swarf used for sale

turning diameter: 300 mm turning length: 710 mm control: SIEMENS SINUMERIC 840 total power requirement: 40 kW weight of the machine ca.: 6000 kg dimensions of the machine ca.: m I N D E X (Germany) CNC Controlled Slant-Bed Chuck Lathe with Turret and Tailstock and INDEX CNC Control C 200 – 4 (SIEMENS) Model G 300 Year 1995 S/N 5000 65 _____________________________________________________________ Turning - Ø, with chuck, max. 300 mm Spindle bore 90 mm Max. Workpiece Swing dia. 400 / 590 mm Turning length / travel of turning slide, (X-Achse) max. 710 mm Turret head slide cross movement (Z-Axis) max. 140 mm Turret with 12 tool holder positions DIN 30 mm Feed range of turret slide / Quickfeed 0,1 - 20 m/Min. Feed Force of X/Z-Axis 8 – 13 kN Steplessly a ...

: 820 mm saw band length: 8200 mm cutting width: 850 mm : 850 x 820 mm : 820 x 820 mm : 480 mm : 480 x 480 mm Capacity 45° rectangular: 480 x 820 mm table height: 585 mm cutting speed: 20 - 100 m/min dimensions of saw-band: 8200 x 54 x 1,6 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 9,4 kW weight of the machine ca.: 3,43 t dimensions of the machine ca.: 3,9 x 1,2 x 2,35 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. ?inverter ?hydromechanic blade tension ?swar ...

dimensions of saw-band: 3650x27x0,9 mm speed: 15-100 m/min vice: 335 mm capacity 90 degrees: round: 300 mm capacity 90 degrees: square: 260 mm capacity 90 degrees: flat: 330x260 mm capacity 45 degrees: round: 260/200 mm capacity 45 degrees: square: 250/180 mm capacity 45 degrees: flat: 270x200/200x160 mm capacity 60 degrees: round: 180 mm capacity 60 degrees: square: 170 mm capacity 60 degrees: flat: 170x170 mm total power requirement: 2,2 kW weight: 1.105 kg dimensions: 2700x2300x1800 mm Fully automatic electro-hydraulic band saw with multi-micro processors and additionally semi-automatic, semi-automatic-dynamic and manual Function. - Automatic cycle (cuts from 0 ° to 60 ° link). CNC machine with two controlled axes that allow for the same material thickness 1000 various editing programs, each with a different cutting length and quantity, too program. - Semi-automatic, semi-automatic- ...

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine, 3 clamps ? Maintenance free drives ? Repositioning device with programmable presser foot ? Parts chute 500 x 500 mm ? Good parts container ? Swarf bucket Cutting head ? Hydraulic punching head ? Single tool adapter ? 360? rotation of all tools ? Programmable presser foot ? Tool length compensation ? Spray lubrication for punches ? Vacuum slug removal ? Forming Control ? Open control system based on BOSCH ? Control panel with TFT colour screen 12.0? ? Program management ? Online-help ? Integrated technology data ? Diagnostic functions ? Teleservice Programming ? Machine-oriented shopfloor programming Data transmission ? Disc drive and network connection Safety ? CE marking ? Light barriers ? Rapid hydraulic shutdown Additional equipment ? Function Mul ...

Key data: 380 mm, 500 mm, 4500 1/min

Machine Details Stock-No. 1105-03994 Type of machine CNC Lathe Make GOODWAY Type GA 200 Year of manufacture 2002 Type of control CNC Storage location FRANCE Country of origin JAPAN Delivery time immediately Freight basis EXW -free on truck Technical details turning diameter 500 mm turning length 500 mm Control Fanuc 18 T greates pass round over bed 380 mm centre distance 500 mm X-Travel Plan Top 210/ mm Z-Travel longitudinal 520 mm Spindle Bore 65 mm turning speeds 4500 rpm total power requirement 21 kVA Weight of the machine approx. 3.5 t Additional information equipment: with out chuck 2 star turret with 12 tool stations coolant basin, measuring arm Swarf Conveyor transformer (L:1,0xB:0,46xH:0,86m) machine can be demonstrated under power

