125452359 106

URPEMAK URPE CC 50 for sale


Aluminum injection molding machine URPEMAK URPE CC 50 was built in 2005 in Spain. URPEMAK URPE CC 50 casting machine - characteristic parameters: - closing force: 500 kN - closing distance: 260 mm - ejector force:  ...
used machine

Aluminum injection molding machine URPEMAK URPE CC 50 was built in 2005 in Spain.

URPEMAK URPE CC 50 casting machine - characteristic parameters:
- closing force: 500 kN
- closing distance: 260 mm
- ejector force: 62.8 kN
- ejector stroke: 50 mm
- mold height (min-max): 100/325 mm
- dimensions of plates: 500 x 500 mm
- distance between columns: 320 x 290 mm
- column diameter: 60 mm
- injection position: 0-50 mm
- maximum casting force: 50 kN
- Injection piston diameter: 45-50-55 mm
- casting feed: 140 mm
- casting surface: 159-196-238 cm2
- injection mass / volume: 91-140-188 cm3
- injection pressure: 314-254-210 daN / cm2
- piston feed: 150 mm
- engine: 11 kW
- weight: 4900 kg
- dimensions: approx. 407 x 225 x 220 cm
2005
22,475 €
  PL   request
125494857 107

STÖLTING 2000/5 for sale


sheet width: 2050 mmplate thickness: 5 mmdistance between columns: 2240 mmdiameter of upper rolls: 140 mmdiameter of lower rolls: 130 mmtotal power requirement: 4 KWweight of the machine ca.: 1,5 tdimensions of the machi ...


sheet width: 2050 mm
plate thickness: 5 mm
distance between columns: 2240 mm
diameter of upper rolls: 140 mm
diameter of lower rolls: 130 mm
total power requirement: 4 KW
weight of the machine ca.: 1,5 t
dimensions of the machine ca.: 3,0 x 0,8 x 1,6 mm




This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125452355 106

WEKO WE 680-2-20 for sale


Hydraulic presses WEKO in 680-2-20 was produced in 1997. Technical parameters : - pressure force: approx. 120 t - table base on the form: 46 cm - distance between columns: 67 cm - die stroke: 70 cm
used machine

Hydraulic presses WEKO in 680-2-20 was produced in 1997.

Technical parameters :
- pressure force: approx. 120 t
- table base on the form: 46 cm
- distance between columns: 67 cm
- die stroke: 70 cm
1997
4,975 €
  PL   request
125494826 107

HERA UM II for sale


sheet width: 3000 mmplate thickness: 2,00 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 2,7 tdimensions of the machine ca.: 4,00 x 1,00 x 1,30 mEquipment:- Bend angle adjustable vi ...
used machine

sheet width: 3000 mm
plate thickness: 2,00 mm
distance between columns: mm
total power requirement: kW
weight of the machine ca.: 2,7 t
dimensions of the machine ca.: 4,00 x 1,00 x 1,30 m
Equipment:
- Bend angle adjustable via potentiometer
- Height of the upper boom infinitely adjustable
- manual, semi-automatic and automatic mode possible



This ad was created with MODUL MWS - the software solution of LogoTech.
1977
Price
    request
125452353 106

URPEMAK URPE CFA 220 for sale


Casting machine URPEMAK URPE CFA 220 was manufactured in 2005 in Spain. In the price of the machine, an aluminum melt crucible with a capacity of approx. 500 l, visible in the last picture. Injection molding machine U ...
used machine

Casting machine URPEMAK URPE CFA 220 was manufactured in 2005 in Spain. In the price of the machine, an aluminum melt crucible with a capacity of approx. 500 l, visible in the last picture.

Injection molding machine URPAKAK URPE CFA 220 - technical parameters:
- closing force: 2250 kN
- closing distance: 440 mm
- ejector force: 120 kN
- ejector stroke: 100 mm
- mold height (min-max): 240/600 mm
- dimensions of the panels: 780 x 780 mm
- distance between columns: 510 x 510 mm
- column diameter: 90 mm
- injection position: 0-90-180 mm
- maximum casting force: 121-250 kN
- Injection piston diameter: 40-50-60-70 mm
- casting feed: 360 mm
- casting surface: 113-714 cm2
- injection mass / volume: 301-471-678-923 cm3
- injection pressure: 315-1990 daN / cm2
- engine: 20 kW
- weight: 13000 kg
- dimensions: approx. 590 x 238 x 275 cm
2005
37,475 €
  PL   request
125494828 107

STÜCKMANN + HILLEN 165.05 for sale


sheet width: 1500 mmplate thickness: 2,50 mmdistance between columns: mmmanual back gauge: 750 mmside stop: 1000 total power requirement: kWweight of the machine ca.: 1,8 tdimensions of the machine ca.: 2,00 x 1,50 x 1 ...


sheet width: 1500 mm
plate thickness: 2,50 mm
distance between columns: mm
manual back gauge: 750 mm
side stop: 1000
total power requirement: kW
weight of the machine ca.: 1,8 t
dimensions of the machine ca.: 2,00 x 1,50 x 1,30 m
- sharpened knife



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125452333 106

URPEMAK URPE CFA 330 for sale


Aluminum injection molding machine URPEMAK URPE CFA 330 was produced in 2008 in Spain. The price of the machine is a melting pot of zinc, with a capacity of approx. 400 l, visible in the last photo. URPEMAK URPE CFA  ...
used machine

Aluminum injection molding machine URPEMAK URPE CFA 330 was produced in 2008 in Spain. The price of the machine is a melting pot of zinc, with a capacity of approx. 400 l, visible in the last photo.

URPEMAK URPE CFA 330 casting machine - technical data:
- closing force: 3300 kN
- closing distance: 510 mm
- ejector force: 181 kN
- ejector stroke: 120 mm
- mold height (min-max): 300/700 mm
- dimensions of plates: 910 x 910 mm
- distance between columns: 572 x 572 mm
- diameter of the columns: 115 mm
- injection position: 0-80-160 mm
- maximum casting force: 155-350 kN
- Injection piston diameter: 50-60-70-80 mm
- casting feed: 445 mm
- surface of the cast: 170-1089 cm2
- injection volume / volume: 655-943-1294-1677 cm3
- injection pressure: 308-1782 daN / cm2
- engine: 33 kW
- weight: 16000 kg
- injection molder dimensions: 700 x 270 x 290 cm
2008
37,475 €
  PL   request
125494830 107

SCHRÖDER HS 200 for sale


sheet width: 2000 mmplate thickness: 1,25 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 0,66 tdimensions of the machine ca.: 2,50 x 1,10 x 1,30 m- Manual backgauge up to 500 mm- ta ...
used machine

sheet width: 2000 mm
plate thickness: 1,25 mm
distance between columns: mm
total power requirement: kW
weight of the machine ca.: 0,66 t
dimensions of the machine ca.: 2,50 x 1,10 x 1,30 m
- Manual backgauge up to 500 mm
- table extension (extendable)



This ad was created with MODUL MWS - the software solution of LogoTech.
2002
Price
    request
125436643 106

ERFURT PTRZSST 210 for sale


ERFURT PTRZSST 210 transfer press was built in 1991 in Germany. ERFURT PTRZSST 210/11/280 progressive press - technical parameters: - maximum pressure force: 160 tons - number of jumps: 20-40 min-1 - maximum travel ...
used machine

ERFURT PTRZSST 210 transfer press was built in 1991 in Germany.

