cnc press brake used for sale

Capacity: 220 t Folding length: 4200 mm CNC Brand: _Unknown / Other CNC Model: Operator AMADA - HFBO 220-4 CNC Pressbrake 4200 x 220 Ton MACH - ID 6330 Make: AMADA Type: HFBO 220-4 Control: Operateur YOP: 1994 Max. bending length    4.200 mm Distance between column     3.760 mm Max. pressing force     220 T Dis. Beam – Table       450 mm Beam stroke        180 mm Troth beam          410 mm Approch speed       100 mm Working speed        7,5 mm Return speed           75 mm Adjustment X-Axis back gauge       1.000 mm Number of controlled axis       4 Control      Operateur 8 Axis Crowning&nb ...

Capacity: 35 t Folding length: 1200 mm CNC Brand: Delem TRUMPF - TrumaBend E35 Servo Mechanical Pressbrake 1250 x 35 Ton MACH - ID 6327 Make: TRUMPF Type: TrumaBend E35 Control: Delem YOP: 2000 Max. bending length    1.200 mm Distance between column    900 mm Max. pressing force      35 T Beam stroke      100 mm Adjustment X-Axis back gauge     500 mm Number of controlled axis      3 Control      DELEM Power        2 x 7.5 kW Dimensions Length       1.500 mm Width         1.500 mm Height        2.100 mm Weight       3.100 kg

Capacity: 200 t Folding length: 4100 mm (1) Down stroke / (2) Up stroke: 1   CNC Brand: Safan CNC Model: ARA Touchscreen MACH-id    6042 MAKE        Safan Darley Holland TYPE          E-BRAKE 200 - 4100 YOP            2010 SPECIFICATIONS Max. bending length    4100 mm Distance between column        4100 mm Max. pressing force          200 T Dis. Beam - Table         690 mm Beam stroke                  300 mm Approch speed         200 mm/min. Working speed         10 mm/min. Return feed               100 mm/min. Adjustment X-Axis back gauge        ...

Capacity: 110 t Folding length: 4100 mm CNC Brand: _Unknown / Other MACH-id     6041 MAKE         Deratech TYPE           ULTIMA 130 - 4100 YOP             2015 SPECIFICATIONS Max. bending length          4100 mm Distance between column          3600 mm Max. pressing force         110 T Dis. Beam - Table         440 mm Beam stroke          250 mm Troth beam            400 mm Approch speed         200 mm/min. Working speed          10 mm/min. Return feed               165 mm/min. Adjustment X-Axis back  gauge&n ...

Press brake URSVIKEN KDP 16031 160 ton built in 1987 in Sweden. Technical parameters : - maximum pressure: 160 tons - working length: 2.50 m - total length of the machine: 3.20 m - weight: 8.6 tons

Capacity: 80 t Folding length: 2550 mm CNC Brand: Safan CNC Model: TS1 MACH-id     5585 MAKE         Safan Darley Holland TYPE           SMK - K 80 - 2550 TS1 YOP             2003 SPECIFICATIONS Max. bending length        2550 mm Distance between column           2550 mm Max. pressing force           80 T Beam stroke         115 mm Approch speed          115 mm/min. Working speed        90 mm/min. Return feed             100 mm/min. Adjustment  X-Axis bac gauge        700 mm Number of controlled axis          X, R, Z1, Z2 Co ...

Capacity: 320 t Folding length: 4100 mm CNC Brand: _Unknown / Other CNC Model: Robosoft ATS 900 MACH-id     5560 MAKE         HACO belgium TYPE           ERM 40320 YOP             2005 SPECIFICATIONS Max. bending length         4100 mm Distance between column        3150 mm Max. pressing force           320 T Dis. Beam - Table         500 mm Beam stroke                  250 mm Troth beam                     330 mm Approch speed               80 mm/min. Working speed                8 m ...

Capacity: 80 t Folding length: 2550 mm CNC Brand: Delem CNC Model: DA 23 MACH-id     5558 MAKE          Darley Holland          TYPE            EHP 80 25/20 YOP              1991 SPECIFICATIONS Max. bending length         2550 mm Distance between column       2050 mm Max. pressing force        80 T Dis. Beam - Table           410 mm Beam stroke                     225 mm Table Width                      160 mm Troth beam                       400 mm Approch speed    ...

