1000 items ordered by
post used machinery
No. Cat. Photo Manufacturer | Model
Type of machinery
Year Price Country Contact
 page 1  > 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
125465503 101

MORI SEIKI MV-45/40 for sale
Milling machine centers


OVERVIEW: Brand: MORI SEIKI Model: MV-45/40 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 1986 Production hours: 28000 Location: Netherlands Origin country ...
used machine

OVERVIEW:
Brand: MORI SEIKI
Model: MV-45/40
Application type: Milling
Machine type: Machining Center
Availability: Immediately
Construction year: 1986
Production hours: 28000
Location: Netherlands
Origin country: Japan

GENERAL DATA:
Measurements width: 3800 mm
Measurements depth: 3500 mm
Measurements height: 3150 mm
Machine weight: 8000 kg

MAIN DRIVE:
Number of spindle: 1
Spindle speed range: 6000 1/min

CONTROL UNIT:
Brand: Fanuc
Model: 11M

MOVEMENT:
X-AXIS movement: 800 mm
Y-AXIS movement: 460 mm
Z-AXIS movement: 510 mm

WORKPIECE:
Workpiece drm: 160 mm
Workpiece weight: 1000 kg

TABLE:
Outer length: 1200 mm
Outer width: 460 mm

TOOLS:
Max weight: 20 kg
Max tool diameter: 95 mm
Max tool length: 300 mm

MEDIA:
Main electronic connection: 380 V
Power consumption: 22 kVA
Chip conveyer: yes
Internal cooling: yes
1986
Price
  NL   request
125460803 102

HARRISON M 450 for sale
Center Lathe


turning diameter over bed: 450 mmturning diameter over slide rest: 280 mmturning length: 1000 mmturning speeds: 40 - 2000 U/mincentre height: 225 mmspindle bore: 67 mmtailstock quill taper MT: 4 MKtotal power requirement ...


turning diameter over bed: 450 mm
turning diameter over slide rest: 280 mm
turning length: 1000 mm
turning speeds: 40 - 2000 U/min
centre height: 225 mm
spindle bore: 67 mm
tailstock quill taper MT: 4 MK
total power requirement: 7,5 kW
weight of the machine ca.: 1,7 t
Dimensions (LxWxH): 2,3 x 1,2 x 1,7 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465425 101

DECKEL DC 45 for sale
Processing Centers


Horizontal machining center cover DC 45 â?¢ n = 6000U/min â?¢ SK 50 â?¢ Internal coolant feed 50 bar â?¢ Auto. Tool changer 160 fold â?¢ 14 pallets 630 500mm  ...
used machine

Horizontal machining center cover DC 45
â?¢ n = 6000U/min
â?¢ SK 50
â?¢ Internal coolant feed 50 bar
â?¢ Auto. Tool changer 160 fold
â?¢ 14 pallets 630 500mm
â?¢ Including tools and recording
â?¢ Fully functional, operational at all times
â?¢ Editing only aluminium and bronze
â?¢ Price negotiable
â?¢ Visit at any time by appointment

Price
    request
125460805 102

GEMA LZ 185 for sale
Center Lathe


turning diameter over bed: 370 mmturning diameter over slide rest: 230 mmturning length: 700 mmturning speeds: 25 - 2000 U/mincentre height: 185 mmspindle bore: 40 mmtailstock quill taper MT: 3 MKtotal power requirement: ...


turning diameter over bed: 370 mm
turning diameter over slide rest: 230 mm
turning length: 700 mm
turning speeds: 25 - 2000 U/min
centre height: 185 mm
spindle bore: 40 mm
tailstock quill taper MT: 3 MK
total power requirement: 3,2 kW
weight of the machine ca.: 1,2 t
Dimensions (LxWxH): 1,85 x 0,8 x 1,5 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465382 101

DMG DECKEL MAHO DMC 50 V for sale
Numerically Controlled Machining Centres


Machining center - vertical DECKEL MAHO DMC 50 V bearing no 1105-01865 category machining center - vertical make DECKEL-MAHO type DMC 50 V year 1995 State second-hand machine control CNC dialog 112 storage France country ...
used machine

Machining center - vertical DECKEL MAHO DMC 50 V bearing no 1105-01865 category machining center - vertical make DECKEL-MAHO type DMC 50 V year 1995 State second-hand machine control CNC dialog 112 storage France country of origin Germany
Delivery time immediately cargo base EX WORK technical details x way 500 mm y way 420 mm z trail 500 mm control dialog 112 table size 1 table: 700 x 400 mm speed range - milling power 0-15000 rpm tool holder SK 40 - Milling spindle 15 kW who kzeugwechsler - places: 30 stations feed range 1-10000 mm / min rapid traverse x and Y-axis 30 m / min rapid traverse Z axis 20 m/min total power 25 kW machine weight 7000 kg space requirement approx. 3400 x 3400 x 2900 mm accessories electronic hand wheel conveyors Centre ralschmierung RS 232 data interface coolant system complete machine documentation work light description with control dialog 112
BEAUTIFUL MACHINE

1995
13,000 €
    request
125460811 102

GEMA LZ 185 for sale
Center Lathe


turning diameter over bed: 370 mmturning diameter over slide rest: 230 mmturning length: 700 mmturning speeds: 25 - 2000 U/mincentre height: 185 mmspindle bore: 40 mmtailstock quill taper MT: 3 MKtotal power requirement: ...


turning diameter over bed: 370 mm
turning diameter over slide rest: 230 mm
turning length: 700 mm
turning speeds: 25 - 2000 U/min
centre height: 185 mm
spindle bore: 40 mm
tailstock quill taper MT: 3 MK
total power requirement: 3,2 kW
weight of the machine ca.: 1,2 t
Dimensions (LxWxH): 1,85 x 0,8 x 1,5 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465282 101

DECKEL MAHO SMC 50 V for sale
Processing Centers


Machining center Manufacturer: Lid MAHO Type: SMC 50 V Year of construction: 1996 Clamping table 700 x 400 Control: CNC 3D path control dialog 112 15000 rpm Magazine 20 tools. Contact person Mr. Muel ...
used machine

Machining center

Manufacturer: Lid MAHO
Type: SMC 50 V
Year of construction: 1996

Clamping table 700 x 400

Control: CNC 3D path control dialog 112

15000 rpm

Magazine 20 tools.

Contact person Mr. Mueller see also our over 200 more deals at.

(Changes and errors in the technical data, information
and prices and subject to prior sale!)
1996
Price
    request
125460772 210

SCM Method K for sale
Window production centre


Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mm In order to sell still in useSCM METHOD K Machining center for windows and doorsTechnical specificationsMax. Working length: 2800 mm(using ...