ERFURT PTRZSST 210/11/280 progressive press - technical parameters:
- maximum pressure force: 160 tons
- number of jumps: 20-40 min-1
- maximum travel of the upper table: 400 mm
- the ability to adjust the tool holders: 63 mm
- working capacity per stroke: 40 kNm
- pulling depth: 125 mm
- ejector force: 50 tons
- ejector stroke: 80 mm
- ejector adjustment: 63 mm
- range controlled by the ejector: 63 mm
- distance between columns: 3500 mm
- distance between tool centers: 280
- number of positions: 10
- dimensions of the press: 6.6 x 2 m
- weight: 80,000 kg
1991
58,500 €
  PL   request
125494816 107

EHT VarioPress 175-30 for sale


pressure: 170 tchamfer lenght: 3050 mmdistance between columns: 2550 mmControl: CYBELEC ModEva 10 S total power requirement: kWweight of the machine ca.: 13.600 kgdimensions of the machine ca.: mThis ad was created wit ...
used machine

pressure: 170 t
chamfer lenght: 3050 mm
distance between columns: 2550 mm
Control: CYBELEC ModEva 10 S
total power requirement: kW
weight of the machine ca.: 13.600 kg
dimensions of the machine ca.: m



This ad was created with MODUL MWS - the software solution of LogoTech.
2011
Price
    request
125374541 106

KRUPP PST-A 160 for sale


KRUPP PST-A 160 transfer press built in 1980. Technical data of the KRUPP PST-A 160 press: - nominal pressure: 160 tons - cutting force grade 1: 400 KN - force between stands: 1200 KN - number of working steps inc ...
used machine

KRUPP PST-A 160 transfer press built in 1980.

Technical data of the KRUPP PST-A 160 press:
- nominal pressure: 160 tons
- cutting force grade 1: 400 KN
- force between stands: 1200 KN
- number of working steps including cutting stage: 11
- distance between stands: 200 mm
- slider stroke: 210 mm
- drawing depth: 70 mm
- range of jumps, infinitely adjustable: 15-75 / min.
- production range of jumps with repeatability of its setting: 25-75 / min.
- number of actuation movements: 15-25 / min.
- a usable work resource for a jump in the range of 25-75 strokes per minute. : 20,000 J
- maximum load on a single step: 500 KN
- maximum load of a single step using inserts: 630 KN
- maximum width of the tape: approx. 340 mm
- maximum diameter of the cut: 120 mm
- minimum diameter of the pattern: 30 mm
- distance between stands: 2450 mm
- height of tool building at the lower position of the slider and its adjustment at the top (space between the table and the jacks of the upper tools): 470 mm
- height of the surface of the transport of stampings over the table: 270 mm
- tool height adjustment: 40 mm
- table working surface (width x depth): 2000 x 700 mm
- adjustable distance between terminal blocks: 210 + - 300 mm
- closing stroke of the feeding strips for each slat: 75 mm

The KRUPP PST-A 160/11/200/210 progressive machining press is connected and can be checked on the move.
1980
224,750 €
  PL   request
125494820 107

HERA COP for sale


pressure: 300 tchamfer lenght: 4100 mmdistance between columns: 3550 mmMachine No.: 5083 weight of the machine ca.: 24.000 kgdimensions of the machine ca.: 5000x2000x3100 mmNew controller: DNC 884sPSDomestic equipments:- ...
used machine

pressure: 300 t
chamfer lenght: 4100 mm
distance between columns: 3550 mm
Machine No.: 5083
weight of the machine ca.: 24.000 kg
dimensions of the machine ca.: 5000x2000x3100 mm
New controller: DNC 884sPS
Domestic equipments:
- CNC controlled X & R axis
- CNC controlled crowning
- hydraulic stamp clamping
- Fiessler safety light barrier



This ad was created with MODUL MWS - the software solution of LogoTech.
1992
Price
    request
125355245 1407

BLUME 3.800-9.000/600 for sale


Scissor roller width 600 mm Retracted length (min) = 3,800 mm Extended length (maximum) = 125 mm 9.000 mm at Division (roll axis distance) Rollers made of blue plastic pipe, 3-split Ground OK roller supports are  ...


Scissor roller width 600 mm

Retracted length (min) = 3,800 mm
Extended length (maximum) = 125 mm 9.000 mm at Division (roll axis distance)
Rollers made of blue plastic pipe, 3-split

Ground OK roller supports are height-adjustable,
Height (min.) = 750 mm
Height (max) = 950 mm
7 columns per track (6 scissors segments)
Lifting capacity between 2 uprights: approx. 100kg

variable course with tight turns possible
variable length - low space requirement, when not in use
movable for flexible use at different locations

1,510 €
    request
125494822 107

EHT EcoPress 125 for sale


pressure: 125 tchamfer lenght: 3550 mmdistance between columns: 3050 mmcolumn arm: 300 mmstroke of ram: 240 mmdistance between table / ram: 320-560 mm: 5-1.000 mmcontrol: Cybelec DNC 70 : 13,8 kWvoltage: 3x 400V/N/PE 50  ...
used machine

pressure: 125 t
chamfer lenght: 3550 mm
distance between columns: 3050 mm
column arm: 300 mm
stroke of ram: 240 mm
distance between table / ram: 320-560 mm
: 5-1.000 mm
control: Cybelec DNC 70
: 13,8 kW
voltage: 3x 400V/N/PE 50 Hz
: mm
height: mm
weight: 12.800 kg



This ad was created with MODUL MWS - the software solution of LogoTech.
1997
Price
    request
125210746 106

AGOSTINO COLOMBO 2200 TON 800 tons + 630 tons for sale


Line of 3 Mechanical Presses brand AGOSTINO COLOMBO complete of nr. 2 presses 800 tons and 1 press 630 tons The machines can be sold individually Techical data Agostino Colombo 800 Tons Front Light between upright ...


Line of 3 Mechanical Presses brand AGOSTINO COLOMBO complete of nr. 2 presses 800 tons and 1 press 630 tons

The machines can be sold individually

Techical data Agostino Colombo 800 Tons
Front Light between uprights2000 mm
Nominal power800 Tons
Dimension table 2000 x 1350 mm
Fixed stroke400 mm
Working frequency march continues22 cycles/1’
Distance max table – ram1585 mm
Adjustment mold vertical160 mm
Passage between the colums900 mm
Blank holder125 Tonn
Stroke blank holder250 mm
Dimension blank holder1000x500 mm
Motor power75 kwWeight100.000 Kg
Year1971
Technical data Agostino Colombo 630 Tonn
Front Light between uprights1430 mm
Nominal power630 Tons
Dimension table 1400X1350 mm
Fixed stroke400 mm
Working frequency march continues22 cycles/1’
Light at closed ram802,5 mm
Adjustment mold vertical15
Passage between the columns1020 mm
Blank holder20 ton
Stroke blank holder250 mm
Motor power55 kw
Weight52.000 Kg
Year1971

Price
  IT   request
125493602 1300

DYNETICS Dynaflow HS 800D for sale


honing diameter: - mm stroke: - mm throat: - mm distance between columns: 610 mm cylinder diameter: 203 mm pressure of medium: 0 -60 bar flow volume: 63 l/min total power requirement: 6,5 kW Weight approx.: 1,7 t dimensi ...
used machine

honing diameter: - mm
stroke: - mm
throat: - mm
distance between columns: 610 mm
cylinder diameter: 203 mm
pressure of medium: 0 -60 bar
flow volume: 63 l/min
total power requirement: 6,5 kW
Weight approx.: 1,7 t
dimension machine [...]: 1,53 x 1,53 x 2,8 m
flow grinding machine / Extrude Honing Machine
Opening width min: 12mm
Opening width max. 318mm
Medium quantity approx. 20 kg, with heating-cooling system approx. 30 kg, with medium storage 60kg
Clamping pressure 30t
1994
Price
    request
125164586 103

TOS HD 12B for sale


Plano Milling machine Model: HD12 B Manufacturer: TOS Holoubkov Year of manufacture: 1971 Condition: Good Machine is able of milling Technical details: Table height: 1000x4000mm Dist ...


