x 004002 (Siegmund Workstation) 1x 224004.P (perforated plate) 1x 224030 (clamp holder) 1x 004020 (shelf) 1x 224035 (bolt and prism holder) 1x 004025 (tool wall including shelf) 2x 004210 (drawer) 4x 220610.1 (clamp) 8x 220511 (double quick release bolts without groove) 6x 220410.N (stop) 2x 220110.N (angle) 1x 220852 (Allen key) 1x 004303 (vice) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table diameter: 600 mm table load: 0,6 t swivelling range: 0 - 90 Grad turning speeds: 0,1 - 1,8 U/min max. torque on the faceplate: 450 Nm table pass: 80 mm welding current: 500 Ampere total power requirement: 0,18 + 0,18 kW weight of the machine ca.: t ELDING TABLE WITH LARGE THROUGH BORE • Self-locking gearbox, no pre- or after-run with eccentric load. • Electronic components from Siemens and Schneider. • Frequency-controlled, very accurate speed control. • Turntable with large through hole and T-slots. • High stability through a clever construction. • CE certificate. • Very good price / quality ratio. • The D-TLP series comes with remote control and foot pedal (left / right). No original pictures. Design but identical. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
