The Smipack XP 650 ALX is a fully automatic monobloc overlap shrink
wrapper with an inline infeed conveyor. It packs products like
glass/PET bottles, cans, jars, and boxes at speeds up to 25 packs per
minute using a single film reel system. [1, 2, 3, 4], Key Features,
Operation Modes: Works with film-only, or with pad/tray configurations
depending on exact model variations (like ALX-T or ALX-P)., Infeed
System: Multi-row inline infeed with an electromechanical oscillating
sorter to align products., Film Handling: Single film reel design with
optional printed film centering devices., Shrink Tunnel: Built with an
efficient double-chamber shrinking setup. [1, 2, 3, 4, 5, 6],
Technical Specifications, Max Output: Up to 25 packs per minute (ppm),
Max Product Height: 380 mm, Max Reel Size: 650 x Ø 400 mm, Working
Pressure: 6 Bar, Machine Weight: Approx. 1,682 kg, ed linking conveyor
into a high-performance double-chamber tunnel for final heat
shrinking., Standard Built-In Features, Pneumatic Reel Locking: Uses a
dedicated reel chuck with convenient built-in rollers to streamline
heavy roll replacements., Safety & Control: Equipped with sliding
protection doors featuring a deceleration device, manual reel sealers,
and a metric-graduation centering system., Sensor Grid: Features a
complete array of photocells monitoring product presence, infeed
obstruction, film wrapping, and tunnel outlet accumulation., Are you
interested in reading about the FLXMOD® control system details, or do
you need a list of available optionals like the printed-film centering
device?, AI responses may include mistakes. Learn more, Year of
construction: 2019 & 2021, Max speed: 72000, Current size (ml): 3×2,
Container material: Can, Glass, Pet, Max. container: height 170 mm,
Packaging Type: Film, Number of lanes: 8, Max reel size: Ø 500 mm,
Number of reels: 2, Automatic Changeover: No, Compatible Spare Parts:
6 months, Dimensions: 17500x1800x2400 mm, Power: 182 kW, Compressed
Air: 6 bar
