Key data: 600 mm, 200 mm

We can offer you following machine (Subject to being unsold ) Terms of delivery/payment: payable before/ by order . All information and offers are subject to our general terms & conditions If there are further questions, don't hesitate to contact us. Double-sided planer copper mill DOIN- VUIN 605 year of construction 1975 S/N 3310 Manufacturer Kupfermühle woodworking machines Working width / maximum width 600 mm Working thickness: 200 mm chip removal max 20mm ( upper shaft ) chip removal 12mm ( under shaft ) Shortest piece length 350mm Technical equipment: from above: toothed draw shaft Toothed Pull Shaft 2 PCs 4-blade planner shaft, 605 mm, 15 kW from below: Table top, adjustable Traction shaft, smooth-running, adjustable 4-blade planner shaft, 600 mm, 11 kW 2 adjustable tables/pull roller in the lower table top Electric height adjustment Lift motor a ...

Single sided edge banding machine Brand: IMA Type: COMPACT PC-6220 F Year: 2000 Left hand machine Workpiece transport via a driven transport chain and adjustable top pressure Beckhoff control Need of space LxWxH mm: 7400x1500x2000mm Weight: approx. 3600kg Technical data: Edge material: a) Veneer/coil and strip ware, b) PVC/coil and strip ware c) Solid wood strips min. edge height = approx. 14 mm max. edge height = approx. 55 mm min. edge tickness = approx. 0,4 mm max. edge thickness = approx. 20 mm min. panel thickness = approx. 10 mm min. panel thickness = approx. 16 mm at use of the multi function unit max. panel thickness = approx. 50 mm min. panel width = appprox . 60 mm min. panel length = approx. 150 mm max. strips = approx. 20x50 mm Panel supernatant from the chain conveyor = approx. 35 mm Pneumatic connection: approx. 7 - 8 bar The basic  ...

CONTROLS   PLC SIEMENS S7-1500 FEEDSTOCK TUBE   external diameter min.: 27.5 mm   external diameter max.: 160 mm   wall thickness min.: 1 mm   wall thickness max.: 15 mm   length min.: 3500 mm   lenght max.: 13000 mm TUBE LEVELLING UNIT   number of leveller rolls: 6   number of intermediate rolls: 3   main drive power: 110 kW   feedstock transport direction: left to right System consisting of:+ various existing and supplemented pipe transport systems+ Tube Straightener Montbard DMS 168, YoM 1989+ Chipless Cutting System Bültmann STA 120 H, YoM 2005+ Saw Ohler KA-630-7877, YoM 1988+ Sample Saw Ohler K-400Modernized:2005 new Bültmann chipless cutting system2018 overhaul of complete electrical system2018 new safty protection systemInlet Feed Drive (top and bottom rolle ...

Cat.-Nr. 11-3200 new Necessary space for mash and lauter tun: LxWxH: 3 x 2 x 2,80 m Necessary space for tanks: LxWxH: 4,0 x 5,0 m complete 2 brews / day = 10hl Basic Equipment The Brew House is complete with all equipment. All equipment are with high standard an very simple to use. This 5 hl Brew House is built as 2 devices-brew house manual version with manual butterfly valve. It is possible to make 2 brews/day (10 hl) Technology All the pipes can be cleaned and sterilized in the circuit over the pump included. a) In the mash boiler the mash will be cooked, then it will be pumped with one beer pump made of stainless steel from mash boiler to the lauter tun. b) After the lauter wort will be pumped back to the mash boiler. c) After emptying the lauter tun the grit floor will be removed. The lauter tun will be changed to a whirlpool. d) After cooking th ...

Cat.-Nr. 11-3210 new Basic Equipment The Brew House is complete with all equipment. All equipment are with high standard an very simple to use. This 10 hl Brew House is built as 2 devices-brew house manual version with manual butterfly valve. It is possible to make 2 brews/day (40 hl) Technology All the pipes can be cleaned and sterilized in the circuit over the pump included. a) In the mash boiler the mash will be cooked, then it will be pumped with one beer pump made of stainless steel from mash boiler to the lauter tun. b) After the lauter wort will be pumped back to the mash boiler. c) After emptying the lauter tun the grit floor will be removed. The lauter tun will be changed to a whirlpool. d) After cooking the hops a special injection valve is introduced inside the lauter tun so that it can be used as a whirlpool. Mashing Tun / Wort Boiler Volume brutto: ...