Tenoning spindle: 1 St.
Number of milling agregates: 5 St.
Spindle diameter: 50 mm
In order to sell still in use

SCM METHOD K Machining center for windows and doors

Technical specifications
Max. Working length: 2800 mm
(using the stops)
minute Workpiece length: 200 mm
(clear pin dimension)
minute Workpiece height: 30 mm
Max. Workpiece height: 140 mm
Tenoning speed: 4/16 m / min
Feed rate: 3-15 m / min

Crosscut saw 4 kW with motor horizontal positioning over free
programmable axis control
Speed 3000 rpm
Saw blade diameter 400 mm, bore 80 mm
Extraction nozzle diameter 120 mm
automatic engine brake

Slotted spindle 7.5 kW with

Spindle diameter 50 mm
Spindle clamping length 620 mm
Spindle stroke under table 575 mm
Speed 3500 rpm
Max. Tool diameter 320 mm
upper bearings
Motorized vertical positioning via freely programmable axis control
automatic counter-timber beam
automatic engine brake
automatic star delta connection
Suction nozzle diameter 2 x 160 mm

1st profile spindle 5.5 kW clockwise and counterclockwise
(Synchronization) with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
automatic engine brake
Extraction nozzle diameter 150 mm

2. Profile spindle 5.5 kW clockwise with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
Extraction nozzle diameter 150 mm
automatic engine brake

Gear milling unit 5.5 kW with
Spindle diameter 50 mm
Spindle clamping length 160 mm
Spindle stroke 100 mm
Horizontal adjustment 60 mm
Speed 6500 rpm.
Tool diameter min./max. 100/200 mm
pneumatic single stroke programmable via control
Timed horizontal feed-in for insert milling for the execution of
non-continuous grooves via CNC control
Extraction nozzle diameter 150 mm
automatic engine brake

Glass saw 2,2 kW with
Saw shaft diameter 25 mm
Saw blade diameter max. 220 mm
Saw shaft clamping length max. 22 mm
Speed 5000 rpm.
Extraction nozzle diameter 50 mm
automatic engine brake

Motorized, height-adjustable roller feed with
closest roll spacing
Motor power 1.1 kW

complete with
-CE Compliance
- Crosscut saw, tenon cutting and slot part horizontally infinitely programmable
- Slot part 620 mm spindle length, anti-clockwise
- Programmable vertical movement via ball screws
- motor-driven tapping table movement
- automatically trailing splitter wood for all slot tool positions
- Workpiece clamping for single / double wood operation with
automatic pressure drop protection
- precise swiveling tap table +/- 0 - 60 °
- Extendable telescopic length stop with automatic
Differential control, working length 2800 mm
- Programmable vertical movement via ball screw
in position 2, 3 and 4
- Horizontal positioning on manually programmable
4-fold revolver to operate from the front of the machine
for positions 3, 4 and 5
- Continuous roller feed, swiveling for light
Tool change, with additional feed roller for
Milling and motorized height adjustment according to scale
- Glass bead saw with pneumatic vertical positioning on manual
adjustable 4-fold revolver,
Forced guidance of the glass retaining strip with non-return valve, use of the
Glass bead saw automatically controlled via cycle
- automatic synchronization - immersion function of the first
Profile spindle for tear-free milling of sash frames,
Horizontal positioning on manually programmable
4-speed turret to be operated from the front of the machine
- extendable support rail for large format sash frames
- Gear milling unit with pneumatic horizontal positioning,
Use of the glass bead cutting saw via automatic cycle of the
machine program
Vertical positioning on manually programmable 4-fold turret
- CNC machine control via programmable logic controllers
electronics (PLC) type CONTROL 20
- Motor protection switches for all motors
- Operating tools, operating instructions
- Weight 3600 Kg

special accessories

Motor amplification 11 kW in Pos. 2, 3, 4

(Technical information according to the manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

3,000 €
    request
125452415 101

DMG DECKEL MAHO DMU 50 EVO for sale
Numerically Controlled Machining Centres


Machining center - universal DMG DECKEL-MAHO DMU 50 EVO / 5-axis bearing no 1105-00930 category machining center - universal make DMG DECKEL-MAHO type DMU 50 EVO / 5 axes built in 2001 State second-hand machine control C ...
used machine

Machining center - universal DMG DECKEL-MAHO DMU 50 EVO / 5-axis bearing no 1105-00930 category machining center - universal make DMG DECKEL-MAHO type DMU 50 EVO / 5 axes built in 2001 State second-hand machine control CNC HEIDENHAIN TNC 430 Vidia RT France country of origin Germany delivery immediately cargo base EX WORK technical details x way 500 mm y way 420 mm z-way 380 mm control HEIDENHAIN TNC 430 spindle taper SK 40 speed 18,000 rpm spindle motor 15 kW rapid 50 m / min table on clamping area 500 diameter. x 380 mm feed range up to 20 000 mm / min tool changer 32 x total power consumption 38 kVA machine weight approx. 5.9 t description - CNC - screen control HEIDENHAIN TNC 430 - 5-axis machine with B + C - axis
-Spindle: 19 500 h - a power: 88 000 h - machine documents
2001
59,000 €
    request
125460774 210

WEINIG Unicontrol 6 CNC Spindeln for sale
Window production centre


Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mmweight: 4300 kgWeinig Unicontrol 6 with CNC-spindle with full options/features!Cut-off saw-----------------motor: 3 KWspindle diameter 40 mm ...


Tenoning spindle: 1 St.
Number of milling agregates: 5 St.
Spindle diameter: 50 mm
weight: 4300 kg
Weinig Unicontrol 6 with CNC-spindle with full options/features!

Cut-off saw
-----------------
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 2.800 Upm
tool diameter max.: 400 mm
horizontal adjsutment variable by control

length stop CNC controlled 3500 mm
------------------------------------------------------------

Tenoning spindle
---------------------------------
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 3.500 Upm
tool diameter max.: 320 mm
Usable length of spindle 320 mm
Adjjustment by CNC-axis axial variable max. 240 mm for IV 68-92
adjustment speed approx. 50 mm/sek.
Number of tool postion variable because of CNC axis

1. profiling spindle (turning direction in both directions)
--------------------
Clockwise running for rip-off free stormproofing
Switsch for turning in normal direction for normal milling
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 6.000 Upm
tool diameter max.: 232 mm
tool zero cycle 112 to 140 mm
Usable length of spindle 120 mm
Number of tool positions

2. Profilspindel
--------------------
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 6.000 Upm
Max. tool diameter with zero cycle 112 mm: 210 mm
Max. tool diameter with zero cycle 140 mm: 232 mm
usable spindle length: 320 mm
Adjjustment by CNC-axis axial variable max. 240 mm for IV 68-92
adjustment speed approx. 50 mm/sek.
Number of tool postion variable because of CNC axis

3. spindle: grooving aggregate from top, horizonal and vertical clocked
------------------------------------------------------------------
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 5850 Upm
adjustment way axial: 30 mm
adjustment way radial: 125 mm

