DMG MORI T2 円卓製ミリング機

· General

· 2-axes universal turning center with driven tools and C-axis; Control: Control SIEMENS SINUMERIK ONE
·

· Working area

· Swing diameter over bed
· 650 mm

· Swing diameter over X linear guideways
· 520 mm

· Max machining diameter
· 460 mm

· Clamping chuck Ø
· 254 mm

· X travel
· 300 mm

· Z travel
· 730 mm

· Main drive 1

· Type of main drive
· AC

· Drive power (100% DC)
· 15 kW

· Drive power (40% DC)
· 19,5 kW

· Speed range
· -3500 rpm

· Torque (100% DC)
· 246 Nm

· Max. torque (40% DC)
· 319 Nm

· Work spindle

· Spindle nose
· A2-8

· Spindle diametre on front bearing
· 140 mm

· Spindle bore
· 91 mm

· Bar diameter max.
· 80 mm

· Tool holder 1

· Number of tool stations
· 12

· Shank diametre according to DIN 69880
· 40 mm

· Number of driven tools
· 12

· Speed max.
· 4000 rpm

· Power max. (40% DC)
· 5,44 kW

· Signal lamp with 4 colours standard
· Signal lamp with 4 colours Red: general error Yellow: intervention necessary Green: automatic mode Blue: setup mode