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine with 17 tool stations, 2 clamps ? Drives with maintenance free 3-phase servo motors ? Repositioning unit with programmable stripper ? Ball tables ? Parts chute 180 x 150 mm ? Swarf bucket ? Punching head ? Hydraulic punching head ? Rotatable single tool adapter ? 360? rotation of all tools ? Programmable presser foot ? Tool length compensation ? Spray lubrication for punches ? Vacuum slug removal ? Forming Control ? Controller based on Bosch PNC-P ? Control panel with 15 TFT color touch screen ? Easy to use ? Online-help ? Integrated USB interface ? RJ 45 network connection ? Diagnostic functions Safety ? CE marking ? Light barriers ? Rapid hydraulic shutdown Additional equipment ? Function Multitool ? Function MultiShear ? Function Roller Technology ?  ...

Standard configuration ? Stable C-frame ? Coordinate guide with integrated linear magazine, 18 tool stations, automatic tool changer, 3 clamps ? Automatic parts chute 500 x 500 mm ? Parts container ? Drives: Maintenance-free, three-phase servo motors ? Programmable presser foot for repositioning ? Punching head: Hydraulic single tool adapter, 360? rotation of all tools, automatic tool length compensation, spray tool lubrication, 2nd lubricant container, programmable stripper movement, vacuum slug removal, swarf bucket ? Control: 32 bit microprocessor control TRUMAGRAPH CC 220 S, 10.4 color screen, programmable logic controller, easy to use, diagnostic functions, graphic programming TRUMAGRAPH, integrated 3.5 disk drive, RJ45 network connection ? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdown Additional equipment ? Function MultiTool ? Pneumatic repositioning  ...

Standard configuration ? Stable C-frame ? Coordinate guide with integrated linear magazine, 11 tool stations for tools and clamps ? Drives: Maintenance-free, digital three-phase servo motors ? Punching head: Hydraulic system with closed control loop, single tool adapter, 360? rotation of all tools ? Automatic repositioning device with programmable presser foot ? Vacuum slug removal ? Swarf bucket ? Brush tables ? Parts chute 200 x 200 mm and sorting of parts into 2 containers ? 2 parts containers ? Controller BOSCH Type 3, activity-oriented user interface, Online help, diagnostic functions, 3.5 disk drive, BNC/RJ45 connection, TFT color screen 10.4 ? Graphic programming ToPs 2000 ? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdown Additional equipment ? MultitShear ? MultiBend ? SoftPunch ? Table extension ? Start post

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine, 21 tool stations, 3 clamps ? Drives with maintenance free 3-phase servo motors ? Repositioning unit with programmable stripper ? Ball tables ? Sensor-monitored parts chutes 500 x 500 mm for punching and laser station, ejection cylinder on the laser chute ? 2 Good parts containers ? AutoLas TRUMPF Laser ? Laser unit: TruFlow 2700 CO2-Laser ? Radio-frequency excitation ? Chiller unit ? Laser control: TASC 3 ? Encapsulated beam delivery Cutting head ? Cutting head with 5.0 and cutting head with 7.5 lens focal length ? Cutting head quick-change device ? Programmable cutting gas pressure ? DIAS ? ContourLas Punching head ? Hydraulic punching head, 360? rotation for all tools ? Programmable presser foot for repositioning ? Tool length compensation ? Vacuum slu ...

Standard Configuration ? Stable C-frame ? Coordinate guide with integrated linear magazine, 19 tool stations,2 clamps ? Drives: Maintenance-free, three-phase servo motors ? Programmable presser foot for repositioning with preselectable pressing force ? Sensor-monitored part chutes 500 x 500 mm for punching and laser station, ejection cylinder on the laser chute ? 2 good parts containers ? Laser unit: CO2 laser TLF2700, radio-frequency excited, insulated against vibrations, integrated in machine frame, incl. chiller, and laser control DIAS 3 ? High speed processing with SprintLas ? ContourLas for producing small holes ? Programmable cutting gas pressure setting ? Punch stroke / thread counter ? Laser cutting head: 5? lens, quick-change device, height regulation APC ? Additional laser cutting head with 7.5? lens ? Punching head: Hydraulic single tool adapter, 360? rotation of all tools,  ...