Cat. No. 11-3600-1 New V2A storage tank / combination tank / stacking tank with cooling jacket - 1000 + 500 litres Standard: 3 feet Stand display with bar and scale incl. Fender filling nozzle supfront NW 50 Cone bottom bottom and top Surface: 3D and exterior marbled inside Remaining outlet NW 50 Connection for barrel hole flap DN 50 Manhole front oval 300 x 435 mm - extended Diameter 920 mm Volume: bottom (Basei): 1000 litres top (stack): 500 litres Base tank height (bottom): 2085 mm Stacking tank height (top): 1050 mm Total height: 3135 mm Surcharges/pieces: Disc valve DN 50 Tap flap gr.37 Cutting tube for tap flap size 37 m.Disc valve NW 40=Clear drain Trial tap Agitator 0.37 kW, 400 V, 1370 rpm with connection for tap flap Gr.37 For inquiries: Tel: 09353 90905-0 or Fax: 09353 90905-22 ...

Cat. No. 11-3600-9 New V2A storage tank / combination tank / stacking tank with cooling jacket standing round on feet Standard: 3 feet Stand display with bar and scale incl. Fender filling nozzle supfront NW 50 Cone bottom bottom and top Surface: 3D and exterior marbled inside Remaining outlet NW 50 Connection for barrel hole flap DN 50 Manhole front oval 300 x 435 mm - extended Diameter 920 mm Volume: bottom (base): 500 litres top (stack): 500 litres Base tank height (bottom): 1335 mm Stacking tank height (top): 1050 mm Total height: 2385 mm Surcharges/pieces: Disc valve DN 50 Tap flap gr.37 Cutting tube for tap flap size 37 m.Disc valve NW 40=Clear drain Trial tap Agitator 0.37 kW, 400 V, 1370 rpm with connection for tap flap Gr.37 For inquiries: Tel: 09353 90905-0 or Fax: 09353 90905- ...

THREE ROLL BLECHBIEGEMASCH. m. conical bending and in turn, used three rollers bending m/c with conical and prebending, used Typ / type: UBBDA 32 x 2000 Manufacturer / make: heavy machinery Wildau Baujahr/ new: 1984 Workspace, sheet width max. / maximum working length: 2000-.2100 mm maximum sheet thickness maximum sheet width rounding (cold) / Max sheet thickness at max.working length at bending(cold): 32 mm (270 MPa) On bending (cold) /. at prebending(cold): 23 mm Smallest sheet metal thickness maximum sheet width /. min. sheet thickness at maximum working length: 4 mm Bending rolls / bending rollers: top: 1 piece, bottom: 2 PCs Driven / driven: 2 bottom rollers / bottom rollers upper roll diameter / diameter of top roller: 382 mm Under Roll diameter / diame ...

DECKLAGEN PRODUCTION LINE TORWEGGE with WEINIG H22BL FINSIH LAYER PRODUCTION LINE ML-Presseen Torwegge Heating bed length 3 m Wood types FI, AI, LÄ, DG, ZI ML slat width 60 - 140 mm ML- Slat thickness 8 - 15 mm Rod width 25-45 Rod thickness 17-31 mm Possible. Carpet widths 1273 - 2073 mm Special widths 1000, 1700 mm Target capacity/layer 300 m2 LH 500 m2 19 - 31 mm Fi Functional principle continuous Plate length mm 10000 Plate width mm 6600 Workpiece thickness max mm 45 Pressing force t 10 Further technical data Workpiece thickness min mm 25 Input length min mm 450 Fugue glue press Yes The technical data are partly estimated. Actual values can be may differ. = English = Technical data are partially estimated. Actual values may ... WEINIG High Performance Profile Machine, Type Hydromat 22 BL Built in 1995 with splitting unit (lamella saw) Bring (au ...

Spuelmachine / Hoods backService-Milbrandt The TOP Model! Model: BSM 857 Stainless steel performance Powerful and Universal Sprout Machine 1.5 and 3 min Spueldauer 1 universal basket, 1 plate basket 500 x 500 and cutlery insert Power: 20 and 40 Koerbe/hr with drain pump sprouts and clear-spreaders dosing TOP Price = power ! Optional: - Water enath - Drain tables and inlet Ttices - Hose pendulum shower - Koerbe --- Our TOP model! --- available immediately! Now NEW with attractive financing!

Technical data: -Get well plate surface -Length approx. 2000 mm -Width approx. 1000 mm -Height approx. 1600 mm -Top plate thickness approx. 95 mm -Top plate with internal ribbing - 4 piece t grooves on the surface of the table length 2000 mm -Centre distance of the T-slot table top 230 mm each -Table side L 2000 mm with 12 holes M27 -T - slot width approx. 40 / 67 mm -T - groove depth approx. 35 / 60 mm -Space requirement L 2200 x T 1200 x H 1600 mm - weight approx. 4980 kg

AMOB MAH 60/3 Section: 20 cm ³ Power: 5.5 kW - 7 hp Rpm: 11 rpm Ø instrument: 170/108 mm Ø shaft: 55/55 mm Weight: 600 kg Dimensions: 1300x890x1550 mm Nr. 3 motorized rollers hydraulic adjustment top roller Side guide rollers Programmable and displayed top roller Horizontal and vertical working position Pedal with safety device start/stop General information: The AMOB MAH series top roll profile hydraulic bending machines are the backbone of the widest selection of profile curves in the world. The MAH series is perfect for those applications that require multiple passes, where repeatability is paramount. Motorized 3-roller machines are suitable for narrower spokes and minimize material marking. Both horizontal and vertical working positions ensure that, even in the smallest workspaces, a mah series profiling machine will be placed. T ...

