No. Cat. Photo Manufacturer | Model
Type of machinery
Year Price Country Contact
 page 1  > 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
121704316 107

SPOTTI/VIGANO for sale
Cutting-To-Length Lines


Material width of 2,000 mm Material thickness 1.50-12,00 mm Coil weight of up to 30,0 tons Coilinnen - Ã? 500-800 mm CoilauÃ?en - Ã? 1.900 mm Material steel hot rolled / pickled and oiled Table ...
used machine

Material width of 2,000 mm
Material thickness 1.50-12,00 mm
Coil weight of up to 30,0 tons
Coilinnen - Ã? 500-800 mm
CoilauÃ?en - Ã? 1.900 mm
Material steel hot rolled / pickled and oiled
Table length mm
Working speed m/min.
Working direction of right ï links system consisting of:
Federal truck under floor (moveable)
Double Cone Uncoiler power 45,5 kW / per page
Coilöffner - / driver unit
(DUO-role structure), with mounting frame and roller (driven)
Transfer table
Leveler 1 make SPOTTI
168 kW
4-column design lift / lower - upper block through 4 drive units number - straightening rolls 15 (7 x up / 8 x below)
Leveling rollers - ø 110 mm
Number - supports 14 (7 x up / 7 x below), per page
Number - track rollers 14 (7 x up / 7 x below), per page
Height adjustment - upper roller block motor (see above)
Support roller adjustment - up hydraulically
Support roller adjustment - down motor (Gearmotor)
Control over roller brushing unit with suction device
Delivery via spindle stroke - power 15 kW
Control of roller leveler 2 make VIGANO
Built in 2003
138 kW
4-column version with 4 drive units
Lift / lower - upper block of 2 piece transfer case number - straightening rolls 17 (8 x up / 9 x below)
Leveling rollers - ø 48 mm
Number - supports 14 (7 x up / 7 x below), per page
Number - track rollers 9, per support height adjustment - upper roller block motor (see above)
Support roller adjustment - above on the upper block
Support roller adjustment - down motor (Gearmotor)
Measuring frame with measuring rollers mounted on machine design
(Discharge side - leveler)
Transverse scissors of part of make SPOTTI
Scissors flying version
Accelerating volume 1 with attached scrap soft
Accelerating volume 2
Drivers unit (DUO rolling scaffold) upper roller pneumatic deliverable
Stacking unit make SPOTTI
Number - scissor lift 2
with built Kettenförder units
Pages "push" via transfer case and connection shaft
Number - outlet chain conveyor 4
(Chain conveyor with weighing system 1)
Electrics
Hydraulic
Spare parts
2002
Price
    request
121686725 702

KÖNIG Industrie Rex T 5 for sale
Systems for bread rolls


König Bun roll line. consisting of: - König Headmachine 5 rows - König First Proofer - König Longmolder - Performance: 9-10.000 pieces/h - Weight range: from 30 to 80 grams Option: - König Second Proofer ...
used machine

König Bun roll line.

consisting of:

- König Headmachine 5 rows
- König First Proofer
- König Longmolder
- Performance: 9-10.000 pieces/h
- Weight range: from 30 to 80 grams
Option:
- König Second Proofer in stainlees steel
- With wather spaying and seeds station
- With 4 interchangeable seed stations
- Setting device
- LxWxH = 17000 x 800 x 3000 mm

By request recondidioning, delivery and set up.
2000
Price
    request
121653286 1707

HP DesignJet T 7100 for sale
HP plotter model DesignJet T 7100


Used HP - plotter DesignJet T 7100 model 2 rolls unit including ink and printheads approx. 23,000 prints
used machine

Used HP - plotter DesignJet T 7100 model
2 rolls unit including ink and printheads approx. 23,000 prints
2012
2,750 €
    request
121632750 107

BOLLINA for sale
Cutting-To-Length Lines


Bandwidth / strip width: 1,852 mm Band thickness / strip thickness: 0.5-3.0 mm Weight of coil / coil weight: 28,000 kg Setting rollers number / no of leveling rolls: 19 St / No. Setting rollers diameter / leveler-dia ...
used machine

Bandwidth / strip width: 1,852 mm
Band thickness / strip thickness: 0.5-3.0 mm
Weight of coil / coil weight: 28,000 kg
Setting rollers number / no of leveling rolls: 19 St / No.
Setting rollers diameter / leveler-dia: 50 mm
Stacking / length of stacking length: 4.000 mm
Stack weight / weight of stacking: 5,000 kg
2006
Price
    request
121632746 107