6 spindle bar automatic Gildemeister GS20, compound slide with drive in pos. 1, compound slide with drive in pos. 2, compound slide in pos. 4, compound slide in pos. 5, 4x axial spindle (pos. 1, 2, 4, 5), rotating milling device in pos. 3, pick-up spindle pos. 6, swing rear machining arm drive in pos. 3, swing rear machining arm drive in pos. 6, swarf coneveyor, worm type, set of tool holders, set of cams, Number of spindles: 6, Max bar diameter [mm]: 20, Max bar feed [mm]: 100, Spindle speed [rpm]: 214 - 5.168, Spindle motor [kW]: 11, Weight of the machine ca. [kg]: 5.000, Auto bar loader: Pietro Cucchi

Machine Details Stock-No. 1105-03848 Type of machine Machining Center - Vertical Make DMG DECKEL MAHO GILDEMEISTER Type DMU50 evolution Year of manufacture 2000 Type of control CNC Storage location from location Country of origin Germany Delivery time by arrangement Freight basis from location, free loaded Price Technical details X-Travel 500 mm Y-Travel 380 mm Z-Travel 380 mm turning speeds 20 - 18 000 rpm spindle taper ISO SK 40 DIN 69871 control Heidenhain MILL PLUS rapid travel x/y/z 30 000 mm/min surface area 500 x 380 mm number of T-slots 7 pieces tool length from spindle nose 280 mm weight of the machine approx. 6 t total power requirement 36 kVA Additional information 3 axis B-axis, C-axis control Heidenhain MILL PLUS magazine places: 32, space requirements with swarf conveyor: about L:3,0:W:2,53xH:3,15m Machine still is placed at the customer  ...

Machine Details Stock-No. 1105-03856 Type of machine CNC Lathe Make COLCHESTER Type TORNADO T 6M Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Great Britain Delivery time immediately Freight basis EX WORK Technical details turning diameter 440 mm turning length 450 mm control FANUC 21 ITB total power requirement 15 kW Weight of the machine approx. 4 t Additional information NICE COLCHESTER T 6M FROM 2006 FANUC 21 ITB CUCK TAILSTOCK SWARF CONVEYOR VDI 30 TURRET 12 P LIVE TOOLS BARFEEDER MBF 1000 INCLUD

MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...

Chiron FZ15KS HIGH SPEED, 4 axis vertical machining center, X: 550mm, Y: 400mm, Z: 360mm, 4th axis original Peiseler 360.000 pos, CNC Siemens 840D, Table 1050 x 450mm, Toolchanger 48 pockets, ISO 40, Spindle 12000 1/min, Renishaw tool control, Coolant through spindle, Hydraulic clamping, Swarf conveyor, Under power in our warehouse in Gussago BS, Mimu machine tools, Spindle: 12000 RPM, 4th axis: 360 000 pos

MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...

x-travel: 400 mm y-travel: 250 mm z-travel: 400 mm tool taper: ISO 40 spindle turning speed range: 30-6300 / 20-4200 U/min feeds: 0 - 10.000 mm/min quill stroke: 90,0 mm table-size: 600 x 320 mm T-slots: 5 x 14 x 63 mm Control: TNC 410 CA spindle: ein ~ 126 Std. engine output: 11,0 kW weight: 1300 kg dimensions of the machine ca.: 1600 x 1500 x 1900 mm Original price incl. special accessories ~ 72.000 euros Machine was very rarely used () with only approx. 126 spindle hours (spindle on) Furnishing : - MACMOM / INAS CNC universal milling and drilling machine - HEIDENHAIN CNC path control TNC 410 CA workshop-oriented path controls, with Programming in easy-to-understand plain text dialog HEIDENHAIN electr. Remote control with handwheel - Pivoting control panel, to the right of the machine - hydraulic tool clamping (tie bolt DIN69872-A) - Vertical milling head rotating on both sides - ...

