122,472 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
Clamping force kN 2400 Mould thickness mm 460-800 Opening stroke mm 0-510 Distance between tie-bars V/H mm/mm 630/630 Stroke, injection unit mm 550 Nozzle contact force KN 78 Screw diameter mm 60 Injection pressure bar 1534 Max. injection volume cm3 565 ø centring ring mm 160 ø mould release bar (=standard) mm M16-M20 Max. cylinder temperature °C 400 SW release bar mm 32 - 36 - 41 ø clamping screw M20 Robot Yes
used
Clamping force kN 2000 Mould thickness mm 200-500 Minimum mould diameter mm 315 Opening stroke mm 200-480 Distance between tie-bars V/H mm/mm 510/430 Stroke, injection unit mm 470 Nozzle contact force KN 75 Screw diameter mm 55 Injection pressure bar 1751 Max. injection volume cm3 465 ø centring ring mm 125 ø mould release bar (=standard) mm M16-M20 Max. cylinder temperature °C 400 SW release bar mm 32 - 36 - 41 ø clamping screw M16 Robot Yes
used
Closing force: 50 T Opening stroke: 400 mm Between columns: 500 mm x 450 mm Tray dimensions: 500 mm x 450 mm Mini/maxi mould: 200 mm Max gap between trays: 600 mm Injection: Screw diameter: 25mm Screw length: 20D cm3: 45 Bars: 2400 General: Motor power: 15 kW Heating power: 5.3 kw Closing weight: 3T
used
BMB 1000 T injection press Reference: 7500/100 Closing force: 1000 T Screw diameter: 110 mm L/D ratio: 22 Maximum material pressure: 1600 bars Injectable volume: 4650 cm3 Injectable weight (PS): 4400 g Injection speed: 2350 cm3 / sec Dimensions of the trays: 1660 x 1560 mm Distance between columns: 1110 x 1010 mm Machine weight: 62,000 kg
used
INJECTION UNIT Screw diameter: 35 mm Calculated injection volume: 139 cm³ Length / diameter ratio: 23 L / D Max injection rate: cm³ / s Pressure on the material: 2500 bars Laminating capacity PS: Kg / h Screw Speed: 58 RPM Hydraulic motor torque: 560 Nm Hydraulic Motor Power: HP Nb Temperature Zones: N CLOSURE UNIT Closing force: 1300 kN Opening stroke: 650 mm Thickness Mold Mini / Max: mm Max distance between plate: mm Passage between columns: 470 x 470 mm Tray size: 715 x 715 mm GENERAL Heating power: 22 kW Total installed power: 38 kW Amount of oil: 260 l. Dimension: (WxHxD) m. Weight: 6380 Kg
used
Manufacturer : ENGEL Model: VICTORY 200-45T Year of manufacture: 2005 Number of hours: 42500 h Closing force: 45 T Control Type: CC100 Opening stroke: 400 mm Distance between columns: 500 x 450 mm Tray dimensions: 500 x 450 mm Mini/maxi mould: 200 mm Max gap between trays: 600 mm Screw diameter: 25mm Screw length: 20D Injection volume: 69 cm3 Injection pressure: 2400 bar Motor power: 15 kW Heating power: 12 kW Closing weight: 2.9 T Dimensions length: 3.4m Dimensions width: 1.3 m Dimensions height: 1.80 m Cores: 0 robot interface Bi-metal
used
Manufacturer : Sandretto Model: 300T 860 NOVE S Year of manufacture: 2004 Screw diameter: 50 mm Calculated injection volume: 475 cm³ Length/diameter ratio: 20 L/D Maximum injection rate: 193.2 cm³/s Pressure on the material: 1815 bars Plasticising capacity PS: 32.7 Kg/h Screw Speed: 295 RPM Hydraulic motor torque: 1128 Nm Temperature zones: 3 + 1 N Closing force: 3000 kN Opening stroke: 630 mm Mini /Max Mold Thickness: 210-730 mm Max distance between tray: 30 mm Passage between columns: 570 x 570 mm Dimensions of the trays: 860 x 860 mm Heating power: 30 kW Total installed power: 44.20 kW Oil quantity: 350 l.