Plano Milling machine

Model: HD12 B
Manufacturer: TOS Holoubkov
Year of manufacture: 1971
Condition: Good
Machine is able of milling


Technical details:

Table height: 1000x4000mm
Distance between columns: 1250mm
Max workpiece height: about 1250mm

Price
  PL   request
125475385 107

BEYELER / SAGITA 3100/75 for sale


pressure: 075 tchamfer lenght: 3100 mmdistance between columns: mmtotal power requirement: kWweight of the machine ca.: 8,00 tdimensions of the machine ca.: 3,40 x 1,60 x 2,20 m- manual back gauge- cranked top tool 320 ...
used machine

pressure: 075 t
chamfer lenght: 3100 mm
distance between columns: mm
total power requirement: kW
weight of the machine ca.: 8,00 t
dimensions of the machine ca.: 3,40 x 1,60 x 2,20 m
- manual back gauge
- cranked top tool 3200 mm
- block die 3200 mm, V8, V10, V12, V16, V24, V36, V50, V75



This ad was created with MODUL MWS - the software solution of LogoTech.
1977
Price
    request
124798182 106

DURMA 2040 for sale
Gesenkbiegepressen


Type||Kantpresse Manufacturer||Durma Model||2040 Year of Manufacturing|| 2003 Serial Number||750203301 Control||DNC 80 Length|mm|2200 Width|mm|2000 Weight|kg|2500 Electrical||400 v - 50 hz Electrical Consumptio ...
used machine

Type||Kantpresse
Manufacturer||Durma
Model||2040
Year of Manufacturing|| 2003
Serial Number||750203301
Control||DNC 80
Length|mm|2200
Width|mm|2000
Weight|kg|2500
Electrical||400 v - 50 hz
Electrical Consumption|kW|7,5

Y Axis||Automatic
X Axis||Automatic
Z Axis||Manuel
R Axis||Automatic
Bending Length||2000
Tonnage|T|40
Tool Type||Promacam
Top Tool Clamping||Manuel
Bottom Tool Clamping||Manuel
Crowning||Excl.
Distance Between Columns|mm|1550

2003
Price
  DK   request
125475387 107

LVD MV 25-4 for sale


sheet width: 2540 mmplate thickness: 4,00 mmdistance between columns: mmback gauge - adjustable by motor: 750 mmside stop: ja/yes total power requirement: kWweight of the machine ca.: 4,0 tdimensions of the machine ca. ...
used machine

sheet width: 2540 mm
plate thickness: 4,00 mm
distance between columns: mm
back gauge - adjustable by motor: 750 mm
side stop: ja/yes
total power requirement: kW
weight of the machine ca.: 4,0 t
dimensions of the machine ca.: 3,40 x 1,50 x 1,20 m



This ad was created with MODUL MWS - the software solution of LogoTech.
1972
Price
    request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold

Sold machinery

Casting press URPEMAK URPE CC 50


Injection molding machine for aluminium URPEMAK URPE CC 50 built in 2005 the year in Spain. Foundry machine URPE URPEMAK CC 50-parameters: -clamping force: 500 kN -Road: 260 mm -the strength of the ejector: 62.8 kN -ejector stroke: 50 mm -height (min-max): 100/325 mm -dimensions: 500 x 500 mm -distance between columns: 320 x 290 mm -diameter: 60 mm -the position of the injection: 0-50 mm -the maximum force-cast: 50 kN -diameter of piston injection: 45-50-55 mm -feed cast: 140 mm -the surface of the casting: 159-196-238 cm2 the mass/volume of injection: 91-140-188 cm3 -injection pressure: 314-254-210 daN/cm2 -the feed piston: 150 mm -motor: 11 kW -weight: 4900 kg -dimensions: ok. 407 x 225 x 220 cm

Hydraulic Presses WEKO WE 680-2-20


Hydraulic presses WEKO in 680-2-20 was produced in 1997. Technical parameters: -clamping force: ok. 120 t -base form: 46 cm -distance between columns: 67 cm -making a stroke: 70 cm

Casting press URPEMAK URPE CFA 220


Foundry machine URPE URPEMAK CFA 220 produced in 2005 year in Spain. The price of the machine the crucible for melt aluminum, with a capacity of approx. 500 l, visible on the last photo. Injection molding machine for aluminium URPEMAK URPE CFA 220-technical parameters: -clamping force: 2250 kN -Road: 440 mm -the strength of the ejector: 120 kN -ejector stroke: 100 mm -height (min-max): 240/600 mm -dimensions: 780 x 780 mm -distance between columns: 510 x 510 mm -diameter: 90 mm -the position of the injection: 0-90-180 mm -the maximum force-cast: 121-250 kN -piston injection: 40-50-60-70 mm -feed cast: 360 mm -the surface of the casting: 113-714 cm2 the mass/volume of injection: 301-471-678-923 cm3 -injection pressure: 315-1990 daN/cm2 -engine: 20 kW -weight: 13000 kg -dimensions: ok. 590 x 238 x 275 cm

Casting press URPEMAK URPE CFA 330


Injection molding machine for aluminium URPEMAK URPE CFA 330 manufactured in 2008 year in Spain. The price of the machine is the crucible to melt zinc, with a capacity of approx. 400 l, visible on the last photo. Foundry machine URPE URPEMAK CFA 330-technical data: -clamping force: 3300 kN -road closure: 510 mm -the strength of the ejector: 181 kN -ejector stroke: 120 mm -height (min-max): 300/700 mm -dimensions: 910 x 910 mm -distance between columns: 572 x 572 mm -diameter: 115 mm -the position of the injection: 0-80-160 mm -the maximum force-cast: 155-350 kN -piston injection: 50-60-70-80 mm -feed cast: 445 mm -the surface of the casting: 170-1089 cm2 the mass/volume of injection: 655-943-1294-1677 cm3 -injection pressure: 308-1782 daN/cm2 -engine: 33 kW -weight: 16000 kg -machine dimensions: 700 x 270 x 290 cm

Cylindrical Grinding Machine TSCHUDIN HTG 430


Center distance: 480mm, center height: 100mm, grinding wheel diameter: 500mm, max. grinding wheel width: 80mm, grinding wheel bore: 203.2mm, motor power: 5.5kW, spindle cone: MK 4, spindle nose: 3x M48, swivelling range: 360°, rotational speed: 65-500/min, quill cone: MK 3, quill stroke: 20mm, length: 2200mm, width: 1700mm, weight: 2.6t.