HYBRID for sale
Longitudinal Cutting Lines


Band width max. / sheet maximum width: 1,550 mm Weight of coil / coil weight: 10 to. I Unwinder diameter coil / coil I slide. decoiler: 470-530 mm I winder diameter coil / coil I slide recoiler: 508 mm Power consumpt ...
used machine

Band width max. / sheet maximum width: 1,550 mm
Weight of coil / coil weight: 10 to.
I Unwinder diameter coil / coil I slide. decoiler: 470-530 mm
I winder diameter coil / coil I slide recoiler: 508 mm
Power consumption/power approx. 30 kW
Band thickness/strip thickness 420N/mm2 of 0.4-3.0 mm decoiler coil with hydraulic car with hydraulic arm with hydraulic contraction and release of rolls.
Sheet unwinding is performed via electromotor by start - stop system
The machine is in excellent condition and has approximately 70 hours of operation. /
The machine is in excellent condition and has about 70 hours of operation
2016
Price
    request
121632737 203

WEINIG HYDROMAT H23C for sale
Four-sided planing machines


-machine in stock -After reviewing the technical -very good condition -year of manufacture 2001 TECHNICAL PARAMETERS: PLANER: -planing width 230 mm -planing height 180 mm -spindle diameter 50 mm -the maxim ...


-machine in stock
-After reviewing the technical
-very good condition
-year of manufacture 2001

TECHNICAL PARAMETERS:

PLANER:
-planing width 230 mm
-planing height 180 mm
-spindle diameter 50 mm

-the maximum diameter 220 mm

-the feed rate to 80 m/min
-adjustable feed on the inverter

1) head the lower 15 kW
2) head right 11 kW
3) head left 11 kW
4) upper head 11 kW
5) upper head 18 kW
4) lower head 22 kW

-electrically height-adjustable
-electrically adjustable upper heads
-pneumatic clamps

-cardan shafts feed
-five top steel roller
-the two upper rollers, rubber
-four rolls in the worktop extending

-auxiliary pressure on the left of the head
-the last two heads on podtrzymkach
-nozzle diameter 140 mm

SYSTEM ADMINISTRATION:
-packet length 6100 mm
-width: 1200 mm
-height 1300 mm
-the possibility of stacking two packages at the same time
-for
-the brackets to the narrow items
-chain feeder 2500 mm
-initial material segregation
-Cross-feeder Planer 1500 mm
-hydraulic Accelerator

SYSTEM:
-conveyor 7000 mm
-the receiving table transverse conveyor 2100 mm
-receiving rollers-powered 6000 mm
-receiving roller and adjustable flame launchers, 7100 mm
-gravity rollers receivers

Automatic line strugaj?ca Weinig is a system for improving productivity, while increasing its efficiency. Solutions of this type are directed to the companies that make the process of automation of production facilities. Planing process elements is operated by two persons who are responsible for the initial choice of material and the reception. The principle of operation of the line shall be as follows, the material is delivered with a forklift on the chain conveyor, which thanks to its long sleeps two packages at the same time. This affects directly the effectiveness as it unfolded one of the operator can immediately place again at the right place, without downtime caused by not delivering material by fork-lift truck. Rozsztalowania system tilts the entire package and raises it at the same time, releasing the single guides layers that directly hit the chain feeder. The individual elements at this stage pass prequalification for those suitable for planing and waste. Material not suitable for further processing is separated by an operator who has a position at this stage, who, through the button adjusts the rollers stop line continuity by what material falls under the tray and does not goes to the Planer. Material that has passed segregation and is suitable for further stage goes through gravity rollers for another chain feeder. At the end of the feeder is equipped with a system of rollers and hydraulic Accelerator, which is responsible for moving items from the tray to the Planer Weinig Hydromat H23C. Planing process then takes place elements that has the possibility of processing them at speeds up to 80 m/min. Integrated system of elements after the planing them tape feeder table transverse equipped with automatic system dump the material. At this stage, ready to cross conveyors transporting it over the core. Material when you hit the Skate moved
is them to ejectors which expel material on gravity rollers where they are received by the employee. The line is the ideal solution for companies who appreciate the quality and the efficiency of the elements. Planer is able to meet even the most demanding expectations, while the system input and output only to increase its performance.