used
Manufacturer : BILLION Model: 50T H310 Year of manufacture: 2000 Number of hours: 30600 h Type of control: DIXIT 1 Closing force: 50T Opening stroke: 270 mm Distance between columns: 580 x 520 mm Tray dimensions: 580 x 520 mm Mini/maxi mould: 180/360 mm Max gap between trays: 630 mm Screw diameter: 35 mm Screw length: 20D Injection volume: 168 cm3 Injection pressure: 2025 bar Engine power: 15KW Heating power: 9.4 KW Closing weight: 3.4 Tn Dimensions length: 3.5m Dimensions width: 1.17 m Dimensions height: 1.72 m Cores: 2 robot interface Bi-metal
used
Machine: BILLION 80T PROXIMA 310H YEAR 2007 Year: 2007 Control type: DIXIT 2 Number of hours: 32,000 H Closing Closing force: 80T Opening stroke: 330 mm Tray dimensions: 660 x 600 mm Mini / maxi mold: 200/400 Max distance between plates: 730 mm Injection: Screw diameter: 35 mm Screw length: 20D cm3: 168 Bars: 2,020 General: Motor power: 24KW Heating power: 9KW Closing weight: 4T2 Dimensions length: 4M Dimensions width: 1M30 Dimensions height: 1M85 Options: Cores: 1 Robot interface: YES Bi metal: YES Blow guns: 2 Others: 8 HOT CHANNELS
used
Type of control: NC 4 Number of hours: 48,500 H Closing force: 1300 T Opening stroke: 1500 mm Screw diameter: 110 mm Screw length: 20 D cm3: 5797 Cores: 4 Robot interface: yes Bi metal: yes Others: 24 hot runners, wittmann DEMAG robot
used
INJECTION UNIT Screw diameter: 35 mm Calculated injection volume: 154 cm³ Length / diameter ratio: 23 L / D Pressure on the material: 2429 bars CLOSING UNIT Closing force: 1100 kN Passage between columns: 430 x 470 mm Tray size: 760 x 770 mm
used
SANDRETTO Serie nove T injection molding machine 300T E1300 Screw D63 / 863 cm3 / 1523 bar Between columns: 665 x 665 Aperture: 660 Mold thickness: min 230 / max 730 Dim trays: 980 x 980 Installed power: 55.5 kW Dimensions: 7055 x 2547 x 2160 Weight: 12900 kg Euromap 12 robot interface Auxiliary cores (PF and PM) Top dosage 2 socket boards 10-way stainless steel water box APEX robot
used
BILLION 100T H 470/100 SELECT INJECTION UNIT Screw diameter: 40 mm Calculated injection volume: 220 cm³ Length / diameter ratio: 23.5 L / D Maximum injection flow: 251 cm³ / s Pressure on the material: 2030 bars Screw Speed: 175 RPM CLOSING UNIT Closing force: 1000 kN Opening stroke: 175 mm Passage between columns: 445 x 445 mm Tray size: 630 x 630 mm GENERAL Dimension: (WxHxD) 5.3 x 1.8 x 1.35 m. Weight: 5230 Kg
used
INJECTION UNIT Screw diameter: 85 mm Calculated injection volume: 2128 cm³ Length / diameter ratio: L / D Pressure on the material: 1624 bars CLOSING UNIT Closing force: 4500 kN Opening stroke: 950 mm Mold thickness Mini / Max: 970 mm Passage between columns: 900 x 800 mm EQUIPMENT Extended press for a mold thickness of 970 mm and opening of 950 mm UNILOG B4 command
used
Control type: DIXIT Closing force: 140 T Opening stroke: 500 mm Between columns: 430 x 430 mm Tray dimensions: 650 x 650 mm Mini / maxi mold: 240 x 480 mm Max distance between plates: 980 mm Screw diameter: 40 mm Screw length: 20D cm3: 220 Bars: 2100 Engine power: 18.50 kw Heating power: 9.60 kw Closing weight: 6.80 tonnes Cores: 1 Robot interface Bi metal
used
Year: 2018 Type of control: Euromap 67 Number of hours: 900 Place of storage: FRANCE Timeframe: AVAILABLE Closing force: 200 T Opening stroke: 510 mm Between columns: 570 x 570 mm Mini mold: 200/710 mm Diameter of the screw: 50 Length of the screw: cm3: 471 Bars: 2047 Cores: 2 Robot interface: yes
used
