No. Cat. Photo Manufacturer | Model
Type of machinery
Year Price Country Contact
 page 1  > 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
124970745 101

TAILIFT TRP-1600H for sale
Drilling And Boring Machines


Dai.of column: 432 mm Distance from column surface to spindle center , Max: 1580 mm Distance from column surface to spindle center , Min: 440 mm Travel of spindle head: 1140 mm Distance from base surface to spindle e ...
used machine

Dai.of column: 432 mm
Distance from column surface to spindle center , Max: 1580 mm
Distance from column surface to spindle center , Min: 440 mm
Travel of spindle head: 1140 mm
Distance from base surface to spindle end , Max: 1600 mm
Distance from base surface to spindle end , Min: 380 mm
Elevating height of Arm: 850 mm
Effective area of box table: 700x500x400 mm
Dimension of base: 2480x1050x210 mm
Taper hole spindle: MT#5
Stroke of spindle: 370
R.P.M of spindle (rpm x steps): 40-1920x12 steps
Feed of spindle (rev. x steps): 7 1/2HP
Main motor (HP): 2HP
Elevating motor (HP): 2HP
Hydraulic clamping motor (HP): 1 HP
Coolant equipment (HP): 1/8 HP
Machine height from floor (Max.): 3170 mm
Base + column height: 2660 mm
Net weight (approx)kgs: 4600
Shipping weight (approx)kgs: 5100
Shipping dimensions (LxWxH): 2850x1400x2940 mm

2011
Price
  SK   request
124965315 102

MORI SEIKI SL 204 MC for sale
CNC Turning- and Milling Center


turning diameter: 390 mmturning length: 507 mmcontrol: MSG 806 MAPPSmax. turning diameter: 390 mmgreates pass round over bed: 680 mmSwing dia. over traverse guideway: 510 mmcentre distance: 618 mmMain spindle:: turning ...
used machine

turning diameter: 390 mm
turning length: 507 mm
control: MSG 806 MAPPS
max. turning diameter: 390 mm
greates pass round over bed: 680 mm
Swing dia. over traverse guideway: 510 mm
centre distance: 618 mm
Main spindle::
turning speed range - main spindle: 45 - 4.500 min/-1
power capacity - main spindel: 11 / 7,5 kW
spindle bearing diameter: 110 mm
spindle bore: 73 mm
max. bar capacity: 51 mm
spindle nose: JIS A2-6
C-Axis: 0,001 °
axis stroke::
x-axis: 235 (195+40) mm
z-axis: 520 mm
turret::
number of toolpositions: 12 pos.
Number of driven toolspositions: 12 pos.
Spindle speed - driven tool stations: max. 3.000 min -1
power capacity driven tool-stations: 5,9 / 4,5 kW
Shank height for square tool: 25 mm
Drill shank diameter: max. 50 mm
turret change time: 0,2 sec.
Tailstock::
tailstock adjustment: 490 mm
dia. of quill: 85 mm
taper of center: MT 4
quill stroke: 120 mm
feeds::
rapid traverse: X: 18 / Z: 24 m/min
Tipp feed: 0 - 1.260 mm/min
total power requirement: 30,1 kW
weight of the machine ca.: 4,5 t
dimensions of the machine ca.: 5,0 x 2,5 x 2,5 m
Documents:
Chip conveyor:
Coolantsystem:
Tailstock:
hydraulic system:
Three Jaw Chuck:
Turret:
Tool drive mechanisum:
C-axis:
tool setting:
parts catcher:
div. tooling:
CNC - Turning- and Millingcenter
MORI SEIKI - SL 204 MC



This ad was created with MODUL MWS - the software solution of LogoTech.
2002
Price
    request
124970699 103

BROTHER TC 32 for sale
CENTER FOR DRILLING-TAPPING


CNC B 00 AXIS X STROKE 550 MM RACE Y AXIS 400 MM Z-AXIS STROKE 415 MM DISTANCE BETWEEN TABLE AND NOSE CHUCK 645 MM RACING QUICK XYZ 70 M / MIN SPEED 'WORK XYZ 1-20000 mm / MIN ERROR REPEATABILITY '+/- 0.003 MM PO ...
used machine