WEINIG high performance planer Type Hydromat 22 BL (full checked!) Built in 1995 With safety hood and soundproofing cabin! Machine specifications: - Planing capacity 220 x 120 mm - Feeding, 8- 80 m/min, motor 18.5 kW Spindle layout: Bottom-right-Links Top - bottom, table rigid Bottom, table rigid, spindle prepared Top - bottom, table rigid, spindle prepared gap unit, consisting of 1 right and 1 left spindle 30 kW each (4500 rpm) incl. table roll, sliding roller, spray indentation and wedge dissipation 4 Roller pull-out Special printing and fittings for the production of top layer slats Feed (divider) for slats and pull-out tape

Sheet thickness: 16,00 mm Bending length: 2000 mm Number of rolls: 4   Extra top rol 200 mm SIEMENS SIMATEC CNC Top support Double cylinder for more pressure on lower roll Rolling width:                 2.000mm Rolling thickness 3x toproll Ø:13mm Rolling thickness 5x toproll Ø:16mm Rolling thickness prebending:  10mm Top Roll Ø:                    280mm Bottom Roll Ø:                 250mm Side roll Ø:                   200mm Number of rolls:               4 Rolling speed:                 5m/min Control:                       Sieme ...

Sheet thickness: 20,00 mm Bending length: 3000 mm Number of rolls: 4   incl. hydraulic top support incl. side support incl. spare roll 300 mm ( small cones) Rolling width:                 3.000mm Rolling thickness 3x toproll Ø:20mm Rolling thickness 5x toproll Ø:25mm Rolling thickness prebending:  18mm Top Roll Ø:                    430 + 300 mm Bottom Roll Ø:                 430mm Side roll Ø:                   300mm Number of rolls:               4 Rolling speed:                 2 + 4 m/min Adjustiment lower roll:        200mm/min. Adjustment side rolls:    & ...

Powder mixing plant Ytron Dr. Karg, built in 2012 and with Flow tank. Capacity up to 10 to/h The powder was treated via pipes into the flow vessel. The whey or milk powder mixture was via the plate heater and hot water Cycle in batch operation with the basic tanks set and then released for further processing. With frame and staircase a.) With a GEA plate heater for treatment the powder water solution. Hersteler FA. GEA TDS GmbH, Sarstedt Type: VT 20 CD-9-C-16 170/7412 No. 3600 4074, year of construction 2012 b.) With wall-mounted control cabinet system Siemens S 7 for process technology, CIP tank system and Control of cleaning paths c.) With 1 CIP system for the standing tank as a 1-tank cleaning system for the Batch operation and for the powder mixing plant Self. Content CIP tanks 15,000 l insulated, deformed inwards in the upper area with valve no ...

A HOSOKAWA ALPINE Originals machine Refurbished by the original manufacturer Use of original components only Original manufacturer warranty Guaranteed manufacturer spare parts supply Short lead time Before delivery, the machine is overhauled, all wear parts are revised and exchanged if needed and customized to your specific needs Possibility to provide all additionally required peripherals or adapt to existing production plant We are also interested in buying back disused HOSOKAWA ALPINE machinery Used Hosokawa Alpine AFG-R 200 fluidised bed classifier jet mill system. The AFG-R is a special variant of the standard AFG where one nozzle is placed vertically pointing upwards on the bottom of the grinding chamber to elevate all the material in the fluidised bed to the jets meeting point, specially interesting for heavy and difficult to grind materials. This machine is specially  ...

Capacity: in 180 x 130 mm., out 170 x 120 mm Feed speed: 6 to 28 m/min, 2,2 kW motor Cardan shaft drive Pneumatic pressures Spindles: 8 Bottom 5,5 kW, fence 5,5 kW, near 5,5 kW, fence 5,5 kW, top 11 kW, top 7,5 kW, bottom 5,5 kW, universal 5,5 kW Spindles 40 mm diameter Spindle speed: 6000 rpm Mechanical digital read-out Infeed table length: 2 m. Max. cut on 1st spindle: 10 mm. Min tool diameter: 100 mm, max tool diameter: 180 mm on first and universal spindle, 195 mm on vertical spindles, 200 mm on top spindles and 2nd bottom spindle Safety hood

