vertical lathe used for sale

Brand : Comi Pack Model : VM40 Year : 2003   Type : Vertical bagging machine Voltage : 380 / 400 Volt Hz Power : 3,7Kw Air consumption : 60 Lt/min Tube diameter : min 40 - max 120 mm Product dimensions : length: min 40 - max 280 mm Width: min 40 - max 180 mm Winding band: max 400 mm Roll diameter : max 400 mm Machine dimensions: L 1700 x W 950 x H 1620 mm 2 formats available

Description: Dörries VCE 2800 SM F Single-column Vertical Lathe with 2.8 m swing diameter. Control system SIEMENS Sinumerik 840 D Geometric main dimensions Swing diameter: 2800 Basic turning height with fixed crossbeam: 1335 Turning height including adjustment of the grid steps: 1935 mm Cross-section of chisel slide: 250 x 250 mm , Travelling distance of chisel slide: 1100 mm Fixed Crossbar Machine table Machine table diameter: 2500 mm Maximum table load: 25 tonnes Drive power main drive: 80kW Torque on machine table: 35900 Nm Speed range in 2 gear stages: up to 224 rpm Feed drives and Cutting forces Horizontal and vertical crossbeam support: 0 - 18000 mm/min Cutting force when turning: 19000 N Tool system Vertical 4-fold Capto C6 turret Please have a look at the technical data and the layout plans in the PDF file. turning height: 1,935 mm, swing di ...

CNC Vertical Lathe VTL with Tool Changer.You Ji GTH-35/45 ATC-I.Year of manufacture 2012.Fanuc 0i-TD CNC Control.Face plate diameter 3500 mm.Hydrostatic table - Load max. 50 t.Swing diameter max. 4500 mm.Turning diameter max. 4000 mm.Turning height max. 2200 mm.Ram cross travel X -1750/+2160 mm.Ram vertical travel Z 1500 mm.Table drive 60/75 KW.Table turning speeds 2 ~ 75 mm.Torque at the table 67330 Nm.Tool magazine with 16 positions.Tool taper 7/24 BT 60.Floor space required 12375 x 8210 mm.Machine height 7920 mm.Full guarding.3-colour signal lamp (tower).AS NEW - 200 run hours !Available immediately.; As new

Description: Dörries single-column vertical lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Machine number Control: SIEMENS Sinumerik 840 D Machine number: ,V-800292 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400  ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter and hydraulic clamping table. Control and machine number SIEMENS Sinumerik 840 D control system Machine number: V-800289 Geometric main dimensions Machine table diameter: 2000 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2445 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Cross beam support Travelling distance: ± 1350 mm Crossbeam travel: 1000 mm (100 mm steps) Crossbeam travel (100 mm steps): 1000 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm/min Milling drive Milling drive power: 37 k ...

Description: Dörries Single-column Vertical Lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Serial number Control: SIEMENS Sinumerik 840 D Serial number: ,V-800288 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Machine number Control system: SIEMENS Sinumerik 840 D Machine number: V-800291 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 40 ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter. Control and machine number SIEMENS Sinumerik 840 D control system Machine number: V-800290 Geometric main dimensions Machine table diameter: 2000 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2445 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Crossbeam travel (100 mm steps): 1000 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm/min Milling drive Milling drive power: 37 kW Speed range in 2 gear stag ...

This CMIDurango TVF210-2000 Vertical Lathe was made in 2016 in Spain. It is equipped with a Fagor 8060-T control unit and has 2 axis. the machine has a spindle speed of 140 mm.

This Famar Tandem 200 Vertical Lathe was manufactured in the year 2012 in Italy. It is equipped with a SIEMENS 840 D control unit. The machine has a spindle speed of 6000 rpm.

This Famar Tandem 200 Vertical Lathe was manufactured in the year 2010 in Italy. It is equipped with a SIEMENS 840 D control unit. The machine has a spindle speed of 6000 rpm.

VERTICAL LATHE TITAN MOD. SC33 Retrofited in 2003. 2-arm CNC: FAGOR 8050 Maximum diameter: 3,300 mm Table diameter: 3,000 mm. Main motor: 70 KW. Maximum S: 90 RPM (3 speed ranges) Approximate total weight: 47,000 Kg. Chip conveyor. Machine currently working in Industrial Barranquesa

TOS SKJ 12 vertical lathe The machine is technically efficient after replacing the transformer from the table rotation, worn out, requires inspection and feed adjustment Year of manufacture 1987 Documentation in Czech electrical cabinet dmensions 1630x590 mm, weight 675 kg