Machine: BILLION HERCULE 140 T Year: 2004 Control type: DIXIT Number of hours: 33,000H Closing Closing force: 140 T Opening stroke: 500 mm Between columns: 430 x 430 mm Tray dimensions: 650 x 650 mm Mini / maxi mold: 240 x 480 mm Max distance between plates: 980 mm Injection: Screw diameter: 40 mm Screw length: 20D cm3: 220 Bars: 2100 General: Engine power: 18.50 kw Heating power: 9.60 kw Closing weight: 6.80 tonnes Dimensions length: 5M10 Dimensions width: 1M80 Dimensions height: 2M25 Options: Cores: 1 Robot interface: YES Bi metal: YES
used
INJECTION UNIT Screw diameter: 35 mm Calculated injection volume: 168 cm³ Length / diameter ratio: 20 L / D Pressure on the material: 2020 bars CLOSING UNIT Closing force: 800 kN Opening stroke: 450 mm Mold thickness Mini / Max: 250 mm Max distance between tray: 700 mm Passage between columns: 400 x 400 mm Tray size: 580 x 590 mm GENERAL Heat output: 22 kW Total installed power: 30 kW Quantity of oil: 250 l. NC4 control Machine used exclusively in a clean room
used
Year of manufacture: 2004 Type of control: NC4 Number of hours: 27,000 H Closing force: 200T Opening stroke: 575 mm Distance between columns: 560 x 560 mm Tray dimensions: 830 X 830 mm Mini/maxi mould: 310/660 mm Max gap between trays: 1235 mm Screw diameter: 50/25 mm Screw length: 20 D Injection volume: 442/61 cm3 Injection pressure: 1946/1940 bar Motor power: 30KW Heating power: 14.8 KW Closing weight: 10T Dimensions length: 5.70 m Dimensions width: 1.70 m Dimensions height: 2.10 m 1 hydraulic core robot interface Bi-metal Turntable
used
Battenfeld HM 300/2250 Year: 2009 Type of control: Unilog B6S Number of hours: 17,463H Closing Closing force: 300 T Opening stroke: 900 mm Between columns: 1030 x 1100 mm Mini/maxi mould: 225 mm Max gap between trays: 1125 mm Injection: Screw diameter: 65 mm cm3: 1078 Bars: 2075 General: Motor power: 46kw Heating power: 26.6kw Weight: 14.6T Dimensions length: 6.18 m Dimensions width: 2.5 m Dimensions height: 2.3 m Options: Cores: 3 Robot interface: YES Bi metal: YES Others: 1 BLOWER
used
Machine: ENGEL 100T E ELECTRIC MOTION YEAR 2011 Year: 2011 Control type: CC200 Number of hours: 32 718H Closing Closing force: 100T Opening stroke: 460 mm Between columns: 520 x 520 mm Tray dimensions: 760 X 760 mm Mini / maxi mold: 250/600 mm Max distance between plates: 1060 mm Injection: Screw diameter: 35mm Screw length: 20D cm3: 168 Bars: 2400 General: Motor power: 21KW Heating power: 9.2KW Closing weight: 8t4 Dimensions length: 5.9m Dimensions width: 1.7m Dimensions height: 2.2m Options: Cores: NO Robot interface: YES Bi metal: YES
used
ENGEL 40T VERTICAL INSERT 200V40 + rotary table Control Type: CC200 Number of hours: 9000 H Closing force: 40T Opening stroke: 330 mm Rotary table: 1200 mm Tray dimensions: 1200 mm Mini/maxi mould: 190 mm Max gap between trays: 520 mm Injection: Screw diameter: 18mm Screw length: 20D cm3: 38 Bars: 2060 General: Motor power: 15KW Heating power: 5.3KW Cores: Robot interface: no Bi metal: yes Others: rotary table
used
Machine: BILLION HERCULE 320 T -2000 Year: 2008 Control type: DIXIT II Number of hours: 21,000 H Closing Closing force: 320 T Opening stroke: 660 mm Between columns: 735 x 735 mm Tray dimensions: 1045 x 1045 mm Mini / maxi mold: 330 x 680 mm Max distance between plates: 1340 mm Injection: Screw diameter: 75 mm Screw length: 21.50 D cm3: 1259 Bars: 1600 General: Engine power: 75 kw Heating power: 27 kw Closing weight: 17 tonnes Dimensions length: 7.60 m Dimensions width: 2.10 m Dimensions height: 2.60 m Options: Cores: 2 Robot interface: yes Bi metal: yes Batteries: yes
used