Special lathe for turning turbine shafts / large pulleys / large rotors / large pistons Type: DS 2000-13/IV Lathe is equipped with 2 cross-slides: - one is mounted on a chassis bed installed next to the main chassis of the lathe - one is mounted on an upper chassis bed on top of the main chassis of the lathe - the upper chassis bed is also movable on top of the main chassis of the lathe Max length of workpiece on main chassis: 13 meter Max length of workpiece on top of upper chassis bed: 6,5 meter Max swing in gap using main cross-slide: 4000 mm Max swing over bed usingnbsp;using secondary cross-slide: 2700 mm Max swing over cross-slide: 2220 mm Distance between centers: 13 000 mm Swing over bed: 4000 mm Swing over cross-slide: 2220 mm Diametre of main spindle bore: 95 mm Power on main spindle: 70 kW Weight: 130 ton Max weight between centers: 100 ton

A HOSOKAWA ALPINE Originals machine Refurbished by the original manufacturer Use of original components only Original manufacturer warranty Guaranteed manufacturer spare parts supply Short lead time Before delivery, the machine is overhauled, all wear parts are revised and exchanged if needed and customized to your specific needs Possibility to provide all additionally required peripherals or adapt to existing production plant We are also interested in buying back disused HOSOKAWA ALPINE machinery Used Hosokawa Alpine AFG 400 classifier jet mill for the ultrafine grinding of different products with a sharp top cut. This pulveriser allows the fine comminution of products in the bottom chamber of the machine. Thanks to the different nozzles, the pressurized air reduces the product size to the desired one. The top part is fitted with air classifiers that ensure the required top c ...

Holzkraft Precision Wood Band Saw HBS 533 SET Product name: Precision wood band saw HBS 533 SET Manufacturer: Holzkraft Item number: 5155303 SET Year of construction: 01/2022 Condition: As good as new technical details: • Dimensions work table (L x W x H): 535 mm x 535 mm x 945 mm • Saw table inclination: -10° to +45° • 2 x suction nozzles • Diameter suction nozzle: 2 x 120 mm • Working table length max.: 685 mm • Work table widening length: 535 mm • Work table widening width: 150 mm • Cutting height max. 90°: 270 mm • Cutting width max. with stop: 474 mm • Cutting width max. without stop: 514 mm • Band saw blade speeds: 850/430 m/min • Band saw length: 3,865 mm • Band saw guide: precision guide at the top and bottom • Weight: approx. 163 kg • incl. band saw set, length 3865 mm, 3 pieces - 1x band saw blade wood 3865 x 10 x 0.5  ...

WEINIG HYDROMAT 22 BL Year of construction 1995 with splitting unit (lamellar saw) Feeding (Automatic feeder and pull-out unit!) With safety hood and soundproof cabin! Machine specifications:  - Planning capacity 220 x 120 mm  - Feeding, 8– 80 m/min, motor 18.5 kW Spindle layout:  Bottom-right-left Top - bottom, table rigid Bottom, table rigid, spindle prepared Top - bottom, table rigid, spindle prepared Gap unit, consisting of 1 right and 1 left spindle each 30 kW (4500 rpm) incl. table roll, sliding roller, spray barrier and gap wedge removal 4 roller pull-out Special pressure and fixtures for the production of top layer slats Feeder (all-in) for slats and pull-out tape

GeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross700 mmVertical950 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...

sheet width: 3100 mm plate thickness: 50 mm pre-bending: 40 mm total power requirement: kW weight of the machine ca.: 40 t dimensions of the machine ca.: 6,7 x 3,0 x 3,0 m 4-ROLL Hydraulic Plate Rolling Machine Working length 3100 mm Maximum thickness Pre-bending 40 mm Bending 50 mm Yield Point: 240 N/mm2 Number of rolls 4 Motor Power 55 kW Min. diameter mm - Ø Top Roll Diameter x 3 Top roll Ø 540 mm Bottom roll Ø 510 mm Side roll Ø 440 mm Length 6700 mm Height 3000 mm Width 3000 mm Weight 40.000 kg With: Cone bending device Induction hardened rolls Digital readout for side rolls Fully welded steel (St-52) frame Separate moveable control panel Dual bending speeds Electronic Parallelism All rolls are mounted in spherical roller bearings Hydraulically opened/closed drop end controlled from control panel Activation of cone rolling function and position adjustment via buttons on the  ...