Radial Drilling Machines Z 3050 X 16


Radial drilling machine with 3050 X 16 was built in 1989. This versatile general-purpose machine. It is suitable for drilling, countersinking, reaming, chamfering and thread cutting medium and large items. With the right equipment it is also possible to boring. Technical data drilling machine Z3050 X 16: -the maximum drilling diameter: 50 mm maximum range: 1600 mm -the maximum distance between the axis of the spindle and the column: 1600 mm -the minimum distance between the spindle axis and column: 350 mm -horizontal spindle head on your shoulder: 1250 mm -maximum distance from spindle face to the working surface of the base plate: 1220 mm (1250 mm) -minimum distance from spindle to base plate working surface: 320 mm (350 mm) -vertical stroke in column: 580 mm -arm lifting speed: 0.02 m/sec. -angle of rotation of the arm: 360 degrees -taper in the spindle: Morsea Nr. 5 -spindle speed range: 25-2000 RPM. -number of spindle speeds: 16 PCs. -feed range: 0.04-3.2 mm/Rev. -the amount of feeds: 16 PCs. -extension: 315 mm -depth of feed per rotation of graduated: 122.5 mm -maximum permitted torque on the spindle: 490 Nm -maximum permitted weight spindle: 15680 N -the power of main motor: 4 kW -engine power lifting arm: 1.5 kW -engine power the hydraulic lock: 0.75 kW -Coolant pump motor power: 0.09 kW -overall dimensions (l x w x h): 2500 x 1060 x 2655 mm -weight of the machine: ok. 3500 kg (3900 kg with a column guide)

Eccentric Presses SMERAL LENP 40 A


Eccentric press SMERAL PRESSES OFFERING LENP 40 and was produced by the machine manufacturer SMERAL PRESSES OFFERING. Machine SMERAL PRESSES OFFERING LENP 40 and was built in 1977. Technical parameters of the press SMERAL PRESSES OFFERING LENP 40 and: -maximum pressure: 40 t -outreach: 220 mm -the range of adjustment stroke: 8-90 mm -adjustment range slider: 60 mm -the gap between the slider and a table with a maximum of spring, in the lower turning point on the wykr?conym a: 250 mm -between the walls of the body: 250 mm -lower table: 630 x 430 mm -bore in a slider-diameter/height: 40/75 mm -the maximum number of strokes per minute slider (continuous operation): 67 1/min -the number of possible jumps-the largest number of individual jumping: 60 1/min -the minimum length of the pitch slider: 8 mm -maximum length of the pitch slider: 90 mm -pitch fastening grooves: 280 mm -the dimensions of grooves in the table: 22 x 38 x 16 x 27 mm -the dimensions of grooves in the disc table: 22 x 37 x 16 x 27 mm mounting holes diameter/distance mounting holes: 24/200/580 degrees -draft: 28 degrees -mounting plate thickness: 60 mm -through hole in mounting plate: 200/220 mm -through hole in the interface plate/height weaning: 100/20 mm -main motor power: 3 kW (1420 RPM) -air consumption for one include: 4 l -basic power supply: 3 x 380/220 V 50/60 Hz -dimensions (l x w x h): 1080 x 1530 x 2110 mm -weight of the machine: 2480 kg Eccentric presses equipment SMERAL PRESSES OFFERING LENP 40A: -an intermediate table -foot control -set covers -DTR (technical motor)

Heavy Lathes POREBA TCA 160


Heavy lathe POREBA TCA 160 was produced in 1959 by the famous Polish FUM POREBA. Technical data of lathe POREBA TCA 160: Scope of work:-height of tusks: 800 mm -maximum turning diameter over bed: 1600 mm -maximum turning diameter over support: 1300 mm -eyepiece: fi 800 mm -maximum turning diameter in the pó?okularze: 250 mm -maximum turning length: 6000 mm -maximum weight of workpiece between centers in: 16000 kG -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 30 mm2 -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 50 mm2 -permissible force on the knife: 6000 kG -the maximum torque at the spindle: 630000 kg.cm -the maximum cross section 70 x 70 mm knife: Cap Headstock: -number of spindle speeds: 24 n -the exponent of the speed: 1.25 -spindle speed range: 1,12-224 RPM., 1,12-224 r/min, 0.85-170 RPM. -front spindle neck diameter: 260 mm -slot in the spindle of the cone metric: # 120 -reducing Bush metric cone Tip: # 120/80 -spindle bore diameter: 105 mm -diameter of the blade Cap: 1600 mm Suport, feeds the normal: -20 longitudinal feed range: 0,19-5,0 mm/Rev. -20 transverse feed range: 0,095-2.5 mm/Rev. -20 feed on the upper tray of the range: 0,095-2.5 mm/Rev. Suport, feeds 8-20 longitudinal feed range: 1.5-40 mm/Rev. -20 transverse feed range: 0.75-20.0 mm/Rev. -20 feed on the upper tray of the range: 0.75-20.0 mm/Rev. Suport, feeds minute:-20 longitudinal feed range: 12-320 mm/Rev. -20 transverse feed range: 6-160 mm/Rev. -20 feed on the upper tray with a range: 6-160 mm/Rev. Suport, feeds to thread (the main screws. train.):-35 thread jumping metrycz. about t. : 1-50 mm -jumping 35 inch threads range: 24-1/2 scroll/inch Suport, feeds for threading on the top tray:-25 thread jumping metrycz. about t. 0.25-7 mm -jumping 35 inch threads/inch scroll: the scroll 28-3/inch Feed rates associated to the rolling cones of gradients creating: 1:1.5 (d) 1:1000 -rapid traverse: 4000 mm/min. Konik: -barrel diameter: 200 mm -stroke sleeve: 600 mm -slot in the spindle sto?. meter.: # 80 -radial offset: +-30 mm Glasses: -diameter adjustment range normal: 200-600, 200-500 equipment, okular, 300-800 mm -adjustment range of diameters okular special equipment: 30-300, 50-400, 200-500 mm Pó?okular: -adjustment range pó?okulara diameter: 50-250 mm Drive:-main motor power: 40 kW -the engine speed: 750 RPM. -rapid feed motor power: 2.2 kW -the engine speed rapid feed rate: 3000 rpm. -oil pump motor power: 0.37 kW -engine oil pump: 1500 rpm. -performance oil pump: 25 l/min. Sizes and weights: -distance between centres: 3000-15000 mm -weight for length 6000 mm and 1 support: ok. 30000 kg -extra weight Prov difference length 1000 mm: 1200 kg -the weight of the additional bracket: 1500 kg

Eccentric Presses SMERAL TRNAVA LEN 40 C


Eccentric press SMERAL PRESSES OFFERING TRNAVA LEN 40 C produced in 1985 year in Czechoslovakia. Press-specific data LEN 40 c: -pressure: 40 tons -table surface: 660 x 530 mm -the surface of the slider: 400 x 250 mm -outreach: 265 mm -the distance between the table and the slider: 295 mm -the size of the adjustment between the table and the slider: 80 mm -the number of jumps the slider with continuous movement: 70 or the 142 ppm -number of jumping individual: 50/min -adjustable pitch slider: 8-95 mm -pneumatic coupling, min. air pressure: 0.4 MPa -motor power: 3/4 kW -overall dimensions (l x w x h): 1585 x 1245 x 2370 mm -weight: 4500 kg