TRUMPF TruPunch 3000-1300 (S11) punching machine was built in Germany in 2013. The reliable machine with extensive equipment and modern components offers its user unparalleled precision and accuracy in machining both thick and thin sheet metal. In addition to standard punching and marking, the punching machine also allows fast grooving, surface embossing, forming and chipless threading in stainless steel, structural steel and aluminium. On the machine’s sturdy and welded C” shaped structure, sits a specially designed brush table with integrated balls, designed to facilitate the loading and unloading of workpieces. The use of this type of table prevents scratches and nicks from appearing on the surface of the sheet, which results in a significant increase in the quality of the machining. During the entire production process, the sheet is held rigidly by hydraulic clamps fixed to th ...

Key data: 1050 mm, 510 mm, 510 mm

Machine Details Stock-No. 1105-03920 Type of machine Machining Center - Vertical Make MORI SEIKI Type NV 5000 B / 40 Year of manufacture 2004 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time on request Freight basis ex location Technical details x-travel 1050 mm Y-Travel 510 mm Z-Travel 510 mm Control FANUC MSG 501 turning speeds 12000 rpm tool change unit 30 table-size 1100x600 mm Drive 18,5/11 kW tool taper BT 40 transmission ratio 1 spindle diameter in front bearing 65 mm table load 1000 kg T-slots 6x18x100 mm distance spindle /table 150-660 mm max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool weight 8.0 kg Change-time tool to tool approx. 1.0 sec Change-time chip to chip approx. 2.6 sec Rapid Traverse 42 m/min feed speeds 1-6000 mm/min total power requirement 48 kVA Weight of the mac ...

Key data: 400 mm, 760 mm

Machine Details Stock-No. 1105-03941 Type of machine CNC Turning- and Milling Center Make DOOSAN daewoo Type PUMA 2100 lm Year of manufacture 2012 Type of control CNC Storage location FRANCE Country of origin Korea Delivery time by arrangement Freight basis ex. location Price Technical details turning diameter 406 mm turning length 830 mm control FANUC Travel -X Axis 260 mm Travel -Z Axis 830 mm Rapid Travel - Longitudinal/Face 24 m/min C-axis 20 min-¹ Spindle Bore Diameter 76 mm spindle drive 18.5 kW Milling Spindle Motor 7.5 kW Spindle Speed: 4500 min-¹ Number tool positions lower turret 12 Stations which are driven 12 total power requirement ca 40 kVA Weight of the machine approx. 7000 kg dimensions of the machine approx. 3.5 x 2.3 x 2.2 m Additional information PUMA 2100 LM - Control FANUC - Spindle bore 76 - SPINDLE 1 CHUCK 25 MM 18.5 KW 4500 RP ...

CNC multi spindle bar automatic, Gildemeister GMC 35 ISM, - 6 integretat spidles with C-axis, - 5 compound slides pos. 1; 2; 3, 4; 5;, - intipendend feed for central block, - douple slide in pos. 6, - pick-up spindle in pos. 6, - 5 frontal spindles, rotating, with internal coolant supply, ISO 40, - swarf conveyor, - Fire fihthing system CO2, - ARTIS tool breakage control system, Stangenlademagazin :, Cucchi Pietro PB 41 Compact, Country of origin: Italy, Control: Siemens 840D, Operating hours: 56.000, Number of spindles: 6, Max bar diameter [mm]: 35, Spindle speed [rpm]: 6.000, Spindle motor [kW]: 21, Total power requirement [kVA]: 107, Auto bar loader: Cucchi Pietro PB 41 Compact

CNC bar lathe Gildemeister CTX 300 with Y axis Fanuc CNC model 16i - T Main spindle nose ASA 6 Main spindle power 12 Kw Main spindle hole 60 mm Turning diameter 230 mm Turning length 500 mm Number of RPM main spindle 5000 Number of tool holder turrets 1 Number of tools 12 Number of live tools 12 tool attachment type VDI 30 X-axis travel 160 mm Y axis travel + - 32 mm Z axis travel 500 mm Rapid feeds X Y Z 24 m/min Sub-spindle yes ASA 5 spindle nose Sub-spindle RPM 5000 / 9 Kw Sub-spindle hole 30 mm Iemca bar loader Swarf conveyor 2002 The machine can be seen working in our warehouse in Gussago BS.