4 ROLL HYDRAULIC MODEL M2008 EVO_4.0 CNC GRAPHIC CAD-CAM Machine serial number 2022 PLATE BENDING ROLL PLANETARY DESIGN DOUBLE PINCH PRE-BENDING Capacity -Width of plate: 2000 mm -Thickness of plate rolling 8 mm -Thickness of plate pre-bending 6 mm -top roll 190 mm -lower roll 170 mm minimum rolling shell ID 220 mm -Power 5,5 Hp to run the hydraulic unit Voltage 400/50 – 480/60 -Weight of the machine 3400 Kg Configuration installed Surface hardening of the four rolls, smooth finishing suitable for stainless plates rolling Dual pre-pinch, with adjustable force upon the input of plate thickness Conical bending hydraulic attachment - hardened contrast pad. Power driven rolls rotation top/bottom gearbox axial direct drive hydraulic each roll. Calibration system f re-rolling of welded shells rounding. Console electric in ...

WEINIG planer/moulder Unimat 22A with 9 heads Year of construction: 1987 Serial number 222-896. The planer is in good working condition and has been partially overhauled, cleaned and subjected to careful technical controls. • The machine has been thoroughly cleaned and technically checked. • Some wear parts have been replaced. • A test run was carried out to ensure functionality. • The machine is bolted to a wooden structure and is ready for shipment. • The planer and moulder is equipped with all the tools and is sold as such. Further technical data of the machine: Maximum planing width: 220 mm Maximum planing height: 140 mm Diameter of the spindles: 40 mm Spindle speed: 6000 rpm Length of the inlet table: 2 m The machine has a total of 9 spindles with the following configuration: 1. Lower spindle / dressing spindle : 5.5 kW 2. Right spindle /  ...

Bakery shop fittings Aichinger ArtLine III sales counter 3.9 m shop counter bakery sales stand CoolMaxx HotMaxx CoolBottle, used from 11/2018 Type: ArtLine III Manufacturer: AICHINGER GmbH, Ostring 2, 90530 Wendelstein, Germany Purchase according to invoice: 11/2018 Properly and professionally dismantled and stored on pallets in our warehouse. Very good condition. Disc type: ARTLine OK 1252mm I ZP 330mm Countertop Type: Postforming APL Depth: 1060 Front Type: Decor APL Decor Edge: A1 MGM_Schwarz APL Postforming: G/A1 MGM_Schwarz Display: table-level Price bar: EV 1 Front décor top: E/H3395 ST12_Corbridge natural oak Front edge top: H3395 ST12_Corbridge natural oak Version: Standard (V20) Front profile: EV 1 Skirting board: EV 1 Pocket tray type: 1-tube/Waab CNS The shop fittings consist of: #Theke Free-standing end side for modules with glass attachment, ...

WEINIG / GreCon Short Wood Finger-jointing Line Ultra TT Data of the system: • Wood inlet length (min. - max.) 150 - 1000 mm (1300 mm) • Reference timber inlet length at the finger-jointing line 400 mm • The length of the wood to be processed must be at least 25 percent longer than the width of the wood to be processed • Wood thickness (min. - max.) 20 - 80 mm • Reference wood thickness 28 mm • Wood width (min. - max.) 40 - 205 mm • Reference wood width 90 mm • Reference wood cross-section 28 mm x 90 mm • Wood outlet length (min. - max.) 3000 - 6100 mm • Reference wood outlet length 6100 mm • Tine profile (length) 10 – 11 mm • Max. wood cross-section for processing softwoods (with specified tine length) 100 cm² • Max. wood cross-section for processing hardwoods (with specified tine length) 80 cm² • Glue type PVAC • Species: Softwood / ...

High quality machine housing, 548 x 129 x 200cm hoch, KMS, mint condition -90% Special price ! If you have an UID number, we will gladly issue an invoice without VAT Top condition like a demonstration unit The part was removed from a new machine, which can be proven to have run only about 100 hours. The parts have minor signs of disassembly. High quality machine enclosure, length 5480, width 1285, height 2000mm, Consisting of: - Total 12.24 running metres of enclosure, - High quality frame with removable panels, all top painted, - 2 large double doors without locking system with plexiglass, - The back consists of 7 removable elements of plexiglass and sheet metal - The top is made of plexiglass all round - The roof consists of slide-on frames with plexiglass edging. - The elements are all very strong and of high quality - Incl. the many machine feet and the  ...