CNC B 00
AXIS X STROKE 550 MM
RACE Y AXIS 400 MM
Z-AXIS STROKE 415 MM
DISTANCE BETWEEN TABLE AND NOSE CHUCK 645 MM
RACING QUICK XYZ 70 M / MIN
SPEED 'WORK XYZ 1-20000 mm / MIN
ERROR REPEATABILITY '+/- 0.003 MM
POSITIONING ERROR ON 0,005 300 MM
Ranked # 2 TABLES OF WORK AREA 600 X 425 MM
ALLOWED WEIGHT 200 KG
POSIIZONE TABLE 3.4 / 180
POWER SPINDLE 11/6 KW
SPEED 'CHUCK 12000 RPM / MIN
CONE BT 30
RIGID TAPPING
ATC 26 + 1 TOOL
HSK A 40 ATTACK
MAX DIA. TOOL 0-30 MM
MAX TOOL LENGTH 200 MM
TOOL WEIGHT 3.5 KG
TYPE OF RANDOM SELECTION
TIME CHANGE TOOL 0.9 SEC.
TIME CHIP / CHIP 2 SEC
REFRIGERATION THROUGH THE MANDREL BAR 40
CHIP CONVEYOR
FLYER
Input correction CHUCK
LIGHT WORK AREA
COMPENSATION AXIS Z
ROTARY IN PALLET CENTER
HEIGHT 2360 WIDTH 1890 LENGTH 3669
WEIGHT 4500 KG

Price
  IT   request
124965185 205

BENZ QUATTRO for sale
Aggregate for Homag or Weeke


Weight approx.: 9,6 kgDimensions (l x w x h) approx.: 450x250x300 mmDescription: BENZ angle head 4-fold + saw (rigid) - for Homag / Weeke machines 484/5000 Version: 4-fold + saw (rigid) Max. Drive speed (motor): 3 200 1 ...
used machine

Weight approx.: 9,6 kg
Dimensions (l x w x h) approx.: 450x250x300 mm
Description: BENZ angle head 4-fold + saw (rigid) - for Homag / Weeke machines 484/5000 Version: 4-fold + saw (rigid) Max. Drive speed (motor): 3 200 1 / min Max. Spindle speed: 8 000 1 / min Direction of rotation of the spindle outputs, opposite drive direction motor Lifting stroke: 112.5 mm Axial holding force: 3 000 N Operating pressure: 6 bar Total Gear Ratio Saw Blades / Drill Spindles i = 1: 2.47 ATTENTION: max. Saw blade diameter 125mm
2011
used machinery auction RESALE 900 €
  DE   request
124946008 107

BYSTRONIC Byjet 3015 for sale
Water Jet Cutting Machines


Overhauled machine Hydraulic pump Overhauled Scraper conveyor New Bystronic laser safety lightscreen New MMC computer + remote 2 spare watercylinders available Manufacturer||Bystronic Model||Byjet 3015 Year of ...
used machine

Overhauled machine Hydraulic pump
Overhauled Scraper conveyor
New Bystronic laser safety lightscreen
New MMC computer + remote

2 spare watercylinders available

Manufacturer||Bystronic
Model||Byjet 3015
Year of Manufacturing|| 2004
Serial Number||Job nr.: 30002067
Working Hours|H|39900
Control||MMC
Available for Delivery||Immideatly

Working Area||3000 x 1500
Number of cutting heads|#|2
Max. Working pressure|Bar|3600 bar. Bypump 50APC
Drill spindle||Yes

Drag conveyor
Abrasiv tank
Accessories Various tools for repair of the machine (thread cutter, etc)

No Offline software
2004
Price
  DK   request
124965229 205

BENZ Winkelkopf 3x2 for sale
Aggregate and Spare Part


Weight approx.: 14 kgDimensions (l x w x h) approx.: 450x4250x300 mmDescription: BENZ Winkelkopf 3x2 Aggregate and Spare Part BENZ HSK-A63 aggregate / angle head 3x2 spindles horizontal - for Homag / Weeke machines Vers ...
used machine