PRESSA PER PRESSOFUSIONE Italpresse


ISOLA CASTING ITALPRESSE BRAND Italpresse The MODEL 300 YEAR 1974 Horizontal press for die casting with charger and Lubricator Datasheet Closing power 350 Ton Max power injection 40 Ton Central extraction power 18 Ton Max height 750 mm moulds Minimum height 250 mm moulds Stroke 130 mm 500 mm stroke central extraction platen 960x960 plans size mm Distance within the columns 580x580 mm motor power 18.5 Kw Printable area max 400 cm2 metal pressure Kg/cm2 845 total weight of 14.8 Tons press overall dimensions 1450x6100x1900 h mm For more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

Transfer Presses ( 2 - 4 Columns) ERFURT PTRZSST 210


Transfer press ERFURT PTRZSST 210 was built in the year 1991 in Germany. The progressive press ERFURT PTRZSST 210/11/280-technical parameters: -maximum pressure: 160 tons -the number of jumps: 20-40 min-1 -the maximum stroke of the upper table: 400 mm -adjustable handles tools: 63 mm -working capacity per stroke: 40 kNm -depth of draw: 125 mm -the strength of the ejector: 50 tons -ejector stroke: 80 mm -adjust the ejector: 63 mm -the range controlled by the ejector: 63 mm -distance between columns: 3500 mm -the distance between the centres of the utility: 280 -number of posts: 10 -overall dimensions: 6.6 x 2 m -weight: 80000 kg

Eccentric Presses FPA PMS 63 CP


Eccentric press FPA PMS 63 CP produced in 1983 by the Warsaw Factory Machines. FPA press parameters PMS 63 CP: -maximum load: 63 tons -size disc table: 800 x 560 mm -outreach, the table height: 280 mm -adjustable pitch slider: 8-110 mm -diving slider: 65, 85, 110 strokes/min. -maximum number of inclusions in the clutch to intermittent traffic: 20 on/min. -the largest distance slider from the table: 315 mm -the diameter of the hole in the table: 250/280 mm -the self-alignment capacity of slider in the direction of the axis: 90 mm -thickness: 90 mm -hole diameter: 140 mm -slider surface dimensions: 350 x 315 mm -the diameter of the hole in the slider: 40 mm -the ground clearance between the walls of the body: 380 mm -the width of the t-slots: 22 mm -air pressure: 4.5 at -the engine speed: 1500 rpm. -engine power: 5.5 kW -dimensions (l x w x h): 1550 x 1400 x 2650 mm-weight: ok. 6200 kg -an intermediate table -foot pedal -DTR-technical-functional

CNC Bending Presses EHT EHPS 11-35


CNC press brake EHT EHPS 11-35 was produced in 1992. Characteristic parameters of CNC presses EHT EHPS 110-3550: -CNC control -maximum pressure: 110 t -maximum length of bending: 3550 mm -maximum length of the pitch slider: 200 mm -the distance between the walls of the body: 3050 mm -outreach: 350 mm -maximum speed bending: 13 mm/s -the maximum distance between a slider and a dining table: 460 mm -the minimum distance between a slider and a dining table: 260 mm -speed: 130 mm/sec. -return speed: 138 mm/sec. -the distance between the bumper: 5-1000 mm -bumper speed: 250 mm/sec. -the height of the bumper over the table: 100-200 mm -a safety distance between the tool and support elements: 128 mm -stop time: 79 ms -the road stopping: 11.3 mm -power of the main engine Y1 + Y2:15 kW -the stopping of the bumper X: 3 Nm -maximum pressure in the hydraulic system: 280 bar -maximum air pressure: 6 bar -oil capacity: 390 l -type of oil: HLPD 46 -operating voltage: three-phase 380 V, 50 Hz -control voltage: 24 V -the total connected load: 21.5 kW -the total rated current: 42 Amp. -maximum switching current: 63 Amp. -machine weight: 9500 kg

Radial Drilling Machines WRS 25/08


Radial drilling machine WRS 25 produced in 1992. WRS drills specific data 25/08: -the size of the work surface: 660 x 360 mm -the size of the work surface: 860 x 560 mm -dimensions: 1400 x 700 mm -drilling capacity in steel: 25 mm -drilling in cast iron: 30 mm -spindle speed: 65-2880 RPM -the largest travel: 160 mm -the number of feed motor spindle: 6 -distance between the spindle from the table: 10-500 mm -distance between the spindle from the Base: 780-940 mm -radial drilling range: 315-815 mm -motor power: 3 KW -Cone Morsea: MK3 -dimensions (l x w x h): 1460 x 700 x 2300 mm -weight: 1100 kg

Hob milling machines BARBER COLMAN AEDA 27-7


Hobbes BARBER COLMAN AEDA 27-7 produced in 1989. Milling machine to machine the wheel teeth straight and slanted. Technical data routing, BARBER COLMAN AEDA 27-7: -module: 1 mm-max. module: 10 mm -the maximum diameter of the wheel: 360 mm -distance from the catch of centres: 1000 mm -overall dimensions of the machine (w x l x h): 900 x 2600 x 2200 mm -weight: ok. 4.5 tons

PRESSA PER PRESSOFUSIONE IDRA


PRESSES for DIE CASTING HYDRA Hydra BRAND MODEL OL 220 PRP YEAR 1995 DESCRIPTION Horizontal press for die casting included STP brand charger Datasheet Closing power 2450 KN Max power injection central extraction Power 180 285 KN KN Max height 550 mm minimum height 180 mm moulds molds 500 mm Race racing mobile plan measures Central ejection stroke 100 mm Dimension 765x765 mm Distance plans within the columns 500x500mm Engine power: 22 Kw total weight 10.2 press Ton 1592x5320x2293 h overall dimensions mm for more details and vision of machinery call us at + 39 030 725026 Monday through Friday from 8:30 19:00 13:00 and 14:00 hours at at

Circular Sawing Automatics Elumatec SA73


Automatic saw SA 73/36 Description Suitable for high-volume cutting of aluminium profiles for window manufacturing and industrial applications Material infeed (cycling) protects the surface of the workpiece by means of a single-stage profile lifting system One, two or three-stroke feed can be selected using a selector switch Reliable material feed using two horizontal clamping cylinders Automatic machine shut-down at the end of the profile Pulsed coolant system Equipped with saw blade as standard Technical specifications Cutting range 150 x 110 mm Saw blade diameter 380 mm Saw blade speed 2,800 rpm Power supply 230/400 V, 3~, 50 Hz Power output 3 kW Compressed air supply 7 bar Air consumption per working cycle 19 l without spraying, 31 l with spraying Length 1,500 mm, depth 1,100 mm, height 1,550 mm, weight 290 kg Feed distance per cycle 5 – 250 mm (up to three cycles possible)