Planer-saw combination copper mill DK-14 Year of construction 1982 Working width 605 mm Working height 200 mm Number of spindles 3 Shaft arrangement Hobewelle bottom+top / Saw shaft bottom Spindle speed 6000 rpm Motor power 5.5 - 7.5 - 30 kW Feed speeds 7 - 23 m/min Feed motor 2.2 / 3 kW Driven rollers in table 3 Feed rollers top 4 Yt9k30 Transport rollers in extract 2 Tool head horizontal dia. 126mm, L=610mm Chip removal below 12 mm Chip removal top 20 mm Suction nozzle diameter 140-140-120 mm Weight 3500 kg Space requirement 1500 x 1900 x 1500 mm Voltage / Frequency 380V 50Hz 3Ph Cutting height saw max.: 50mm Saw blade diameter max.: 250mm

Technical specifications Year of manufacture 1972 Working width mm 220 Planing height mm 120 Number of spindles 5 Spindle configuration b-r-l-t-b Spindle rotation speed max 1/min 6000 Infeed table length mm 2500 Feedrate max m/min 36 Type of feed roller drive Chain Further technical details Bottom spindles 2 Right spindles 1 Left spindles 1 Top spindles top 1 Spindle diameter mm 40 Seperate motor per spindle Lubrication pump manually Pneumatic top pressure Continuously variable feed Total power, kW 32 Weight kg 3700

Number of sanding units: 8 st. sanding width: 150 mm Machine can be inspected during production! Leistomat - Finisch and intermediate leveling machine Löwer LZ 8 -------------------------------------------------- ------------------- for finish sanding (smoothing, defibering and edge breaking) or intermediate sanding profiled window latch - Finish and intermediate sanding machine with eight sanding blade aggregates, 2 surface units at the top (synchronism / counter-rotation) 2 surface units below (synchronism / counter-rotation) 4 profile units with angled arrangement top right, bottom right, top left, bottom left, all mating - linear guidance of all grinding units over Linear ball bearing sets on hardened shafts - Timed immersion of all in the opposite direction rotating grinding units directly above the incoming Workpiece edges to avoid looping through the Primer in the front edge area ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal400 mmCross400 mmVertical375 mmTechnical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightWeight approx.6800 KgDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mSpindle speed 28.000 rpm HSK-A63Spindle speed 20 up to 28.000 U/min Motor spindle with shaft cooling power 30/20 kW // 40.23hp/ 26.82 hp (40/100% DC) torque 40/27 Nm (40/100% DC) tool clamping HSK 63 according to DIN69893 (different from standard)Chain-type tool magazine 60 po ...

GeneralHorizontal 5-axis universal machining centre; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal850 mmCross900 mmVertical1150 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDrive CNC swivel rotary table direct drive C-axis with pallet carrier Permissible load: 800 kg / 1,760 lbs C-axis: 80 min-1 direct drive A-axis: 15 min-1 single drive Rotation C axis: endlessly turning Swivel range A axis: +120°/-120° (replacement of base machKi ...

Part Number 6368 TECHNICAL DATA - max width of the workpiece 230mm - max height of the workpiece 130mm 7 spindles: 1) horizontal bottom 230mm 5,5kW 2) vertical right 130mm 5,5kW 3) vertical left 130mm 5.5kW 4) horizontal top 230mm 7,5kW 5) horizontal upper 230mm 11kW 6) horizontal bottom 230mm 18,5kW 7) universal 230mm adjustable at 360 degrees 5.5kW - all spindles adjustable up/down, right/left - all spindles equipped with an electric brake - spindle diameter 40mm - spindles 4 and 5 electrically adjustable up/down - from above 8 metal pulling introductory shafts, swivel including 2 double - from above 4 pulling rollers, rubber - pressure from above 2pcs - from the bottom of the ratchet - from the bottom from the side 3 clamps - from below 2 metal rollers, smooth, pulling - from the bottom 2 double rollers, pulling, rubber - pneumatically pressed shafts ...

Part Number 6393 TECHNICAL DATA - max width of the workpiece 200mm - max height of the workpiece 150mm - number of spindles 4: 1) horizontal bottom 200mm 5,5kW 2) vertical right 150mm 4kW 3) vertical left 150mm 4kW 4) horizontal upper 200mm 5,5kW - all heads adjustable up/down, right left - spindle diameter 40mm - spindle speed 6000rpm in advance: - pulling introductory shafts, toothed 6 pcs including 2 double - 1 pulling shaft, rubber bottom: - introductory shaft toothed, pulling, torsional in the lower table top - side pressure 3pcs - lead roller, pulling, metal, smooth - all pneumatically pressed rollers - length of the introductory table top 2130mm - table top adjustable up / down - central lubrication - electrical setting of planing thickness - lifting motor 1,1kW - smooth regulation of the feed speed on the inverter - feed motor 3kW - feed  ...

GeneralUniversal machining centre; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal600 mmCross500 mmVertical500 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmDie and Mold Package linear incl. B-/C-TorqueDie and Mold Package linear incl. B-/C-Torque Dynamic package V-type Eagle timing belt for Z axis Torque table B-/C-axis including ATC AVD - Heidenhain or MVC - Heidenhain (starting NC 340590 11) APC and Top Speed - Siemens High End cooling unit for machiSpindle speed 20.000 rpm, HSK-A63Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min- ...