Capacity: 200 t Folding length: 3000 mm MACH-id      5485 MAKE           Promecam France TYPE              RG 203 YOP                1980 SPECIFICATIONS Max. bending length          3100 mm Distance between column        2700 mm Max. pressing force          200 T Beam stroke         150 mm Troth beam           300 mm Approch speed      37 mm/min. Working speed      7,5 mm/min. Return feed            60 mm/min. Number of controlled axis       2 DIMENSIONS Length         3115 mm Width        &n ...

Capacity: 50 t Folding length: 2050 mm MACH-id      5319 MAKE          Safan Darley Holland TYPE            UCK 50 - 2050 YOP              1987 SPECIFICATIONS Max. bending length        2050 mm Distance between column       1600 mm Max. pressing force        50 T Dis. Beam - Table        350 mm Beam stroke      115 mm Table Width       100 mm Troth beam         400 mm Approch speed      60 mm/min. Working speed     10 mm/min. Return feed           53 mm/min. Adjustment X-Axis bac gauge        500 mm Number of controlled axis  &nbs ...

Capacity: 600 t Folding length: 2700 mm CNC Brand: Delem CNC Model: DA 66 T Touch MACH-id    5453 MAKE        BAYKAL TYPE          APHS 37600 YOP             2014 SPECIFICATIONS Max. bending length        3700 mm Distance between column        3000 mm Max. pressing force       600 T Dis. Beam - Table         1000 mm Beam stroke           510 mm Adjustment X-Axis bac gauge        1000 mm Number of controlled axis       4 Control         Delem DA66  T TOUCH Power        45 kW DIMENSIONS Length        3700 mm Width          ...

Capacity: 240 t Folding length: 3100 mm CNC Brand: _Unknown / Other MACH-id    5342 MAKE        Baykal TYPE          APHS 3112 x 240 SERIAL      19099 YOP            2013 SPECIFICATIONS Pressbrake / Folding / Mech. / Hydr.   Pressbrake Hydraulic / Mechanical       Hydraulic Backgauge stroke X in mm       700 mm Power        18.5 kW Max. bending length        3100 mm Distance between column       2550 mm Max. pressing force        240 T Beam stroke        260 mm Table Width           90 mm Troth beam           410 mm Approch speed       ...

Capacity: 50 t Folding length: 2050 mm MACH-id    5319 MAKE         Safan Darley Holland TYPE           UCK 50 - 2050 YOP              1987 SPECIFICATIONS Max. bending length         2050 mm Distance between column       1600 mm Max. pressing force                 50 T Beam stroke           115 mm Table Width            100 mm Troth beam             400 mm Approch speed        60 mm/min. Working speed        10 Return feed             53 mm/min. Adjustment X-Axis bac gauge      500 mm Num ...

Capacity: 150 t Folding length: 4300 mm CNC Brand: Safan CNC Model: TS3 Touchscreen MACH-id    5213 MAKE        Safan Darley Holland TYPE          CNCL - K YOP            2002 SPECIFICATIONS Max. bending length          4300 mm Distance between column         3600 mm Max. pressing force          150 T Dis. Beam - table             590 mm Beam stroke                     200 mm Table Width       55 mm Troth beam        400 mm Approch speed     65 mm/min. Working speed       10 Return feed            41 mm/min.  ...

Rated force 2200 Kn Max bending length 3340 mm Table length 3220 mm Table width 180 mm Table height 960 mm Passage between press bar 450 mm Stroke 180 mm Extension 410 mm Distance between stands 2700 mm Max Print 292 Bar Number of cylinders 2 pieces Oil capacity 190 litres Engine power 15 kW Max delivery speed 100 mm/s Working speed 1 - 7.5 mm/s Stroke speed 1 - 75 mm/s Total height with NC 2990 mm Total length with NC 3750 mm Total width with NC 2200 mm and light curtain 250 mm Total weight with NC 12500 kg Amada bending system Length 3750 mm Depth 2200 mm Height 2940 mm

Capacity: 40 t Folding length: 1000 mm CNC Brand: Cybelec CNC Model: DNC 880 MACH-id    5203 MAKE         Beyeler Swiss TYPE           RTS 40 / 1000 YOP             1987 SPECIFICATIONS Max. bending length       1000 mm Distance between column       1000 mm Max. pressing force        40 T Dis. Beam - table        380 mm Troth beam          350 mm Approch speed         110 mm/min. Working speed          10 Return feed         120 mm/min. Adjustment       X-Axis bac gauge   500 mm Number of controlled axis         3 Control   ...