Price
  PL   request
121632671 702

KÖNIG Eco Twin for sale
Systems for bread rolls


It is a used King Brötchen system with King to sell eco twin classic head machine (year 2007). The following products can be produced with this compact system: Kaiser rolls, salt bread and long rolled German rolls. It' ...
used machine

It is a used King Brötchen system with King to sell eco twin classic head machine (year 2007). The following products can be produced with this compact system: Kaiser rolls, salt bread and long rolled German rolls.
It's a clean and fully functional bread plant. This was used as a second system and was only reduced in use. Incl. punching for Kaiser rolls, salt bread, pressed sandwiches and Housky (see pictures).

-Execution 600mm, 4-way series
-Overall length: 3, 80m (maximum width: 1, 15 m)
-Automatic puller (dough pieces directly on fermenting tray lays off)
-Quick-change Stüpfelwerkzeuge and cutting stations
-Stainless steel
-Operation via touch Simatic Panel
-entire plant on base with wheels
-Weight range King classic head machine: 50gr. -110gr. (dependent on dough)
-Weight range provers eco twin: 50gr. -80gr. (dependent on dough)
-Hourly output form rolls (Kaiser, salt,...): 4500 PCs / h

Price on request.
2007
Price
    request
121632611 403

HS 966-24, YEAR 2012 45.000 bph for sale
Roll Feed Sleever KRONES Contiroll


Labeling Machine KRONES Contiroll HS 966-24, year 2012 This Krones Contiroll roll feed sleever has been used for three years before it was professionally dismantled, packaged for transportation and placed in a wareho ...
used machine

Labeling Machine KRONES Contiroll HS 966-24, year 2012

This Krones Contiroll roll feed sleever has been used for three years before it was professionally dismantled, packaged for transportation and placed in a warehouse. It makes wrap-around plastic labels glued with two narrow strips of hotmelt glue on both ends of the label. Labels are fed on two rolls and change from one to another roll is automatic. The machine is in very good condition, safely stored and ready for shipment. It has been used for wrap around label up to 45 000 bph using 20 oz hot fill vitamin water.

The equipment has following features:

- Parallel configuration U (infeed and outfeed on same side)
- Bottle orientation by vision system
- Motorized bottle tabels, using servo motors
- Cutting system plates using servo motor
- Label lengths of between 172 mm and 640 mm can be handled with one labeling station
- Motorized double reels with automatic splicing of the label webs during reel change-over
- All label transfers are done by vacuum grip system
- Replaceable hot melt gluing unit

Manufacturer: Krones
Type: Contiroll HS 960-24 Roll Feed
Manufactured in: 2012
Type/Serial: 810+764
Capacity Max: 750 bpm (45.000 bph)
Container material: PET
Running hours: Approx 22.000
Power / voltage 460/266 V - 60 Hz
2012
Price
  FI   request
121614616 1401

STOW for sale
Flow rack - 3.250x54.300x3.150mm - 6 Levels


Used flow rack - approximately 54 No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the  ...
used machine

Used flow rack - approximately 54 No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet places: 108 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 54,300 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-3 basic shelves and 15 mounting racks comprising
-21 stand: 2,750 x 1,100 mm
-21 stand: approx. 3,250 x 1,100 mm
-72 bars: approx. 2,900 mm
-90 frame for roller Rails
-1,800 roller Rails
-360 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Dimensions and loads (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 54,300 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm: 21 PCs.
Stand 3,250 mm: 21 PCs.
Bars: 72 PCs.
Frame for roller Rails: 90 PCs.
Roller Rails: 1.800 PCs.
Shelf divider: 360 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

14,700 €
    request
121614614 1401

STOW for sale
Flow rack - 3250 x 18100 x 3150 mm - 6 levels


Used flow rack - approximately 18 No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the  ...
used machine

Used flow rack - approximately 18 No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet spaces: 36 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 18,100 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-1 Basic shelf and 5 mounting racks comprising
-7 stand: 2,750 x 1,100 mm
-7 stand: approx. 3,250 x 1,100 mm
-24 bars: approx. 2,900 mm
-30 frames for roller Rails
-600 roller Rails
-120 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Dimensions and loads (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 18,100 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm-7 PCs.
Stand 3,250 mm-7 PCs.
Bars: 24 PCs.
Frame for roller Rails: 30 PCs.
Roller Rails: 600 PCs.
Shelf divider: 120 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

4,900 €
    request
121614540 1401

STOW for sale
Flow rack - 3.250x30.200x3.150mm - 6 Levels


Used flow rack - approximately 30 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At ...
used machine