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

4. profiling spindle
--------------------
profiling spindle vertical right
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 5850 Upm
tool diameter : 210 mm
usable length 160 mm, 3 tools
adjustment way radial: 100 mm
adjustment way axial: 115 mm

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

5. spindle: groowing aggregate from bottom side
--------------------

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

More features:

- equipment for stormproofing of presses sashes
- Automatic turnng of the work pieces with lammella conveyour
- PC-control / NEXUS:
- laser lighter for cut-off saw
- studio window equipment (not straight windows)
- double piece package
- bars support in profiling unit
- carriage for profiling small sashes smaller 500 mm

Option:
LEITZ IV 78/90 Holz und Holz-Alu

(techncial details according to manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125452409 101

DMG DECKEL MAHO DMU 50 for sale
Numerically Controlled Machining Centres


Machining center - universal lid MAHO DMG DMU 50 5-axis 3 + 2 bearing no 1105-00660 category machining center - universal make lid MAHO DMG type DMU 50 5-axis 3 + 2 year 2005 State second-hand machine control CNC HEIDENH ...
used machine

Machining center - universal lid MAHO DMG DMU 50 5-axis 3 + 2 bearing no 1105-00660 category machining center - universal make lid MAHO DMG type DMU 50 5-axis 3 + 2 year 2005 State second-hand machine control CNC HEIDENHAIN ITNC 530
Storage location France country of origin Germany delivery immediately cargo base EX WORK technical details x way 500 mm y way 420 mm z-way 380 mm control HEIDENHAIN ITNC 530
Recording SK 40 10000 rpm 1/min table surface 500 X 380 MM mm description HEINDENHAIN ITNC 530
Controlled NC round swivel table, 2 axle coolant system,
Full cabin,
10000 RPM
Magazine 16 professional SK 40

2005
55,000 €
    request
125460776 210

WEINIG Unicontrol 12 CNC - Video - for sale
Window production centre


Tenoning spindle: 2 St.Number of milling agregates: 10 St.Spindle diameter: 50 mm! MACHINE CAN BE INSPECTED DURING PRODUCTION Machine for sale in customer orders !# 6192 Weinig Unicontrol 12 CNC, with 2 tenoning spindle ...


Tenoning spindle: 2 St.
Number of milling agregates: 10 St.
Spindle diameter: 50 mm
! MACHINE CAN BE INSPECTED DURING PRODUCTION !

! Machine for sale in customer orders !

# 6192 Weinig Unicontrol 12 CNC, with 2 tenoning spindles and Vario table
..

Specifications Summary
(Possibly more included equpment please inquire)
..


Cut-off saw
..
cut-off saw electronically, horizontally adjustable: NC axis
Number of tools: 1 pcs.
Spindle speed: 3000-6000 r / min
Spindle diameter: 40 mm
Tool clamping length: 13 mm
Tool diameter max .: 400 mm
Motor power: 3 kW
Alignment laser for detecting the cut
Displacement axial: NC-axis integrated into control
Displacement axial: 150 mm

Aggregate for edge rounding of the bottom
..
Axial adjustment along with Ablängsäge
Spindle speed: 9000 U / min
Spindle diameter: 20 mm
Tool clamping length: 25 mm
Tool diameter max .: 130 mm
Motor power: 3 kW

Length stop CNC controlled
..
Length 3500 mm
Incl. Positioned cut-off saw integrated into control

1st tenoning spindle
..
Number of tools: variable, CNC-axis
Spindle length: 640 mm
Spindle stroke vertical: variable, CNC-axis
Spindle speed: 2800 U / min
Spindle diameter: 50 mm
Tool diameter max .: 380 mm
Engine power: 15 kW
With hydraulic tensioned outboard bearing
Complete counterprofile: Complete spindle length is countered


2. tenoning spindle
..
Number of tools: variable, CNC-axis
Spindle length: 640 mm
Spindle stroke vertical: variable, CNC-axis
Spindle speed: 2800 U / min
Spindle diameter: 50 mm
Tool diameter max .: 380 mm
Engine power: 15 kW
With hydraulic tensioned outboard bearing
Complete counterprofile: Complete spindle length is countered


Vario table with horizontal NC-axis


1. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 7000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis

2. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 7000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis

Grooving aggregate from above - before the final profile spindle
..
Position: horizontal top
Spindle speed: 9000 U / min
Spindle diameter: 40 mm
Spindle length: 40 mm
Engine power: 3.7 kW
Displacement axial: 30mm
Displacement radial: 125 mm
Radial clock to 8 positions by pneumatic gun
Axial adjustment with NC-axis


3. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 6000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis


Profiling spindle - fitting spindle - at the machine end
..
Position: vertical right up
Spindle length: 160 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 210 mm
Engine power: 3.7 kW
Displacement axial: 115 mm
Displacement radial: 100 mm
Radial adjustment: CNC axis
Axial adjustment: CNC axis

grooving aggregate from top - in addition stand
..
Position: vertical right
Spindle length: 40 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 180 mm
Motor power: 3 kW
Displacement axial: 100 mm
Displacement radial: 80 mm
Radial clocked to 8 positions by pneumatic gun
Axial clocked to 8 positions by pneumatic gun

Grooving aggregate from bottom side - in addition stand
..
Position: horizontal bottom
Spindle length: 125 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 200 mm
Motor power: 3 kW
Displacement axial: 100 mm
Displacement radial: 100 mm
Radial adjustment infinitely variable NC axis
Axial clocked to 8 positions by pneumatic gun


Other features
..

Online-capable
equipment for stormproofing of already pressed sashes.
That means on the machine you can do the outside profiles on single pieces or
in pressed condition
Double piece package
Return conveyor for 1-man operation: turning system with collet
Studio window equipment
Electronic angle display for angular windows
Control: PC-Nexus
NC-axis for feed height adjustment
2 axially clocked feed rollers opposite profile spindle for manufacturing
narrow and short parts
Rung leadership and shoot Supports bar
pressure lineal from side is divided in sections
Automatic central lubrication
Vario table with horizontal NC-axis


Option:
used Oertli tools in different systems for single part production (that means
customer did the outide profile of the sahes on the single piece)


techn. details according to manufacturer - without guarantee!