Weight approx.: 14 kg
Dimensions (l x w x h) approx.: 450x4250x300 mm
Description: BENZ Winkelkopf 3x2 Aggregate and Spare Part BENZ HSK-A63 aggregate / angle head 3x2 spindles horizontal - for Homag / Weeke machines Version: 3x2 horizontal drilling unit For attachment to the following multi-spindle engine: 17-spindle 000M11100777 (Homag. No .: 2-056-08-3461) // 000M1117U1111 (Homag. No .: 2-056-08-3462) 12-Spindler 000M11100789 (Homag. No .: 2-056-08-3641) // 000M1117U1112 (Homag-No .: 2-056-08-3642) 17-spindler 000M11100799 (Homag-No .: 2-056-08-3511) Max. Drive speed (motor): 4 480 1 / min Max. Spindle speed: 7 200 1 / min Holding force: 700 Nm Translation: (bevel gear = 1: 1) Total translation: i = 1: 1.61
2007
used machinery auction RESALE 490 €
  DE   request
124945967 103

DECKEL FP3A for sale
CNC Universal Milling and Drilling Machine


X-travel: 400mm, y-travel: 400mm, z-travel: 400mm, quill stroke: 80mm, tool mount: SK 40, rotational speed: 40-4000/min, feed rate: 2-3600mm/min, rapid traverse: 4000mm/min, control: Contour 3, number of available machin ...
used machine

X-travel: 400mm, y-travel: 400mm, z-travel: 400mm, quill stroke: 80mm, tool mount: SK 40, rotational speed: 40-4000/min, feed rate: 2-3600mm/min, rapid traverse: 4000mm/min, control: Contour 3, number of available machines: 2, year of construction: 1983, 1989.
1989
Price
  DE   request
124964659 109

Bohner & Koehle F3 for sale
Milling head


used, good fully functioning condition from plant disassembly 1 x Bohner & Köhle Bokö F3 milling tool holder: iso50 Speed: 25-2550 RPM Drilling depth Milling spindle: 300 mm changes / errors in the technical data  ...


used, good fully functioning condition from plant disassembly

1 x Bohner & Köhle Bokö F3 milling tool holder: iso50
Speed: 25-2550 RPM
Drilling depth Milling spindle: 300 mm changes / errors in the technical data as well as intermediate sales reserved!

Price
    request
124935974 101

UNION BFT 130/6 for sale
Table Drills


Type: BFT 130/6 Manufacturer: Union Condition: used, fully functional Year of construction: 1981 Spindle diameter: 130 mm Spindle taper: ISO 50 Table size: 2000 x 1800 mm maximum table load: 8 t Plan slide stroke ...
used machine

Type: BFT 130/6
Manufacturer: Union
Condition: used, fully functional
Year of construction: 1981
Spindle diameter: 130 mm
Spindle taper: ISO 50
Table size: 2000 x 1800 mm
maximum table load: 8 t
Plan slide stroke: 320 mm
Faceplate diameter: 785 mm
Vertical adjustment of the drilling slide: 1750 mm (y)
Table cross travel: 2785 mm (x)
Tischlängsweg: 2300 mm (z)
Spindle stroke: 900 mm (w)
Spindle speed: 4.5-900 rounds / min / / rpm
Plan slide speed: 5-250 U / min / / rpm
Total power: 40 kw
Machine weight: 32 tons

The machine is sold with lots of tools and accessories.

More details can be found in the images (plate) or on request.
Pick up in Neubrandenburg, delivery possible. Loading possible.

More information on request, sales as shown (see pictures). Changes and error in the technical details and information and subject to prior sale.
1981
Price
    request
124964681 101

HUHNHOLZ / WMW BT10 for sale
Bench drilling machine drilling machines


used, good fully functioning condition of workshop resolution: 1 x George Hardy / WMW BT10 bench drill Year of construction: 1962 incl. Chuck Ø 13 mm Speed: 355 / 710 / 1000 / 2000 RPM Operating voltage 380 V  ...
used machine

used, good fully functioning condition of workshop resolution:

1 x George Hardy / WMW BT10 bench drill

Year of construction: 1962
incl. Chuck Ø 13 mm
Speed: 355 / 710 / 1000 / 2000 RPM
Operating voltage 380 V
Capacity: 0.45 / 0.6 of kW projection: 210 mm
Quill stroke: 100 mm
Table Lxw: 350 x 280 mm
maximum distance from table / drill Chuck: 330 mm

equipped with new cable and CEE plug 16A

Space Lxwxh: 550 x 430 x 1150 mm
1962
Price
    request
124930123 109

DRILL 18 for sale
VERTICAL DRILL


BRAND: DRILL Model: 18 Type: bench drill Maximum diameter: Ø 18 mm. Surface dimensions: 320 x 310 mm. Dimensions: 850 x 400 x 1050 mm.