Hob milling machines POREBA ZFA 75


POREBA enveloping machine ZFA 75 was produced in 1967 by Mechanical Factory "MUNICH". The machine is designed for the production of gears with straight, oblique teeth and worm gears. During operation without a steady handle, it allows for machining wheels with a maximum diameter of 800 mm, and when working with a steady support, the maximum diameter of the wheel is 450 mm. Technical date: The largest cut-out module: -normally: 6 mm -with reduced accuracy: 8 mm The largest diameter of the gear being machined: -with the support fixed: 450 mm -without a steady: 800 mm The largest diameter of a toothed wheel work with helical teeth: -at a helix angle of 30 °: 500 mm -at a helix angle of 60 °: 190 mm The largest milling length for straight teeth: 275 mm Range of distances between the workpiece the axes and the milling cutter: -the smallest 30 mm -the largest 500 mm Vertical milling cutter: 310 mm The smallest distance from the table surface to the milling cutter axis: 200 mm The largest diameter of the milling cutter: 120 mm Diameter of mandrels for setting the cutters: 22, 27, 32 mm Diameter of the hole on the table: 80 mm The number of spindles of the milling spindle: 7 Range of rotation of the milling spindle: 47.5-192 Vertical cutter range for 1 turn of the workpiece: 0.5-3 mm The range of radial feeds of the milling cutter for 1 turn of the workpiece: 0.1-1 mm The range of axial feeds of the milling cutter for 1 turn of the workpiece: 0.25-1 mm Main engine power: 2.8 kW Machine dimensions: 2395 x 1210 x 1975 mm Milling weight: 3800 kg Equipment: -a set of shift wheels for the guitar -change tires/wheels for the second guitar: 7 pcs. -spindles: 5 items -conical wheels: 2 pcs -claw coupling -tests: 5 items -hook key -DTR-technical and operational documentation It is possible to buy additional equipment of the machine, i.e.: -modular cutters with various modules, from 1-8:100 pieces (additional fee, price: $9990 net, visible in the last two photos)

PRESSA PER PRESSOFUSIONE IDRA


HYDRO PRESS FOR DIE CASTING Hydro BRAND MODEL OL 220 PRP YEAR 1995 Horizontal press for die casting included STP brand charger Datasheet Closing power 2450 KN Max power injection 285 KN Central extraction power 180 KN 550 mm mould height 180 mm mould height Racing measurements Stroke 500 mm Cabinet plan Central ejection stroke 100 mm 765x765 plans size mm Distance within the columns 500x500mm Engine power: 22 Kw Total weight of 10.2 Ton press Overall dimensions 1592x5320x2293 h mm

ISOLA PRESSOFUSIONE ITALPRESSE


ISOLA CASTING ITALPRESSE BRAND Italpresse MODELL OAL300 YEAR 1974 Horizontal press for die casting with charger and Lubricator Datasheet Closing power 350 Ton Max power injection 40 Ton Central extraction power 18 Ton Max height 750 mm moulds Minimum height 250 mm moulds Stroke 130 mm 500 mm stroke central extraction platen 960x960 plans size mm Distance within the columns 580x580 mm motor power 18.5 Kw Printable area max 400 cm2 metal pressure Kg/cm2 845 total weight of 14.8 Tons press overall dimensions 1450x6100x1900 h mm

Two-crank press of single action Voronezh KB3534A (250ton)


Nominal force, kN 2500 Slider stroke, mm 400 Number stroke per minute 25 adjustment mm 260 Distance between table and slider, mm 750 Distance between table and slider, mm 750 Main motor power kW 47 Table size width / length mm 1250/2500 Dimensions of the machine Length Width Height (mm) 4555_2900_5855 Weight kg 50100

Sheet-metal-stamping trimming press Voronezh KV2536,400T


Maximum force ton-force 400 Slider stroke length mm 250 Slider stroke length to lower position mm 12 Slider strokes per minute 25 Number of single turn-on 19 Maximum distance between table and slider (in lower position of slider) mm 510 Adjustment mm 160 The sizes of a under-forginig plate mm 1000 Table overall dimensions: mm - from front to rear 1000 - from left to right 1000 The sizes of an aperture in a table mm 630 Slider overall dimensions mm 800 x 800 window dimensions in cheeks mm 600 Total power of electric motors kW 43,3 Press overall dimensions mm - length 3470 - width 3140 - height 5940 Press weight without hydropneumatic pillow kg 31 400

Eccentric Presses STANKOIMPORT KD 2330


Eccentric press STANKOIMPORT KD 2330 was built in 1980. Characteristics of the press STANKOIMPORT KD 2330: -nominal pressure: 100 t -table dimensions: 850 x 560 mm -adjustable slider stroke: 10-130 mm -the number of jumps the slider: 95/min -adjust the distance between the table and the slider: 10 mm -the maximum distance between the table and the slider in the lower position the slider at the maximum stroke: 400 mm -the distance from the axis of the slider to the press corps: 320 mm -distance from the press table to guides: 550 mm -the distance between the uprights in clearance: 400 mm -the angle of the body: 10 degrees, 20 degrees, 30 degrees -dimensions of the machine: 1745 x 2360 x 3180 mm -weight: 8650 kg

H-Frame Crank Presses PKrR 200/2


Crank press PKrR framework 200/2 pressure 200 tons was built in 1971 by Zamech-. Technical data of the press PKrR 200/2: -nominal pressure: 200 ton-clearance between uprights: 2000 mm-pitch slider: 200 mm-number of jumps: 23, 27, 32 l/min. -distance from the table slider closed (closed is the distance slider from the table in the lower turning position and first engages a): 630 mm-nastwano?? slider: 150 mm-length: 1000 mm-length slider: 900 mm-hole in the table: 1600 x 600 mm-gr ubo??: interface plate 150 mm-width Windows in the rack: 400 mm-the air pressure in the clutch: 3 atn. -odci??aczach air pressure: 5 bar -intake air when jumping individual: 0.035 Nm3/sk. -maximum number of inclusions in the clutch to intermittent traffic: 12 l/min. -main motor power: 22 kW-RPM main motor: 1500 l/min. -engine power to set the slider: 3 kW-engine speed to set the slider: 1500 l/min. -string device, wypych.: 10 t-string device, the power of przytrz: 40 t-string, stroke: 125 mm -maximum air pressure in the device pass design: 6 atn. -the weight of the tool ci?gowego: 2020 kG -the weight of the press without pads: 30580 kG -overall dimensions of the machine (w x l x h): 3100 x 2150 x 5600 mm

Eccentric Presses ZAMECH PMS 160 A


Eccentric press ZAMECH PMS 160 and produced in 1965 by Zamech-. Characteristics of the press PMS 160 and: -nominal pressure: 160 t -table dimensions: 1140 x 760 mm -thickness: 125 mm -the diameter of the hole in the table: 490/450 mm-diameter hole in the plate: 250 mm -diameter of the socket in a slider: 50 mm -the ground clearance between the walls of the body: 840 mm -adjustable slider jump in gran. : 20-140 mm -the nominal quantity: 40 1/min -outreach to table height: 400 mm -the largest distance between the table and the slider, with the largest jump the slider in the upper position and first engages a: 580 mm -the distance between the table and the guides: 585 mm -the self-alignment capacity of slider in the direction of the axis: 120 mm -electric motor: main: 10 kW, for setting the slider: 1.1 kW -the turnover of the main electric motor: 1420 RPM -the power of air pressure ejector 5.4 atm.: 16000 kG -the biggest jump ejector: 75 mm -indicative cooling air flow: 1.3 Nm3/min -the air pressure in the odci??aczach: 4.8 atm. -maximum air pressure in wyrzutniku: 5.7 atm. -nominal air pressure in the clutch: 4.5 atm. -the weight of the ejector: ok. 400 kg -the weight of the press without ejector: ok. 14100 kg -overall dimensions: 2000 x 2325 x 3390 mm