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125451800 101

MORI SEIKI DMG NVX 5100 II for sale
Numerically Controlled Machining Centres


Machining center - vertical MORI SEIKI NVX 5100 5 axis bearing no 1105-02401 category machining center - vertical make MORI SEIKI type NVX 5100 5 axis year 2013 State second-hand machine control CNC MSX 853 storage Franc ...
used machine

Machining center - vertical MORI SEIKI NVX 5100 5 axis bearing no 1105-02401 category machining center - vertical make MORI SEIKI type NVX 5100 5 axis year 2013 State second-hand machine control CNC MSX 853 storage France origin JAPA n delivery after agreement cargo base EX WORK technical details of travel: X 1050 Y 530 Z 510 mm control: MSX 853 tool changer: 40 x with BT 40 x way 1050 mm control MSX 853 z route 510 mm y route 530 mm table size 1350 X 600 mm speed range 120 00 RPM tool holder BT 40 power - Milling spindle of 15/11 kW tool changer - places: 40 stations tool change time 1 sec feed range 30 mm / min rapid traverse - longitudinal/transverse/vertical 30 m / min total power consumption 35 kW machine weight approx. 7200 kg Raumbedar f approx. 3800 x 2600 x 2700 mm accessories complete machine documentation coolant system electronic hand wheel lubrication RS 232 data interface chip conveyor 1 unit description high MACHINING Center
WITH fanuc mori msx 853 IKZ HOCH DRuck through spindle 15 bars
SPAENEFOERDRER
40 SPECIALIST BT 40 MAGAZINE
2900 SPINDLE HOURS

4/5-AXIS DIVIDING HEAD



2013
85,000 €
    request
125460495 205

HOMAG OPTIMAT BAZ 211/VENTURE 20 for sale
CNC Machining Centre


serial number: 0-201-21-6004 Weight approx.: 6000 kgcontrol: Power Control PC 85 Dimensions (l x w x h) approx.: 12000 x 2500 x 2400 mmc-axis: mit Aggregateschnittstelle setting measure approx (l x w x h): 6000 x 4250  ...
used machine

serial number: 0-201-21-6004
Weight approx.: 6000 kg
control: Power Control PC 85
Dimensions (l x w x h) approx.: 12000 x 2500 x 2400 mm
c-axis: mit Aggregateschnittstelle
setting measure approx (l x w x h): 6000 x 4250 x 2900 mm
software: WOODWOP inkl. Postprozessor
working length x-axis: 3050 mm
working width y-axis: 1220 mm
working height y-axis: bei Standardspanner 60 mm
main spindle: HSK F63 11 kW
tool changer: 12 fach
vacuum pump: Wassering 66 cbm/h
drilling head vertical x-axis: 11 piece
drilling head vertical y-axis: 7 piece
drilling head horizontal x-axis: 2 piece
drilling head horizontal y-axis: 2 piece
edge gluing unit: no / nein
path-feed rate max. X-axis: 80 m/min
path-feed rate max. Y-axis: 80 m/min
path-feed rate max. Z-axis: 30 m/min
Description: Machine number 0-201-21-6004
2007
used machinery auction RESALE 26,000 €
  DE   request
125451797 101

DMG DMU 80 monoblock for sale
Vertical Processing Centers


Producer . DMG Year manufacture/Year overhaul . 2006 Control system Heidenhain . TNC 530 Clamping area of table . 1270x700 mm Travel X-axis . 980 mm Travel Y-axis . 630 mm Travel Z-axis . 630 mm Spindle speed .  ...
used machine

Producer . DMG
Year manufacture/Year overhaul . 2006

Control system Heidenhain . TNC 530
Clamping area of table . 1270x700 mm
Travel X-axis . 980 mm
Travel Y-axis . 630 mm
Travel Z-axis . 630 mm
Spindle speed . 20 - 12000 /min.
Number of driven axes . 5
Cooling through spindle
Pressure of cooling . 40 bar
Spindle taper . SK 40 .
Tool magazine
Number of positions in magazine . 32
Max. load of table . 650 kg

Control panel with handwheel, 3D probe, paper filtration. possible to test under power.
2006
Price
  CZ   request
125460508 205

FORMAT 4 profit H350 16.50 for sale
5-Axis Machining Centre


Weight approx.: 9000 kgDimensions (l x w x h) approx.: 8590 x 4060 x 2600 mmsoftware: Woodflash working length x-axis: 5000 mmworking width y-axis: 1500 mmworking height y-axis: 150 mmmain spindle: 12 kWtool changer: 18- ...
used machine

Weight approx.: 9000 kg
Dimensions (l x w x h) approx.: 8590 x 4060 x 2600 mm
software: Woodflash
working length x-axis: 5000 mm
working width y-axis: 1500 mm
working height y-axis: 150 mm
main spindle: 12 kW
tool changer: 18-fach / 18-fold + 10-fach / 10-fold
vacuum pump: 90/108 cbm/h
drilling head vertical x-axis: 7 piece
drilling head vertical y-axis: 5 piece
drilling head horizontal x-axis: 4 piece
drilling head horizontal y-axis: 2 piece
saw unit: ja / yes in X
changing unit: ja / yes
edge gluing unit: nein / no
travelling way X-axis: 6000 mm
travelling way Y-axis: 1970 mm
travelling way Z-axis: 455 mm
Description: A young gantry-style CNC machining center with double-sided digital driving portal.

5-axis gimbal electric spindle 12 kW (S6) HSK F63, 24,000 rpm
Automatic central lubrication

Drilling head DH 18 6H 1S: Vertical 12 spindles: 7 spindles in the X direction and 5 spindles in Y-direction.
Horizontal 6 spindles:
4 spindles in the X direction and 2 spindles in Y-direction.
Forward stroke = 70 mm, max. Drill length = 70 mm and shank D = 10 mm.
All spindles are individually driven and available.
1 grooving saw - in X- Direction:
Max. Saw blade diameter 120 mm, max. Blade thickness 5 mm, max. number of revolutions infinitely variable up to 7500 rpm.

8 workpiece supports:
with front and rear stop row. Vacuum dual-circuit system with Suction cup height 100 mm.

Positioning display of the workpiece supports and vacuum cups in the CNC board.
The exact position of the vacuum cups on the workpiece supports is indicated by laser.

Hand-held terminal for controlling the axle speed incl. Emergency stop switch

Safety system with photocell on the front

18-fold plate changer traveling in X:
Max. Tool diameter 250 mm
Max. Tool length 280 mm

automatic tool length measuring system
2017
used machinery auction RESALE 27,500 €
  CH   request
125437036 101

CHIRON FZ-16 FZ16 for sale
Numerically Controlled Machining Centres


Single-spindle machining centre CNC milling machining centre Chiron FZ-16 Built in 1988 Sinumerik system 3 control Chip conveyor Dimensions Lxwxh 1.9 x 2.9 x 2.7 m Weight 3500 kg The machine is still under pow ...
used machine

Single-spindle machining centre CNC milling machining centre
Chiron FZ-16
Built in 1988
Sinumerik system 3 control
Chip conveyor

Dimensions Lxwxh 1.9 x 2.9 x 2.7 m
Weight 3500 kg

The machine is still under power and is fully functional. A visit is always possible in the vicinity of Berlin.