Fixed side at the left Panel thickness min/max: 16/45 mm Min. panel width: 150 mm Lateral panel support for panel width up to 900 mm Min/max. panel length: 700 / 3100 mm Max. laminate overhang: 110 mm Max. laminate thickness: 0,8 mm Radius min/max: 6 / 22 mm (depends the laminate) Feedspeed max. 18 m/min Top pressure by belt Equipment: Infeed fence, adjustable, defines the panel overhang 2 x trimming unit 0,4 kW, HSK 25 toolholder 1 x PVAc glue application 5 x glue nozzle, adjustable 1 x hot air blower 3 x IR heating on top (55 cm length), 3 x bottom (90 cm length) Postforming zone 1,8 m. length Various pre-installed profiling sets 1 x top trimmer 0,4 kW

Tenoning spindle: 2 St. Number of milling agregates: 7 St. Spindle diameter: 50 mm control: Weinig, PC-Nexus Weinig Unicontrol 12 with radial and axial CNC spindles as well as VARIO table and milling carriage Machine can be seen in use for a short time! Technical data summary (please inquire about any additional accessories included) crosscut saw > Electronic crosscut saw, horizontally infinitely adjustable > Number of tools: 1 piece. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Tool diameter max.: 400 mm > Motor power: 3.7 kW > Laser directional light to detect the saw section > Axial adjustment path 150 mm NC axis, electronically infinitely variable > Radial pneumatic adjustment path 8 positions for e.g. edge rounding from above Rounding aggregate > Position: horizontally below > Motor power: 1.5 kW > Spindle diameter: 20 mm > Tool clamping length: 25 mm > Spindle speed: ...

IMA complete bottling and packaging line for syrup-like products in bottles of 100ML-125ML-200ML-250ML, consisting of: 1. LIBRA Starpack 240 – bottle unpacker, 2. LIBRA Pharmaceutical Technologies MISTRAL Y16 – rotary bottle cleaner and blower, for dry cleaning of glass or plastic bottles with air jets, with a star wheel bottle transport. 3. IMA FARMOMAC F550 – machine for applying anti-drip rings, for bottles with a diameter of 16-80mm and a height of 40-270mm 4. IMA F540 – rotary filling machine with 12 filling heads, dosing capacity up to 300 ml., with star wheel infeed and outfeed for bottles with a diameter of 16-80mm and a height of 40-185mm, machine net weight approx. 2400kg. 5. IMA F572 – capping machine for tamper evident bottle caps (dosing cup, childproof, etc.) with 8 closing stations, for filled bottles with a diameter of 16-80mm and a height of 40-165mm, max. ...

I sell a double end cutting and milling machine FRIULMAC IDRAMAT, built in 2007. Working width up to 2500mm Configuration left side / fix: 1 + 1 pcs. cutting units top + bottom / 3.0 + 3.0 KW 1 + 1 pcs. groove saw units front + rear with jump Configuration right side / movable: 1 + 1 pcs. cutting units top + bottom / 3.0 + 3.0 KW 1 pcs. special milling unit on top / 5.5 KW Material pressure band with support from above. Special design, also suitable for side dimensioning. Continuous machine. Siemens Simantic control panel. Condition Very good. Available the same.

Special attachment for lathes gt; for reworking crankshafts - this attachment can be fixed on top of the cross-slide - via a pneumatic cylinder the top part of the attachment can tilt op to allow the crankshaft to be installed in the chuck - once the crankshaft has been installed in the chuck of the lathe the top part can be closed and positioned around the area that needs to be reworked - once activated the tool insert of the attachment will start turning around the crankshaft to remove excess material. The chuck does not have to turn the crankshaft! The advantage of this concept is that the tool moves around the crankshaft - by doing this the least amount of stress is put on the crankshaft. This in contrast to the classic setup where the stationary tool is pressed into a workpiece being turned by the chuck of the lathe. Max dia of crankshaft: 330 mm

– Italian production – year of manufacture 2007 TECHNICAL PARAMETERS: planing width 230 mm planing height 120 mm 1) horizontal bottom 230 mm 5.5 kW 2) vertical right 130 mm 3) vertical left 130 mm (2 and 3 spindle) 11 kW 4) horizontal top 230 mm 7.5 kW all spindles up/down, right/left spindle diameter 40 mm from above 3 insertion rollers pulling metal, swivel including 2 double pulling lead shaft from above, double rubber on the side, pressure 1 pc. in the lower table top a rubber pulling roller feed on cardan rollers pneumatic clamps infinitely variable feed speed 5-22 m/min feed motor 1,1 kW electrical setting of planing thickness lifting engine 0,37 kW introductory table length 2470 mm enclosed in the cabin central lubrication of the table top extraction pipe diameters 150 and 180 mm dimensions (L/W/H) 3650 / 1200 / 1600 mm wei ...

