external used for sale

Key data: 300 mm, 750 mm, 150 mm

Year of construction: 1981 REFURBISHED: 2016 Scheif-Ø max.: 300 mm Grinding length max.: 750 mm External grinding spindle drive: 5.5 kW External grinding wheel: left External Grinding Wheel Dimensions ØxWxBore Tailstock: manual Tailstock Mounting Cone: MK4 Tailstock stroke max.: 40 mm Workpiece headstock: MK4 Workpiece spindle bore: 24 mm Workpiece weight between tips max.: 200 kg Workpiece weight flying max.: 50 kg Workpiece spindle speed: 32-500 min-1 Strobe lamp for grinding wheel balancing: 1 pc. Grinding wheel flanges: div. External grinding wheels: various Belt filter with pump: 400 l Magnetic chuck Ø: 200 mm 3-jaw chuck Ø: 160 Weight approx.: 3.700 kg Operating Voltage: 380V/50Hz Space requirement LxW approx.: 3,420x2,155x1,700 mm All information is non-binding

2 fingers parallel external gripper, pneumatic, 52.81.3.500, FLT, new Special price We still have several identical and other such devices, but the amount is ending. Buy more than 1 piece, there is still a great discount. If you have a VAT number, we will gladly issue you an invoice without VAT. Mint condition in original packaging! The part was purchased from a spare parts warehouse of a company and has never been in operation, is in a completely mint condition and in its original packaging. 2 Finger Parallel External Gripper, pneumatic, 52.81.3.500 Manufacturer FLT (Fibro Läpple Technologie) Clear width closed 98mm Clear width open 122mm Gripper finger length front 60mm Functional guarantee! We cannot provide a conventional guarantee and warranty for second-hand parts. However, we give you a functional guarantee. If the unit does not function when it is put int ...

An external cylindrical grinding machine is sold, which was in operation until the site was shut down. External dimensions 1.4m wide; 1.2m deep ; 1.6m high Weight approx. 1,5To max grinding length approx. 300mm between the tips max grinding height approx. 80mm top of the table spot center; Grinding diameter approx. 160mm max grinding wheel diameter approx. 300mm Voltage 400V, 50Hz, Cooling medium device a lot of accessories, eg grinding wheels, grinding wheel flange, tool cabinet single-door, see pictures

Universal internal/external grinding machine equipped with Marposs positioner + measurer + balancer External grinding wheel 600 mm

Maximum diameter of external grinding; 250 mm Maximum diameter for grinding holes; 200 mm Maximum length of external grinding: 800 mm Maximum hole grinding length; 150 mm the rise of the canines; 135 mm Maximum workpiece diameter in eyepiece: 80 mm The maximum turn of the table; +/- 8 degrees, head rotation +/- 1 degree Tailstock taper; no 3 The smallest diameter of the ground hole; 20 mm Main engine; 7 KW Dimensions; 2800/1700/1700 mm Mass; 3,800 kg

CONTROLS   CNC controls FANUC 310I-A WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 180 mm   workpiece weight between centers (max): 25 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 400 mm   grinding length: 1000 mm TAILSTOCK   distance betw. centers (max): 1000 mm   taper: MK 4   Z-axis travel: 1600 mm SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 220 mm   Z-axis travel: 1600 mm   tilting range (B-direction) min: 0 °   rotating range B-axis up to: 25 °   drive power: 6.8 kW GRINDING TOOL   type of grinding tool: wheel   diameter (max): 400 mm   borehole: diameter: 127 mm ELECTRICAL SPECIFICATIONS   mains power supply: 45 kVA   mains voltage: 400 V   mains frequ ...

Euro-Pool Grid Box 800 x 1200 mm New goods, see pictures. External dimensions 1,240 x 835 x 970 mm Internal dimensions 1,200 x 800 x 800 mm Capacity 1500 kg Weight 70 kg Weight 70 kg Load 6,000 kg Colour grey Stack height nested 20 Stack height unnested 5 according to UIC standard 435/3 The front side is foldable. One half is open from above the other half is open from below (see pictures). Price: € 109.00 net per piece from stock Larger quantities on request Goods are in stock. Transport possible on request. Visit possible at any time by appointment. More information on request. (changes and errors in the technical data, information prices and intermediate sale reserved! See our Terms and Conditions, all prices excl. VAT from stock) Purchase / Sale We are looking for, or offer numerous items from various areas on an ongoing broom-pure co ...