3000 B CNC circular saw blade grinding machine was built in 2023 in Poland. The brand-new machine, equipped with intuitive software and a CNC controller with memory for 128 programmes, is used to sharpen the following types of circular saws, mainly used in the furniture industry for cutting laminated chipboard: – flat circular saws (GM) – alternately mitre circular saws (GS) – trapezoidal circular saws (GB) – trapezoidal-flat circular saws (GA) The 3000 B CNC circular saw sharpener allows for grinding tooth rake angles and tooth face angles in a single pass without removing the saw blade. The grinding wheel arrives at the tooth plane at two feed speeds – the slower feed increases grinding precision, while the faster one reduces sharpening time by up to half. To ensure precise feeding of the tooth under the grinding wheel, a claw feeder is used, which prevents the grindin ...

Gildemeister GD 16-5 - Top condition!, - Synchronized Guide bush, - 3off life tools slide 1, - rear working, - swarf conveyeor, - oil mist filter, - bar loader Iemca Smart 316

Sinumerik 810M GA3 Basket tool changer: 20 x SK30 Tool change under 2 seconds. Spindle Max: 10500 rpm Table size: 2x (660mm x 350mm) Axes travel: X= 550mm Y= 300mm Z= 425mm B= 360 degrees (4th-axis) Under rotary table on the left: Yes. Coolant unit with Knoll swarf conveyor. Weight: 4000Kg CRT screen was upgreaded to TFT. Equiped with 1x 4th axis

It’s had very little use over the last few years. Has to be the most productive machine in its class. YOM: 2001 Control: Fanuc 21iM Spindle: 15000 RPM Swarf Conveyor Includes all spindle tooling and custom Microloc work holding bases & clamps (as seen in the photos). We have all the manuals, operation, programming, maintenance, spares and electrical.

Mazak Integrex 200-IV ST Ø 660 x 1500 mm Control Unit: Mazatrol Matrix Maximum turning diameter : 660/260 mm Maximum turning length : 1.495 mm Milling spindle speed : 12.000 rpm Main spindle maximum speed : 5000 rpm Subspindle maximum speed : 5000 rpm ATC 40 Capto C6 system 9-station turret swarf conveyor 2 Stck. 3-jawchuck Kitagawa B-208 5-axis simultaneous Full C-axis sub spindle Flash-Tool Synch. MillTapp Gear Hobbing CE-Zeichen Come with tools purchased

DUGARD EAGLE 660 VMC CNC machining centre built in 2007 in Taiwan, is used for precision milling, drilling, threading, boring and reaming of workpieces with rotary tools. The machine, with its extensive machining capabilities, is distinguished by its extremely stable base, which provides rigidity and support for the guideways on which the X,Y,Z axes are guided. To ensure a high level of safety, specially designed sliding guards protect the operator from moving parts, coolant and workpiece fragments. All the processes, from tool selection to the machining cycle, are performed fully automatically by the milling centre. The implemented SIEMENS SINUMERIK 810 D CNC control minimises the operator’s handling of the machine, while the capacious 24-position magazine selects the shortest possible access path to the tool. This solution increases production efficiency while significantly reduci ...