Centering ring diameter on the plate is 160 mm (not the standard 125 mm) This machine was regularly maintained and has CE norms. Type of used material: PBT GF 30 ABS/PA PP Service history: 3.2015 – Replacing the CF card reader with a floppy disk drive 5.2013 – Machine calibration 5.2009 – Machine calibration
used
INJECTION UNIT Screw diameter: 84 mm Calculated injection volume: 1663 cm³ Pressure on the material: 1510 bars Laminating capacity PS: 418 Kg / h Screw Speed: 210 RPM CLOSURE UNIT Closing force: 4500 kN Opening stroke: 800 mm Thickness Mold Mini / Max: 350/750 mm Passage between columns: 810 x 810 mm Tray size: 1210 x 1210 mm GENERAL Total installed power: 26.2 kW Size: (WxHxD) 8.37 x 2.21 x 1.89 m. Weight: 24000 Kg EQUIPMENT Locking - Double toggle
used
Machine: ENGEL VICTORY ECODRIVE 160T Year: 2011 Control type: CC200 Number of hours: 35,000 H Closing Closing force: 160T Opening stroke: 600 mm Between columns: 850 x 750 mm Tray dimensions: 850 X 750mm Mini / maxi mold: 300 mm Max distance between plates: 900mm Injection: Screw diameter: 30/35 mm Screw length: 20D cm3: 113/192 Bars: 2400/2390 General: Motor power: 30KW Heating power: 16KW Closing weight: 9T5 Dimensions length: 5.8M Dimensions width: 1.7M Dimensions height: 1.4M Options: Cores: 5 Robot interface: yes Bi metal: yes Others: 8 sequential, 12/1 hot runner 24 zones, viper robot, carpet
used
Machine: BILLION HERCULE 320 T -2000 from 2006 Year: 2006 Control type: DIXIT II Number of hours: 36 800 H Closing Closing force: 320 T Opening stroke: 660 mm Between columns: 735 x 753 mm Tray dimensions: 1045 x 1045 mm Mini / maxi mold: 330 x 680 mm Max distance between plates: 1340 mm Injection: Screw diameter: 50 Screw length: 22D cm3: 422 Bars: 1843 General: Motor power: 45 kw Heating power: 15 kw Injection weight: 14T Dimensions length: 7.10 m Dimensions width: 2.10m Dimensions height: 2.60 m Options: Cores: 2 Robot interface: YES E67 Bi metal: YES
used
Type of control: NC 4 Number of hours: 34,000 H Closing force: 80 T Opening stroke: 450 mm Between columns: 420 x 420 mm Tray dimensions: 600 X 600 mm Mini/maxi mould: 250/mm Max gap between trays: 700 mm Injection: Screw diameter: 35mm Screw length: 20 D cm3: 168 Bars: 2020 General: Motor power: 15 kW Heating power: 9 kw Cores: 1 Robot interface: yes Bi metal: yes
used
Control Type: MC4 Number of hours: 37,121 H Closing force: 110 T Opening stroke: 600 mm Between columns: 470 x 470 mm Tray dimensions: 745 x 770 mm Mini/maxi mould: 300 mm Max gap between trays: 900 mm Injection: Screw diameter: 45 mm Screw length: 20 D cm3: 275 Bars: 1878 General: Motor power: 18.5KW Heating power: 13KW Closing weight: 6T Options: Cores: 2 Robot interface: YES Bi metal: YES Others: accumulators
used
MIR SPA brand RMP 830 model Year 1998 Current status In operation Overall dimensions 11830 x 2225 x 2820 mm Weight 42000 Kg Tonnage 830 Column passage 930 x 930 mm Screw diameter 90 mm Calculated injection volume 2735 cm3 Min/Max mold thickness 350-1000 mm Robot interface Euromap 12 YES Jack YES Moving floor stroke 1030 mm
used
Control type: CC200 Number of hours: 45,000 hours Closing force: 50T Opening stroke: 400 mm Between columns: 500 mm x 450 mm Tray dimensions: 500 m x 450 mm Mini/maxi mold: 200 mm Max distance between trays: 600 mm Injection: Screw diameter: 25 mm Screw length: 24.8D cm3: 69 Bars: 2400 General: Motor power: 15KW Heating power: 6.8KW Closing weight: 3T Injection weight: Length dimensions: 3.4M Width dimensions: 1.3M Dimensions height: 1.8M Options: Cores: 1 Robot interface: yes Bi metal: yes
used