BRAND: DRILL
Model: 18
Type: bench drill
Maximum diameter: Ø 18 mm.
Surface dimensions: 320 x 310 mm.
Dimensions: 850 x 400 x 1050 mm.

Price
  IT   request
124964696 101

SOMEX Max3TP00 for sale
Drilling unit Gewindebohreinheit


used, good condition from bearing resolution: 1 x SOMEX Max3TP00 drilling unit / Gewindebohreinheit A total of 2 pieces available Year of construction: 2000 equipped with SEW DFV112M6/BMG driving motor 230 / ...
used machine

used, good condition from bearing resolution:

1 x SOMEX Max3TP00 drilling unit / Gewindebohreinheit

A total of 2 pieces available

Year of construction: 2000

equipped with SEW DFV112M6/BMG driving motor
230 / 400 V
2,2 kW
940 RPM

Tool holder ø 31 mm
Feed slider Lxw: approx. 195 x 150 mm

Total length without tool: 1000 mm

Space Lxwxh: approx. 1000 x 500 x 160 mm
Weight: approx. 70 kg changes / errors in the technical data as well as intermediate sales reserved
2000
Price
    request
124929833 205

SCHLEICHER Borfix / S for sale
Dowel drilling machines


Description: They offer here on a super, functional dowel boring machine, the traditional brand Schleicher, which of course quality is 1A. It is in excellent condition. Minor signs of use are included, which are but c ...
used machine

Description:

They offer here on a super, functional dowel boring machine, the traditional brand Schleicher, which of course quality is 1A. It is in excellent condition. Minor signs of use are included, which are but cannot be seen with the naked eye.

Technical data:

Brand: Schleicher

Type: Borfix / S

Year: 1985

V: 400

HZ: 50

A: 3.9

bar: 3-6

With fence right and left.

Spindles: 9
1985
1,260 €
    request
124964632 101

SIP Hydroptic-6A for sale
Jig boring machine


Movement X/Y/Z [mm] 700/1.000/795 Technical Data In general: Clamping surface: 1.100 x 842 mm Table loading (max.): 1.000 kg Drilling spindle stroke: 300 mm Drilling spindle-ø: 135 mm Taper: MK4
used machine

Movement X/Y/Z [mm] 700/1.000/795

Technical Data
In general:
Clamping surface: 1.100 x 842 mm
Table loading (max.): 1.000 kg
Drilling spindle stroke: 300 mm
Drilling spindle-ø: 135 mm
Taper: MK4
1968
Price
    request
124929744 101

FÖHRENBACH GMBH F GRIND 605 Professional for sale
Drilling And Milling Machines


5 axes, one-head cutter-CNC grinding machine intended for the production of cutting tools, numerically controlled. Very precise, Professional machine numerical German production with full instrumentation. Made of a grani ...
used machine

5 axes, one-head cutter-CNC grinding machine intended for the production of cutting tools, numerically controlled. Very precise, Professional machine numerical German production with full instrumentation. Made of a granite block. The device would cost € 380 000. The machine in perfect working condition with complete extra this offer is based on. Grinder manufactured in 2012 year, running in 2014. She worked in the company producing components for aircraft for a period of 1 year. The machine is connected to the power supply, currently not used the opportunity to test while on the job.