Used flow rack - approximately 30 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet capacity: 60 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 30,200 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-2 Basic shelves and 8 mounting racks comprising
-12 stand: 2,750 x 1,100 mm
-12 stand: approx. 3,250 x 1,100 mm
-40 traverses: 2,900 mm
-50 frames for roller Rails
-1,000 roller Rails
-200 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Mass (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 30,200 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm: 12 PCs.
Stand 3,250 mm: 12 PCs.
Bars: 40 PCs.
Frame for roller Rails: 50 PCs.
Roller Rails: 1,000 PCs.
Shelf divider: 200 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

8,200 €
    request
121614516 1401

STOW for sale
Flow rack - 3.250x72.400x3.150mm - 6 Levels


Used flow rack - approximately 72 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At ...
used machine

Used flow rack - approximately 72 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet places: 144 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 72.400 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-4 basic shelves and 20 mounted regiments consisting
-28 stand: 2,750 x 1,100 mm
-28 stand: approx. 3,250 x 1,100 mm
-96 beams: 2,900 mm
-120 frame for roller Rails
-2,400 roller Rails
-480 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Dimensions and loads (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 72.400 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm: 28 PCs.
Stand 3,250 mm: 28 PCs.
Bars: 96 PCs.
Frame for roller Rails: 120 PCs.
Roller Rails: 2,400 PCs.
Shelf divider: 480 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

19,600 €
    request
121614450 1401

STOW for sale
Flow rack - 3.250x15.100x3.150mm - 6 Levels


Used flow rack - approximately 15 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At ...
used machine

Used flow rack - approximately 15 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet places: 30 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 15,100 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-1 Basic shelf and 4 mounted regiments consisting
-6 stands: 2,750 x 1,100 mm
-6 stand: approx. 3,250 x 1,100 mm
-20 bars: approx. 2,900 mm
-25 frame for roller Rails
-500 roller Rails
-100 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Dimensions and loads (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 15,100 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm, 6 PCs.
Stand 3,250 mm, 6 PCs.
Crossbars: 20 PCs.
Frame for roller Rails: 25 PCs.
Roller Rails: 500 PCs.
Shelf divider: 100 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

4,100 €
    request
121614448 1401

STOW for sale
Flow rack - 3.250x36.200x3.150mm - 6 Levels


Used flow rack - approx. 36 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the l ...
used machine

Used flow rack - approx. 36 Item No. M H 3,250 mm - 6 levels - roller shelf - rolls shelf stow

Here a very well-preserved, used carton flow rack offered called - the manufacturer of Stow also picking shelves. At the levels of the rolls you store open boxes and cartons. When removing the front boxes independently to slip behind storage boxes on the rolls. So you can very quickly and gently force pick up. The shelf divider on the desired widths between the rolls elements are mounted to the Department of railways. In order to ensure a clean leadership of cartons or crates. About the rolls levels Euro pallets can be on the bars or cages store to refill if necessary the rolls levels quickly to. Long driveways can be avoided.

We have also other storage shelves or high shelves and accessories in used, as well as in new condition in stock. If you are interested, we look forward to your call.

We also recommend us as a supplier of complete storage and operating facilities. Request our printed catalogue.

Properties:
-Flow rack to the fast picking
-Five flow levels with roller Rails
-A storage level for Euro pallets
-Manufacturer: Stow
-Pallet places: 72 PCs.
-Used, in very good condition
-Stand Blue - Cross-arms in orange
-Shelves are degraded and available by arrangement, or ready for pickup.
-Stands are already pre-assembled

Dimensions:
-Shelf height front approx: 2,750 mm
-Shelf height rear approx.: 3,250 mm
-Shelf width approx.: 36.200 mm
-Shelf depth approx.: 3,150 mm
-Tray width approx.: 2,900 mm

Scope of delivery:
-2 Basic shelves and 10 mounted regiments consisting
-14 stand: 2,750 x 1,100 mm
-14 stand: approx. 3,250 x 1,100 mm
-48 bars: approx. 2,900 mm
-60 frame for roller Rails
-1,200 roller Rails
-240 shelf divider
-Incl. locking pins

All information without guarantee.

Lagertechnik Becker GmbH offers only used pallet racks, which withstand EN 15635 professional Assembly, after a check.