Turning + Thread cutting semi-automatic M32 The machine was never used for production. Suitable for internal and external threads max. diameter 90 mm max. turning length 45 mm max. thread pitch 1.5 mm max. thread length 14 mm Max. Thread pitch multi-speed 3 mm largest thread length multi-speed 21 mm Drive motor approx. 3 hp Machine weight 800 Kg

We offer a position new formwork supports galvanized, with external thread 1,95-3,50m according to DIN Euro standard 1065 manufactured with flat head Class B/D tested 144 pieces a 47,90EUR + 3 x stack pallets 1.43 x 0.87 x 0.69m new a 150.00EUR total 7347,60EUR net Purchase and sale of scaffolding/formwork systems and construction machinery; Formwork restoration at fair conditions. Company SFS Meisterbetrieb Andreas Becker e. Kfm. Office/ warehouse address: Birkenstrasse 15 89185 Humlangen- Hüttisheim, Germany Register court Ulm: HRA722943 VAT-ID-NR: DE279047055

5 Rhymes steel external silos Ø 2,800 mm Content 51m³ = 30 tons of flour per silo Height per silo 12,500 mm Silos stand on frame for sale Price on request Phone +49 172 8345457

Workspace: External grinding ? Top height: 181 mm ? Center width: 1000 mm ? grinding length: 1000 mm ? Grinding diameter min./max.: 5 / 360 mm ? Grinding length for penetration grinding: 250 mm workpiece weight: 250 kg Grinding spindle: ? Cone 1:10 ?120 ? Tool holder: ?304.8 Workpiece spindle ? Mk4 ? ? 24 mm Feed speed: ? Grinding spindle min./max.: 0.01/15000 mm/min ? Workpiece table min./max. .: 0.01/15000 mm/min Spindle speeds: ? Stepless from 1580 to 2040 rpm Workpiece spindle speeds: ? Stepless from 1 to 1000 rpm Dimensions (L X W X H): 5600 mm x 3700 mm x 2500 mm ? Minimum height requirement: 3500 mm Weight: 10300 kg Year of Manufacture: 2001

Schaudt PF4 1000 - Premium overhaul [RETROFIT] - CNC grinding machine for individual requirements - Tip height: 180 mm - Grinding length: 1,000 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: approx. 300kg - Workpiece headstock: MK4 - Tailstock: MK4 - Installation dimensions: approx. 4,500x2,400 mm Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Second / Third External Loop Unit - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Schaudt & Studer Grinding Machines - Premium Overhauled [RETROFIT] - various conventional, cycle-controlled & CNC grinding machines - for various workpiece Ø - with grinding lengths from 200 to 3,000 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: according to customer requirements - The attractive alternative to the new machine - We are also happy to overhaul your machine, more information on our homepage Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Second / Third External Loop Unit - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Centerless external cylindrical grinding machines Herminghausen SR 40-3 Machine Was improved and rebuilt by the company Ebert. Thus type designation CL 43. Original price 299.000, - €. Operating voltage: 400 volts, power consumption: 22 kW, workpiece diameter 2 - 130 mm, largest grinding length for through grinding 250 mm, grinding wheel diameter min/max 400/600 mm, grinding wheel bore 604.8 mm, control wheel diameter min/max 220/300 mm, control wheel bore 152.4 mm, grinding wheel circumferential speed 40 m/s, control spindle speed infinitely adjustable 0 - 200 rpm, control Siemens S7, cooling lubricant supply unit, weight of the machine ca. 6000 medical history Errors excepted!

CNC external cylindrical grinding machine, brand Studer, type S40-4, Bi 1987, Documents are available. The price is net

Used Studer s 31 Cylindrical external / internal grinding machine Visible under power in Italy Year: 2003

Universal external cylindrical grinding machine Studer S 12 + Automation loading system Seckler Manufacturer [manufacturer]: Studer CH Switzerland Type [ type]: Studer S 12 Control unit: Siemens 840D Sinumerik + Seckler Automation Ldesystem A16 + Streuli filtration system + Hönag Filtec exhaust air system Incl. handwheel/control panel Year of construction[construction year]: 10/2004 - 09/2017 Operating hours approx. 39.700h Dimensions Center width 150mm Grinding length max. 150mm Center height 175mm Grinding diameter 500mm workpiece weight 80kg Cross slide (X) travel 300mm Speed 0.001-30'000 mm/min. Lin. Mot. Resolution 0.00001 mm Longitudinal slide (Z) travel 350mm Speed 0.001-30'000 mm/min. Lin. Mot. Resolution 0.00001 mm Sanding headstock Grinding head pos. 0° or 30° Drive power 7.5/12.5 kW Grinding wheel right ø 500 x 80 x 203mm In ...

