入选编号：9154 类型：17-10 FP NC/5 制片人：瓦尔德里希·科堡 创建时间：1985年，GO 2011年 参数： 操作系统：Sinumerik 840 桌面长度：5000毫米 桌面宽度：2500毫米 最大工件重量：60000 kg 重量：125000公斤 冷却液在机器主轴区域泄漏。 1997/2008/2011年间，该机进行了操作操作。
这款五轴的WALDRICH COBURG 17-10 FP NC/5发动机于1985年制造，最终于2011年完成改装。其最 工件重量为60吨，工作台尺寸为2,500毫米乘5,000毫米 该机配备了Sinumerik 840控制系统，确保操作的精准。如果您希望获得高质 的铣床功能，可以考虑我们正在出售的WALDRICH COBURG 17-10 FP NC/5门式铣床。如需更多信息，请联系我们
Waldrich Coburg 17 S-10 FP 300 NC / 5 m – CNC Gantry Milling Machine Machine: 17-10 FP 300 NC / 5 m Serial Number: 2.8304.06 Original Year of Manufacture: 1983 In 2016, it was comprehensively overhauled and modernized by the manufacturer Waldrich Coburg. The machine is equipped with a modern Siemens SINUMERIK 840D sl control system and is ideally suited for heavy-duty machining of large and complex workpieces in machine, tool, mold, and power plant construction. The delivery includes a Universal Fork Milling Head USP 300 C 350 with B-axis as well as an additional Angle Milling Head WFU 500 SZ 400 F17 , ensuring versatile machining capabilities for demanding milling tasks. The machine features a modern full protective enclosure, coolant system, chip conveyor technology, and extensive technical documentation including circuit diagrams and overhaul documentation. The system ...
Upper support, cross support, cross table, cross slide table -Upper support comes from a Waldrich Coburg portal milling machine type: 12 D 3232-550 HL -Table surface: mm -Travel: x 350 mm/y 220 mm -Dimensions: 1380/1000/H800 mm -Weight: 800 kg
x-travel: 6000 mm y-travel: 3500 mm z-travel: 1500 mm Control: 840 D table load: 12 t height over floor: 6300 mm table dimension - longitudinal: 5000 mm table dimension - cross: 2500 mm tool change unit: 200- fach weight of tools max.: 30 kg tool taper: HSK A 100 tool diameter: 250 mm tool length - max.: 500 mm spindle speed:: 5 -6000 U / min c-axis: -10 bis 370 ° b-axis: 5 bis -95 ° column daylight: 3000 mm total power requirement: kW weight of the machine ca.: 161 t dimensions of the machine ca.: 20,5 x 11 x 6,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
workpiece diameter: 25-90 mm threading length: 3000 mm thread pitch: 2-16 mm total power requirement: 25 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
grinding length: 8400 mm grinding width: 1450 mm workpiece height: 1250 mm surface area: 8000 x 1250 mm table height over floor: 920 mm distance between columns: 1470 mm workpiece weight max.: 59700 kg weight of the machine ca.: 59,7 t dimensions of the machine ca.: 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW The data for this ad was created with ModulMWS - the ...
x-travel: 6000 mm y-travel: 3500 mm z-travel: 1500 mm total power requirement: kW weight of the machine ca.: 161 t dimensions of the machine ca.: m x-travel 6000 mm y-travel 3500 mm z-travel 1500 mm CNC control 840 D Table load 12 t Table dimensions - lengthways 5000 mm Table dimensions - crossways 2500 mm ATC tool changing device 200-pos. Tool weight max. 30 kg Tool holder HSK A 100 Tool diameter 250 mm Tool length - max. 500 mm Spindle speed: 5 - 6000 rpm C-axis -10 to 370 deg B-axis 5 to -95 deg Column distance 3000 mm Machine weight approx. 161 t Space requirement approx. 20.5 x 11 x 6.3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
table diameter: 900 mm Table load: 3000 kg Daylight: 580 stroke: 95-800 mm total power requirement: kW weight of the machine ca.: 8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 6300 mm y-travel: 2200 mm workpiece height: 1835 mm Table area: 6000x1835 mm Rest: 2 Side head: 2 number of T-slots: 7 T-slot - distance: 240 mm T-slot - width: 28 mm bed length: 14650 mm column daylight: 2075 mm feed: 5-60 m/min workpiece weight: 15000 kg total power requirement: kW weight of the machine ca.: 55 t dimensions of the machine ca.: 14,65x4,37x4,05 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 15500 mm y-travel: 6800 mm z-travel: 3400 mm Control: Siemens Sinumerik 840 D w-axis: 2000 mm table surface area: 15000 x 5000 mm passage width: 5900 mm Passage height: 5030 mm main drive motor: 150 kW spindle taper ISO: 60 milling head speed: 6-750 (2250) U/min workpiece weight: . t total power requirement: - kW weight of the machine ca.: ca 270 t dimensions of the machine ca.: - m modernized in 2008 and equipped with: - CNC control Siemens Sinumerik 840 Dsl - movable Portal - Coolant -- Coolant through spindle -- external Cooling - set of milling heads 9ea -- high speed spindle head SLA 23 / 3 SZ (2250 U/min) -- horizontal head WFU 2100 SZ / 500 S 22 -- WFU 500 SZ / 500 S 22 -- WFU 250 B / 500 S 22 -- EFK 40 E / 600 C 22 -- EFK 250 SZ / 850 S 22 -- horizontal head HSD 250 C / 1450 S 22 -- HS 800 C / 600 S 22 -- vertical head VL 300 SZ / 65 ...