Capacity: 150 t Folding length: 3100 mm CNC Brand: Delem CNC Model: DA 56 MACH-id     5081 MAKE          Darley Holland TYPE            EHP - L YOP              2000 SPECIFICATIONS Throat      250 mm Controll     Delem DA 56 Pressbrake / Folding / Mech. / Hydr.      Hydraulic Pressbrake Hydraulic / Mechanical        Hydraulic Bending length       3100 mm Distance between column       2500 mm Press force      150 Ton Stroke        175 mm Die height        400 mm Backgauge stroke X in mm       1000 mm Power        14 Kw DIMENSIONS  Length    ...

Capacity: 110 t Folding length: 3100 mm CNC Brand: Delem CNC Model: DA 56 MACH-id    5080 MAKE        Darley Holland TYPE          EHP - L YOP            2000 SPECIFICATIONS Throat      250 mm Controll     Delem DA 56 Pressbrake / Folding / Mech. / Hydr.      Hydraulic Pressbrake Hydraulic / Mechanical         Hydraulic Bending length         3100 mm Distance between column        2500 mm Press force        110 Ton Stroke          150 mm Die height       375 mm Backgauge stroke  X  in mm     1000 mm Power         7.5 Kw DIMENSIONS Length  ...

Capacity: 170 t Folding length: 3600 mm CNC Brand: Safan CNC Model: TS 3 Touchscreen MACH-id    5021 MAKE        Safan Darley Holland TYPE          CNCL-K YOP             2003 SPECIFICATIONS        Controll        TS 3 Touchscreen Pressbrake / Folding / Mech. / Hydr.    Pressbrake Hydraulic / Mechanical        Hydraulic Bending length        3600 mm Distance between column         3100 mm Press force        170 Ton Throat         400 mm Stroke        200 mm Die height        590 mm Backgauge stroke X in mm      1000 mm Number off controlled axis    ...

Capacity: 150 t Folding length: 4300 mm CNC Brand: Delem CNC Model: DA 23 MACH-id    5019 MAKE         Darley Holland TYPE           EHP 150 43 /37 YOP              1993 SPECIFICATIONS Controll        Delem DA 23 Pressbrake / Folding / Mech. / Hydr.       Pressbrake Hydraulic / Mechanical         Hydraulic Bending length      4300 mm Distance between column       3700 mm Press force      150 Ton Throat     300 mm Stroke         175 mm Die height         400 mm Backgauge stroke  X in mm      1000 mm Number off controlled axis         4  ...

Capacity: 50 t Folding length: 1550 mm CNC Brand: Delem CNC Model: DA 66 W MACH-id     4471 MAKE         Darley TYPE          EHP LS 50 . 15 CL YEAR         2010 SPECIFICATIONS Controll        Delem DA 66 W Pressbrake / Folding / Mech. / Hydr.     Pressbrake Hydraulic / Mechanical         Hydraulic Bending length          1550 mm Distance between column         1250 mm Press force         50 Ton Throat          400 mm Stroke           225 mm Die height       410 mm Backgauge stroke       X in mm       1000 mm Number off co ...

Capacity: 110 t Folding length: 4300 mm CNC Brand: _Unknown / Other CNC Model: Touchscreen ARA MACH-id    4418 MAKE        SAFAN Holland TYPE           PLCS 110 - 4300 TS3 YEAR           1998 SPECIFICATIONS Controll         Touchscreen  ARA Pressbrake / Folding / Mech. / Hydr.       Pressbrake Hydraulic / Mechanical            Hydraulic Bending length       4300 mm Distance between column           3600 mm Press force        110 Ton Throat         400 mm Stroke         180 mm Die height      480 mm Backgauge stroke X in mm       1000 mm  ...

Capacity: 320 t Folding length: 4500 mm CNC Brand: Cadman CNC Model: B Touch MACH-id   4181 MAKE        LVD Belgium TYPE         PPEB-EFL 320/4500 YEAR        2011 SPECIFICATIONS Controll       Cadman B Touch Pressbrake / Folding / Mech. / Hydr.   Pressbrake      Hydraulic / Mechanical       Hydraulic Bending length      4500 mm Distance between column      3820 mm Press force      320 Ton Throat    600 mm Stroke     500 mm Die height       770 mm Backgauge stroke X in mm   1000 mm Number off controlled axis   6 Power    37 kW DIMENSIONS Length   4500 mm Width     2500 ...