CNC Hydraulic Plate Shear SAFAN HVR 310-8 TS


CNC guillotine shears SAFAN HVR 310-8 TS produced in 1999 year. The price of the machine is a set of knives. Technical data of the guillotine CNC SAFAN HVR 310-8 TS: -maximum sheet thickness: 8 mm -cutting length: 3100 mm -connection power: 15 kw -connecting voltage: 3 x 400 Volt 50 Hz -maximum working pressure: 300 bar -a safety distance: 12 mm -weight: 9200 kg

Transfer Presses ( 2 - 4 Columns) KRUPP PST-A 160


Transfer press KRUPP PST-and 160 built in 1980. Technical data of the press KRUPP PST-and 160: -nominal pressure: 160 tons -cutting force degree 1:400 KN -clamping force between uprights: 1200 KN -the number of stages including the cutting level: 11 -the distance between uprights: 200 mm -pitch slider: 210 mm -drawing depth: 70 mm -the amount of jumping, infinitely adjustable: 15-75/min. -production range jumping from repeatability of its settings: 25-75/min. -number of jumping motion Setup: 15-25/min. -wykorzystywalny resource work per stroke in terms of 25-75 strokes per min.: 20000 J -maximum load single degree: 500 KN -the maximum load of a single degree by using the inserts: 630 KN -the maximum tape width: ok. 340 mm -the maximum cut-out diameter: 120 mm -the minimum cut-out diameter: 30 mm -the distance between uprights: 2450 mm -the height of the built-in tools in the lower position of the slider and its regulations (the space between the table and the imakami of the upper toolbar): 470 mm -the height of the surface transport extrusions over a dining table: 270 mm -height adjustment tool blocks: 40 mm -table clamping surface (width x depth): 2000 x 700 mm -adjustable spacing between the slats podajacymi: 210 +-300 mm -stroke closing slats which indicate for each terminal: 75 mm The progressive press wielooperacyjna KRUPP PST-and 160/11/200/210 is connected and can be checked on the move.

Injection molding machines Engel ES 330H/90V SO-TR


control: EC100 Closing force (t): 90 Mold height min./max.: min 270 Dimensions between posts: 1100 Dimensions of plaque plates Distance. plate: 585 x 340 Worm diameter: 30 Injection volume: 113 Injection pressure: 2180

Eccentric Presses KOSICE LE 160 C


Eccentric press KOSICE LE 160 C was produced in 1981 year in Czechoslovakia by ZTS Kosice. Technical parameters of the KOSICE LE 160 c: -nominal pressure: 160 t -outreach: 355 mm -the self-alignment capacity of slider: 100 mm -adjustable stroke: 20-120 mm -distance slider from the table: 450 mm -the thickness of the intermediate plate: 100 mm -table surface: 995 x 700 mm -hole in the disc table: 290 H8 mm -the number of strokes per minute (continuous operation): 50 -hole in the slider: 50 H8 mm -air consumption: 0.5 Mpa, 28 litres/cycle -demand for power: 11 kW -overall dimensions: (l x w x h): 2310 x 1270 x 2587 mm -weight: kg 10150

Eccentric Presses PLASOMAT PMS 63 MA


Eccentric press PLASOMAT PMS 63 HAS a built in 1989 by the factory Automatic Presses PLASOMAT Warsaw, Poland-Italy. Characteristics of the press PLASOMAT PMS 63MA: -nominal pressure: 63 tons -Board size: 800 x 560 mm -thickness: 90 mm -adjustable pitch slider: 8-110 mm -outreach to table height: 280 mm -the largest distance slider from the table: 315 mm -the diameter of the hole in the table: 280/250 mm -central lubrication system -engine power: 5.5 kW -weight: 5200 kg -dimensions (l x w x h): 1360 x 1530 x 2580 mm

Eccentric Presses PLASOMAT PMS 63 MA


Eccentric press PLASOMAT PMS 63 HAS a built in 1988 by the factory Automatic Presses PLASOMAT Warsaw, Poland-Italy. Characteristics of the press PLASOMAT PMS 63MA: -nominal pressure: 63 tons -adjustable pitch slider: 8-110 mm -outreach to table height: 280 mm -the largest distance slider from the table: 315 mm -Board size: 800x560 mm -thickness: 90 mm -the diameter of the hole in the table: 280/250 mm -engine power: 5.5 kW -central lubrication system -weight: 5200 kg -the press dimensions (l x w x h): 1360 x 1530 x 2580 mm

Eccentric Presses FPA PLASOMAT PMS 63 MA


Eccentric press FPA PLASOMAT PMS 63 HAS built by FPA PLASOMAT Warsaw, Poland-Italy in 1988. FPA presses technical data PLASOMAT PMS 63MA: -nominal pressure: 63 tons -adjustable pitch slider: 8-110 mm -outreach to table height: 280 mm -the largest distance slider from the table: 315 mm -Board size: 800x560 mm -thickness: 90 mm -the diameter of the hole in the table: 280/250 mm -engine power: 5.5 kW -weight: 5200 kg -overall dimensions (l x w x h): 1360 x 1530 x 2580 mm -central lubrication system

CNC Bending Presses LVD PPBL 200/30


Press brake LVD PPBL 200/30 manufactured in 2000. The machine allows you to fold items on length 3100 mm with the force 200 tons. Control and control cabinet have been completely upgraded in November 2017 (on work carried a guarantee). Early upgrades carried out the company HARTMANN from Germany. Technical data of the press LVD PPBL 200/30: -pressure capacity: 200 tons -bending length: 3100 mm -distance: 160 mm -maximum pressure: 300 bar -power: 11 kW -machine weight: 11200 kg -menu machine and manual work: in Polish language -a complete wiring diagram

Eccentric Presses BZMP KE 2130


Eccentric press BZMP KE 2130 100 TONNES built 1986 year. The parameters of the technicznbe press BZMP KE 2130 100 TONNES: -nominal pressure: 100 tons -the maximum slider stroke: 130 mm-minimum pitch slider: 10 mm -the number of jumps the slider continuous: 100/min -the number of strokes a slider sweeps: 45/min -the size of the jump to its lower position, which corresponds to the nominal pressure-continuous movements: 2.5 mm -the size of the jump to its lower position, which corresponds to the nominal pressure-sweeps: 5.0 mm -table dimensions: 950 x 630 mm -the maximum distance between the table and the slider in the bottom position at maximum stroke: 400 mm -the distance between the uprights of the body (clearance): 400 mm -the size of the adjustment of the distance between the table and the slider: 100 mm -main engine power: 9 kW -dimensions: 2660 x 2380 x 970 mm -weight: 9500 kg

Lathe GRAZIANO SAG 210


Center height: 225mm, center distance: 1000mm, swing over bed: 268mm, rotational speed: 45-2400/min, bore: 57mm, cross slide travel: 240mm, top slide travel: 130mm, feed rate: 0.019-0.3mm/U, quill stroke: 200mm, quill diameter: 68mm, length: 2700mm, width: 1400mm, height: 1400mm, weight: 2.3t, when overheated the machine shuts itself down.