Control type: SELOGICA TOUCH Number of hours: 35,000 hours Closing force: 80 T Opening stroke: 500 mm Between columns: 470 x 470 mm Tray dimensions: 637 x 637 mm Mini/maxi mold: 250 mm Max distance between trays: 750 mm Injection: Screw diameter: 30 mm Screw length: 23.3/D cm3: 106 Bars: 2500 General: Motor power: 18.5 kW Heating power: 6.4 kW Closing weight: 3.5 Tons Injection weight: Dimensions length: 4 m Width dimensions: 1.3 m Dimensions height: 2 m Options: Cores: 1 Robot interface: YES Bi metal: YES
used
Closing force: 60 T Opening stroke: 300 mm Between columns: 370 x 370 mm Tray dimensions: 510 x 510 mm Min/max mould: 200/400 Max gap between trays: 700 mm Injection: Screw diameter: 30 mm Screw length: 20/D cm3: 85 Bars: 2000 General: Motor power: 19kw Heating power: 9.4kw Closing weight: 4 Tons Injection weight: 77 GRAMS Dimensions length: 3.5m Dimensions width: 1.4m Dimensions height: 1.8 m Options: Cores: 0 Robot interface: yes Bi metal: yes Others: 1 blow gun
used
ARBURG 400T 820S 4000/1300 YEAR 2014 Year of manufacture: 2014 Type of control: SELOGICA Number of hours: 31,086 H Closing force: 400 T Opening stroke: 700 mm Distance between tie-bars: 820 x 820 mm Plates dimensions: 1171 x 1171 mm Min/max mould: 850 mm Max gap between plates: 1550 mm Screw diameter: 60 mm Screw length: 20/D cm3: 664 Bars: 2000 Motor power: 55kw Heating power: 23kw Closing weight: 20 Tons Injection weight: Dimensions length: 6.5m Dimensions width: 2.4 m Dimensions height: 3.5 m Options: Cores: 2 Robot interface: yes 1 blow gun
used
Control type: NC 4 Number of hours: 32,500 hours Closing force: 80 T Opening stroke: 450 mm Between columns: 420 x 420 mm Tray dimensions: 600 X 600 mm Mini/maxi mold: 250/mm Max distance between trays: 700 mm Injection: Screw diameter: 35mm Screw length: 20 D cm3: 168 Bars: 2020 General: Motor power: 15 kW Heating power: 9 kW Closing weight: 4 T Injection weight: Dimensions length: 4.2 m Width dimensions: 1.4m Height dimensions: 4.8 m Options: Cores: 1 Robot interface: yes Bi metal: yes
used
INJECTION UNIT Screw diameter: 40 mm Calculated injection volume: 182 cm³ Pressure on the material: 2120 bars Screw speed: 145 RPM CLOSING UNIT Closing force: 1300 kN Opening stroke: 850 mm Mini /Max Mold Thickness: 275 mm Max distance between tray: 800 mm Passage between columns: 470 x 470 mm Dimensions of the trays: 650 x 650 mm GENERAL Heating power: 22 kW Total installed power: 33.9 kW
used
Screw diameter: 22 mm Calculated injection volume: 40 cm³ Length/diameter ratio: 23 L/D Pressure on the material: 2259 bars Screw speed: 465/560 RPM Number of temperature zones: 4 N CLOSING UNIT Closing force: 500 kN Passage between columns: 320 x 320 mm Dimensions of the trays: 540 x 540 mm GENERAL Heating power: 6 kW Total installed power: 11 kW Oil quantity: 170 l. Dimension: (WxHxD) 3.2 x 1.8 x 1.31 m. Weight: 2500 Kg
used
Screw diameter: 55 mm Calculated injection volume: 582 cm³ Pressure on the material: 2200 bar Mini /Max Mold Thickness: 330/680 mm Passage between columns: 615 x 615 mm Dimensions of the trays: 920 x 920 mm EUROMAP 12 DIXIT 2 2 cores Central ejection Year of manufacture: 11/2002
used
Ferromatik K140-S Injection moulding machine Year : 1997 Weight : 9300 kg clamping force : 1400 kN voltage: 230 motor outputs power : 44,7 kW minimum moulding size in mm : 200 mm mould opening size : 750 mm (950 mm) tie bar distance : 500 x 500 mm maximum produce parts with a shot size 254 ccm / 216 gramm oil to fill in : 400 l hours of Production : 137,000 working Condition : good special features : 2 pcs. hydraulic core pull 4 pcs. air valves hot runner 16 zones color feeder connectivity option