Capacity: 110 t Folding length: 4300 mm CNC Brand: _Unknown / Other CNC Model: Touchscreen TS3 MACH-id   4144 MAKE      Safan - Darley Holland TYPE        PLCS 110 - 4300 YEAR       1998 SPECIFICATIONS Controll    Touchscreen TS3 Pressbrake / Folding / Mech. / Hydr.   Pressbrake Hydraulic / Mechanical         Hydraulic Bending length        4300 mm Distance between column         3600 mm Press force         110 Ton Throat       400 mm Stroke         180 mm Die height      480 mm Backgauge stroke X in mm      1000 mm Number off controlled axis      4 Power       7.5 kW  ...

Capacity: 25 t Folding length: 1250 mm CNC Brand: _Unknown / Other CNC Model: ARA Touchscreen TS1 MACH-id   4147 MAKE       Safan Darley TYPE         SMK 15 - 1250 TS1 YEAR   1999 SPECIFICATIONS Controll        ARA Touchscreen TS1 Pressbrake / Folding / Mech. / Hydr.        Pressbrake      Hydraulic / Mechanical      Mechanical Bending length     1250 mm Distance between column        1250 mm Press force           25 Ton Stroke        115 mm Backgauge stroke X in mm         600 mm Number off controlled axis     3 Power     6 kW DIMENSIONS Length      1600 mm Width&nbs ...

Capacity: 80 t Folding length: 2000 mm CNC Brand: Cadman CNC Model: B MACH-id     4142 MAKE          LVD - Belgium TYPE           PPEB - EQ YEAR         2001 SPECIFICATIONS Controll      CADMAN B Pressbrake / Folding / Mech. / Hydr.       Pressbrake Hydraulic / Mechanical        Hydraulic Bending length       2000 mm Distance between column        1550 mm Press force         80 Ton Throat       400 mm Stroke         200 mm Die height        400 mm Number off controlled axis       6 Power   12.5 kW DIMENSIONS Length       3000 mm ...

Capacity: 110 t Folding length: 3100 mm CNC Brand: _Unknown / Other CNC Model: ARA MACH-id   4026 MAKE       Safan Darley Holland TYPE         CNCS 110 - 3100 YEAR        1989 SPECIFICATIONS Controll    ARA Backgauge Pressbrake / Folding / Mech. / Hydr.   Pressbrake Hydraulic / Mechanical      Hydraulic Bending length     3100 mm Distance between column    2550 mm Press force       110 Ton    Stroke           300 mm Backgauge stroke       X in mm     0 - 1000 mm Number off controlled axis     4

Capacity: 35 t Folding length: 1200 mm CNC Brand: Delem CNC Model: M - 51 MACH-id   3969 MAKE        Baykal TYPE          APH YEAR         20.. SPECIFICATIONS Controll   Delem M-51 Pressbrake / Folding / Mech. / Hydr.   Pressbrake      Hydraulic / Mechanical     Hydraulic Bending length     1200 mm Distance between column   1070 mm Press force    35 Ton Throat    410 mm Stroke    60 mm Die height    470 mm Backgauge stroke X in mm500 mmNumber off controlled axis3Power4 kWDIMENSIONSLength1250 mmWidth1270 mmHeight2150 mmBaykal CNC Pressbrake

Capacity: 200 t Folding length: 3100 mm CNC Brand: Delem CNC Model: DA 70 in 4 Axis MAKE   ERMAK TYPE    CNC HAP YEAR    2007 SPECIFICATIONS Controll   Delem DA 70 in 4 Axis Pressbrake / Folding / Mech. / Hydr.   Pressbrake Hydraulic / Mechanical    Hydraulic Bending length   3100 mm Distance between column  2550 mm Press force  200 Ton Throat        400 mm Stroke   200 mm Die height    435 mm Backgauge stroke X in mm   750 mm Number off controlled axis  4 Power   15 kW DIMENSIONS Length   4550 mm Width    2250 mm Height   2850 mm Ermak cnc pressbrake

Capacity: 130 t Folding length: 2690 mm CNC Brand: Delem MAKE   TRUMPF Austria TYPE     Trumabend V130 YEAR    2002 SPECIFICATIONS Controll      DELEM Pressbrake / Folding / Mech. / Hydr.   Pressbrake    Hydraulic / Mechanical    Hydraulic Bending length    3060 mm Distance between column   2690 mm Press force   130 Ton Throat   410 mm Stroke    365 mm Die height    535 mm Backgauge stroke X in mm    860 mm Number off controlled axis   6 Power    18.5 kW DIMENSIONS Length    4000 mm Width      3000 mm Height     2800 mm Trumpf CNC Pressbrake TRUMABEND V130, we have more Trumpf machines in stock.