Honor VL-400CM Vertical CNC Lathe Machine is in excellent condition Table diameter : 4000 mm Max swing diameter : 4500 mm Maximum turning diameter : 4500 mm Maximum cutting height : 2000 mm Maximum weight of workpiece : 40000 KG Distance from table to ram : 880-2320 mm

Doosan Puma V8300 CNC Vertical Lathe like new condition Control Unit : FANUC-Ä° Chuck : 24 inches Main Spindle Max Chuck 609.6 mm (24) Max Turn Length 750 mm Max Turn Diameter 830 mm X Axis Rapid Traverse 20 m/min Z Axis Rapid Traverse 20 m/min Swing Over Bed 920 mm Spindle Power 37 kW Spindle RPM 2,000 RPM

Doosan Puma V8300 CNC Vertical Lathe like new condition Production : 11.2019 Max. turning dia. : 830 mm Maximum turning length : 750 mm Maximum spindle speed : 2000 rpm Fanuc control unit

Year of construction 2008 Vertical lathe type Working range 760 mm for two mandarins Spindle motor power 30 37 kW Asa 11 spindle connection Spindle revolutions 25 1500 Turret with 12 positions on each side FANUC numerical control Machine weight 23,500 kg Year 2008

This DMG GILDEMEISTER CTV 250 Vertical lathe machine was manufactured in 2012 in Germany and has 38984 production hours. It is equipped with a SIEMENS control unit. The machine dispose of a chip conveyor and a high pressure cooling system with paper filter. The revolver head was completely renewed at the end of the previous year.

This EMAG VL3 Vertical Lathe was manufactured in the year 2001. It is equipped with a Fanuc Series 18i-T control unit. The machine was refurbished completely in 2022 to have equivalent condition as new machine. See all details of overhaul in attached PDF.

This STANKO 1525 Vertical Lathe was manufactured in the year 1972 in Russia. The machine has a maximum turning diameter of 2500 mm.

Description: SCHERER FEINBAU VDZ 220 XL DS Vertical lathe with Double spindle and Robot cell Serial number and Control Serial number: 68333 Control: SIEMENS Sinumerik 840D sl Working area Workpiece height max.: 200 mm Workpiece diameter max.: 250 mm Rotation diameter max.: 390 mm Spindle stop-turret distance max.: 580 mm Spindle stop-turret distance min.: 240 mm Spindles Spindle speed max.: 5500 rpm Spindle power per spindle: 37.7 kW Spindle torque per spindle max.: 300 Nm Spindle head with short taper (DIN 55026): A6 Axis travel X-axis axis travel (in the work area with closed cover): 365 mm Axis travel X-axis (total): 886 mm X-axis axis travel (via turret centre): -20 mm Axis travel Y-axis: +100/-80 Axis travel Z-axis: 250 mm 12-position disc turret VDI 40 All tool positions driven Max. speed (25% ED): 4000 rpm Max. power (25% ED): 10 kW Torque max. ...

faceplate diameter:5700 mm swing diameter:6300 mm turning height:4000 mm total power requirement:DC 110 kW workpiece weight max.:100 t table speeds:0.2 ~ 20 U/min Torque:des Tisches 300 kN.m slide stroke:vertikal: 2000 mm ram diameter:280 mm rapid traverse:2000 mm/min control:CNC Siemens oder Fanuc _ head swivability:-15°?+30 ° weight of the machine ca.:127 t Rams:2 New CNC Vertical Turret Lathe - Double Column with Siemens 828D or Fanuc 0i TF and extensive accessories. Further technical details and accessories appearing in Appendix.

faceplate diameter:4000 mm swing diameter:4300 mm turning height:2500 mm max. workpiece weight:63 t total power requirement:125 kW weight of the machine ca.:134 t dimensions:6100x10400x8400 mm Used Vertical Turret Lathe with 2 plungers and CNC Siemens 840 table is hydrostatically. Machine equipped with a grinding head. CNC was overhauled in 2000.

faceplate diameter:4000 mm swing diameter:4300 mm turning height:2060 mm spindle drive:55 kW CNC controller:NUM T PLUS 2 axis Used CNC Vertical Turret Lathe (overhauled in 2010). Further technical data and accessories, as defined in Appendix. Warranty: no Take advantage of the favorable leasing and rental conditions of ABC Leasing. Ask us about it.

faceplate diameter:7100 mm swing diameter:8000 mm turning height:5000 mm total power requirement:DC 132 kW workpiece weight max.:180 t table speeds:0.2 ~ 20 U/min Torque:des Tisches 300 kN.m slide stroke:vertikal: 2500 mm ram diameter:320 mm rapid traverse:2000 mm/min control:CNC Siemens oder Fanuc _ head swivability:-15°~+30 ° weight of the machine ca.:127 t Rams:2 New CNC Vertical Turret Lathe - Double Column with Siemens 828D or Fanuc 0i TF and extensive accessories. Further technical details and accessories appearing in Appendix.