Karstens US 16A -500 External cylindrical grinding machine Center height 150 mm Center width approx. 500 mm Infinitely variable spindle speed from 50-450 U/1 Workpiece spindle swivelling 360° MK4 Workpiece Spindle Holder Grinding wheel D=350x60mm with flange Workpiece spindle bore 24mm Motor 4KW 400V 50HZ Weight: approx. 1600kg

External Grinding + Marposs Morara brand Model Reu 800 Revised 2018 Serial number 3124 Technical features Point height 255 mm Max rectifiable length 600 mm Max Distance Between Tips 700mm Marpos measurer The above data are indicative and not binding

Maximum tool diameter 200 mm Distance between centers 460 mm Surface grinding 200 x 50 mm External grinding dimensions Ø 5 - 50 x 400 mm Internal grinding dimensions Ø 10 - 50 x 75 mm - Workpiece spindle head Rotation range -90° to +90° Speed ​​110 / 200 / 300 rpm MT 2 tool holder Jaw chuck diameter 100 mm - grinding head Rotation range -90° to +90° trip Across 200 mm Vertical 200 mm Vertical scale division 0.01 mm Vertical feed per handwheel revolution 1 mm/rev Graduation across fine / coarse 0.005 / 0.02 mm Side adjustment per turn of the knob 1 / 4 mm/rev Grinding wheel 200 x 20 x 75 mm Speed ​​2500 rpm Internal rotational speed of the grinding spindle 13,500 rpm - worktable Max. stroke 480 mm Hydraulic longitudinal feed 0.01 - 6 m/min Table rotation range -45° to +45° Total engine  ...

Schaudt PS51 Cnc external grinding machine with Knoll vacuum filter, Promot Cnc Cartesian robot, Donaldson vacuum filter and Marposs unit. Ø 360 max workable x 600 mm, max weight 300 kg With Promot CNC magazine Length 375 mm, weight 5 + 5 kg Grinding wheel Ø 762 mm, grinding wheel pack weight 500 kg, max width 125 mm, grinding wheel pack up to 300 mm with crankcase modification, programmable rotation speed 45 - 60 m/sec - Grinding wheel motor power 22 kW Dressing system for shaped rollers Workpiece rotation 1 - 1000 rpm Complete with Promot ELP A0029904 magazine - 2000 Cnc Siemens Weight 10 t grinding only. Accessories: Knoll 2000/MW475 Belt Filter Series No. 214472 Ref. 384014 from 2003 Donaldson DMG D1 57171684 vacuum cleaner from 2007 Two Marposs units Fully functional machine, both Shaudt and Promot can do installation, language change, staff training

Studer S31 Spw.: 1000mm/ Sph.: 175mm Fanuc 16i- TB Control Commissioning 2004 Strokes X-axis 285mm/ Z-axis 1150mm Universal cylindrical grinding machine 2x external and 1x internal grinding

Year of construction 2009 External dry cooler with double blower Delivery date: immediately from stock Price on request. We deliver and install worldwide!

Used Robbi 300 Cylindrical external / internal grinding machine the machine can hone a cylinder of 8000mm x 300mm in diameter

Used external grinding machine Brand: DANOBAT Model: 1200 RP Weight: 4150kg Power: 12CV - Distance between points: 1200mm - Grinding wheel dimension: 500x80x203mm - Maximum diameter to rectify: 348mm - Angle workpiece head (Min./Max): 45/450 rpm - Internal cone spindle workpiece head: Morse 5 - Center height: 175mm It has a measuring center for grinding Marposs E9. The meter measures the part material removed during the grinding process.

Distance between centers : 1000 mm Centers height : 175 mm Grinding wheel holder headstock orientation : 0 - 180 ° Grinding wheel holder headstock indexing precision : 5 ° Grinding wheel dimensions : 500 x 63 x 203 mm Cutting speed : 35 m/sec Headstock power : 7.5 kW Maximum workpiece weight : 130 kg Table orientation : 10 ° headstock rotation speed : 35-520 rpm EQUIPMENT : Sensitron 6 : Internal grinding spindle : 1 Measuring head MOVOMATIC ES124 for the diameter : 1 Tailstock : 1 Diamond grinding device for external wheel : 1 Radius grinding devic : 1 Display 2 axes HEIDENHAIN : 1 Lubricating tank with paper filtration : 1 Set of grinding wheel holders and grinding wheels : 1

NOVAMODUL Internal Grinding S300/235p Max internal grinding diameter 300 Max length 235 Max diameter of rotation 400 Retrofitted machine with tex compiuter control automatic grinding and dressing cycles with measurement recovery Faceting fixture 3 spindles x internal Diamond copying in machine plus Diamond and copy machine external

The diameter of the ground workpiece for internal grinding is 8 - 190 mm. External grinding: - center distance 640 mm - workpiece diameter 295 mm Total machine input 35kVA. The machine is functional, but needs an initial investment in repairs.