Dimensions and loads (approx.):

Shelf height front: 2,750 mm
Shelf height rear: 3,250 mm
Shelf width: 36.200 mm
Shelf depth: 3,150 mm
Compartment width: 2,900 mm

Data:

Manufacturer: Stow condition: used very well supplied with:

Stand 2,750 mm: 14 PCs.
Stand 3,250 mm: 14 PCs.
Bars: 48 PCs.
Frame for roller Rails: 60 PCs.
Roller Rails: 1.200 PCs.
Shelf divider: 240 PCs.
Locking pins: incl.


You can pick up this article by appointment at our warehouse in Krefeld, Germany. Of course, we deliver you the articles also in the House. To do this we will create an offer you. Please have understanding that we can call you free shipping without the zip code of your delivery address. We cooperate with several carriers, which operate different routes. Your advantage: We can gain the best transport price for you. Please contact them before you buy.

9,800 €
    request
121596385 201

BRODPOL TT5/600/400G for sale
Multi-blade saws


-machine in stock -After reviewing the technical -very good condition -year of manufacture: 2008 TECHNICAL PARAMETERS: -the maximum diameter of the element 400 mm -minimum diameter of element 120 mm -maximum l ...


-machine in stock
-After reviewing the technical
-very good condition
-year of manufacture: 2008

TECHNICAL PARAMETERS:

-the maximum diameter of the element 400 mm
-minimum diameter of element 120 mm
-maximum length of item 6000 mm
-the minimum length of item 150 mm

-circular saw diameter 600 mm
-dual spindle
-spindle diameter 2 x 60 mm
-spindle speed ~ 2220 RPM
-feed adjustable 8-25 m/min

-winch oflisów
-four top pneumatic clamps
– diameter 250 mm
– roller table output centering
-spiral rollers

-main engines 90 kW + 70 kW
-track feed engines 2 x 3 kW
– Motors winches oflisów 2 x 1.1 kW
-engine pressure top 1.1 kW
– Motor rollers 1 kW
-power supply 3 x 380 V

-intake air 14000 m3/h

Overall dimensions (after removing) length/width/height
1) 270 cm/80 cm/210 cm
2) 215 cm/200 cm/230 cm
3) 280 cm/130 cm/210 cm
4) 600 cm/105 cm/100 cm

total weight ~ 7000 kg

Purpose:

TRAK g?sienicowo-chain is intended for longitudinal sawing round wood. The logs are served to the roller conveyor sawmill-duty table (increasing), on which are the automatic centring. It will. Material from the conveyor belt, in a continuous manner, by the team is tracked for the saw. Next the team cutting logs are split (using the band saw on two parallel to each other, spindles) on one or two of the Prism plus two boards and oflisy. After the intersection, a table with a single, specially adapted chain receives an uncut portion of the body. System side rolls dociskaj?cych keeps oflisy, side boards and the stockpile (Prism) into one, coherent whole until rozchylenia reels-automatic separation of the prism from the rest of the boards and the oflisy up under the table that receives, for example, on the belt conveyor. This process ensures that modern sensor, you do not need to make any additional, complicated regulations, for example, when you change the diameter of the logs. TRAK set in technological line along with logs and conveyors are characterized by very high efficiency up to 30 m3 per 1 h.

Price
  PL   request
121595147 204

SCM RSC 110 for sale


-machine in stock -After overhaul, ready to work -a well known reputable brand SCM TECHNICAL PARAMETERS: -grinding width 1100 mm -height grinding 150 mm -two units -steel shaft -shoe combo with a rubber s ...


-machine in stock
-After overhaul, ready to work
-a well known reputable brand SCM

TECHNICAL PARAMETERS:

-grinding width 1100 mm
-height grinding 150 mm

-two units
-steel shaft

-shoe combo with a rubber shaft 45 shor
-blowing on tape

-electrical height adjustment
-two types of feed rate

-main motor 22 kW
-the engine feed 0.45 kW

-the ability to precisely set the grinding
-oscillation of pneumatic
-ammeter

-two rolls on input and output
-the pedal height adjustment
-the diameter of the nozzle 1 x 150 mm and 4 x 110 mM

Overall dimensions of the machine:

– length 170 cm
– width 200 cm
-height 230 cm

-weight 1750 kg

Price
  PL   request
121595047 201

RAIMANN K31M for sale
Multi-blade saws


-machine in stock -After reviewing the technical -very good condition TECHNICAL PARAMETERS: -cutting width 400 mm -cutting height 120 mm -crawler width 335 mm -main motor 22 kW -feed motor 1.5 kW -Caterp ...


