utilisé
Force de compression : 80 t Saillie : 350 mm Taille de la table : 700 x 720 mm Niveau de diarrhée dans la table : 160 mm Surface du piston : 300 x 445 mm Réglage du piston : env. 80 mm Réglage de la course : 8 - 100 mm Cadence de course : env. 90 tr/min Moteur d’entraînement : 380 V, env. 5 kW Dimensions : 2050 x 1100 x 2450 mm Poids : env. 3800 kg
utilisé
Key data: 75 t, 80 mm, 250 1/min
Force de pressage : 75t Table : 650 x 560 mm Surface du piston : 500 x 300 mm Cadence : 50-250 coups/min Hauteur de levage : 8-80 mm Hauteur d’installation max. : 400 mm Passage entre les béquilles latérales : 300 millimètre Mangeoire: Fabricant : GSW Modèle : WV32/80 Largeur de la bande : max. 320 mm Épaisseur du ruban : max. 3,5 mm Diamètre du rouleau : 80mm
utilisé
Force de pressage 50 tonnes Course 8 - 100 mm Taux de course max. 140 coups/min Puissance d’entraînement 3 kW Surface de serrage 650 x 500 mm Poids de la machine env. 2 750 kg
utilisé
Table d’indexation rotative avec 12 stations Éjecteur automatique Trois étapes de pressage Capacité de pression 1,000 KN Course 12-120 mm Taux de course 30-60 1/min Réglage du piston 80 mm Poids total 9 500 kg
utilisé
Machine de redressage de bande avec la paire de rouleau d’alimentation, moitié supérieure hydr. pliable, zsélectr la largeur max. 320 mm, rouleaux 60 mm, autrement voir les photos
utilisé
Pression: 65 t - Course: 140 mm - Taille de la table: 720 x 600 mm - Stoesselflaeche: 500 x 300 mm - Création Stoesselv : 80 mm - Huebe: 20 - 40 par min. - Mash. Poids: 6000 kg - Exigences de chambre (L x W x H): hauteur 3.1 m - Trou d’épingle de serrage 60 x 80 mm Plus d’informations sur demande
Pression: 100 t Extension: 350 mm Taille de la table : 690 x 840 mm Diarrhée dans le tableau: 160 mm Ajustement de la table : Surface de peste : 450 x 600 mm Achèvement de l’impact : 80 mm Ajustement de l’AVC : 8 - 100 mm Capacité d’AVC: 60 /min Moteur : 380 V, 5,5 kW Exigence d’espace: 1850 x 1850 x 2650 mm Poids: 6800 kg
utilisé
Punching force: 75t, with Band Feeder GSW WV32/80, max. band width: 320mm, max. band thickness: 3.5mm, roller diameter: 80mm, an inspection is possible.
utilisé
Pressure capacity: 500KN, stroke: 8-100mm, stroke rate: 100/min. Ram adjustment: 80mm, drive: 4kW, weight: 2850kg. Safety distance: 175mm, overtravel: 53mm, overtravel time: 110ms.
utilisé
Capacity: 25 ton Throat depth: 250 mm Ram stroke: 6 - 60 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 190 mm Height of the bolster plate: 50 mm Table surface area : 500 x 400 mm Slide area: 350 x 250 mm Tool Clamping Hole Ram: 40 H7 mm Number of strokes: 160 s.p.m. Dimensions L x W x H: 1.300 x 1.500 x 1.995 mm Weight of machine approx.: 2 ton
utilisé
pressure:100 t throat:350 mm stroke:6 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:850 x 700 mm hole in the table:470 x 150 mm table height over floor:855 mm ram surface:450 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,0 t dimensions (WxDxH):1,5 x 2,3 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
utilisé
Pressure:080 t throat:300 mm stroke:8 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:440 mm table surface area:720 x 600 mm hole in the table:300 x 175 mm table height over floor:860 mm ram surface:400 x 270 mm ram adjustment:60 mm power requirement:7,5 kW weight:6,0 t dimensions (WxDxH):1,3 x 2,2 x 3,05 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic, Ortlinghaus overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic
utilisé
pressure:080 t throat:300 mm stroke:7 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:450 mm table surface area:720 x 600 mm hole in the table:300 x 120 mm table height over floor:850 mm ram surface:400 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:6,5 t dimensions (WxDxH):1,2 x 2,0 x 2,9 m German Safety: permitted for manual loading:CE-sign light guard:Sick clutch:hydraulic overload protection in ram:hydraulic ram adjustment:motoric stroke adjustment:automatic
utilisé
pressure:160 t throat:690 mm stroke:8 - 180 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1300 x 1000 mm hole in the table:400 / 120 mm table height over floor:850 mm passage to the back:900 mm ram surface:1000 x 700 mm ram adjustment:130 mm power requirement:11,0 kW weight:19,0 t dimensions (WxDxH):2,4 x 2,8 x 3,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