Disassembly and transport is at the expense and at the risk of the purchaser. A professional machine carrier can be conveyed if required.
1988
5,000 €
    request
125459113 104

KELLENBERGER UR 175 x 1000 KEL-VARIA for sale
Cylindrical Grinding Machine - Universal


grinding diameter: mmgrinding length: mmcentre height:175 mmtotal power requirement: kWweight of the machine ca.:6 tdimensions of the machine ca.:4,84 x 2,26 x 2,12 m
used machine

grinding diameter: mm
grinding length: mm
centre height:175 mm
total power requirement: kW
weight of the machine ca.:6 t
dimensions of the machine ca.:4,84 x 2,26 x 2,12 m

1998
Price
    request
125437022 101

MATSUURA H 300 PLUS for sale
Numerically Controlled Machining Centres


Machining center - horizontal MATSUURA H PLUS 300 bearing no 1105-02399 category machining center - horizontal make MATSUURA type H PLUS 300 built in 2005 State second-hand machine control CNC storage France country of o ...
used machine

Machining center - horizontal MATSUURA H PLUS 300 bearing no 1105-02399 category machining center - horizontal make MATSUURA type H PLUS 300 built in 2005 State second-hand machine control CNC storage France country of origin JAPAN delivery time s ofort cargo basis FCA further details on request technical details x way 500 mm y way 560 mm z trail 500 mm CNC FANUC 30 I - workspace-FRÃ?SEN-- traverse path X-axis 500 mm - travel Y-axis 560 m m travel z 500 mm table 300 X 300 - clamping surface (left-right) 300 mm - clamping surface (front rear) 300 mm - workpiece weight (max.) 400 kg spindle / head - speed range from 60 rpm - speed range up to 15 RPM - stem diameter 70 mm - on employing ISO BT 40 - torque (max) 146 nm axle drives - feed x 30000 mm/min - feed x up to 30000 mm / min - feed of y of 30000 mm / min - feed y up to 30000 mm / min - feed of z of 1 mm / min - feed z up to 30000 mm/min - rapid traverse x 60000 mm/min - rapid traverse y 60000 mm/min - rapid traverse z 60000 mm / min tool magazine - number of tool positions 51 - tool weight max. 10 kg - tool change time 1.3 s electrical connection data - power supply 42 kVA â connection voltage 400 V mains frequency 50 Hz dimensions / weights - space length 4344 mm - 2.5 mm wide - space total height 2680 mm - weight approx. 8000 kg optional equipment drilling/milling - chip conveyors yes description technical description:
2 compartment pallets.
4th axis. X 360000°
FANUC 30 I

State Description:

This machine can be seen under power.

2005
53,000 €
    request
125447269 102

RAVENSBURG for sale
Sliding bed lathe


swing diameter: 1420 mmfaceplate: 1000 mmturning diameter over bed: 1000 mmturning diameter over slide: 700 mmturning dia. in gap: 1420 mmcentre distance: 2000 mmcentre distance: 3000 mmturning speeds: 1,4-380 U/minspind ...


swing diameter: 1420 mm
faceplate: 1000 mm
turning diameter over bed: 1000 mm
turning diameter over slide: 700 mm
turning dia. in gap: 1420 mm
centre distance: 2000 mm
centre distance: 3000 mm
turning speeds: 1,4-380 U/min
spindle passage: 85 mm
total power requirement: kW
weight of the machine ca.: t
dimensions of the machine ca.: m



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
More models (2 or more machines):
(17)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold

Sold machinery

Transfer Presses ( 2 - 4 Columns) ERFURT PTRZSST 210


Transfer press ERFURT PTRZSST 210 was built in the year 1991 in Germany. The progressive press ERFURT PTRZSST 210/11/280-technical parameters: -maximum pressure: 160 tons -the number of jumps: 20-40 min-1 -the maximum stroke of the upper table: 400 mm -adjustable handles tools: 63 mm -working capacity per stroke: 40 kNm -depth of draw: 125 mm -the strength of the ejector: 50 tons -ejector stroke: 80 mm -adjust the ejector: 63 mm -the range controlled by the ejector: 63 mm -distance between columns: 3500 mm -the distance between the centres of the utility: 280 -number of posts: 10 -overall dimensions: 6.6 x 2 m -weight: 80000 kg

Milling machining centres RIS-INGOLD Rismatic 151G-12


OVERVIEW: Brand: RIS-INGOLD Model: Rismatic 151G-12 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 1992 Production hours: 52000 Location: Germany Origin country: Switzerland CONTROL UNIT: Brand: Rismat TURRET: Number of turrets: 12 processing stations TOOLS: Max tool diameter: 1.5 - 18 mm Max tool length: 50 mm ADDITIONAL EQUIPMENT: 1 - 12x Processing station tools

Milling machining centres RIS-INGOLD Rismatic 151LN-6


OVERVIEW: Brand: RIS Model: Rismatic 151LN-6 Application type: Milling Machine type: Revolving Index Machine Availability: Immediately Construction year: 1995 Production hours: 88521 Location: Germany Origin country: Switzerland CONTROL UNIT: Brand: Rismat TURRET: Number of turrets: 6 TOOLS: Max tool diameter: 1,5 - 18 mm Max tool length: 50 mm ADDITIONAL EQUIPMENT: 1 - 6x Processing station tools

Milling machining centres RIS-INGOLD Rismatic 151LN-6


OVERVIEW: Brand: RIS Model: Rismatic 151LN-6 Application type: Milling Machine type: Revolving Index Machine Availability: Immediately Construction year: 1997 Production hours: 88000 Location: Germany Origin country: Switzerland CONTROL UNIT: Brand: Rismat TURRET: Number of turrets: 6 TOOLS: Max tool diameter: 1,5 - 18 mm Max tool length: 50 mm ADDITIONAL EQUIPMENT: 1 - 6x Processing station tools

Milling machining centres RIS-INGOLD Rismatic 151G-12


OVERVIEW: Brand: RIS Model: Rismatic-151G 12 Application type: Milling Machine type: Revolving Index Machine Availability: Immediately Construction year: 1982 Production hours: 56000 Location: Germany Origin country: Switzerland TURRET: Number of turrets: 12 TOOLS: Max tool diameter: 1,5 - 15 mm Max tool length: 50 mm ADDITIONAL EQUIPMENT: 1 - 12x Processing station tools

Hob milling machines BARBER COLMAN AEDA 27-7


Hobbes BARBER COLMAN AEDA 27-7 produced in 1989. Milling machine to machine the wheel teeth straight and slanted. Technical data routing, BARBER COLMAN AEDA 27-7: -module: 1 mm-max. module: 10 mm -the maximum diameter of the wheel: 360 mm -distance from the catch of centres: 1000 mm -overall dimensions of the machine (w x l x h): 900 x 2600 x 2200 mm -weight: ok. 4.5 tons

Vertical Numerically Controlled Machining Centres BMEI BV100


Vertical machining center BMEI BV100 built in 2007 year. Technical parameters of the moulder Center BMEI BV 100: -CNC control: FANUC Series Oi-MC