Gildemeister GMC20 ONE, Options / Accessories, - 5 Cross-slides pos. 1;2;3;4;5, - 2 Radial slides pos. 6 for cutting and rear-working operations, - 1 C-axis for the pick up spindle, - Pneumatic work-piece unloading chute for pos. 6, - Work-piece conveyor belt, - Swarf conveyor, worm type, - 5x Frontal tool spindle, fix, - Pick- up spindle in pos. 6, - High pressure coolant device 70l / 50bar, Country of origin: Italy, Control: Siemens 840D, Number of spindles: 6, Max bar diameter [mm]: 25, Spindle speed [rpm]: 6.000, Spindle motor [kW]: 9,1, Z - travel [mm]: 70 / 140, Total power requirement [kVA]: 98, Weight of the machine ca. [kg]: 9.800, Auto bar loader: Cucchi Giovanni DBM.625

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface900 x 560 mmDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z600/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque82 NmTorque (100% DC)54 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmMaximum load (table centre)600 KgWeight approx.5200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hSafety Package for Power FailureSafety Package for Power ...

Mori Say TM626 AC, 5 axial slides, 4 cross slides, double slide pos. 6, pickup spindle, swarf conveyor with vibrating filter device, high pressure coolant system, set of tool holders, auto bar loader L = 3 m, Country of origin: Czech Republic, Number of spindles: 6, Max bar diameter [mm]: 26, Spindle speed [rpm]: 500 - 6.000, Spindle motor [kW]: 20, Total power requirement [kVA]: 40, Weight of the machine ca. [kg]: 5.500, Auto bar loader: Iemca PRA 52/32 P

Control model: T - I Distance between Centres: 3000mm Swing Over Bed: 840mm Tool Turret Vertical: 8 Tool Turret Horizontal on Saddle: 4 Diameter Forkardt Chuck: 610mm (3) x Fixed Steadies up to: 430mm Powered Tailstock Rear Swarf Conveyor Hydraulic Pack Spindle Motor and Transformer Machine photos : workdrive.zohoexternal.com/external/095d10894a930f82961d3848e923ca59ea 41ff8cb0da13021715cab758adfb2b

4 axes X-way 600 mm Y-path 450 mm Z-path 450 mm A 360° Control Heidenhain TNC 430 M IKZ package 16000 revolutions HSK-A63 Chip conveyor Electronic manual control module Renishaw measuring probe system Electr. thermal expansion compensation Swarf pistol New spindle cooling and various others

XYZ EMX EMILL 2000 Year 2008 Proto TRAK EMX 2 -axis control Table 1,270 x 254mm Table travel 750 x 380mm Quill travel 127mm Spindle taper R8 Spindle speeds 60-4,200rpm Spindle drive motor 2.2 kW (3 HP). Manual operation/CNC cycles Interlocked table guards Automatic lubrication Low volt light, Coolant Swarf tray Excellent condition

Machine is in good working condition • Control unit: FANUC 18-T • Year : 1998 • Double Mirror: 8 and 6 inch available • C Axis: Available • Magazine: 12 sets • Machining Diameter Max. : Ø350x640mm • Spindle Diameter: Ø60mm • Conveyor: Available this extra information is standard for this model. Please always double-check the details during a visit The Doosan DOOTURN 310TML CNC lathe, manufactured in 1998, continues to stand as a reliable and efficient machine for precision turning operations. Equipped with a FANUC 18-T control unit, this lathe offers advanced control capabilities for precise and versatile machining tasks. Featuring a double mirror configuration with 8 and 6 inch options, the DOOTURN 310TML provides flexibility in accommodating a wide range of workpiece sizes and configurations. The availability of a C-axis further enhances its machining ...

x-travel: 650 mm y-travel: 650 mm z-travel: 680 mm Control: Siemens 840 D sl size of pallet: 500 x 400 mm table load: 500 (600) kg tool taper: HSK-A63 spindle turning speed range: 50 - 10000 U/min rapid travel x/y/z: 65/65/65 m/min no. of tools in the magazine: 80 Stück Tool diameter: 160 mm tool length - max.: 350 (400) mm spindle motor: (S6) 32,4 kW weight of the machine ca.: 12,8 t dimensions of the machine ca.: 6,2 x 3,9 x 3,95 m CNC-control SIEMENS Sinumerik 840 D sl 80-pos. ATC 2-pos. pallet changer NC-rotary table Increased spindle torque up to 259 Nm Coolant equipment with paper band filter Coolant through spindle 80 bar Swarf conveyor Max. workpiece diameter: 750 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This CHIRON DZ15W MAGNUM HS Vertical Machining Centre was manufactured in 2015. It is equipped with a FANUC Series 31i-model B5 control unit, has 4 axes and a 12000 rpm spindle. The machine comes with swarf conveyor, tooling, coolant / paper filtration unit, high pressure coolant and pallet.