Vertical CNC centre lathe, uses / outdated machine type: Emag VSC 200 control: Siemens 840 C construction year: From the in 1995 to the in 2007 overtakes TECHNICAL DATA: speed area / speeds: [1 / min].: 6,000 Drehmoment:/torque [Nm]: 480 Max dreh-? over bed swing diam .: 290 mms impulse achievement / power: [kW] 34 feed ? / chuck diam. 200 mms revolver / turret: 12-fold, VDI 40, shoemaker powered work witness / driven tools 7.8 kW Verfahrwege: X axis / x-travel: 550 mms Z-Achse/z-travel: 200 mms express way / rapidly travel: (X/Z) [m / min] 30 / 20 prepush / feeds: (X/Z) [m / min]. 11 KN connected load: [KW] 36 kW machine weight: [kg] 6,500 equipment signs: filings sponsor / chip conveyor, crowd

Manufacturer: GORBREX Model: TKV 532 CNC New in: 2015 Control: SIEMENS SINUMERIK 828 Machine fully modernized and modified of SEDIN 1L532 with new electrical and lubrication unit, painted, replacement of damaged mechanical parts, with possibility of upgrading. The upgrade is made of cast iron, on request we can equip the machine with the new CNC control SIEMENS SINUMERIK 840. Delivery time: max. to 3 - 4 months Technical details Number of columns: 2 Number of carriages: 1-option 2 Type of carriage: Ram Number of axis controlled: X/Z option X1/Z1,C Max. turning diameter: 3200 mm Table diameter: 2800 mm Max workpiece height: 1600 mm with possibility of upgrading up to 2200 mm Max table load: 16 000 kg Range of table speeds: 70 rpm Number of table speeds ranges: 3 Vertical travel in Z axis( ram travel): 1200 mm Horizontal travel of carriage in X axis: 1720 mm Working ...

Manufacturer: GORBREX Model: TKV 516 New in: 2015 CNC control: CNC SIEMENS SINUMERIK 828 Location: our workshop, Rudniki - Poland Machine fully modernized and modified of SEDIN 1516. Machine with new electrical unit, new lubrication unit, painted, slideways regrinded, replacement of worn mechanical parts. Machine will be equipped with new CNC control SIEMENS SINUMERIK 828. Delivery time: 3-4 months Tool Changer and Warranty Technical details Numbr of columns: 1 Number of carriages: 1 Type of carriage: Rotary head in 5 position or Ram Axis controlled: X/Z Turning diameter: 1 600 mm Faceplate diameter: 1 400 mm Max workpiece height: 1 000 mm( with possibility of extension to 1400 mm) Max table load: 5 000 kg Range of table speeds: 5-200 rpm Number of speeds range stepless: 3 Vertical travel of Z axis: Rotary head: 700 mm Ram: 1000 mm Horizontal carriage travel in X a ...

Manufacturer: GORBREX-POLAND Model: TKV 540 New in: 2015 Condition: New machine Location: Rudniki, Poland Control: CNC SIEMENS 828 Technical details Number of columns: 2 Number of carriage: 1 Type of carriage: RAM Number of axis controlled: X/Z Turning diameter: 4000mm Table diameter: 2800mm Max. workpiece height: 1600mm( with possibility of upgrading to 2200mm) Max. table load: 16 000kg Table speeds range: 70rpm Number of table speeds range: 3 Vertical travel in Z axis 1200mm Horizontal carriage travel in X axis: 2120mm Work feeds range: 2-2000mm/min Rapid feeds in X/Z axis: 10m/ min Knife intersection: 63 x 40mm Traversal beam vertical travel: 1240mm Traversal beam feed: 360mm/min Main motor power: 55kW Installed power: 69kW Positioning accuracy: 0,01-1000mm Machine dimension: 5500 x 6750 x 4900mm Net weight: 49000kg

Manufacturer: GORBREX Model: TKV 580 CNC New in: 2015 Condition: excellent, like a new one, equipped with a CNC control SIEMENS SINUMERIK 828 Location: our warehouse Rudniki, Poland Delivery time: ca. 12 months Technical details Max turning diameter: 8000 mm Max turning height: 3200 mm Max workpiece weight: 125 000 kg Table diameter: 7100 mm Max slider stroke: 2000 mm Max travel of cross slide: 4275 mm Table rotation range: 0,22 - 20,1 r / min Slide feed range: 0,0352 - 285 mm/min Rapid slide feed range: 2500 mm/min Feeds crossbeam: 300 mm/min Dimensions: 8615 x 17600 x 9800 mm Machine weight with electrics: 258 000 kg Weight without electrical equipment: 247 300 kg

