AMTEC TB M GL 管状バッグマシン水平

Automatic packing machine for filling and packing tea into common rectangle tea bags. Including Volume dosing unit and tag system. Tag system: in the standard version the label is folded and glued together with the inserted thread. Optionally, a heat-sealing module is available for this production step. Method for attaching the thread to tea bags: by heat sealing into the tea bag edge. Tea bags are dispensed stacked e.g. into a tray or into an already erected tea package.- Specifications: max. speed of the machine in neutral: 120 cycles per minute | dosing volume: max. 6cm? | tea bag dimensions LxW: 62.5x50 mm | roll width tea bag material: 125 mm | suitable tea bag material: 16.5-20g/m?, one side heat sealable | label (LxW): 28x24mm | thread length: 210mm | number of pieces output stack: a) 25 / 50 / 100 b) 30 / 60 c) 20 / 40 | power supply: 380V | power consumption: 1.5kW | machine dimensions LxWxH: 1700x900x200 mm | weight: 640kg.
Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