CNC Milling Machines Elumatec 2009


Profile machining centre SBZ 130 eluCam Description 3-axis profile machining centre Designed for economical and efficient machining of aluminium, steel and stainless steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces The on-board turret head ensures that tool changing times are kept very short, thereby optimising machining cycles The turret head can be equipped with eight tools or angle routing heads Automatic clamping adjustment enables the machine to position the material clamps 3-axis controller The tool spindle is designed as an additional axis Network connection Technical specifications Traverse path X-axis, 4,200 mm, 7,200 mm, 8,500 mm, 10,200 mm, 11,500 mm (additional lengths on request) Vmax. 60 m/min. Traverse path Y-axis, 485 mm, Vmax. 30 m/min. Traverse path Z-axis, 340 mm, Vmax. 30 m/min. Max. spindle speed 6,000 rpm, 18,000 rpm with high-speed spindle Spindle power output 5.5 kW Tool changer for eight tools on a turret head Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 35 A Air consumption per minute 100 l with spraying Machining length SBZ 130 – 7.2 m Max. machining length with profile end machining, 7,080 mm Max. machining length without profile end machining, 7,200 mm

Elumatec 2011


Profile machining centre SBZ 140 Description 4-axis profile machining centre Designed for economical and efficient machining of aluminium and thin-walled steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces Machining with all tools at angles continuously adjustable from 0° - 180° The on-board tool magazine ensures that tool changing times are kept short, thereby optimising machining cycles The magazine can be equipped with eight tools A rotating angle head with two different tools is available for double-bar and end machining (0°?-?90°?-?180°?-?270°) (option) Two separate working zones enable machining in shuttle operation (option) 4-axis controller 15" colour display, USB ports and network connection Windows operating system Technical specifications Traverse path X-axis, 4,200 mm, 6,400 mm, 7,600 mm, 9,700 mm (additional lengths on request) Vmax. 65 m/min. Traverse path Y-axis, 850 mm, Vmax. 60 m/min. Traverse path Z-axis, 650 mm, Vmax. 60 m/min. Pivoting angle A-axis, 0° - 180°; freely programmable in 1/10° steps Max. spindle speed 24,000 rpm Spindle power output 11 kW, S1 Tool changer for eight tools, additional tool positions on request Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 63 A Air consumption per minute 180 l with spraying Machining length SBZ 140 - 9.7 m Max. machining length with profile end machining, 9,580 mm Max. machining length without profile end machining, 9,700 mm MACHINE IS PERFECT CONDITION. SET UP TIME IS END OF 2012. NOT USED SO MUCH AND FULL FUNTIONALITY.

CNC Milling Machines INFOTEC 3121 PRO


CNC milling-milling plotter INFOTEC 3121 PRO was built in the year 2016. Plotter is designed for 2D and 3D milling materials that lend themselves to machining. These could be e.g.: composites, pleksa, dibond, tubond, PVC, ABS, teflon, nylon, resin, PRO LAB, korian, aluminum, brass, bronze, steel construction (engraving), mdf, hdf, plywood, particle board, solid wood and other materials like wood. Technical data for CNC milling machines INFOTEC 3121 PRO: -dimensions of the working field of machinery gave the X and Y axis: 2100 x 3100 mm jump in the Z axis: 500 mm -the speed of the machine is X, Y, Z: 60, 60, 12 m/min. -overall dimensions: 4280 x 2900 x 3500 mm -weight: 3300 kg Milling Centre InfoTEC 3121 Professional-sample application: -cieci? of furniture panels -production of furniture fronts -production of furniture -production of façade -aluminium profiles

Numerically Controlled Machining Centres MORBIDELLI M100


Full equiped demo 5 axis CNC working center for drilling, routing and cutting. - year of production 2018 - boring unit 31 borers - 5 axis agregate 10 kW - HSK F63 max. 24.000 r.p.m. - Xilog Maestro software - PRO-SPACE SAFETY SYSTEM - working dimensions 3110x1620x180 mm - Z axis hood - 560 mm, clearance 180 mm - TECpad remote control - 2 pc tool changer, TBR11 linear + fast 14 beside motor - total 25 - 4 lifting assistance device - pods 145x145 12 pc - rotating pods 145x55 mm 6 pc - vacum pump becker 250 m3/h Machine has been used around 20 working hour.VERY GOOD PRICE FOR DEMO MACHINE!

Vertical Numerically Controlled Machining Centres Dahlih DL-MCV 1020 BA


Make: Dahlih Model: DL-MCV 1020 BA Vertical Machining Centre Year: 2006 Condition: Used Machine type: Other Location of machine: UK Machine Details MAKE DAHLIH MODEL DL-MCV 1020 BA YEAR 2006 CONTROL FANUC 0i MC TABLE SIZE 1250 mm x 660 mm TRAVERSES X: 1020 mm Y: 550mm Z: 560 mm RANGE OF SPINDLE SPEEDS Upto 8000 RPM ATC 24 STATIONS SPINDLE TAPER BT 40 PLUS TWIN SCREW CONVEYORS COOLANT TRAY MACHINE MANUALS PRICE INCLUDES LOADING!

Universal grinding machines KOMMUNAR 3Y131 (3U131)


Universal grinder for shafts and bores KOMMUNAR 3Y131 (3U131) produced in 1977 year in the Soviet Union. The machine is designed for external and internal grinding of cylindrical surface, and the surface of the flat flange, conical shaped. Grinder allows external grinding machines with automatic grinding wheel, on the headland of the table or a hand-fed and sanding with manual feed. Universal 3Y131 Sanders-specific data: -the maximum diameter of workpiece: 280 mm -maximum length of workpiece: 710 mm -the maximum diameter of workpiece in podtrzymce: 60 mm -height of tusks: 185 mm -maximum weight of workpiece: 55 kg -the largest grinding wheel diameter: 600 mm -rotation speed spindle grinding wheel diameter: 600 Prov 1111 Rev/min -the maximum angle of rotation of the spindle head: 30 degrees -the maximum diameter of the cut: 100 mm -maximum length of cut: 125 mm -spindle speed: 16900 RPM. -the size of the sanding spindle head stroke after bolt: 290 mm -time supply fast grinding wheel: 2 s -the size of the feeding speed, spindle head szlifirskiego from hydraulic drive: 50 mm -feed for one turn of the wheel: 0.5 mm -the value of the plot of limbusa feed precision: 0.001 mm -the value of the parcel for the diameter transverse feed limbusa: 0.005 mm -periodic feed grinding spindle head (headland of the table): 0,0025 – 0,025 mm -fast speed adjusting sanding spindle head: 240 mm/min -the amount of speed of rotation of the product: smooth, bezskokowa speed control -speed range: 40-327 RPM -angle of rotation: 0-90 degrees -dimensions of centres: SM4 -the weight of the grinder with accessories: 6200 kg -size grinding machines (at the extreme position of the moving parts): 5620 x 2585 x 1982 mm