Condition: very good mechanical part Technical details : Turning diameter 3200mm Table diameter 3200mm Turning height 2000mm Max workpiece weight 50 t Table speeds 0.66-62.1 rpm Vertical crossrail movement 1870 mm Main motor power 125 kW Machine dimensions 5100 x 9200 x 7200 mm Machine weight 90.4 t

Manufacturer: GORBREX Model: TKV 512 New in: 2015 CNC Control: SIEMENS SINUMERIK 828 Location: our warehouse Rudniki - Poland Machine fully modernized and modified of SEDIN 1512. Machine with new electrical unit, new lubrication unit, painted, slideways regrinded, replacement of worn mechanical parts. Machine will be equipped with new CNC control SIEMENS SINUMERIK 828. Delivery time about: 2 months Technical details Number of columns: 1 Number of carriages: 1 Type of carriages: Rotary head in 5 position or ram Number of axis controlled: X/Z Turning diameter: 1 250 mm Table diameter: 1 120 mm Max. Turning Height: 1 000 mm Max.weight of workpiece: 3 200 kg Table speeds: 5-250 rpm Number of table speeds ranges stepless: 3 Vertical travel in Z axis: Rotary head: 700 mm Ram: 1000 mm Horizontal travel in Z axis: 775 mm Range of working feeds: 2-2000 mm/min Rapid fee ...

Manufacturer: KOLOMNA Model: 1540 New in: 1978 Condition: very good, machine complete Technical details Table diameter: 4000 mm Turning diameter: 4000 mm Turning height: 2000 mm Table speeds: 0.52 – 49 rpm Max.workpiece weight: 63 T Max.weight approximately: 105 T

Table diameter: 2,000 mm Max diameter of workpiece: 3,000 mm Main drive: 60 KW Speed rotation of the table: 2.8 - 162 rpm Max workpiece height under the cross member: 2,500 mm Travel RAM: 1,750 mm Tool magazine: 12 workstations Machine Weight: 35 t Accessories: Grinding spindle and various tool holders 3000 rpm Wheel diameter 250 mm

turning diameter: 200 mm swing diameter: 250 mm turning height: 350 mm control: Siemens Sinumerik 840 D spindle diameter in front bearing: 100 mm feed range: 0,1 - 20000 mm/min rapid traverse: 20 m/min stroke of vertical slide: 300 mm spindle head DIN 55026 - Size: A 6 : 50 - 6500 1/min Speed range drive tool: 0 - 3000 1/min total power requirement: 40 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 4,5 x 4,0 x 3,5 m equipped with: - CNC Control Siemens 840 D - Tool turret for 12 tools VDI 40 - driven tools on station 1/4/7/10 - conveyor belt - no coolant system (machines was added to a centrelized coolant system) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 200 mm swing diameter: 250 mm turning height: 350 mm control: Siemens Sinumerik 840 C spindle diameter in front bearing: 100 mm feed range: 0,1 - 20000 mm/min rapid traverse: 20 m/min stroke of vertical slide: 300 mm spindle head DIN 55026 - Size: A 6 : 50 - 6500 1/min Speed range drive tool: 0 - 3000 1/min total power requirement: 40 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 4,5 x 4,0 x 3,5 m equipped with: - CNC Control Siemens 840 D - Tool turret for 12 tools VDI 40 - driven tools on station 1/4/7/10 - conveyor belt - no coolant system (machines was added to a centrelized coolant system) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter:8000 mm swing diameter:10000 mm turning height:4500 mm workpiece weight:120/200 t table speeds:0.2-16 U/min (2 Stufen) max. torque on the faceplate:200/460 k.Nm slide stroke:vertikal: 2300 mm slide stroke:horizontal: 5300 mm cross section of ram:300x300 mm Max. cutting force of tool head :links: 63 kN / rechts: 80 kN Cross rail travel :2000 mm rapid feed cross beam:300 mm/min feed stepless:X-Achse: 1-500 mm/min main drive:110 kW weight of the machine ca.:270 t Machine size (LxWxH):14000x10000x9000 mm control:Siemens 828D/Siemens 840D worktool support (A-axis):2 Stück :1 Stück Rams:1 Stück konventioneller und 1 Stück CNC-Stößel CE-design:inkl. Zertifikat European electric:Schneider, Siemens, ABB oder ähnlich Servo motors:von Siemens SPS machine control:von Siemens CNC controls from:Siemens/Fanuc/Fagor for more information please check attached pdf file on the ri ...