Capacity: 50 t Folding length: 1270 mm CNC Brand: _Unknown / Other CNC Model: AB PAD Revolition Touch Screen MACH-id   3726 MAKE        AMADA Japan TYPE          HFE M2 5012 YEAR         2011 SPECIFICATIONS Controll     AB - PAD EVOLUTION TOCH SCREEN Pressbrake / Folding / Mech. / Hydr.     Pressbrake   Hydraulic Bending length    1270 mm Distance between column       1035 mm Press force             50 Ton Throat       100 mm Stroke          150 mm Die height    370 mm Number off controlled axis   R / Z Power   6 kW DIMENSIONS Length    2710 mm Width     2320 mm Height&n ...

Capacity: 80 t Folding length: 2550 mm CNC Brand: Cadman CNC Model: Touch MAKE   LVD - Belgium TYPE    PPEB EASY FORM YEAR   2010 SPECIFICATIONS Controll   CADMAN TOUCH Pressbrake / Folding / Mech. / Hydr.  Pressbrake Hydraulic / Mechanical   Hydraulic    Bending length   2550 mm Distance between column   2000 mm  Press force   80 Ton Throat   200 mm Stroke   400 mm Die height   400 mm Backgauge stroke X in mm   600 mm Number off controlled axis  8 Axis X1 / Xz / r1 / Y / Z1 / V1 / Z 2 / W1 Power   11 kW DIMENSIONS Length   3380 mm Width    1900 mm Height   2700 mm

Capacity: 340 t Folding length: 6200 mm CNC Brand: Delem CNC Model: DA 42 MACH-id   3446 MAKE   Darley Holland TYPE   EHP 340 / 62/51 YEAR   1989 SPECIFICATIONS   Controll   Delem DA 42 Pressbrake / Folding / Mech. / Hydr.  Pressbrake   Hydraulic / Mechanical   Hydraulic Bending length   6200 mm Distance between column   5100 mm Press force   340 Ton Throat   350 mm Stroke   250 mm Die height   500 mm Backgauge stroke X in mm  1000 ? mm Number off controlled axis   4 Power 33.5 kW DIMENSIONS   Length   6400 mm Width   2075 mm Height   3680 + 1470 Ground mm

Capacity: 100 t Folding length: 3110 mm CNC Brand: Amada CNC Model: AB PAD Max. bending length:        3110mm Distance between column:    2705mm Max. pressing force:        100T Dis. Beam - Table:          470mm Beam stroke:                200mm Troth beam:                 420mm Approch speed:              100mm/min. Working speed:              10mm/min. Return speed:               100mm/min. Adjustment X-Axis back gauge:1000mm Number of controlled axis:  4 (Y/X/R/Z-Axis) Control:                    AMADA AB Pad 10,4" TOUCH Power:      &nbs ...

The press brake HAMMERLE BM 200-3100 press brake was built in 1996. The folding machine was serviced regularly. Technical parameters of the press: - control: INFINITRON - number of NC axes: 11 - pressure: 200 tons - bending length: 3100 mm - working stroke: 400 mm - distance between the body walls: 3240 mm - maximum distance between the table and the bumper: 965 mm - voltage: 3 x 400 Volt - control voltage: 24 V = - total power: 28 kW - deflection arrow compensation - total machine width: 4400 mm - total height of the press: 3400 mm - weight of the press: 16 600 kg

Hydraulic press brake make EHT type APN 80Machine -No: 20377, built in 1970Max. Pressing pressure: 80 tTable length: 3550 mmTool length: 3550 mmDistance between the stands: 3050 mmStand projection: 250 mmRam stroke hydraulic: 100 mmPush stroke mechanical: 80 mmDrive power of the high-pressure pump: 11 kWDrive power of the gear motor: 0.75 kWPressure in the retraction system: 120 - 150 atüNitrogen loading in the accumulator: 80 atmContent of accumulator: 10 lContent of the oil tank: 280 lOil quality Hydraulic oil: 3 ° E at 50 ° COperating voltage three-phase: 380 volts, 50 HzControl voltage: 220 voltsDrive power: 12 kWWeight approx: 9550 kgExternal dimensions: 3565 x 1680 x 2700 mmusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer ...

