PRESS BRAKES TRUMPF TruBend Cell 5230 S (B03)

Standard configuration

Machine
⦁ Stable machine frame as all-steel construction
⦁ Ram, stress relief annealed
⦁ Spherical ram suspension, with ram tilt
⦁ Electro-hydraulic upper drive with 4-cylinder technology (IE3 drive motor)
⦁ Electronic pressure balance
⦁ Measuring system: With centered glass scales and temperature compensation.
⦁ Hydraulic oil filled in the machine (lifetime lubrication)
⦁ Oil cooler
⦁ Switch cabinet cooling (air-air heat exchanger)

Backgauge system
⦁ Backgauge system 2-axes
⦁ 2 pieces back gauge fingers

Tool holder
⦁ Manual upper tool clamping
⦁ Hydraulic lower tool

Crowning
⦁ Manual crowning: Integrated in the table, manual adjustable crowning via wedges.

Lower Tool Adjustement
⦁ Lower tool adjustment CNC, programmable

Safety
⦁ Standard Safety equipment

Control options
⦁ TRUMPF TASC 6000
⦁ Network connection machine control

Operation
⦁ Communication Track: For use of ACB-angle sensor tools (module) and the options Mobile Control
⦁ Control panel: With LCD panel, footswitch for Emergency up, down and E-STOP

Additional Equipment

Backgauge system
⦁ 6-axis backgauge system

Clamping system
⦁ Hydraulic upper tool clamping

Crowning options
⦁ CNC crowning

Machine Options
⦁ Tank heating
⦁ Additional options TruBend
⦁ Optical setup and positioning aid
⦁ Work area lighting rear
⦁ Work area lighting front
⦁ Switch cabinet air conditioning
- Up to 50 °C ambient temperature

Automation

Stan dard configuration BendMaster (150)
Machine
⦁ Stable frame and manipulator: Light-weight and rigid aluminum cast construction
⦁ Payload: the max. payload of 150 kg consists of gripper and blank weight. The max. blank weight is 100 kg
⦁ Floor tracks: Low in height, of welded construction with stable guide rail. Length 6000 mm, travel 4550 mm
⦁ Electrical drives: Electrical servo-motors with gearing
⦁ Double sheet detection
⦁ Sheet sensor
⦁ Rotary harness for easy Gripper change
⦁ Gripper coupling
⦁ Sensors for 4-axis backgauge system
⦁ Vacuum generation for suction Grippers
⦁ NC repositioning station
⦁ Platform for TruBend

Safety
⦁ Safety fence with access door

Control options
⦁ TRUMPF PC control with operating terminal
⦁ Comfort operation with monitor, mouse, keyboard

Automation options

Extension of floor tracks
⦁ Extension of floor tracks to 12 m

Material handling
⦁ Sensor for 6 axis back gauge
⦁ Automatic Gripper change module

Vacuum Gripper Technology
⦁ 2 x vaccuum grippers
⦁ Vacuum Gripper kit without separator
- contains several components for assembling another 3 grippers



seller offer No. resale PM-1450