Injection molding machines BMB KW 20 PI/1300


Plastic injection molding machine BMB KW 20 PI/1300 produced in the year 2000 in Italy. Characteristics of injection molding machine BMB 1300/20 PI: -distance between columns: 560 mm-distance between columns in the vertical: 510 mm-max opening stroke: 600 mm -maximum weight of injection: ok. 500 g -screw diameter: 55 mm -clamping forces: 2200 kN

Injection Moulding Machine ARBURG ALLROUNDER SELECTA 270 S 250-1


Max. injection pressure: 2210bar, screw diameter: 30mm, max. injection weight: 71g, closing force: 273kN, distance between tie bars: 2700x270mm, daylight: 200mm, max. plate distance: 475mm, control: MIRONIC PLUS, operational hours: ca. 90000h.

Injection Moulding Machine KRAUSS MAFFEI 1000-8100 MC


Max. injection pressure: 1778bar, screw diameter: 105mm, max. injection weight: 4137g, closing force: 10000kN, distance between tie bars: 1400x1120mm, daylight: 700-1200mm, max. plate distance: 2400mm, centering diameter: 2500mm, control: MC-4, operational hours: ca. 80000h, including Robot WITTMANN W643-0216: x-travel: 1200mm, y-travel: 2400mm, z-travel: 3500mm, control: CNC6, weight: 740kg.

lathe CNC EMCOTURN E65


CNC Fanuc Oi / TC Year 2005 Racing in X / Y / Z: 210 / +/- 40/610 mm from bar diameter: 65 mm Swing diameter max .: 500 mm Vaulting on the bench: 610 mm Distance between centers: 682 mm Rapid traverse in X / Y / Z 30/15/30 m / min CHUCK HOME Top speed .: 5000 rev / min Spindle nose: A2-6 Maximum drive power: 22

Press 1222


IDRA DIE CASTING ALUMINUM Hydro BRAND MODEL OL320/ST About horizontal cold Chamber aluminum die casting Press. Are included: Cabinet, fairings, paintwork plc and keyboard, linear charger and Lubricator Jrobi proportional pressure and flow; second and third injection manual phase; pneumatic doors; No radial 3 Datasheet: 650 mm mould height 200 mm mould height Platen stroke 570 mm Central ejection stroke 120 mm 870x870 plans size mm Distance within the columns 570x570 mm Motor power 22 Kw power max Power injection 345 3450 closing Power central extraction KN KN 180 KN total weight 13.5 Ton press Overall dimensions 1905x5940x2588 h mm For more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

issola al 300


ISOLA CASTING ITALPRESSE I MARKED talpresse The MODEL 300 YEAR 1974 About horizontal baler for casting with Loader and Lubricator Datasheet Closing power 350 Ton Max power injection 40 Ton Central extraction power 18 Ton Max height 750 mm moulds Minimum height 250 mm moulds Stroke 130 mm 500 mm stroke central extraction platen 960x960 plans size mm Distance within the columns 580x580 mm motor power 18.5 Kw Printable area max 400 cm2 metal pressure Kg/cm2 845 total weight of 14.8 Tons press overall dimensions 1450x6100x1900 h mm for more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

Tool Milling Machine PECKERMANN Kombi 1300


Max. spindle clamping surface distance: 450mm, x-travel: 1115mm, y-travel: 400mm, z-travel: 430mm, swivelling range: 90°, spindle bore: 27mm, clamping surface: 1500x560mm, number of T-grooves: 7, T-groove width: 18mm, T-groove distance: 70mm.

Manzoni 1222


HYDRO PRESS FOR DIE CASTING Hydro BRAND MODEL OL 220 PRP YEAR 1995 About horizontal baler for die casting included brand charger STP Datasheet Closing power 2450 KN Max power injection 285 KN Central extraction power 180 KN 550 mm mould height 180 mm mould height Racing measurements Stroke 500 mm Cabinet plan Central ejection stroke 100 mm 765x765 plans size mm Distance within the columns 500x500mm Engine power: 22 Kw Total weight of 10.2 Ton press Overall dimensions 1592x5320x2293 h mm For more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

CNC Lathe WABECO CC-D6200 hs


Rotational speed: 50-5000/min, center distance: 600mm, center height: 135mm, max. workpiece diameter: 270mm, 3-jaw lathe chuck diameter: 125mm, main spindle opening: 30mm, number of tool slots: 8.

Vertical turning lathe SEDIN 1516F1 (D1600x1000)


Turning diameter: 1600 mm Table diameter: 1400 mm Max work-piece height: 1000 mm Max table loading: 8000 kg Max horizontal ram travel: 630 mm Max horizontal carriage travel: 975 mm Max vertical ram travel: 700 mm Max vertical carriage travel: 1000 mm No of feed carriages: 16 Carriages feed range: 0,07-12,5 mm/rev Distance between table and ram: 0-1225mm Fast stroke: 2000 mm/min Main motor power: 30 kW Speeds range: 4 - 200 rpm Dimensions: 3190x3360x4100 mm Weight: 19200 kg

Vertical Lathe Double spindle COMEC THOR


CNC Fanuc Max. rotating 380 mm Max. turning length 250 mm Max. turning length 200 mm Spindle distance mm 500 Spindle nose ASA 6 " Chuck diameter 250 mm 100 mm diameter front bearing Spindle speed 4000 mm Spindle motor power kW 9/11 VDI30 Tower - 8 stations 1998

CNC Long Turning Machines NILES 7000 CNC


Height of centres mm 500 Distance between centres mm 7400 Swing over bed mm 1000 Swing over cross slide mm 700 Swing in gap mm 1100 Effective lenght in gap mm 500 Wide of bed mm 740 Spindle nose 11" Spindle speed: 560RPM Spindle bore mm 87 N.2 Plataform diam. mm 1000 Weight Kg.19000 CNC MITSUBISHI 700 M70 N.2 Self centering chuck diam.600 N.1 Self centering chuck diam.420 N.1 Plateau diam.1000 N.1 flange diam.600 N.2 Steady rests diam. 600 N.2 Steady rests diam.370 N.2 Open rests diam.280 N.1 Roller bezel Coolant system with tank

Single Column Eccentric Press STANKOIMPORT KE 2130


Nominal force: 1000kN, stroke: 10-130mm, stroke speed: 45/min, max. table ram distance: 400mm, weight: 9.5t.

Jig Grinding Machine HAUSER 3 SMO 560/400


Table size: 595x320mm, adjustment area: 400x250mm, grinding diameter: 220mm, grinding diameter with intermediate plate: 280mm, includud angle: 12°, vertical sledge stroke: 500mm, grinding motor table passage: 480mm, spindle vertical sledge distance: 310mm, vertical spindle stroke: 3-110mm, stroke speed: 5-330/min, grinding motor speed: 9000-80000/min, length: 1700mm, width: 1500mm, height: 2900mm, weight: 1.8t.

Surface Grinding Machine WMW SFW 315x1500


Swing: 315mm, center height: 165mm, center distance: 1500mm, max. workpiece weight: 300kg, table feed: 0.05-5m/min, rotational speed: 1340-1675/min, power: 7.5kW, length: 4960mm, width: 2000mm, height: 1500mm, weigth: 3.2t.
Find used machinery dealers in your country