Chuck diameter : 1600 mm Turning diameter : 1840 mm Motor : 30 Kw Machine can be seen in working condition

control: Siemens 840-D tool taper: HSK & VDI 40 - - -: - - - - - - Vertical Turning Machine | EMAG - VTC 250 DUO ED with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets, - 6-station end-processing turret with HSK tool holder, - 12-station disc turret for driven tools and VDI 40 tool holder, - 12-position disc revolver with cross slot and VDI 40 tool holder, - NC - clamping head, - NC bezel, self-centering, - EMAG hydraulic double-piston clamping cylinder, - tailstock down, - Hydraulic double-piston clamping cylinder at the top, - chip conveyor, - Knoll plant 1.500 l, - Coolant supply 7-30 bar, - OP20: shaft chuck with retractable jaws and face drivers, - Tool holder with Capto 5, - Artis quick-change system for tool and process monitoring, - Tool pack is included, The machine is in a well-maintained condition and can be inspected at any time  ...

control: Siemens 840-D tool taper: HSK & VDI 40 - - -: - - - - - - Vertical Turning Machine EMAG - VTC 250 DUO DD with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets - 12-position disc turret for driven tools and VDI 40 tool holders, - 12-station disc turret with cross-slot and VDI 40 tool holders, - 12-station disc turret for driven tools and VDI 40 tool holders, - NC steady rest, self-centering, - headstock below, - tailstock below, - chip conveyor - Knoll unit 1.500 l, - OP10: Three-jaw chuck Rhöm KFD-N 220/3, - OP20: Hainbuch Spanntop pull-back BZI65, - Live tool for axial and radial machining, - Tool holder with Capto 5 quick change system, - Artis as tool and process monitoring, The machine is in a well-maintained condition and can be inspected at any time under power. A machine video from the production plant will be shared on reques ...

Machine weight: 20,000 kg Faceplate diameter 1250 mm Number of supports: 1 pcs Dimensions: height 4250 mm width 5630 mm depth of 3550 mm Extras: copying apparatus, turret head on the vertical support Technical condition at the time of sale: Replacement rotary amplifier on thyristor converter. Not operated since 1994 p. Small repair and adjustment of electrical and mechanical parts. The maximum dimensions of a workpiece Height 1150 mm The diameter of 1400 mm Weight 8000 kg

Swing: 2200 mm Table diameter: 2000 mm Max. working height: 1500 mm Table speed range: 1-140 rpm Max. work-piece weight: 12000 kg Right head vertical stroke: 760 mm Left head vertical stroke: 1250 mm Ram travel: 1500 mm Main motor: 55 kW Dimensions: -Length: 4600 mm -Width: 4300 mm -Height: 4200 mm Machine weight: 32000 kg

Table ø 1000mm Max turning height 1100mm

faceplate diameter:3500 mm swing diameter:3800 mm turning height:2300 mm max. turning diameter:3800 mm table load:40 t table speeds:10 - 38 1/min transmission ratio:2 Stufen cross travel of ram-slide:rechts: 2500 mm cross travel of ram-slide:links: 2200 mm Travel of Ram (vertical):1500 mm total power requirement:70 kW Rams:2 Stück

faceplate diameter:3000 mm swing diameter:3400 mm turning height:3000 mm max. turning diameter:3400 mm max. workpiece weight:25 t weight of the machine ca.:105 t Dimensions (L/W/H):6450x7500x6950 mm

Clamping plate diameter: 3200 mm Max. workpiece diameter: 6300 mm Max. workpiece height: 2500 mm Max. workpiece weight: 5000 kg Stand movement:: 1550 mm Crossbar movement: : 1900 mm

Turning length: 300mm, turning diameter over bed: 200mm, control: Siemens Sinumerik, with documentation, cooling lubricant system and chip conveyor, the machine has only rarely been in operation for approx. 2.5 years, an on-site inspection is possible.

Rotation diameter: 450mm, control: GE Fanuc Series 21i-TB, weight: 13.5t, operating hours: 80,305h, available from 1st quarter 2024.

X-travel: +/-2750mm, z-travel: 2000mm, B-travel: +/-90°, C-travel: 360°, table diameter: 4500mm, turning and circumferential diameter: 5000mm, max. turning height: 2645mm, rotational speed: 8-3000/min, controls: Siemens SINUMERIK 840D, with documentation, base, stand, crossbar, support and chisel pusher.
