Hymmen CombiCoater
已验证卖家
询问价格
直接联系卖家
暂无图片
暂无图片
技术参数
· ID 170389261二手设备
- 出厂年份
- 2004
- 所在地
- D - Nordrhein-Westfalen
Identifikation
制造商Hymmen
型号CombiCoater
物品编号3317899
Technik
数量1
描述
- Manufacturer: Hymmen
- Type: ULX
-S, Combi Coater
- Year of manufacture: 2004
- Operating side: left
- For single
-sided coating application
- Oscillating coating roller squeegee Technical data:
- Maximum working width: 1.300 mm
- Conveyor belt width: 1.270 mm
- Workpiece thickness 3
- 120 mm
- Working height: 850
-950 mm
- Installation length: 940 mm
- Width: 2.800 mm
- Height: 1.860 mm
- Application roller, rubberized EPDM, ~ D: 238 mm
- Application roller Shore hardness: 45 (can be changed)
- Metering roller, chrome
-plated, D: 174 mm
- Counterpressure roller, D: 190 mm
- Transport speed, adjustable from approx. 6
- 30 m/min.
- Compressed air 6 bar, G1/4 inch, approx. 50 NL/min.
- Operating voltage 400 V, 50 Hz, 3 phases
- Total connected load: ~ 5 kW
- With control cabinet
- Weight: ~ 1.400 kg
- Location: in warehouse 32825 Blomberg
- Type: ULX
-S, Combi Coater
- Year of manufacture: 2004
- Operating side: left
- For single
-sided coating application
- Oscillating coating roller squeegee Technical data:
- Maximum working width: 1.300 mm
- Conveyor belt width: 1.270 mm
- Workpiece thickness 3
- 120 mm
- Working height: 850
-950 mm
- Installation length: 940 mm
- Width: 2.800 mm
- Height: 1.860 mm
- Application roller, rubberized EPDM, ~ D: 238 mm
- Application roller Shore hardness: 45 (can be changed)
- Metering roller, chrome
-plated, D: 174 mm
- Counterpressure roller, D: 190 mm
- Transport speed, adjustable from approx. 6
- 30 m/min.
- Compressed air 6 bar, G1/4 inch, approx. 50 NL/min.
- Operating voltage 400 V, 50 Hz, 3 phases
- Total connected load: ~ 5 kW
- With control cabinet
- Weight: ~ 1.400 kg
- Location: in warehouse 32825 Blomberg