pressure: 65 t chamfer lenght: 2500 mm distance between columns: 2050 mm table width: 140 mm table height: 750 mm total power requirement: 8 kW weight of the machine ca.: 4,5 t dimensions of the machine ca.: 3, x 1,2 x 2,6 m Equipment: • manual back stop • upper and lower tools • 2 manual operation / foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hydr. Press brake LAMI-NOVA (Spain) Type G-4180 Fabr. No. G-94472506 Year of construction 1994 Printing capacity 180 ton. Working length 4000 mm Projection 300 mm Stand width 3100 mm Ram stroke 200 mm Distance table - tappet max. 410 mm Table size 4050 x 188 mm Motor power 11 kW Mains connection 400 Volt, 50 Hz, approx. 18 kW - Lower tool with 6 different prisms (4050 mm long)- split upper tool (7 parts, 4250 mm) - manual adjustment of the press depth via handwheel with counter- motorized backgauge 750 mm - electric foot control and 2-hand control - 2 pieces material support arms foldable Space requirement L x W x H 4250 x 1700 x 2500 mm Weight 12 ton. good condition; used

pressure: 160 t chamfer lenght: 4000 mm distance between columns: 3060 mm control: FORTRON CNC 10 H 4 throat: 280 mm stroke: 250 mm dayligth: 500 mm table length: 4050 mm table width: 280 mm feed down: 70 mm/sec feed up: 68,4 mm/sec working feed: 9 / 3,5 mm/sec operating pressure: max. 205 bar oil volume: 400 l total power requirement: 19,5 kW weight of the machine ca.: 20,8 t Total weight including accessories: 22 t dimensions of machine L x W x H: 4,8 x 1,88 x 2,93 m dimensions of switch cabinet: 1,6 x 0,5 x 2,25 m Acc.: programmable back gauge, upper and lower dies, table extensions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t chamfer lenght: 3000 mm distance between columns: 2560 mm dayligth: 450 mm throat: 450 mm adjustment of stroke: 240 mm horn length over column outer edge each: 175 mm table length: 3050 mm table width: 280 mm table height over floor: 820 mm electrics - voltage/frequency: 220/50 V/Hz control: CYBELEC, DNC60 stroke: 250 mm operating pressure: 150 bar total power requirement: kW weight of the machine ca.: 15 t dimensions of the machine ca.: L:4,0 x B:3,2 x H:3,44 m • hydraulical press brake, • new control CYBELEC DNC60 (in 2005), • lower part of the machine moves down 500 mm to the floor, at the moment the machine is mounted on a double-T-support, • prism and upper part of the machine in 3000 mm length The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 300 t chamfer lenght: 3050 mm distance between columns: . mm Control: Cybeleg type: DNC880S total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

LVD tooling Capacity: 100 ton x 3100 mm Backgauge: CNC Passage between uprights: 2550 mm Max stroke: 150 mm Max distance between table -- ram: 350 mm Depth of throat: 250 mm Table width: 200 mm Locking speed: 100 mm/sec Working speed: 8 mm/sec Returning speed: 50 mm/sec Electric motor (power): 10 HP Length: 3410 mm Depth: 1480 mm Height: 3050 mm Weight: 9 ton

pressure: 160 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 90 mm/sec return speed: 80 mm/sec work speed: 7,5 mm/sec work stroke: 160 mm dayligth: 395 mm oil volume: 200 ltr. table height: 900 mm back stop - adjustable: 800 mm voltage: 400 Volt total power requirement: 11,0 kW weight: 7.524 kg range L-W-H: 4250x1900x2550 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 60 t chamfer lenght: 2100 mm distance between columns: 1700 mm column arm: 410 mm ram stroke speed: 200 mm/sec return speed: 165 mm/sec work speed: 14,0 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90,0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7,5 kW weight: 5640 kg range L-W-H: 3012x1960x2750 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 135 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90,0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15,0 kW weight: 11.950 kg range L-W-H: 5100 x 2150 x 2850 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 185 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm voltage: 400 Volt back stop - adjustable: 800 mm table width: 160 mm total power requirement: 18,5 kW weight: 14.000 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z ...

pressure: 160 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 250 mm ram stroke speed: 90 mm/sec return speed: 6,1 mm/sec work speed: 60 mm/min work stroke: 160 mm dayligth: 395 mm oil volume: 200 ltr. table height: 900 mm voltage: 400 Volt weight: 8.514 kg range L-W-H: 4910x1900x2550 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 160 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18,5 kW weight: 12.906 kg range L-W-H: 5100 x 2250 x 2900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 185 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 930 mm table width: 200 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18,5 kW weight: 11.020 kg Dimensions (HxWxD): 5050 x 2250 x 2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 320 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 140 mm/sec return speed: 150 mm/sec work speed: 10,5 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 240 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30,0 kW weight: 16.925 kg Dimensions (HxWxD): 4550 x 2450 x 3200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