used
Year of manufacture: 2000 Screw diameter: 25 mm Injection volume: 69 cm3 Length/Diameter ratio: 24.8 L/D Maximum injection rate: 104 cm3/s Pressure on the material: 2000 bar Temperature zones: 4 Closing force: 500 kN Mold thickness: 200 mm Heating power: 6.8 kW Total installed power: 15 kW Oil quantity: 140 L Machine dimensions: 3800 x 1280 x 1970 mm Machine weight: 4700 kg
used
Year of issue: 2006 Length of injection molding machine, mm: 6900 Width of injection molding machine, mm: 1700 TPA height, mm: 2500 Clamping force, tons: 320 Weight, t: 12 Screw diameter, mm: 55 Injection volume, cm³: 1026 Productivity kg / hour (РС): 187 Drive, kW: 37 Heating, kW: 18.5 Slab size, mm: 1000 Slab size, mm: 1000 Between columns, mm: 660 Between columns, mm: 660 Fastening of clamps VNUTR cont., Mm: 280 Fastening of clamps VNESHN. cont., mm: 350 KRM plate travel, mm: 670 Package height min, mm: 240 Package height max, mm: 680 Full disclosure KRM, mm: 1350 D of the landing ring fixed plate, mm: 160 D of the landing ring movable plate, mm: 100 Pusher stroke, mm: 160 Hydraulic oil grade: 46 Oil volume, lit .: 620 Oil change, hour: 9000
used
Closing unit Clamping force [kN] 10000 Dimensions of mounting plates (hxv) [mm] 2000 x 1605 Clearance between columns (hxv) [mm] 1550 x 1200 Min./max. mold height [mm] 500 / 1300 Maximum opening width [mm] 2400 Injection unit Screw diameter [mm] 90 Injection volume [cm3] 2799 Injection weight [g] 2407 Injection pressure [bar] 2300 Electrical and hydraulic equipment Rated power of the pump motor [kW] 150 Heater power [kW] 44.1 Dimensions and weight Net weight with control cabinet [t] 52000 Dimensions (length x width x height) [m] 10.45 x 3.18 x 2.82 Injection molding machine included with the Apex robot
used
Clamping force [kN] 1000 Dimensions of mounting plates (hxv) [mm] 570 x 570 Clearance between columns (hxv) [mm] 420 x 420 min./ max. mold height [mm] min 250 injection unit Screw diameter [mm] 30 Injection weight [g] 89 Injection pressure [bar] 2470 Electric-hydraulic equipment Nominal power of the pump motor [kW] 25 Dimensions and weight Net weight with control cabinet [t] 3.18 Dimensions (length x width x height) [m] 4.5 x 1.7
used
Krauss Maffei KM 390-160 CZ Closing unit Clamping force [kN] 1250 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 400 Maximum opening width [mm] 1000mm Injection unit Screw diameter [mm] 40 Injection volume [cm3] 204 Injection weight [g] 186 Injection pressure [bar] 1860 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 21 Dimensions and weight Net weight with control cabinet [t] 7 Dimensions (length x width x height) [m] 4.5 x 1.5 x 3.7
used
Krauss Maffei KM 80-380 CX hydraulic injection molding machine Year of production - 2022 Fully hydraulic closing system. The MC 6 control system is based on an industrial computer in real-time Ethernet technology, equipped with an integrated 21.5” control panel with a color touch screen. Plasticizing system complete plasticizing system for thermoplastics with a screw diameter of 40 mm, with a return lock and an open nozzle Nozzle radius 10mm, nozzle opening 4mm TECHNICAL DATA OF THE MACHINE IN STANDARD VERSION Closing unit – Mold clamping force: kN 800 – Mold opening force: kN 55 – Dimensions of the mounting plate (h x v): mm 670 x 670 – Clearance between columns (h x v): mm 420 x 420 – Mold opening stroke: mm 500 – Minimum mold height: mm 250 – Opening width: mm 750 – Ejector stroke: mm 150 – Ejector force forward/reverse: kN 23 / 10 injection unit ...