导轨磨床 Waldrich Coburg -30-10 S 3640 控制：西门子 840D 制作年份：2012 旅行： X轴 8,825 mm Y 轴 3,010 mm Z轴 2,500 mm 工作台长度 8,000 mm 工作台宽度 1,800 mm 工作台负载： 18,000 kg 进给 X 轴： 1 - 45,000 mm/min 进给 Z 轴：100 - 3,000 mm/min 通用磨头 S10，倾斜 110 度 / 2500 rpm / 7.5 kW 立式磨头 S30,600 x 150 / 930 rpm / 22 kW 机器左右两侧双西门子840D控制器 自动门 （4x），便于进入机器/负载/夹紧 工作载荷为18000 kg的液压工作台驱动 KNOLL HL650/4000 过滤系统 2023 年新品 各种砂轮 大型包装备件/滚珠丝杠/盖板 2012年装修，耗资150万欧
throat: 1410 mm workpiece height max.: 1150 mm stroke: 1400 mm table diameter: 1400 mm milling-head swivable +/-: 10 ram - range of adjustment: 750 mm pulling power: 50000 N workpiece weight: 10000 kg Ram stroke speed: 30 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
throat: 645 mm workpiece height max.: 550 mm stroke: 360 mm table diameter: 650 mm milling-head swivable +/-: 15/80 no. of strokes: 100 Hub/min total power requirement: 6 kW weight of the machine ca.: 4,3 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 9700 mm y-travel: 3500 mm z-travel: 640 mm w-axis: 3000 mm Control: Siemens type: 840D PL spindle diameter: 200 mm Spindle capacity: 85 Kw surface area: 9000x2800 mm Table load: 40000 kg high speed spindle taper ISO: 50 chip conveyor: coolant: total power requirement: kW weight of the machine ca.: 193,8 t dimensions of the machine ca.: 22,4x10,2x8,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
这台三轴瓦尔德里奇·科堡30-15 S 2525磨床于1991年制造。其结构坚固，尺寸为11,500 x 6,610 x 5,170毫米，重量约为45,800公斤。能够处理高达11,000公 的工件，研磨长度为3,500毫米，研磨宽度为1,450毫米 如果你想获得高质量的研磨能力，可以考虑我们出售 的WALDRICH COBURG 30-15 S 2525机器。请联系我们了解更多信息
- 导轨/滑轨/平面磨床- 通用磨头 S10，倾斜 110 度 / 2500 rpm / 7.5 kW- 立式磨头 S30，Ø 600 x 150 / 930 rpm / 22 kW- 双西门子 840D 控制面板左右机- KNOLL HL650/4000 过滤系统 2023 年新款- 自动门 （4x），便于机器/装载/夹紧通道 - 液压工作台驱动，工作负荷为 18000 公斤 - 2012 年重建，容量为 1.5 Mil EUR- 大包装翻边和石头- 大包装备件/滚珠丝杠/测量/保护
Key data: 10000 , 3950 , 2500
用于加工大型零件以及许多小型工件。 机器于 2021 年进行了现代化改造 CNC FANUC控制架类型 X 轴 10000 mm Y 轴 3950 mm Z 轴 2500 mm 工作台长度 8000 mm 工作台宽度 2800 mm 工作台最大负载 60000 kg 主轴最高转速 2000 rpm ------------------- 长x宽x高171000.0 ×93300.0 ×67600.0 重量 150000 kg 该机器配备了稳定的工作台和坚不可摧的组件，可以 最高精度执行铣削、钻孔和攻丝等任务，从而保证 各行各业的最大程度的工艺优化