CNC Milling Centers SW BA 25


The Centre of the vertical-spindle machining drilling mill SW BA 25 built in 1997. Technical data SW Center BA 25: -CNC control: SINUMERIK 840 SW3 -tool Magazine: 2 x 36 frames SK 40

Numerically Controlled Machining Centres BIESSE ROVER C6.65R


Machining centre Biesse Modello Rover C6.65 R Software BIESSE WORKS Working field X mm 6200 Working field Y mm 1535 Working field Z mm 250 Work table with automatic adjustment of bars supports and sucker holder carriages 08 working areas 10 bar supports with 4 sucker holder carriages 40 Uniclamp sucker holder carriages Suction cups included: 06 of mm 140x75 20 of mm 140x140 10 of mm 140x55 18 Fittings blocks 01 Electro-spindle at 4 axels of 12 kW 01 boring head 22 spindles composed by 13 vertical spindle + horizontal spindle + 1 blade 03 Multi-function heads composed by: 01 Saw blade unit diameter mm 300 01 Boring unit at 6 counterposed bits 01 Milling unit at 2 exits Automatic chain Tool change at 22 positions installed on the machine Depression plant with vacuum pump of 250 m3/h Automatic centralized lubrication Shaving evacuation belt

Laser Cutting Centres FIBER KIMLA LF 2060


Laser FIBER KIMLA LF 2060 6 KW was produced in the year 2016. Technical parameters of KIMLA LF 2060: -supply voltage: 400 V -maximum power: 17000 in -the range of wavelengths and the invisible radiation: 900-1200 nm -power laser sources of radiation an invisible: 6000 in -the range of wavelength of the visible light: 700 nm -laser power visible light: 1 mW working table area: X-2000, Y-6000 mm -minimum pressure: 10 bar -minimum of nitrogen pressure: 30 bar -the minimum air pressure: 7 bar -weight: 18000 kg

Grinding Centres Erwin Junker BUAJ 30 CNC


Max. grinding diameter: 290 mm Max. grinding length: 800 mm Max. workpiece weight: 120 kg Control system: true Fanuc Control System: Internal grinding equipment: true Max. grinding wheel diameter: 400 mm Max. Cut-off diameter: 75 mm Main engine power: 7.5 kW Machine dimensions l x h x h: 3000 x 1850 x 1800 mm Machine weight: 2800 kg ?ídící systém Fanuc

CNC Long Turning Machines NILES 7000 CNC


Height of centres mm 500 Distance between centres mm 7400 Swing over bed mm 1000 Swing over cross slide mm 700 Swing in gap mm 1100 Effective lenght in gap mm 500 Wide of bed mm 740 Spindle nose 11" Spindle speed: 560RPM Spindle bore mm 87 N.2 Plataform diam. mm 1000 Weight Kg.19000 CNC MITSUBISHI 700 M70 N.2 Self centering chuck diam.600 N.1 Self centering chuck diam.420 N.1 Plateau diam.1000 N.1 flange diam.600 N.2 Steady rests diam. 600 N.2 Steady rests diam.370 N.2 Open rests diam.280 N.1 Roller bezel Coolant system with tank

POREBA TCF 200


CNC Horizontal Lathe POREBA Manufacturer: POREBA Model TCF 200 Technical datails: Swing over bed: 2000 mm Swing over carriage: 1680 mm Max.distance between centres: 10000 mm Centers’ height: 1000 mm Max. weight of workpiece in centers: 30000 kg Spindle drive motor power: 75 kW Headstock: spindle clearance: 105mm Chuck wheel diameter: 1600 mm Max. diameter of clamping in jaws: 1400 mm Min. diameter of clamping in jaws: 250 mm Bed: Bed width on the guides height: 1500 mm Bed height: 600 mm Carriage: Guides length of longitudinal carriage: 1400 mm Transversal carriage travelling: 500 mm Longitudinal feed range regulated stepless: 0,1 – 400mm / min Travelling feed range regulated stepless: 0,1 – 200 mm / min Longitudinal carriage skip travelling: 4000 mm / min Transversal carriage skip travelling: 2000 mm / min Longitudinal carriage torgue: 115 Nm Transversal carriage torgue: 65 Nm Tailstock: Pinion diameter: 280 mm Pinion line feed: 200 mm Pinion line feed speed: 300 mm / min Tailstock travelling speed: 1500 mm / min

Horizontal Numerically Controlled Machining Centre Mori seiki NH4000DCG


Single spindle CNC machine Control system: FANUC FS-31 and MSX-701/711 B-axis 360,000 x 0,001 ° Spindle speed 14,000 rpm. Toolkit: Number of toolbars 60 Tool holder: HSK63 Internal cooling Axis X: 560 mm Y axis: 560 mm Axis Z: 630 mm able work s ...

CNC Vertical Machining Centre 5-Axis Mazak Variaxis 500-5x incl Palletech


with palletech. Pallet size 400 x 400 mm. Number of pallets 14. Movement x-Axis 510 mm. y-Axis 510 mm. z-Axis 460 mm. Table indexing (C-Axis) / NC Table 0,001°. Number of tools in magazine 30 pieces. Maximum spindle speed 35-12.000 min. To ...

Horizontal Boring And Milling Centres For Cubical Heckert CWK 500D


Used horizontal machining center HECKERT CWK 500 d Xmm750 Ymm650 (750) Zmm700 Spindle speed 50-10000 (15000) SIEMENS control Sinumerik 840 D Tool magazine 60 positions pallet changer 2000 CE connected load, visible at work, c ...

CNC milling machines UNITEAM MAJOR-2R / 4020 – 4


Working centre UNITEAM model MAJOR-2R / 4020 – 4: - 2 multifunctional working planes 2000x2000mm each - Z axis run about 600mm, piece passage about 500mm - possibility to work on the planes contemporary, alternate, or syncro (useful 4000x2000mm) - 2 v ...

Turning Centre CINCINNATI LAMB HTC150


Fanuc 21it CNC Control Hydrafeed Magazine Barfeed Max Turn Diameter 240mm Max Turn Length 425mm 7.5KW Spindle Motor Spindle Nose A2-5 Max Spindle Speed 5500RPM Diameter of the spindle 42 mm Chuck 160 mm 12 Station VDI30 Turret Selection of VDI30 ...

Vertical Numerically Controlled Machining Centres Chiron DZ18W


2 spindle vertical machining center (twin spindle) CHIRON DZ18W Magnum Highspeed 2 spindle (320mm distance) 2 pallet 10500 rpm spindle / ISO40 18,5kW CNC Fanuc Under power in our warehouse

Milling machining centres RIELLO VFX300-6/5-0


Machine No. 27.148.000 Dimensions[mm] L=5700 W=3470 H=3500 Weight: 45000 kg Year:2001

Turning Centre 2-Axis MAZAK QUICK TURN 6G


Max. work diameter: 95mm, max. work length: 60mm, max. workpiece weight: 3,4kg, max. rotational speed: 6000/min, max. gripping force: 36kN, length: 2250mm, width: 1300mm, height: 1900mm, number of available turning centres: 2.

