Podnośnik magazynowy KARDEX Shuttle XP

We offer an LTG-TowerMax L 67.9-245-3050-610-4360 storage lift modernized by us with a completely new StoreControl L control system.

Exterior Dimensions:
Height 4360 mm
Overall width 3380 mm
Overall depth 2312 mm

Total machine payload up to 2 x 33,950 kg

29 carriers for up to 245 kg payload each (additional carriers optionally available)
in clear usable dimensions:
W = 3050 mm
T = 610 mm
Usable height up to 50 to 750 mm

Start of the operating opening in 900 mm above OKFF, then 800 mm high; with automatic lifting door,

Engine power
Vertical drive 2.2 kW / 400 volts
Horizontal drive 0.75 kW / 400 Volt
Door drive 0.25 k W
Colour scheme grey/blue, Traeger galvanised
Surface cleaned, traces of use possible

subject to errors as well as technical changes or detail deviations in photos,
Delivery and installation currently mainly in D, A and several neighboring countries
seller offer No. resale L67.9-245-3050-610-4360