CNC universal grinder for external grinding of cylindrical surfaces. Two smoothly controllable axes. Precise positioning. Possibility to store 21 programs as standard. The machine is in good technical condition, it is possible to test it by agreement. Workspace: Circulating diameter 320 mm. Distance between tips / max. grinding length 500 mm Max. ground diameter 300 mm Max. workpiece weight - between the tips 150 kg Max. workpiece weight - jaws 40 kg Grinding wheel: Dimensions (diameter x width x opening) 405x75x127 mm Cutting speed 45 m/s Grinding spindle: Starting in the transverse direction - Z axis - mm Starting in the longitudinal direction - axis X 300 mm Angle of rotation ±30 ° Min. increment of 0.0001 mm Rapid feed 4 mm/min Speed ​​- rpm Table: Start-up in the longitudinal direction - axis X - mm Starting in the transverse direction - Z axis 870 mm A ...

External cylindrical grinder -Visualization on 2 axes - distance between tips:400 [mm] - tip height:100 [mm] - longitudinal slide stroke:400 [mm] - cross slide stroke: 45 [mm] automatic rapid feed: 38 [mm] - grinding wheel diameter: 350 [mm] - max. grinding wheel width: 50 [mm]

CNC : Fanuc 21i-TB Internal and External Grinding Machine : Distance between centers : 1000mm Center heights : 175 mm Tailstock :

Key data: 190 mm, 16000 mm, 660 mm

External cylindrical grinding machine for tubes with diameters of 190 .. 660.4 mm, grinding with grinding wheels and abrasive belts, overhauled in 2017

CONTROLS   CNC controls FANUC 0I-TFP WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 80 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 500 mm WORKPIECE SPINDLESTOCK   spindle revolutions (max): 1500 /min   drive power: 3 kW   spindle bore diameter: 30 mm   tool fixture: MK 5   c-axis: yes   - positioning/indexing: 0.5 ° TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 60 mm   taper: MK 4 SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 370 mm   Z-axis travel: 500 mm   tilting range (B-direction) min: 60 °   drive power: 9 kW GRINDING TOOL   diameter (max): 500 mm    ...

CONTROLS   conventional WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 450 mm   workpiece weight between centers (max): 200 kg   workpiece weight flying (max): 50 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 290 mm   grinding length: 966 mm TABLE -CYLINDRICAL GRINDING-   tilting range (B-direction) min: 6 °   rotating range B-axis up to: 9 ° WORKPIECE SPINDLESTOCK   spindle revolutions (min): 32 /min   spindle revolutions (max): 500 /min   drive power: 0.7 kW   spindle bore diameter: 24 mm   tool fixture: MK 4 TAILSTOCK   distance betw. centers (max): 1120 mm   sleeve stroke: 40 mm   taper: MK 4 SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 140 mm   drive power: 5.5 kW ...

CONTROLS   digital read out MITUTOYO WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 320 mm   workpiece weight between centers (max): 150 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 280 mm   grinding length: 1000 mm WORKPIECE SPINDLESTOCK   spindle revolutions (min): 100 /min   spindle revolutions (max): 500 /min TAILSTOCK   distance betw. centers (max): 1000 mm GRINDING TOOL   type of grinding tool: wheel   diameter (max): 355 mm   borehole: diameter: 127 mm   width: 55 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz ATTACHMENTS (GRINDING)   coolant unit: yes

M 1105-02800 Machine type Cylindrical Grinding Machine - Universal Make ZIERSCH & BALTRUSCH Type URS 751 Built in 1982 Control type conventional Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight base from stock Technical details Grinding diameter 270 mm Grinding length 1000 mm Tip height 135 mm Total power requirement 7.5 kW Machine weight approx. 2.8 t Room requirement approx. 3 X 2.7 X 2.5 m Information ZIERSCH & BALTRUSCH Hydraulic Universal ROUND SCHLEIFMASCHINR Type URS 751 1982 built _________________________________________________ Tip height 135 mm Tip width/grinding length 1000 mm Tip width approx. 1100 mm Grinding wheel size: Through. x Width 400 x 50 mm Grinding spindle speeds (belts) 1,800 2,200 rpm Delivery path/rapid path 0.001 / 30 mm Grinding wheels delivery 0.0 ...

