VOLLMER CEF 350

Suitable for automatic, double-sided tooth flank grinding on carbide-tipped circular saw blades., Accessories:, Total enclosure., Coolant System,, Automatic central lubrication,, Expansion of diameter range from 80 – 1,430 mm, Circular sawblade outer diameter: 80 to 1430 mm, Circular sawblade bore diameter: 10 - 220 mm, sheet thickness: up to 14 mm, rake angle: -15° to +40°, Radial free angle: -6° to 6°, Tangential free angle: up to +8°, Grinding path: Max. 30 mm, Grinding speed: 0.5 - 20 mm/s, Tooth pitch: 6 - 120 mm, Grinding wheel diameter: 80 to 125 mm, Grinding wheel bore diameter: 32 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Dimensions W x D x H approx.: 2395 x 1590 x 1970 mm, colour: green/grey, Weight approx: 1750 kg
seller offer No. resale CEF350