– German production – corrugated top – year of production 1996 – rollers in the countertop pulling TECHNICAL PARAMETERS: planing width 230 mm planing height 160 mm corrugated top spindle diameter 40 mm 1 bottom spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 11 kW 5 bottom spindle 7.5 kW smoothly adjustable feed 6-36 m/min feed motor power 5.5 kW six upper steel pulling rollers two top rubber pulling rollers three rollers in the countertop pulling pneumatic feed pressure pneumatic shoe pressure spindles with brakes length of the pre-worktop 1970 mm electric height adjustment central lubrication (split) connection diameter 140 mm dimensions of the machine (L/W/H) 410 / 200 / 180 cm weight ~ 3000 kg

– after technical inspection – year of production 1999 – chrome tops – electronic height setting TECHNICAL PARAMETERS: planing width 230 mm planing height 130 mm electric adjustment of the left head electric adjustment of the upper head electronic height adjustment five steel top rollers one top rubber roller spindle diameter 40 mm 1 bottom spindle 5.5 kW 2 right spindle 3 left spindle 7.5 kW 4 upper spindle 7.5 kW tool diameters 160 and 180 mm pneumatic clamps feed on cardan shafts smoothly adjustable feed 6-20 m/min feed motor power 2.2 kW chrome tops pre-table top length 1980 mm connection diameter 4 x 130 mm dimensions of the machine (L/W/H) 340 / 190 / 200 cm weight 2200 kg

– German production – year of manufacture 2002 –DTR TECHNICAL PARAMETERS: planing width 230 mm planing height 170 mm 1 bottom spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 7.5 kW 5 bottom spindle 7.5 kW 6 upper spindle 7.5 kW spindle diameter 40 mm electric height adjustment five steel top rollers four rubber top rollers pneumatic pressure table top length 1980 mm central lubrication feed adjustable on the inverter 6-26 m/min feed on cardan shafts feed motor power 4 kW connection diameter 140 mm machine dimensions (L/W/H) 520 / 210 / 210 cm weight 4000 kg

Order No. 6762 TECHNICAL DATA - max width of the workpiece 220mm - max height of the workpiece 130mm - 4 spindles: 1) horizontal bottom 220mm 5.5kW 2) vertical right 130mm 3) vertical left 130mm; (2 and 3 spindles) 11kW 4) horizontal top 220mm 7.5kW - all adjustable spindles up / down, right / left - diameter of the spindles 40mm - from the top 4 introducing, drawing, toothed rollers - from above, 1 pulling roller, rubber - at the bottom, a pulling shaft, rubber - feed on cardan shafts - smooth regulation of the feed speed - 1.5kW feed motor - lifting motor 0.25kW - electric adjustment of the planing thickness - length of the introductory top 1970mm - central lubrication - diameter of the extraction connector 3x120mm, 140mm - locked in the cabin - dimensions length / width / height 3350x1400x1430mm - weight about 1500 kg - German production - unpainted - us ...

Booster pump, CR8-140 A-F-A-AUUV, 9,5m³/h, 120m, Grundfos, used Top Used Top! The high quality part comes from a spare parts warehouse of a mechanical processing of a large car manufacturer. The pump is in top condition. Electric motor Function guarantee! For parts from second hand we can not take over conventional guarantee and warranty. But we give you a function guarantee. If the device does not work in the course of commissioning, you can return the goods and we will refund the purchase price.

Four-sided planer WEINIG PROFIMAT 22N. No 4 –DTR – German production – year of manufacture 1988 – adjustable heads TECHNICAL PARAMETERS: planing width 220 mm planing height 120 mm spindle diameter 40 mm 1) bottom head 5.5 kW 2) head of the law 3) left head 7.5 kW 4) top head 7.5 kW feed engine 2.2 kW feed speed 6 – 20 m/min four steel top pulling rollers one upper rubber pulling roller one pulling roller in the countertop feed on cardan shafts electric height adjustment pre-table top length 1975 mm central lubrication pneumatic clamps dimensions of the machine (length / width / height) 350 / 200 / 170 cm weight ~ 1800 kg

Packaging machine Beck Fitpacker Junior FJ 1040 U - Used equipment built in 1995 - small repairs necessary The Fitpacker Junior has a high packing performance and can process products of different lengths in disorder. A programmable logic controller is located at the top of the control cabinet and is easy to handle via a logical user interface. The packer also has a feeding system, which is especially suitable for line operation. Machine changeover times are kept short by a digital operating concept and an adjustable shape shoulder. The control cabinet can be opened and swivelled so that optimal access is guaranteed in the event of maintenance and downtimes are reduced. The film roll holder is mounted at an ergonomically reasonable working height. Working speed: Actual production speed and effective net output depend on format, Type and composition of products and can ...