Stable production machine, peak width 1000mm Peak height 180mm Grinding wheel diameter 500 mm ready for use. We specialize in the revision of grinding machines, and offer service, maintenance, repair, conversion and control modernization.

With matching spacer rings according to photos. Scope of delivery according to photo 1.

! ENTER THE + WORLD! Conventional TSCHUDIN HTG 310 + with innovation and protection packages

Specifications 1.3.1 Dimensions, space requirements, weight, energy requirements Dimensions, weight Machine incl. control cabinet Length x Width (depth) x Height (incl. Levelling elements): approx. 3,600 mm x approx. 2,400 mm x approx. 2,500 mm Minimum height requirement: 3,500 mm Net weight: approx. 8,500 kg Pay attention to the set-up plan! It contains all connection data, space conditions, etc. necessary for energy supply and installation. 1.3.2 Spray-suppression cabin, full-space cover of the machine View into the machine interior: safety window (window composite) Design: polycarbonate lens protected on both sides Cover of mounting or maintenance openings: Sliding door(s) hinged and/or removable body parts Cover of the operators side, loading and unloading opening: sliding door, loading hatch Activity: - Foldable body parts,sliding doors of assembly and maintenance openings: manual - ...

Cylindrical Grinder Model: FM41G-1600CNL45 New in 1988 Control: FM4 CNC Maker: Fortuna (Germany) Ser. No. 15674 Maximum grinding diameter: 275mm Maximum grinding length: 1600mm Additional measurement device

grinding diameter: 250 mm grinding length: 600 mm centre height: 125 mm grinding wheel diameter: 500 mm grinding wheel width: 80 (100) mm bore: 203,2 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm workpiece spindle swivable +/-: 360 ° grinding head swivellable +/-: 0 ° grinding spindle speed: U/min : 0-9,99 mm/Ø : 0-9,99 mm/Ø table swivelabel +/-: 10 ° longitudinal feed of the table: 700 mm table speeds: 0,02-6 m/min : 130 kg max. workpiece weight -without tailstock: 130 inkl. Spannung kg cross travel: 270 mm tailstock quill taper MT: 3 quill travel: 30 mm total power requirement: 5,5-7,5 kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the s ...

TOS 400 X 2000 BHU 40A Cylindrical Grinding Machine The machine is in very good condition

CNC internal grinding machine with loading robot, well-equipped machine in good condition.

I will sell a roller grinder TOS Hostivar BH 25A-1000 Good condition - little used Grinding length - 1000 mm Max. grinding diameter - 300 mm DTR - there is

WMW SIP 400x500 GRINDING MACHINE Magnetic tray The machine is located in France.

We have a second Hand Ribon Internal Grinder we are looking to se11 good condition inspection possible

220627 Code Description Universal Cylindrical Grinder Make Jones - Shipman Model 1310 ( 8" x 18" ) Serial No. Year ? Grinding length, max. 450 mm Grinding diameter, max. 203 mm Center height 103 mm Weight workpiece kg Table tilting angle - 15 ° till + 15° Diam. Grinding wheel 350 mm Width Grinding wheel, max. 40 mm Motor power grindingwheel 1.5 kW Speeds Grindingwheel 1750 / 2300 rpm Speeds workpieceholder ( 6x ) 30 – 415 rpm Total power 3.5 kVA 380 Volts Machine size L x W x H 1.7 x 1.2 x 1.75 meters Weight 1800 kg Accessories internal grinding ( 10500-16500-24500 rpm ) coolant some tooling Condition Machine is in good condition

power supply 3x400 V, 50 Hz spindle speed range 6000-15000 rpm. Workpiece spindle speed range 112-1000 rpm. Workpiece spindle torsion 90 °

Grinding diameter 250 mm Grinding length 650 mm Center width 700 mm Tip height 125 mm Grinding wheel diameter 400/450 mm Grinding wheel width 50/80 mm Workpiece spindle speed up to 675 1/min Workpiece headstock swivel +/- 45 ° Dresser Measuring device Coolant system Grinding wheel
