2003년에 제작된 CO2 레이저 절단기. 이 BLM 아디제 LT702는 최대 절단 두께 8mm를 자랑하며, 최소 20x10mm에서 최대 140mm까지 다양한 프로파일 치수를 처리할 수 있습니다. 튜브 및 박스 단면을 효율적으로 절단하기 위해 2.5kW CO2 레이저 기술을 사용합니다. 고품질 절단 능력을 원하신다면, 저희가 판매 중인 BLM Adige LT702 기계를 고려해 보세요. 자세한 내용은 저희에게 문의해 주세요.
This 9-axis BLM DH4010 fully electric CNC wire bending machine was manufactured in 2022. It features a dual-head design with a maximum wire diameter capacity of up to 12 mm for wire with tensile strength of 600 MPa. The machine includes advanced programming software, realistic 3D simulation, and automatic wire feeding. If you are looking to get high-quality wire bending capabilities, consider the BLM DH4010 machine we have for sale. Contact us for further details.
Fully electric CNC tube bending machine manufactured in 2022. This BLM E-TURN 52B features a Siemens Simotion CNC control system and offers advanced bending capabilities, including fixed radius, variable radius, and multi-radius bending. It is designed for low energy consumption and includes programmable booster and tooling stacks for enhanced performance. If you are looking to get high-quality tube bending capabilities, consider the BLM E-TURN 52B machine we have for sale. Contact us for further details.
This 3-axis BLM Adige LT9 Combo Fiber 3kW was manufactured in 2012. It features a maximum raw material length of 6,500 mm and can process round tubes with a diameter of up to 225 mm. The machine is equipped with a powerful 3 kW fiber laser, ideal for cutting tubes, profiles, and sheet metal. If you are looking to get high-quality cutting capabilities, consider the BLM Adige LT9 Combo Fiber 3kW machine we have for sale. Contact us for further details.
6.5m 번러 로더와 4.5m 방류기를 갖춘 Adige LT5 광섬유는 다음과 같이 장착되어 있습니다: 4.5m 완성 부품 수집 테이블 후방 스크랩 컨베이어 1KW IPG 광섬유 레이저 칠러 추출기 용접 이음새 감지기
Manufacturer: BLM Group Adige Model: LT Fiber Type of Machine: Fiber Laser Tube Cutting Machine Year of Manufacture: 2016 Condition: Works well and is currently in production Operating Hours: 37,169 hours Find more here - .ucymachines/ Contact us at - sales@ucymachines
CNC tube banding machine Type: ELECT 52 Manufacturer: BLM Year: 2016 Fully electric dual-direction tube bending machine (9-axis) Control: Siemens SIMOTION Cycle hour counter: 7344 Number of parts produced: 5143 Mandrel rod set length: 4.2 m + extension of usable length to 4.5 m 3D visual programming system (VGP3D) – software for 3D graphical programming with feasibility analysis and bending process optimization B-RIGHT – automatic springback and elongation correction BOOSTER 20 – pushing booster with 2000 kg force Machine toolings: bending tools for tubes: Ø17.2 (r-68.6 mm) fixed and variable radius + collet (pinza) + clamping plate + adapters + mandrel Ø21.3 (r-70.7 mm) fixed and variable radius + collet (pinza) + clamping plate + adapters Ø26.9 (r-83.5 mm) fixed and variable radius + collet (pinza) + clamping plate + adapters + mandrel Ø33.7 (r-107 mm) fixed ...
CONTROLS CNC controls BLM VGP 3D TECHNICAL SPECIFICATION Max. diameter of tube: 28 mm Max. wall thickness: 1.5 mm DIMENSIONS / WEIGHTS space requirements -left/right-: 3400 mm space requirements -front/back-: 1100 mm total height: 1500 mm total weight approx.: 1850 kg Stainless steel max. 20 mm diameter CNC control with VGP 3D software
CONTROLS CNC controls BLM VGP 3D TECHNICAL SPECIFICATION Max. diameter of tube: 40 mm Max. wall thickness: 2 mm DIMENSIONS / WEIGHTS space requirements -left/right-: 4500 mm space requirements -front/back-: 2150 mm total height: 1800 mm total weight approx.: 4800 kg Loadingstation AL42 max. 2300 mm, min. 500 mm, 150 kg
제품 23291 사양: 6단 터렛이 있는 파이프용 최종 가공 기계 - 공구 홀더 튜브 직경 6 - 40 mm 최대 성형 길이 100mm 드라이브 400 V / 7.5 kW 공간 요구 사항 약 W 1200 x D 2100 x H 1500 mm 무게 약. 1400 킬로그램
토크/각도/바이어스 분석기 테스트 및 측정 장비 상표: BLM 유형: 5040 수량: 2 추가 정보: 사진을 참조하십시오. 보장없이 모든 정
BLM ADIGE 파이버 레이저 2010년 3000x1500 3000와트 로딩/언로딩 Lantek 라이선스 시간 : 약 20,000 시트 두께 20mm. 철 및 8/12 스테인리스 스틸