utilisé
pressure: 160 t throat: 440 mm stroke: 20-150 mm : 50 Hub/min : ca. 390 mm : 1300 x 750 mm : 170 mm : 400 / 250 mm : 50 mm : 445 x 560 mm : 7,5 kW : 8 t : 2,9 x 1,5 x 2,8 m total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
utilisé
Description: Machine number: 4717 Feed size: 500 x 3 mm Belt infeed height (with plate): 170 - 270 mm Additional device: 2-hand operation Table size: 1250 x 900 mm Plunger surface (blue): 800 x 600 mm Projection of ram center dimension stand: 510 mm Installation height center dimension (without plate): 500 mm Clamping plate thickness: 125 mm Trunnion Ø: 65 mm Smallest / largest stroke: 27 - 140 mm Number of strokes: 48 With electronic roller feed: Wanzke WVS 500 Indramat control system, serial no. 102414-1, year of manufacture 1998 With reel straightener: PBK RMC4 80/7/50 RSD GLST, serial no. BA00967, year of manufacture 2006 With minimum quantity lubrication: , Schmidt System 2000 Max. pressing force: 250 to, weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 2,250 x 3,200 x 3,500 mm
utilisé
Eccentric press, single column press, punching machine, single column eccentric press, eccentric press, single column press -Manufacturer: Heilbronn, single column eccentric press type NEPD 50 -Pressure capacity: 50 tons -Clutch: pneumatic -Stroke: adjustable 8 - 100 mm -Table size: 500 x 650 mm -Table recess: Ø 240/100 mm -Projection: 255 mm -Punching fixture: Ø 40 mm -Insertion height 355 mm -Dimensions: 1800/1080/H2260 mm -Weight: 3050 kg
utilisé
pressure: 100 t throat: 350 mm stroke: 8 - 100 mm no. of strokes: 60 Hub/min daylight (stroke down, ram adjustment above): 300 mm ram adjustment: manuell 80 mm table surface area: 850 x 700 mm hole in the table: Dm. 180 mm mm ram surface: 560 x 400 mm ram drills x depth: 40 x 95 mm table height over floor: 850 mm total power requirement: 7,5 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 1,4 x 2,2 x 2,85 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
utilisé
utilisé
Alimentation de préhension pneumatique faire HEILBRONN type PVS 250/100/80Machine -No: 205238 construit en 1993avec lisseur à bande attaché type RLE 27Consescriptions techniques:CLIP FEEDmax.largeur de bande: 250 mmmax.épaisseur de la sangle: 3,0 mmGamme de longueur d’alimentation: 5 - 105 mmmax. section transversale du matériau: 240 mm²Force de serrage de la pince d’alimentation: 17,2 kNcoradant à la force de serrage par frottement: 34,4 kNForce de tension de la calembine: 5,6 kNcorréso en réponse à la force de serrage par frottement: 11,2 kNFeed force: 3,0 kNTAPE redresseurmax.largeur de la bande: 200 mmmax.épaisseur de la sangle: 2,0 mmNombre de rouleaux de redressement: 7Diamètre des rouleaux de redressement: 40 mmNombre de rouleaux d’alimentation: 2Diamètre des rouleaux d’alimentation: 40 mmusedPrix sur demande. Livraison: départ entrepôt ou camion de chargeme ...
utilisé
Presse excentrique faire HEILBRONN type EPT 6Fabr. -No: 4869, construit en 1986Spécifications techniques:Force de pression: 6,3 tThroat: 130 mmTaille de table: 320 x 240 mmBouc trou traversant dans la table: 80 mmHauteur de table: 800 mmMax. Hauteur d’installation: 155 mmSurface de la rame: 128 x 180 mmRéglage de la glissière: 30 mmRéglage de la course: 6 - 60 mmTaux de course: 180 H / minPuissance du lecteur: 0,5 kWDimensions env: 1000 x 1000 x 1800 mmPoids environ: 500 kgAvec- entraînement par volant d’inertie- Désengagement à deux mains- Incrustations manuelles 11062/11064- interrupteur à pied- Armoire de commande à deux mains et à une seule course- armoire de commande séparéeutilisée, en bon étatPrix sur demande. Livraison: départ entrepôt ou camion de chargement sans emplacement. Paiement : net à la reprise ou sur rendez-vous. Les données techniques ne sont pas ...
utilisé
pressure: 100 t throat: 350 mm stroke: 8-80 mm dayligth: 300 mm no. of strokes: 125 Hub/min ram - range of adjustment: 80 mm ram surface: 400x300 mm table surface area: 850x700 mm hole in the table: 350x200 mm total power requirement: 7.5 kW weight of the machine ca.: 4.5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