Multi Spindle Drilling Machines SCM TOP 29


Code: 0344 Brand: SCM Model: TOP 29 - CE Standard Multi boring machine with 29 chucks - CE Standard Powered tilting boring group 0-90 degrees N° 29 chucks with quickrelease couplings Centre distance between chucks mm 32 Max width of pane ...

Numerically Controlled Machining Centres MAZAK IMPULSE 30H


Table size 1450x460 mm Spindle speed 20.000 rpm Travels :X: 1390 Y: 300 Z: 250 mm Controller IMAC-TP

Casemaker Crathern - Perondi Case make


Case maker Crathern - Perondi Model Case maker Year 1985's Sheet feeder Automatic sheet feeder Glueing 830 mm Board feeder Automatic board feeder for a single piece as two pieces Spine board option for spine board feeding (centrepiece) Turning-i ...

Milling machine centers KOVOSVIT MAS MCV 750 CNC


Vertical machining centre Producer : KOVOSVIT MAS Model : MCV 750 CNC YOM : 1998 Number of driven axes : 3 Travel X-axis : 750 mm Travel Y-axis : 500 mm Travel Z-axis : 500 mm Clamping area of table : 1000x500 mm Control ...

Milling machining centres KOVOSVIT MAS MCV 1000 CNC


Vertical machining centre Producer : KOVOSVIT MAS Model : MCV 1000 CNC YOM : 2001 Number of driven axes : 3 Travel X-axis : 1016 mm Travel Y-axis : 610 mm Travel Z-axis : 660 mm Clamping area of table : 1300 x 600 mm Cont ...

Milling machining centres ANAYAK ANAKMATIC 9


OVERVIEW: Brand: ANAYAK Model: ANAKMATIC 9 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 1992 Production hours: 33458 Location: Spain Origin country: Spain GENERAL DATA: Measurements wid ...

Milling machining centres ANAYAK VH-2200


OVERVIEW: Brand: ANAYAK Model: VH-2200 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 1998 Production hours: 4804 Location: Spain Origin country: Spain GENERAL DATA: Measurements width: 3 ...

Cutting centre for beams SMM/HUELLINGHORST - GERMA SLK 300


Code: 0303 Brand: SMM/HUELLINGHORST - GERMANY Model: SLK 300 - CE Standard Cutting centre for beams - CE Standard - Year 2000 Blade diameter mm 800 Motor Hp 20 Saw blade rotation Blade beveling from 90° to 45° Height of the blade above the ...

Cutting-Off Machines Ryazan 1A64


YOM 1988 work piece maximum diameter 800 mm distance between centre 6000 mm. weight 13,5 ton Price 9500 EUR

CNC Turning Machines Wohlenberg U 900 x 10.000 mm


YEAR1990 / 2009 SPECIFICATIONS Swing over bed Ø920 mm ControlFagor 8055 T Swing over cross slide530 mm Swing in the gap Ø920 mm Distance between centres10.000 mm Work piece weight10.000 kg Spindle bore120 mm Spindle speeds / ran ...

Numerically Controlled Machining Centres MAZAK AJV 32/604


x-travel 1500 mm y-travel 700 mm z-traveL 460 mm table-size 650x1740 mm distance between columns 800 mm Spindle taper SK 40 spindle turning speed range 42-6000 U/min tool piece magazine with 40 control Mazatrol M 32

Milling machining centres HAAS VF-2


OVERVIEW: Brand: HAAS Model: VF-2 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 2015 Production hours: 4380 Location: China Origin country: USA GENERAL DATA: Measurements width: 2789 mm ...

Milling machining centres DMG MORI MillTap 700


OVERVIEW: Brand: DMG MORI Model: MillTap 700 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 2015 Production hours: 4050 Location: China Origin country: China GENERAL DATA: Measurements  ...

Heidelberg XL105-8P5


HEIDELBERG XL105-8P5(75 x 105cm), Age c.2008, serial no.FS001015, circa 223 million, Prinect CP2000 Press Centre, INPRESS control, Wallscreen, Autoplate ADVANCED, Alcolor with Vario dampening, Preset Plus non-stop Feeder, Preset Plus Delivery, Heidelberg  ...

Cincinnati Milacron Sabre 1250 CNC


Make: Cincinnati Model: MILACRON SABRE 1250 CNC VERTICAL MACHINING CENTRE Year: 1992/93 Condition: Used Machine type: Other Location of machine: UK Machine Details Year of manufacture: approx 1992/93, Serial Number: 7037-F00-R0-0239, Control: ...

CENTRE LATHE CMT URSUS 250


HEIGHT: 250 mm. Centre distance: 1500 mm. Spindle bore: 105 mm. TURNING DIAMETER: Ø 290 mm. Weight: 1800 Kg. Dimensions: 850 x 2750 x 1250 mm. Notes: Max. Turning on 505 mm.

ZMM


HEIGHT: 300 mm. Centre distance: 3000 mm. TURNING DIAMETER: Ø 400 mm.

CENTRE LATHE MORANDO PN 42


HEIGHT: 450 mm. Centre distance: 4000 mm. Spindle bore: 100 mm. TURNING DIAMETER: Ø 650 mm. Weight: 11000 Kg. Notes: 950 mm diameter turning on the pallet.

Horizontal Turning Centres Gurutzpe CNC horizontal lathe


CNC Horizontal Lathe GURUTZPE Manufacturer: Gurutzpe YOM: 1974 retrofit 2010 Control: Siemens Sinumerik 820 Turning diameter: 1.380 mm Distance between centers 5.000 mm Center height: 600 mm Swing over cross slide: 1.100 mm ...

Universal processing centres HURCO VTX U


Centre Drilling Machines MAZAK VTC 2000 C II


Well maintained Mazak VTC 2000 C II with 4 axes - Mazatrol CNC control Technical data: Movements: X axis: 1660 mm Y axis: 510 mm Z axis: 5210 mm Clamping table length: 2000 mm Clamping table width: 510 mm Max. load on table: 1000 kg Tool maga ...

Gear hobbing machine WAHLI W 90


Distance between centres: 80 mm Max length of milling: 50 mm Max diameter of workpiece: 40 mm Modul of gear wheel: 0,05-1 Milling teeth number: 6-200 Speed of longitudinal feed: 0-2 m/min Speed of forward stroke, longitudinal: 3 m/min

Relieving lathe NILES DH250/4


Centre height of relief turning slide 150 mm Centre height over bed 300 mm Max turning length 630 mm Max centre distance 1000 mm Bore in work spindle 27 mm Relief turning and cross slide swivelling 360 degrees each Relief turning stroke 0–32 mm, s ...
Get the latest machine offers by email: order newsletter