used
Toshiba IS 450 GSW injection molding machine Year of production - 2007 Parameters: Closing force: 4,410 kN Screw diameter: 70 mm Injection volume: 1480 cm³ Shot weight: 1360 g Min.height of the fastening plate: 1230 mm Min.width of the fastening plate: 1230 mm The distance between the columns - 870X870 mm Ejector force: 243 kN Ejector stroke length: 1050 mm Maximum injection pressure: 178 MPa Oil tank capacity - 1500 liters Machine length: 7600 mm Machine width: 2200 mm Machine height: 2100 mm Injection weight: 22,000 kg Machine with a robot and a cage
used
Manufacturer ENGEL Type Victory 500/150 Tech Clamping Force [tons] 150 Manufacturing Year 2005 Screw Size [mm] 40 Number of aggregates 1 Screw Type TW02.1_650 D40 LD20 G1.2 WS8 1180 The minimum height of the mold [mm] 300.0 weight [kg] 9600 installed power kW 39 length mm 5196 width mm 1804 height mm 2333 occupied area 9.4 m2 occupied area with a cage 14.9 m² oil filter HC28 - SM10 oil tank capacity upper 450 hydraulic oil quantity 450 the viscosity is 46 recommended viscosity 46 NAS purity class on July 12, 2012. 5 date of last oil change II.20 CE document 158323 hydraulic pump 1 RKP 80 EHV hydraulic pump 2 RKP 45 EHV insert clutch Rotex size 48 Hardness 98 Technical approval DTW-11-10 MC43 robot (W 721-0303) Diagrams office E v Schematics office H v Machine diagrams E v Machine diagrams H v Control card addresses CPU 1 Analog 4 Thermo 0 Control c ...
used
Manufacturer / type Toshiba IS650GTW i59 Closing force [tons] 650 Year of production 2007 Screw diameter [mm] 95 Number of aggregates 1 type of screw Type: 95DBG-AT, Part # F049997, Stellite12 The minimum height of the mold [mm] 450.0 weight [kg] 32100 installed power kW 101.2 thermal insulation on the aggregate - blanket on the aggregate upper / lower YES nominal power of heaters for units KW 43.95 length mm 7940 width mm 2670 height mm 2300 occupied area of 21.2 m² occupied area with a cage 32.0 m² hydraulic pump 1 SQP43-50 hydraulic pump 2 SQP43-50 MC09 robot (W 733-0610)
used
Injection weight: 85 g Closing force: 700 kN State: Used Screw diameter: thirty Injection pressure: 2470 Column spacing: 320x320 Size of plates: 476x476 Min mold height: 200 Control type: Selogica Tongue: German,Polish Installed power: 35 Working hours: 59684 Libra: 2350 Dimensions: 3.25 x 2 Feed hopper: NO
used
Closing unit Clamping force [kN] 2000 Dimensions of mounting plates (hxv) [mm] 800 x 800 Clearance between columns (hxv) [mm] 560 x 560 Min./max. mold height [mm] 220-520 Maximum opening width [mm] 970 Injection unit Screw diameter [mm] 55mm Injection volume [cm3] 522 Injection weight [g] 595 Injection pressure [bar] 1943 Electrical and hydraulic equipment Rated power of the pump motor [kW] 30 Heater power [kW] 22.6 Dimensions and weight Net weight with control cabinet [t] 9.8 Dimensions (L x W x H) [m] 5.65 m x 1.45 m x 2.10 m