The CNC machine Föhrenwald played in F GRIND 605 Professional was manufactured on special order for the production of cutting tools carbide SOLID CARBIDE, used in the automotive and aerospace industry. Not without reason has a powerful 4.5 ton granite base, ensuring almost 100% eliminate vibration during grinding process. This affects the unique grinding accuracy and surface quality. The grinder has a separate high-performance filter team, this allows her to work at very high feed rates while providing adequate lubrication of polished tools in less time. The hole in the side of the machine, which is a very important advantage of this machine, grinding and sharpening tools with long dimensions even above 1merta. The MTS software in full version allows you to create special tools both in production, as well as a unit. Machine with this software is able to sand mills with variable geometry of the blade, the ideal tool for stainless steel and Inconel used in the aerospace industry. When you buy this machine you will be able to compete with the best global corporations are searching for.

Technical data:
Manufacturer: Föhrenwald Played In GmbH, Germany
Model: F Grind 605
Year: 2012
Serial number: 701600002
Dimensions and weight
-Tool milling machine F-Grind 605
Width: 2600 mm
The depth of 2200 mm (without control panel)
Height 3200 mm
Weight approx. 6000 kg machine with complete cab and control cabinet

Air compressor
-Air consumption 450 litres/min
-compressed air 6-8 bar

Linear axes
X-axis.
-Feed along an axis X 750 mm
-Speed of the axis X 1.0 m/s
-X axis Resolution 0.0001 mm

The Y Axis.
-Feed vertical Y axis 280 mm
-Y axis Speed 0.5 m/s
-Y axis Resolution 0.0001 mm

The Z Axis.
-The feed across the axis of the 350 mm
-The speed of the axis of 0.5 m/s
-Axis Resolution of 0.0001 mm

The Axis U.
-Feed along the axis in 650 mm

Rotary axes with linear drive
B-Axis
-B-axis Speed 0-1500 r/min
-Resolution of the axis (B) ? 0.01 s
-The movement of swinging in the B-axis 220 °

C-Axis
-C axis Speed 0-1500 r/min
-C axis Resolution ? 0.01 s
-C-axis Rotation 0-?

Measuring system
-A direct measurement system for linear and rotary axes

Grinding spindle drive
-Power 7.5 kW at 5000 RPM
-Infinitely variable speed control up to 12000 RPM

Tool holders
Automatic collection of tools to change the set of grinding wheels HSK 50
-Working Head direct drive SK 50

Place to work
-the length of the workpiece to the full working max. 300 mm
-machined Ø for complete machining of max. 100 mm

Grinding wheels
-diameter of max. 150 mm
-Grinding wheels on the photo 3
-Grinding Spindle HSK 50

Control
-CNC Föhrenwald played in uinipos 820-WH

In the basic version of the machine consists of:
-support main
-linear axis
-spindle grinding wheel
-cooling unit
-spindle head of the workpiece
-full cab protector
-Cabinet with cooling device
-a rotating console to operate CNC
In addition, extended with integral is:
-Automatic clamping system
-Manual mounting system
-foot pedal
-grinding, measuring callipers
-coolant unit
-horse with against szpiclem.
-Full documentation in German
2012
106,000 €
  PL   request
124964634 101

DMG DMC 60 H - RS4 for sale
4-Axis horizontal machining centre


Spindle: Speed 15.000 rpm Taper HSK-A63 NC-round table: B-Axis 0,001° Palletsize 500 x 400 mm Drilling pattern threaded holes M12 x 22 Workpieceweight (max.) 600 kg In general: Tool magazine 180 stations P ...
used machine

Spindle:
Speed 15.000 rpm
Taper HSK-A63

NC-round table:
B-Axis 0,001°
Palletsize 500 x 400 mm
Drilling pattern threaded holes M12 x 22
Workpieceweight (max.) 600 kg

In general:
Tool magazine 180 stations
Pallet storage 4 stations

Equipment / Accessories
Position sensor: Direct scales in X/Y/Z
Cooling management: Internal cooling unit with paperbeltfilter, 40 bar
Chipdisposal: Scraper-type-chip-conveyor
Tool monitoring: Breakage control, Laser
Raw material feed: 4-fold pallet storage
Extraction: Preparation mechanical extraction
Additional accessorie: 6 pieces pallets
ATTENTION: New spindle in 2009
1999
Price
    request
124923727 101