-machine in stock
-After reviewing the technical
-very good condition

TECHNICAL PARAMETERS:

-cutting width 400 mm
-cutting height 120 mm
-crawler width 335 mm

-main motor 22 kW
-feed motor 1.5 kW

-Caterpillar has a wood overlay oblodzonego

-feeding speed 8-36 m/min
-adjustable speed on the inverter

-central lubrication

-the possibility to mount a floating shield
-two lasers

maximum disc diameter 350 mm
-three rows of latches
-four top rollers

-barrel diameter 80 mm
-spindle diameter 65 mm

Overall dimensions of the machine:

-length: 184 cm
width 150 cm
-height 185 cm
-weight ~ 2200 kg

The receiving table AT/QL/2000:

-two rolls of extending
-six rolls of auxiliary
-five cross chains
-feed motor 0.75 kW

-conveyor with a length of 4000 mm
-belt width 400 mm
-feed motor 0.75 kW

Price
  PL   request
121595011 206

HESS HESS for sale
Hydraulic presses


-machine in stock -After reviewing the technical -very good condition -year of manufacture 2003 TECHNICAL PARAMETERS: -bonding length 830 cm -gluing width 100 cm -the thickness of the adhesive 20 cm -HYDRAU ...


-machine in stock
-After reviewing the technical
-very good condition
-year of manufacture 2003

TECHNICAL PARAMETERS:

-bonding length 830 cm
-gluing width 100 cm
-the thickness of the adhesive 20 cm

-HYDRAULIC PRESS

-the pump motor 4.5 kW

-15 upper hydraulic cylinders
-8 side clamps 2 pneumatic cylinders
-all adjustable cylinders
-pressure Max 120 bar

-AUTOMATIC CROSS FEEDER

-the length of the tray 510 cm
-the width of the tray 230 cm

-5 cross belts
-distance between straps adjustable

-pneumatic actuator pulling
-maximum width 170 mm

-adjustable feed speed on the geared motor
-total power 1.5 kW

-GLUE SPREADER

-roll width 310 mm
-engine 0.37 kW

-adjustable height
-Glue control

-ROLL/DRAINER

-the length of the rolls of 600 cm
width 250 mm
-24 rolls

Price
  PL   request
121594982 203

WEINIG HYDROMAT 1000 for sale
Four-sided planing machines


-machine in stock -After reviewing the technical -year of manufacture 2007 TECHNICAL PARAMETERS: -working width 230 mm -working height 160 mm -spindle diameter 50 mm -system Memory -total power 82 kW -adju ...


-machine in stock
-After reviewing the technical
-year of manufacture 2007

TECHNICAL PARAMETERS:

-working width 230 mm
-working height 160 mm
-spindle diameter 50 mm
-system Memory
-total power 82 kW

-adjustment of the feed on the inverter
return to 36 m/min
-feed motor 7.5 kW

arrangement of spindles:
DOWN + RIGHT + LEFT + UP + UP + DOWN

1) lower spindle 11 kW
2) spindle right 11 kW
3) spindle left 11 kW
4) upper spindle 11 kW
5) upper spindle 11 kW
6) lower spindle 11 kW

-the last two spindles on podtrzymce + jointer
-pneumatic input
– high low
-nozzle diameter 140 mm

-three rows of steel rollers upper
-four rows of rollers rubber upper
-two rolls of the countertop stretching

-Displays the PLC control trzewików
-display of the PLC spindle adjustment
-electronically regulated left head
-electronically adjustable height

Price
  PL   request
121578552 107

RIBOLDI / STILMEC for sale
SLITTING AND CUT TO LENGTH LINE 1500 x 2,2


Technical data/technical data: Bandwidth/strip width: 1500 mm Band thickness/strip thickness: 0.5-2.2 mm Setting rollers number/no. of leveler: 6 PCs / No. Feed roller number/no. of feedingrolls: 2 PCs / No. Num ...
used machine

Technical data/technical data:

Bandwidth/strip width: 1500 mm
Band thickness/strip thickness: 0.5-2.2 mm
Setting rollers number/no. of leveler: 6 PCs / No.
Feed roller number/no. of feedingrolls: 2 PCs / No.
Number of longitudinal shear blades/No. of slitter blades: 4 couple/pair
Transverse shear/crossshear
Control/regulation: STILMEC new / STILMEC new
2000
Price
    request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold
Find used machinery dealers in your country