This 5-Axis vertical machining centre was manufactured in 2014. The DMG MORI DMF 260/11, equipped with a Heidenhain iTNC 530 HSCI control, boasts a rigid table with an integrated rotary axis, offering precision and versatility. With a swivel head and 10,000 rpm B-axis spindle, it ensures efficient machining of complex parts. Additional features include an infrared measuring probe for accurate measurements and a spray gun for swarf removal. Experience enhanced productivity with this reliable machine center. Contact us for further information.

Description: Highlights CN HEIDENHAIN Spindle speed rotation max: 6000/5000 rpm Power-on time: 30981h Working hours: 7998h Bar feeder SAMSYS+ Type M300 YOM: 2010 , Dimensions of bar feeder: 1900x1000x1400mm - Optimum machining of compact workpieces up to 410 mm turning diameter - Generously dimensioned modules (size 45 guideways), high stability, long service life - New design for optimum ergonomics, with large windows for optimum visibility in the work area and of the machining in progress - X-axis glass ruler for maximum precision - Direct measuring system (no need to move the reference point) - C-axis tailstock and driven tools as standard - User-friendly ERGOline Contro CNC with 19''-TFT Wide Screen, DMG SOFTkeys freely available Basic machine: CTX beta 800 Universal 2-axis lathe, Turning length 800mm - Main spindle: integrated motor spindle - Drive power 25/34 KW (100/40% ...

x-travel:600 mm y-travel:700 mm z-travel:600 mm control:TNC 426 HEIDENHAIN toolpiece magazine: chain magazine:30 Pos. milling spindle - taper:SK 40 turning speeds:12000 1/min rapid traverse:24 m/min weight of the machine ca.:9,5 t 5-axis universal machining center, NC-rotary-table, B-axis (milling head) Swarf conveyor,

x-travel:650 mm y-travel:600 mm z-travel:500 mm rotary table::630 PW800 mm table load:600 kg spindle turning speed range:18.000 1/min drive capacity - spindle motor:15 / 10 kW control:SIEMENS 840D shopmill feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse:45 m/min Tool changer:189 (32+157) Pos. spindle taper ISO:HSK A-63 weight of the machine ca.:9,5 t total power requirement:43 kVA 5-axis simultaneously universal-machining center, with NC-rotary-swivelling-table A-axis +30/-115° (25 1/min), C-axis 360° (65 1/min), internal coolant supply 80bar, 1.000 l, airblast through spindle, cabin roof manually, 3D touch probe RENISHAW, chipconveyor, el. compensation of thermal expansion SIN, 3D toolradius-correction SIN, el. handwheel, BLUM laser, flushgun, oilmist suction, wiper for spindle head, swarf-flushing Z-slide, approx. 23.000 h "spindle on", last spindle change at 13.400h ...

x-travel:650 mm y-travel:600 mm z-travel:500 mm rotary table::280 PW 160 mm table load:300 kg spindle turning speed range:18.000 1/min drive capacity - spindle motor:15 / 10 kW control:SIEMENS 840D shopmill feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse:45 m/min Tool changer:119 (32+87) Pos. spindle taper ISO:HSK A-63 weight of the machine ca.:9,5 t total power requirement:41 kVA 5-axis simultaneously universal-machining center, with NC-rotary-swivelling-table A-axis +-115° (25 1/min), C-axis 360° (40 1/min), internal coolant supply 80bar, 1.000 l, airblast through spindle, pallet pool (PW 160, totally for 7 pallets, size 500x500mm, without pallets, cabin roof manually, 3D touch probe RENISHAW, chipconveyor, el. compensation of thermal expansion SIN, 3D toolradius-correction SIN, A-axis eccentric 262,5, el. handwheel SIN, BLUM laser, flushgun, oilmist suction, wiper f ...