FLOTT SB 25 STV for sale
Column-Type Drilling Machines


Chuck: MK 3 Gr. Bohrlstg. in St.: approx. 28 mm Speed range: up to 1700 RPM - infinitely variable Table size: 420 x 380 mm Throat depth: 300 mm Stroke: 160 mm Total power: 1,5 KW / 380 V / 50 Hz Machine weight: 30 ...
used machine

Chuck: MK 3
Gr. Bohrlstg. in St.: approx. 28 mm
Speed range: up to 1700 RPM - infinitely variable
Table size: 420 x 380 mm
Throat depth: 300 mm
Stroke: 160 mm
Total power: 1,5 KW / 380 V / 50 Hz
Machine weight: 300 kg

Equipment / Accessories:

Automatic drill feeds 0.10 0.16 0.25 mm / U
stepless speed control
Machine lamp
Keyless drill Chuck Röhm supra 1-16 mm
Speed display

Other:

In the front plate 3 cover buttons - s are missing photo.
The machine runs something rough.

All technical data are created according to our best knowledge and existing documents; Expressly reserved by mistake.
Each party has the opportunity to test the machine before purchasing power.
1987
Price
    request
124964614 101

MATSUURA RA-1/MX 3 for sale
VERTICAL MACHINING CENTRE


Project No: 904655 Number: 1 pc. Manufacturer: MATSUURA Type: RA-1/MX 3 Control: Yasnac Year of Manufacture: 1988 Condition: Used Machine MILLING 3 Axis Travel in X 510 mm Travel in Y 360 mm Travel in Z 460  ...
used machine

Project No: 904655
Number: 1 pc.
Manufacturer: MATSUURA
Type: RA-1/MX 3
Control: Yasnac
Year of Manufacture: 1988
Condition: Used Machine

MILLING
3 Axis
Travel in X 510 mm
Travel in Y 360 mm
Travel in Z 460 mm
Tool taper BT 40
Max. speed milling spindle 12000 1/min
Max. power at 10-40/100% duty ratio 3,7 kW
Tool magazine 25 stations

FURTHER EQUIPMENT
Partly enclosed work area
Light in working area
Coolant unit

ACCESSORIES
40 pc. Tool holder for drilling and milling tools


Very reliable machine!

We described the specified product as accurate as possible. As it is not a product manufactured by us, the mentioned data can deviate. Herewith, we point out that the mentioned data are are non-binding and ask you to check them during your inspection.
1988
Price
    request
124892846 836

HANG 157 for sale
Single head paper driller


Single head paper driller Hang Model 157 Year 1980´s Details 1 head paper driller with tabulator Operation by lever Available Direct
used machine

Single head paper driller
Hang
Model 157
Year 1980´s
Details 1 head paper driller
with tabulator
Operation by lever
Available Direct
1980
Price
  NL   request
124964616 101

MATSUURA MC-510 V for sale
VERTICAL MACHINING CENTRE


Project No: 904656 Number: 1 pc. Manufacturer: MATSUURA Type: MC-510 V Control: Yasnac Year of Manufacture: 1989 Condition: Used Machine MILLING 3 Axis Travel in X 510 mm Travel in Y 360 mm Travel in Z 4 ...
used machine

Project No: 904656

Number: 1 pc.
Manufacturer: MATSUURA
Type: MC-510 V

Control: Yasnac
Year of Manufacture: 1989
Condition: Used Machine

MILLING
3 Axis
Travel in X 510 mm
Travel in Y 360 mm
Travel in Z 460 mm
Max. rapid traverse in X/Y/Z 24/-/- m/min
Tool taper BT 40
Max. speed milling spindle 6000 1/min
Max. power at 10-40/100% duty ratio 3,7 kW
Tool magazine 25 stations

FURTHER EQUIPMENT
Partly enclosed work area
Light in working area
Coolant unit

ACCESSORIES
40 pc. Tool holder for drilling and milling tools

Very reliable machine!

We described the specified product as accurate as possible. As it is not a product manufactured by us, the mentioned data can deviate. Herewith, we point out that the mentioned data are are non-binding and ask you to check them during your inspection.
1989
Price
    request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
More DRILL models (2 or more machines):
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold
Find used machinery dealers in your country