x-travel:650 mm y-travel:600 mm z-travel:500 mm rotary table::280 PW 160 mm table load:300 kg spindle turning speed range:18.000 1/min drive capacity - spindle motor:15 / 10 kW control:SIEMENS 840D shopmill feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse:45 m/min Tool changer:119 (32+87) Pos. spindle taper ISO:HSK A-63 weight of the machine ca.:9,5 t total power requirement:41 kVA 5-axis simultaneously universal-machining center, with NC-rotary-swivelling-table A-axis +-115° (25 1/min), C-axis 360° (40 1/min), internal coolant supply 80bar, 1.000 l, 2-pallet changer, pallet pool for 4 pallets, airblast through spindle, cabin roof manually, 3D touch probe RENISHAW, chipconveyor, el. compensation of thermal expansion SIN, 3D toolradius-correction SIN, A-axis eccentric 262,5, el. handwheel SIN, BLUM laser, flushgun, oilmist suction, wiper for spindle head, swarf-flushing  ...

x-travel:2600 mm y-travel:700 mm z-travel:700 mm table surface area:2900 x 700 mm rotary table diameter:750 mm table load:500 kg control:HEIDENHAIN iTNC 530 turning speeds:20 - 14.000 1/min taper ISO:HSK 63 tool change unit:60 Pos. rapid traverse:40 m/min spindle:19 / 14 kW total connected load:56 kVA weight of the machine ca.:16 t dimensions of the machine ca.:6,5 x 3,4 x 3 m 5-axis simultaneously universal machining center, rigid table with integrated NC-rotary table (left) and B-axis in milling head, direct measuring system, Swarf Conveyer, 3D Touch probe HEIDENHAIN TS 649, el. handwheel, internal coolant supply 40 bar, Flush gun, mode 4, partition in working area (removable) safety device (for power failure), tropical package, reading hours: approx. 28.000 h "machine on" approx. 12.000 h "spindle on"

x-travel:2600 mm y-travel:700 mm z-travel:700 mm table surface area:2900 x 700 mm rotary table diameter:750 mm table load:500 kg control:HEIDENHAIN iTNC 640 turning speeds:20 - 15.000 1/min taper ISO:SK 40 tool change unit:120 Pos. rapid traverse:40 m/min spindle:23,5 / 13,5 kW total connected load:56 kVA weight of the machine ca.:16 t dimensions of the machine ca.:6,0 x 3,4 x 3,0 m 5-axis simultaneously universal machining center, installation date 6th December 2018 rigid table with integrated NC-rotary table (left) and B-axis in milling head, direct measuring system, Swarf Conveyer, 3D Touch probe HEIDENHAIN TS 649, el. handwheel, internal coolant supply 40 bar, Flush gun, mode 4, safety device (for power failure), ERGOLINE control 19" reading hours: approx. 25.500 h "machine on" approx. 7.500 h "program on" approx. 8.100 h "spindle on"

mobile finest oil filtering technology, new The mobile ultra fine filter system M 130 is the flagship among the mobile filter systems. Equipped with a scalper, a (washable) pre-filter for coarse impurities (up to 5 µm, for example swarf), and two C-1000 housings, this system leaves nothing to be desired in order to process technical oils, water-/ oil- or oil-/water emulsions to excellent purities. The scalper and the pre-filter increase the life service of your systems and the filter elements significantly due to the two-stage pre-filtration. This is followed by the oil processing with the reliable ultra fine filter elements which are also used in space travel. You achieve purity values up to NAS 1 (ISO 4406: 13/10/7) and better technical data M 130 flow oil: bis 1.050, 1.500, o. 2.100 liter/hour dimensions: height: ca. 1.175 mm, width: 585 mm, depth: 811 mm weight: ca. 93 kg Please, c ...
